Whirlpool Magicook 20G Instructions For Use Manual

1

GB

www.whirlpool.com

Magicook 20G (Elec)

2

GB

INSTALLATION

PRIOR TO CONNECTING

E

NSURE THAT THE APPLIANCE IS NOT DAMAG ED. Check

that the oven door closes  rmly against the
door support. Empty the oven and clean the in­terior with a soft, damp cloth.

AFTER CONNECTING

T

HE EARTHING OF THIS APPLIANCE is compulso-

ry. The manufacturer will accept no re­sponsibility for injury to persons, ani­mals or damage to objects arising from
the non-observance of this requirement.

The manufacturers are not liable for any
problems caused by the user’s failure to ob­serve these instructions.

D

O NOT OPERATE THIS APPLIANCE if it has a

damaged mains cord or plug, if it is not
working properly, or if it has been dam­aged or dropped. Do not immerse the
mains cord or plug in water. Keep the
cord away from hot surfaces. Electrical
shock,  re or other hazards may result.

C

HECK THAT THE VOLTAGE on the rating

plate corresponds to the voltage in your
home.

T

HE OVEN CAN BE OPERATED ONLY if the oven door is

 rmly closed.

PLACE THE OVEN ON A STABLE, EVEN

SURFACE that is strong enough to

hold the oven and the food
utensils you put in it. Use
care when handling.

P

OSITION THE OVEN AT A DISTANCE from other heat-

ing sources. For sufficient ventilation there
must be a space of at least 30 cm above the
oven. The appliance must be placed against a
wall, ensure that the space underneath, above
and both sides of the oven is empty to allow
for proper airflow. The microwave oven shall
not be placed in a cabinet.

POOR TELEVISION RECEPTION and radio interfer­ence may result if the oven is lo­cated close to a TV, radio
or aerial.

3

GB

THE APPLIANCES ARE NOT INTENDED to be operat-

ed by means of an external timer or sepa­rate remote-control system.

O

NLY ALLOW CHILDREN to use the appliance

without adult supervision after adequate
instructions have been given, so that the
child is able to use the appliance in a safe
way and understands the hazards of im­proper use. Children should be supervised
when using other heatsources (if avail­able) separately or in
combination with mi­crowaves due to the
high temperatures gen­erated.

T

HIS APPLIANCE IS NOT INTENDED FOR use by per-

sons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge, un­less they have been given supervision or in­struction concerning use of the appliance
by a person responsible for their safety.
CHILDREN SHOULD BE SUPERVISED to ensure that
they do not play with the appliance.

IMPORTANT SAFETY INSTRUCTIONS

DO NOT HEAT, OR USE FLAMMABLE MATERIALS in
or near the oven. Fumes can create a  re
hazard or explosion.

D

O NOT USE YOUR MICROWAVE oven for drying

textiles, paper, spices, herbs, wood,  ow­ers, fruit or other combustible materials.
Fire could result.

DO NOT OVER-CO OK FOOD. Fire could result.

DO NOT LEAVE THE OVEN UNATTENDED, espe-

cially when using paper, plastic or oth­er combustible materials in the cook­ing process. Paper can char or burn and
some plastics can melt if used when
heating foods.
Do not leave the oven unattended if you
are using a lot of fat or oil since they can
overheat and cause a re!

I

F MATERIAL INSIDE / OUTSIDE THE OVEN SHOULD

IGNITE OR SMOKE IS OBSERVED, keep oven

door closed and turn the oven o . Dis­connect the power cord or shut o pow­er at the fuse or circuit breaker panel.

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

D

O NOT USE YOUR MICROWAVE

oven for heating anything in
airtight sealed contain­ers. The pressure increas­es and may cause damage
when opening or may explode.

EGGS
DO NOT USE YOU R MICROWAVE oven for cook-
ing or reheating whole eggs with or
without shell since they may
explode even after microwave
heating has ended.

T

HE DOOR SEALS AND THE DOOR SEAL AREAS must

be regularly inspected for damage. If these
areas are damaged the appliance should
not be operated until it has been repaired
by a trained service technician.

D

O NOT USE corrosive chemicals or va-

pors in this appliance. This type of oven
is speci cally designed to heat or cook
food. It is not designed for industrial or
laboratory use.

D

O NOT HANG OR PLACE heavy items on the

door as this can damage the oven open­ing and hinges. The door handle should
not be used for hanging things on.

