Page 1
63 dBA* Front Control Dishwasher
WDF130PAH
Stainless Steel
WDF130PAHS
Also available in:
White
Black
WDF130 PAHW
WDF130 PAHB
Capacity
Total Place Settings 12
General Features & Properties
High Temperature Wash Option
Heated Dry Option
Industr y's Best Selling Dishwasher Brand
Designed, Engineered and Assembled in the
U.S.A. with American Pride
†
Electrical Details
Amps 10
Volts 120
Hz 60
Technical Details
Dishwasher Type Built-in
Control Location Front
Control Type Push Button
Number of Wash Cycles 3
Number of Options 2
*
dBA
Number of Racks 2
Tub Material Plastic
Wash System Filter
Wash System Type
Number of Wash Arms 2
63
Removable
Filter
Dimensions
Product Dimensions
(H x W x D)
Depth with Door Open 90° 49 -1/2"
34-1/2" x
23-7/8" x
24-1/2"
Reference Material
Dimension Guide
Key Features & Benefits
1-Hour Wash Cycle
Clean dishes in half the time so your plates,
pans and glasses are thoroughly cleaned up
and taken care of in just an hour.
Normal Cycle
Use for normal amounts of food soil to clean up
leftover messes from your day-to-day meals.
Heavy Cycle
Takes care of heavily soiled messes and other
hard-to-clean dishes without the extra elbow
grease by adding extra time to the cycle.
**
Install Guide
Use & Care Guide
Energy Guide
Warranty
*Per IEC standards. **Compared to Normal cycle with lightly soiled loads. †Based on 12-month average of sales. TraQline 2018. NOTE: Dimensions are
for planning purposes only. For complete details, see Installation Instructions packed with product. Specications subject to change without notice.
®/™ © 2020. All rights reserved. Printed in the U.S.A. D200052XX A. WDF130PAHSPECSHEETV01.
