Page 1
®
MICROWAVE OVEN
Use & Care Guide
For questions about features, operation/performance,
parts, accessories or service, call: 1-800-253-1301.
or visit our website at...
www.whirlpool.com
Table of Contents .......................................2
W10178097A
Model MT4078
Page 2
TABLE OF CONTENTS
MICROWAVE OVEN SAFETY........................................................2
INSTALLATION INSTRUCTIONS .................................................. 4
Unpacking ....................................................................................4
Location Requirements................................................................4
Electrical Requirements ...............................................................5
PARTS AND FEATURES................................................................5
Turntable ...................................................................................... 5
MICROWAVE OVEN CONTROL....................................................6
Display.......................................................................................... 6
Start ..............................................................................................6
Off................................................................................................. 6
Add Minute................................................................................... 6
Clock ............................................................................................ 6
Tones............................................................................................6
Control Lock.................................................................................6
MICROWAVE OVEN USE...............................................................7
Food Characteristics ....................................................................7
Cooking Guidelines ......................................................................7
Cookware and Dinnerware...........................................................7
Aluminum Foil and Metal..............................................................8
Microwave Cooking Power ..........................................................8
Manual Cooking ...........................................................................8
Cooking in Stages ........................................................................8
EZ-CHOICE
Auto Defrost .................................................................................9
MICROWAVE OVEN CARE..........................................................10
General Cleaning........................................................................10
TROUBLESHOOTING ..................................................................10
ASSISTANCE OR SERVICE .........................................................11
Replacement Parts.....................................................................11
WARRANTY ..................................................................................12
®
Feature ...................................................................9
®
MICROWAVE OVEN SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
You can be killed or seriously injured if you don't immediately
DANGER
WARNING
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
follow instructions.
can be killed or seriously injured if you don't
You
instructions.
follow
2
Page 3
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed, including the following:
WARNING: To reduce the risk of burns, electric
shock, fire, injury to persons, or exposure to excessive
microwave energy:
■ Read all instructions before using the microwave oven.
■ Read and follow the specific “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” found in this section.
■ The microwave oven must be grounded. Connect only
to properly grounded outlet. See “GROUNDING
INSTRUCTIONS” found in this section and in the
provided Installation Instructions.
■ Install or locate the microwave oven only in
accordance with the provided Installation Instructions.
■ Some products such as whole eggs in the shell and
sealed containers – for example, closed glass jars –
are able to explode and should not be heated in the
microwave oven.
■ Use the microwave oven only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors in the microwave oven. This type
of oven is specifically designed to heat, cook, or dry
food. It is not designed for industrial or laboratory use.
■ As with any appliance, close supervision is necessary
when used by children.
■ Do not operate the microwave oven if it has a
damaged cord or plug, if it is not working properly, or
if it has been damaged or dropped.
■ The microwave oven should be serviced only by
qualified service personnel. Call an authorized service
company for examination, repair, or adjustment.
■ See door surface cleaning instructions in the
“Microwave Oven Care” section.
■ To reduce the risk of fire in the oven cavity:
– Do not overcook food. Carefully attend the microwave oven
when paper, plastic, or other combustible materials are placed
inside the oven to facilitate cooking.
– Remove wire twist-ties from paper or plastic bags before
placing bags in oven.
– If materials inside the oven ignite, keep oven door closed, turn
oven off, and disconnect the power cord, or shut off power at
the fuse or circuit breaker panel.
– Do not use the cavity for storage purposes. Do not leave
paper products, cooking utensils, or food in the cavity when
not in use.
■ Liquids, such as water, coffee, or tea are able to be overheated
beyond the boiling point without appearing to be boiling. Visible
bubbling or boiling when the container is removed from the
microwave oven is not always present. THIS COULD RESULT
IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN
THE CONTAINER IS DISTURBED OR A SPOON OR OTHER
UTENSIL IS INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
– Do not overheat the liquid.
– Stir the liquid both before and halfway through heating it.
– Do not use straight-sided containers with narrow necks.
– After heating, allow the container to stand in the microwave
oven for a short time before removing the container.
– Use extreme care when inserting a spoon or other utensil into
the container.
■ Oversized foods or oversized metal utensils should not be
inserted in the microwave oven as they may create a fire or risk
of electric shock.
■ Do not clean with metal scouring pads. Pieces can burn off the
pad and touch electrical parts involving a risk of electric shock.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
■ Do not operate any heating or cooking appliance beneath the
microwave oven.
■ Do not mount microwave oven over or near any portion of a
heating or cooking appliance.
■ Do not use paper products when appliance is operated in the
“PAN BROWN” mode (on models with this feature).
■ Do not store any materials, other than manufacturer’s
recommended accessories, in this microwave oven when not
in use.
■ Do not store anything directly on top of the microwave oven
when the microwave oven is in operation.
■ Do not cover or block any openings on the microwave oven.
SAVE THESE INSTRUCTIONS
■ Do not store this microwave oven outdoors. Do not use
the microwave oven near water - for example, near a
kitchen sink, in a wet basement, or near a swimming
pool, or similar locations.
■ Do not immerse cord or plug in water.
■ Keep cord away from heated surfaces.
■ Do not let cord hang over edge of table or counter.
■ Do not mount over a sink.
■ Do not cover racks or any other part of the microwave
oven with metal foil. This will cause overheating of the
microwave oven.
3
Page 4
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open
since open-door operation can result in harmful exposure
to microwave energy. It is important not to defeat or
tamper with the safety interlocks.
(b) Do not place any object between the oven front face and
the door or allow soil or cleaner residue to accumulate on
sealing surfaces.
This device complies with Part 18 of the FCC Rules.
(c) Do not operate the oven if it is damaged. It is particularly
important that the oven door close properly and that there
is no damage to the:
(1) Door (bent),
(2) Hinges and latches (broken or loosened),
(3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone
except properly qualified service personnel.
INSTALLATION INSTRUCTIONS
Unpacking
1. Empty the microwave oven of any packing materials.
2. Clean the inside with a soft, damp cloth.
3. Check for damage, such as:
■ a door that is not lined up correctly
■ damage around the door, or
■ dents on the interior or exterior of the microwave oven.
If there is any damage, do not operate the microwave oven
until a designated service technician has checked it and
made any needed repairs.
Location Requirements
WARNING
Fire Hazard
Do not install oven next to or over a heat source
without a UL listed (CSA approved in Canada)
trim kit.
Doing so can result in death, fire, or electrical shock.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
microwave oven.
Failure to do so can result in back or other injury.
IMPORTANT: The control side of the microwave oven is the
heavy side. Handle the microwave oven gently. The weight of the
microwave oven is 43 lbs (19.5 kg).
■ Place the microwave oven on a cart, counter, table or shelf
that is strong enough to hold the microwave oven and the
food and utensils you place inside it.
■ The microwave oven should be at a temperature above 50°F
(10°C) for proper operation.
NOTE: Some models can be built into a wall or cabinet by using
one of the trim kits listed in the “Assistance or Service” section.
4
Page 5
■ Do not block the exhaust vents or air intake openings. Allow
a few inches of space at the back and side of the microwave
oven where the exhaust vents are located. Blocking the
exhaust vents could cause damage to the microwave oven,
as well as poor cooking results.
■ Make sure the microwave oven legs are in place to ensure
proper airflow. If vents are blocked, a sensitive thermal device
may automatically turn the microwave oven off. The
microwave oven should work properly once it has cooled.
Electrical Requirements
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
Required:
■ A 120 Volt, 60 Hz, AC only, 15- or 20-amp electrical supply
with a fuse or circuit breaker.
Recommended:
■ A time-delay fuse or time-delay circuit breaker.
■ A separate circuit serving only this microwave oven.
GROUNDING INSTRUCTIONS
■
For all cord connected appliances:
The microwave oven must be grounded. In the event of
an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric
current. The microwave oven is equipped with a cord
having a grounding wire with a grounding plug. The plug
must be plugged into an outlet that is properly installed
and grounded.
WARNING: Improper use of the grounding plug can
result in a risk of electric shock. Consult a qualified
electrician or serviceman if the grounding instructions are
not completely understood, or if doubt exists as to whether
the microwave oven is properly grounded.
Do not use an extension cord. If the power supply cord is
too short, have a qualified electrician or serviceman install
an outlet near the microwave oven.
SAVE THESE INSTRUCTIONS
Observe all governing codes and ordinances.
PARTS AND FEATURES
This manual may cover several different models. The model you
have purchased may have some or all of the features shown here.
The appearance of your particular model may differ slightly from
the illustrations in this manual.
BCDE
A
A. Door lock system
B. Metal shielded window
C. Model and serial number
plate
D. Cooking guide Label
G
H
E. Microwave oven light
(not shown)
F. Control panel
G. Removable turntable support
H. Glass turntable
F
Turntable
A
B
A. Turntable
B. Support
The turntable can rotate in either direction to help cook food
more evenly. For best cooking results, do not operate the
microwave oven without having the turntable in place. See
“Assistance or Service” to reorder any of the parts.
To Install:
1. Place the support on the microwave oven cavity bottom.
2. Place the turntable on the support.
5
Page 6
MICROWAVE OVEN CONTROL
Off
The OFF (OFF CANCEL) pad clears any incorrect command and
cancels any program during cooking. It will not erase the time of
day.
The microwave oven will also turn off when the door is opened.
Close the door and touch START to resume the cycle.
Add Minute
The ADD MINUTE pad starts the microwave oven for 1 minute at
100% power. More cook time may be added in 1-minute
increments by touching ADD MINUTE repeatedly.
The Add Minute function may be used only when no other
function is operating.
Clock
This is a standard 12-hour clock (12:00-11:59).
To Se t :
The microwave oven must be off.
1. To u c h C L O CK SET.
2. Touch number pads to enter correct time of day.
3. To u c h C L O CK SET.
Display
When power is first supplied to the microwave oven, “0” will
appear in the display. If the “0” appears in the display at any
other time, a power failure has occurred. Reset the clock if
needed.
When the microwave oven is in use, the display shows cooking
power, quantities, weights and/or prompts. When the microwave
oven is not in use, the display shows the time of day (if the Clock
is set).
Start
The START (START ENTER) pad begins any function. If cooking is
interrupted, touching START will resume the preset cycle.
Tones
Tones are audible signals, indicating the following:
One tone
■ Valid entry (short tone)
Two tones
■ End of stage in multistage cooking
■ Control Lock active (short tones)
Three tones
■ End of cycle
Five tones
■ During Auto Defrost cycle, reminder to check, turn, rearrange,
or separate food
Control Lock
The Control Lock disables the control panel pads to avoid
unintended use of the microwave oven.
To Lock/Unlock Control: The microwave oven must be off.
Touch and hold START for 5 seconds until 2 tones sound and
“L” appears in the display. Repeat to unlock and clear the display
(2 tones will sound).
6
Page 7
MICROWAVE OVEN USE
A magnetron in the microwave oven produces microwaves which
reflect off the metal floor, walls and ceiling and pass through the
turntable and appropriate cookware to the food. Microwaves are
attracted to and absorbed by fat, sugar and water molecules in
the food, causing them to move, producing friction and heat
which cooks the food.
■ To avoid damage to the microwave oven, do not lean on or
allow children to swing on the microwave oven door.
■ To avoid damage to the microwave oven, do not operate
when it is empty.
■ Baby bottles and baby food jars should not be heated in
microwave oven.
■ Clothes, flowers, fruit, herbs, wood, gourds, paper, including
brown paper bags and newspaper, should not be dried in
microwave oven.
■ Paraffin wax will not melt in the microwave oven because it
does not absorb microwaves.
■ Use oven mitts or pot holders when removing containers from
microwave oven.
■ Do not overcook potatoes. At the end of the recommended
cook time, potatoes should be slightly firm. Let potatoes
stand for 5 minutes. They will finish cooking while standing.
■ Do not cook or reheat whole eggs inside the shell. Steam
buildup in whole eggs may cause them to burst, requiring
significant cleanup of microwave oven cavity. Cover poached
eggs and allow a standing time.
Food Characteristics
When microwave cooking, the amount, size and shape, starting
temperature, composition and density of the food affect cooking
results.
Amount of Food
The more food heated at once, the longer the cook time needed.
Check for doneness and add small increments of time if
necessary.
Size and Shape
Smaller pieces of food will cook more quickly than larger pieces,
and uniformly shaped foods cook more evenly than irregularly
shaped food.
Starting Temperature
Room temperature foods will heat faster than refrigerated foods,
and refrigerated foods will heat faster than frozen foods.
Composition and Density
Foods high in fat and sugar will reach a higher temperature, and
will heat faster than other foods. Heavy, dense foods, such as
meat and potatoes, require a longer cook time than the same size
of a light, porous food, such as cake.
Cooking Guidelines
Covering
Covering food helps retain moisture, shorten cook time and
reduce spattering. Use the lid supplied with cookware. If a lid is
not available, wax paper, paper towels or plastic wrap approved
for microwave ovens may be used. Plastic wrap should be turned
back at one corner to provide an opening to vent steam.
Condensation on the door and cavity surfaces is normal during
heavy cooking.
Stirring and Turning
Stirring and turning redistribute heat evenly to avoid overcooking
the outer edges of food. Stir from outside to center. If possible,
turn food over from bottom to top.
Arranging
If heating irregularly shaped or different sized foods, arrange the
thinner parts and smaller sized items toward the center. If
cooking several items of the same size and shape, place them in
a ring pattern, leaving the center of the ring empty.
Piercing
Before heating, use a fork or small knife to pierce or prick foods
that have a skin or membrane, such as potatoes, egg yolks,
chicken livers, hot dogs, and sausage. Prick in several places to
allow steam to vent.
Shielding
Use small, flat pieces of aluminum foil to shield the thin pieces of
irregularly shaped foods, bones and foods such as chicken
wings, leg tips and fish tail. See “Aluminum Foil and Metal” first.
Standing Time
Food will continue to cook by the natural conduction of heat even
after the microwave cooking cycle ends. The length of standing
time depends on the volume and density of the food.
Cookware and Dinnerware
Cookware and dinnerware must fit on the turntable. Always use
oven mitts or pot holders when handling because any dish may
become hot from heat transferred from the food. Do not use
cookware and dinnerware with gold or silver trim. Use the
following chart as a guide, then test before using.
MATERIAL RECOMMENDATIONS
Aluminum Foil,
Metal
Browning Dish Bottom must be at least 3/16" (5 mm)
Ceramic Glass,
Glass
China,
Earthenware
Melamine Follow manufacturer’s recommendations.
Paper: Towels,
Dinnerware,
Napkins
Plastic: Wraps,
Bags, Covers,
Dinnerware,
Containers
Pottery and Clay Follow manufacturer’s recommendations.
Silicone
Bakeware
Straw, Wicker,
Wooden
Containers
Wax Paper Acceptable for use.
To Test Cookware or Dinnerware for Microwave Use:
1. Place cookware or dinnerware in microwave oven with
1 cup (250 mL) of water beside it.
2. Cook at 100% cooking power for 1 minute.
Do not use cookware or dinnerware if it becomes hot and the
water stays cool.
See “Aluminum Foil and Metal” section.
above the turntable. Follow manufacturer’s
recommendations.
Acceptable for use.
Follow manufacturer’s recommendations.
Use nonrecycled and those approved by
the manufacturer for microwave oven use.
Use those approved by the manufacturer
for microwave oven use.
Follow manufacturer’s recommendations.
Do not use in microwave oven.
7
Page 8
Aluminum Foil and Metal
Always use oven mitts or pot holders when removing dishes from
the microwave oven.
Aluminum foil and some metal can be used in the microwave
oven. If not used properly, arcing (a blue flash of light) can occur
and cause damage to the microwave oven.
OK for Use
Racks and bakeware supplied with the microwave oven (on some
models), aluminum foil for shielding, and approved meat
thermometers may be used with the following guidelines:
■ To avoid damage to the microwave oven, do not allow
aluminum foil or metal to touch the inside cavity walls,
ceiling or floor.
■ Always use the turntable.
■ To avoid damage to the microwave oven, do not allow
contact with another metal object during microwave cooking.
Do Not Use
Metal cookware and bakeware, gold, silver, pewter, nonapproved meat thermometers, skewers, twist ties, foil liners
such as sandwich wrappers, staples and objects with gold or
silver trim or a metallic glaze should not be used in the
microwave oven.
Microwave Cooking Power
Many recipes for microwave cooking specify which cooking
power to use by percent, name or number. For example,
70%=7=Medium-High.
Use the following chart as a general guide for the suggested
cooking power of specific foods.
PERCENT/NAME NUMBER USE
100%, High
(default setting)
90% 9 Cooking small, tender pieces
80% 8 Heating rice, pasta or stirrable
70%,
Medium-High
60% 6 Cooking sensitive foods such
10 Quick heating convenience
foods and foods with high
water content, such as soups,
beverages and most
vegetables.
of meat, ground meat, poultry
pieces and fish fillets.
Heating cream soups.
casseroles.
Cooking and heating foods
that need a cook power lower
than high. For example, whole
fish and meat loaf.
7 Reheating a single serving of
food.
as cheese and egg dishes,
pudding and custards.
Cooking non-stirrable
casseroles, such as lasagna.
PERCENT/NAME NUMBER USE
50%, Medium 5 Cooking ham, whole poultry
and pot roasts.
Simmering stews.
40% 4 Melting chocolate.
Heating bread, rolls and
pastries.
30%, MediumLow, Defrost
20% 2 Softening butter, cheese, and
10%, Low 1 Taking chill out of fruit.
3 Defrosting bread, fish, meats,
poultry and precooked foods.
ice cream.
Manual Cooking
To U s e :
1. Place food on the turntable and close the door.
2. Touch COOK TIME.
Enter the length of time for cook.
If cooking with 100% power, skip Step 3.
3. Touch COOK POWER, then set the desired cooking power.
See “Microwave Cooking Power.”
4. Touch START.
The display will count down the cook time.
When the cycle ends. “END” will appear in the display, and
the end-of-cycle tones will sound.
5. Touch OFF or open the door to clear the display.
The cook time and power may not be changed after touching
START without interrupting cooking.
Cooking in Stages
The microwave oven can be set to cook at different cooking
powers for various lengths of time, up to 3 stages, plus a
defrosting stage.
To Cook in Stages:
1. Place food on the turntable and close the door.
2. Touch COOK TIME.
Enter the length of time for cook during the 1st stage.
3. Touch COOK POWER, then set the desired cooking power for
the 1st stage. See “Microwave Cooking Power.”
4. Repeat steps 2 and 3 for each additional stage.
5. Touch START.
Two tones will sound between stages.
When the cycle ends, “END” will appear in the display, and
the end-of-cycle tones will sound.
6. Touch OFF or open the door to clear the display.
8
Page 9
EZ-CHOICE® Feature
The EZ-CHOICE® Feature pads have been programmed with
common microwavable foods, their quantities, cook powers and
cook times.
NOTE: During Popcorn function, as with all microwave cooking
functions, the microwave oven should be attended at all times.
Listen for popping to slow to 1 pop every 1 or 2 seconds, then
stop the cycle.
Use the following chart as a guide for the EZ-CHOICE® pads.
PAD SERVING SIZE INSTRUCTIONS
Popcorn* 3.5 oz (99 g)
3.0 oz (85 g)
1.5 oz (43 g)
Baked
Potatoes
Dinner Plate
(refrigerated)
Frozen
Entrée
Fresh
Vegetable
Pizza
Reheat
(refrigerated)
Beverage 1-2 cups, 8 oz
*To avoid damage to the microwave oven, do not use regular
paper bags or glassware. For best cooking results, do not try to
pop unpopped kernels. Use fresh bags of popcorn for optimal
results. Cooking results may vary by brand and fat content. If
using a microwave popcorn popper, follow manufacturer’s
instructions.
1-4 medium,
10-13 oz (283369 g) each,
similar in size
1-2 servings,
8 oz (227 g) each
10 oz (283 g) Remove from package.
1-4 cups
(250 mL-1 L)
1-3 slices, 4 oz
(113 g) each
(250 mL) each
To Use the EZ-CHOICE® Feature:
1. Place food on the turntable and close the door.
2. Touch one of the EZ-CHOICE
The display will show first programmed serving size. Touch
the pad again to change quantity. See chart for available
serving sizes.
The microwave oven will begin cooking automatically after a
brief delay.
When the cycle ends, “END” will appear in the display, and
the end-of-cycle tones will sound.
3. Touch OFF or open the door to clear the display.
Pop only one package at a
time. For bag sizes not listed
in this section, follow
directions on package.
Pierce each one several times
with a fork. Place on turntable
around edges, at least 1"
(2.5 cm) apart. Let stand
5 minutes after cooking.
Place food on plate, cover
with plastic wrap and vent.
Loosen cover on 3 sides. If
entrée is not in microwavesafe container, place on
plate, cover with plastic wrap
and vent. Let stand
2-3 minutes after cooking.
Place in microwave-safe
container, and add 2-4 tbs
(30-60 mL) water. Cover with
plastic wrap and vent. Stir
and let stand 2-3 minutes
after cooking.
Place on paper towel or
paper plate in the center of
the turntable.
Do not cover. The diameter of
the cup’s opening will affect
how the liquid heats.
Beverages in cups with
smaller openings may heat
faster.
®
pads.
Auto Defrost
The Auto Defrost feature’s preset programs can be used or the
microwave oven can be manually set to defrost.
■ Unwrap foods and remove lids (for example, from fruit juice
containers) before defrosting.
■ Shallow packages will defrost more quickly than deep blocks.
■ Separate food pieces as soon as possible during or at the
end of the cycle for more even defrosting.
■ Use small pieces of aluminum foil to shield parts of food such
as chicken wings, leg tips and fish tails. See “Aluminum Foil
and Metal” first.
The Auto Defrost feature has preset times and cook powers for
3 categories: Meat, Poultry and Fish. It should not be used for
food that has been left outside the freezer for more than
20 minutes, or for frozen ready-made food. Use the following
chart as a guide.
MEAT
Beef: ground, steaks, roast,
stew
Lamb: stew and chops
Pork: chops, ribs, roasts,
sausage
POULTRY
Chicken: whole and cut up Place in microwave-safe
Cornish hens
Turk ey : breast
FISH
Fillets, Steaks, Whole Shellfish Place in microwave-safe
To Use Auto Defrost:
1. Place food, uncovered, on the turntable and close the door.
2. Touch AUTO DEFROST.
The display will show the setting for defrosting Meat. Touch
AUTO DEFROST a second time for the Poultry setting, and a
third time for the Fish setting.
3. Enter the weight.
Weight can be set from 0.1 lb to 6.0 lbs (45 g to 2.7 kg).
4. Touch START.
The display will count down the defrost time.
During defrosting, 5 short tones will sound. These tones
indicate it is time to check, turn, rearrange, or separate food.
Open door, turn food if necessary, close door, and touch
START to resume defrosting.
When the cycle ends, “END” will appear in the display, and
the end-of-cycle tones will sound, followed by reminder
tones.
5. Touch OFF or open the door to clear the display.
To Defrost Manually: Follow direction in “Manual Cooking”
section, and use 30% cooking power. See “Microwave Cooking
Power” chart.
The narrow or fatty areas of
irregular shaped cuts should
be shielded with foil before
defrosting.
Do not defrost less than 1/4 lb
(113 g) or two 4 oz (113 g)
patties.
Place all meats in microwavesafe baking dish. Do not
cover.
baking dish, chicken breast
side up. Do not cover.
baking dish. Do not cover.
9
Page 10
MICROWAVE OVEN CARE
General Cleaning
IMPORTANT: Before cleaning, make sure all controls are off and the microwave oven is cool. Always follow label instructions on
cleaning products.
Soap, water and a soft cloth or sponge are suggested unless otherwise noted.
MICROWAVE OVEN CAVITY
To avoid damage to the microwave oven cavity, do not use soapfilled scouring pads, abrasive cleaners, steel-wool pads, gritty
washcloths or some recycled paper towels.
The area where the microwave oven door and frame touch when
closed should be kept clean.
Average soil
■ Mild, nonabrasive soaps and detergents:
Rinse with clean water and dry with soft, lint-free cloth.
Heavy soil
■ Mild, nonabrasive soaps and detergents:
Heat 1 cup (250 mL) of water for 2 to 5 minutes in microwave
oven. Steam will soften soil. Rinse with clean water and dry
with soft, lint-free cloth.
Odors
■ Lemon juice or vinegar:
Heat 1 cup (250 mL) of water with 1 tbs (15 mL) of either
lemon juice or vinegar for 2 to 5 minutes in microwave oven.
Microwave Inlet Cover
To avoid arcing and microwave oven damage, the microwave
inlet cover (see “Parts and Features”) should be kept clean.
■ Wipe with wet cloth.
MICROWAVE OVEN DOOR AND EXTERIOR
The area where the microwave oven door and frame touch when
closed should be kept clean.
■ Mild, nonabrasive soaps and detergents:
Rinse with clean water and dry with soft, lint-free cloth.
■ Glass cleaner and paper towels or nonabrasive plastic
scrubbing pad:
Apply glass cleaner to towel, not directly to surface.
CONTROL PANEL
■ Sponge or soft cloth and water:
Dampen sponge with water and wipe panel. Dry with soft
cloth.
■ To avoid damage to the control panel, do not use chemical or
abrasive cleansers.
TURNTABLE
Replace turntable immediately after cleaning. Do not operate the
microwave oven without the turntable in place.
■ Mild cleanser and scouring pad
■ Dishwasher
TROUBLESHOOTING
Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.
Nothing will operate
■ Has a household fuse blown, or has a circuit breaker
tripped?
Replace the fuse or reset the circuit breaker. If the problem
continues, call an electrician.
Microwave oven will not operate
■ Is the magnetron working properly?
Try to heat 1 cup (250 mL) of cold water for 2 minutes at
100% cooking power. If water does not heat, try the steps
below. If microwave oven still does not operate, call for
service. See “Assistance or Service” section.
■ Is the door completely closed?
Firmly close door.
■ Is a packaging spacer (on some models) attached to the
inside of the door?
Remove packaging spacer, then firmly close door.
■ Is the electronic microwave oven control set correctly?
See “Microwave Oven Control” section.
■ On some models, is the Control Lock set?
See “Control Lock” section.
Microwave oven makes humming noise
■ This is normal and occurs when the power supply in the
magnetron cycles on.
Microwave oven door looks wavy
■ This is normal and will not affect performance.
Turntable will not operate
■ Is the turntable properly in place?
Make sure turntable is correct side up and is sitting securely
on the turntable support. See “Turntable” section.
■ Is the turntable support operating properly?
Remove turntable. Remove and clean turntable support and
rollers. Replace turntable. Place 1 cup (250 mL) of water on
the turntable, then restart microwave oven. If it still is not
working, call for service. See “Assistance or Service” section.
Do not operate the microwave oven without turntable and
turntable support working properly.
10
Page 11
Turntable alternates rotation directions
■ This is normal and depends on motor rotation at beginning of
cycle.
Display shows messages
■ Is the display showing “:”?
There has been a power failure or the Clock time has been
turned off. See “Display” section to clear display. See “Clock”
section to reset or turn on Clock.
Tones are not sounding
■ Are tones turned off?
See “Tones” section.
Cooking times seem too long
■ Is the cooking power set properly?
See “Cooking Power” section.
ASSISTANCE OR SERVICE
Before calling for assistance or service, please check
“Troubleshooting.” It may save you the cost of a service call. If
you still need help, follow the instructions below.
When calling, please know the purchase date and the complete
model and serial number of your appliance. This information will
help us to better respond to your request.
If you need replacement parts
If you need to order replacement parts, we recommend that you
use only FSP
right and work right because they are made with the same
precision used to build every new WHIRLPOOL
To locat e F S P® replacement parts in your area, call us or your
nearest Whirlpool designated service center.
®
replacement parts. FSP
®
replacement parts will fit
®
appliance.
■ Are large amounts of food being heated?
Larger amounts of food need longer cooking times.
■ Is the incoming voltage less than that specified in
“Microwave Oven Safety?”
Have a qualified electrician check the electrical system in the
home.
Interference with radio, TV, cordless phone, etc.
■ Is the microwave oven plugged into the same outlet?
Try a different outlet for the electronic device.
■ Is the radio or TV receiver near the microwave oven?
Move the receiver away from the microwave oven, or adjust
the radio or TV antenna.
■ Are the microwave oven door and sealing surfaces clean?
Make sure these areas are clean.
■ Is the cordless phone frequency 2.4 GHz?
Some 2.4 GHz-based cordless phones and home wireless
networks may experience static or noise while the microwave
oven is on. Use a corded phone or a different frequency
cordless phone, or avoid using these items during microwave
oven operation.
For further assistance
If you need further assistance, you can write to Whirlpool
Corporation with any questions or concerns at:
Whirlpool Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022-2692
Please include a daytime phone number in your correspondence.
Replacement Parts
Glass Turntable
Part Number 8205098
Turntable Support/Roller Assembly
Part Number 8205099
In the U.S.A.
Call the Whirlpool Customer eXperience Center
toll free: 1-800-253-1301.
Our consultants provide assistance with:
■ Features and specifications on our full line of appliances.
■ Installation information.
■ Use and maintenance procedures.
■ Accessory and repair parts sales.
■ Specialized customer assistance (Spanish speaking, hearing
impaired, limited vision, etc.).
■ Referrals to local dealers, repair parts distributors and service
companies. Whirlpool designated service technicians are
trained to fulfill the product warranty and provide afterwarranty service, anywhere in the United States.
To locate the Whirlpool designated service company in your
area, you can also look in your telephone directory Yellow
Pages.
Cleaning Supplies
Heavy Duty Degreaser
Part Number 31552
All-Purpose Appliance Cleaner
Part Number 31682
11
Page 12
WHIRLPOOL CORPORATION MAJOR APPLIANCE WARRANTY
W10178097A
LIMITED WARRANTY
For one year from the date of purchase, when this major appliance is operated and maintained according to instructions attached to or
furnished with the product, Whirlpool Corporation or Whirlpool Canada LP (hereafter “Whirlpool”) will pay for Factory Specified Parts
and repair labor to correct defects in materials or workmanship. Service must be provided by a Whirlpool designated service company.
This limited warranty is valid only in the United States or Canada and applies only when the major appliance is used in the country in
which it was purchased. Outside the 50 United States and Canada, this limited warranty does not apply. Proof of original purchase date
is required to obtain service under this limited warranty.
ITEMS EXCLUDED FROM WARRANTY
This limited warranty does not cover:
1. Service calls to correct the installation of your major appliance, to instruct you on how to use your major appliance, to replace or
repair house fuses, or to correct house wiring or plumbing.
2. Service calls to repair or replace appliance light bulbs, air filters or water filters. Consumable parts are excluded from warranty
coverage.
3. Repairs when your major appliance is used for other than normal, single-family household use or when it is used in a manner that is
contrary to published user or operator instructions and/or installation instructions.
4. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation not in
accordance with electrical or plumbing codes, or use of consumables or cleaning products not approved by Whirlpool.
5. Cosmetic damage, including scratches, dents, chips or other damage to the finish of your major appliance, unless such damage
results from defects in materials or workmanship and is reported to Whirlpool within 30 days from the date of purchase.
6. Any food loss due to refrigerator or freezer product failures.
7. Costs associated with the removal from your home of your major appliance for repairs. This major appliance is designed to be
repaired in the home and only in-home service is covered by this warranty.
8. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
9. Expenses for travel and transportation for product service if your major appliance is located in a remote area where service by an
authorized Whirlpool servicer is not available.
10. The removal and reinstallation of your major appliance if it is installed in an inaccessible location or is not installed in accordance
with published installation instructions.
11. Major appliances with original model/serial numbers that have been removed, altered or cannot be easily determined. This warranty
is void if the factory applied serial number has been altered or removed from your major appliance.
The cost of repair or replacement under these excluded circumstances shall be borne by the customer.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED
HEREIN. IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. WHIRLPOOL SHALL NOT BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS, SO THESE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES
YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE OR PROVINCE
TO PROVINCE.
If outside the 50 United States and Canada, contact your authorized Whirlpool dealer to determine if another warranty applies.
If you need service, first see the “Troubleshooting” section of the Use & Care Guide. After checking “Troubleshooting,” you may find
additional help by checking the “Assistance or Service” section or by calling Whirlpool. In the U.S.A., call 1-800-253-1301. In Canada,
call 1-800-807-6777.
Keep this book and your sales slip together for future
reference. You must provide proof of purchase or installation
date for in-warranty service.
Write down the following information about your major appliance
to better help you obtain assistance or service if you ever need it.
You will need to know your complete model number and serial
number. You can find this information on the model and serial
number label located on the product.
Dealer name____________________________________________________
Address ________________________________________________________
Phone number__________________________________________________
Model number __________________________________________________
Serial number __________________________________________________
Purchase date __________________________________________________
9/07
SP PN W10174654A
© 2007 Whirlpool Corporation.
All rights reserved. ® Registered Trademark/TM Trademark of Whirlpool, U.S.A.
MFL42364101
Printed in China
12/07
Loading...