4

GB

GENERAL

T

HIS APPLIANCE IS DESIGNED FOR DOMESTIC USE ONLY!

T

HE APPLIANCE SHOULD NOT BE OPERATED without food

in the oven when using microwaves. Operation in
this manner is likely to damage the appliance.

I

F YOU PRACTI CE OPERATING the oven, put a glass

of water inside. The water will absorb the mi­crowave energy and the oven will not be dam­aged.

R

EMOVE WIRE TWIST-TIES from paper or

plastic bags before placing bag in
the oven.

DEEPFRYING

D

O NOT USE YOUR MICROWAVE oven for deep-frying,

because the oil temperature cannot be
controlled.

LIQUIDS

E.

G. BEVERAGES OR WATER. Overheating the liquid

beyond boiling point can occur
without evidence of bubbling.
This could result in a sudden
boil over of the hot liquid.
To prevent this possibility the
following steps should be taken:

1. Avoid using straight-sided containers with
narrow necks.

2. Stir the liquid before placing the container
in the oven and let the teaspoon remain
in the container.

3. After heating, allow standing for a short
time, stirring again before carefully re­moving the container from the oven.

CAREFUL

A

LWAYS REFER to a microwave cookbook for de-

tails. Especially, if cooking or reheating food
that contains alcohol.

A

FTER HEATING BABY FOOD or liquids in a

baby bottle or in a baby food
jar, always stir and check the
temperature before serving.
This will ensure that the heat is evenly distributed
and the risk of scalding or burns can be avoided.

Ensure the Lid and the Teat is removed be­fore heating!

PRECAUTIONS

USE HOT PADS OR OVEN MITTS to prevent
burns, when touching containers, oven
parts, and pan after cooking. Accessi­ble parts may become hot during use,
young children should be kept away.

D

O NOT USE THE CAVITY for any storage purposes.

T

HE VENTILATION OPENINGS on the oven must not be

covered. Blocking the air intake or exhaust vents
may cause damage to the oven and poor cook­ing results.

DO NOT STORE or use this appliance outdoors.

D

O NOT USE this product near a kitchen sink, in

a wet basement, or near a swimming pool, or
similar.

5

GB

ACCESSORIES

GENERAL

I

F ACCESSOR IES CONTAINING METAL comes in contact

with the oven interior, while the oven is in op­eration, sparking can occur and the oven could
be damaged.

TURNTABLE SUPPORT

U

SE THE TURNTABLE SUPPORT under the

Glass turntable. Never put any oth­er utensils on the turntable sup­port.

Fit the turntable support in the oven.



GLASS TURNTABLE
USE THE GLASS TURNTABLE with all cooking meth-
ods. It collects the dripping juic­es and food particles that other­wise would stain and soil the in­terior of the oven.

Place the Glass turntable on the turntable
support.



ENSURE THAT THE UTENSILS YOU USE are oven proof
and allow microwaves to
pass through them before
cooking.

W

HEN YOU PUT FOOD AND ACCE SSORIES in the micro-

wave oven, ensure that they do not come in
contact with the interior of the oven.

This is especially important with accesso­ries made of metal or metal parts.

A

LWAYS ENSURE that the turntable is able to turn

freely before starting the oven. If the turnta­ble isn’t able to turn freely you should use a
smaller vessel.

T

HERE ARE a number of accessories available on

the market. Before you buy, ensure they are
suitable for microwave use.

WIRE RACK
USE THE WIRE RACK with Grill func-
tions.

6

GB

CONTROL PANEL

DIGITAL DISPLAY
The display includes a 24-hour
clock and indicator symbols to
tell you the time of day, cook­ing time, power level, selected
food classes and timer status.

A

UTO MENU BUTTON

Provide 3 kinds of Auto De­frost buttons and 4 kinds of
Auto Cook buttons. No need
to set the power and cook­ing time.

GRILL BUTTON

Use to select desired grill
power level.

POWER BUTTON
Use to set the desired micro­wave power level.

M

EMO BUTTON

Use to recall stored favourite
settings.

S

TART BUTTON

Use to start the cooking
process.

C

LOCK BUTTON

Use to set the 24-hour clock.

+/-

BUTTON

Use to increase/decrease
the cooking time or weight
(In standby mode “-” stand
for defrost per time, and “+“
stand for defrost per weight.)

G

RILL COMBI BUTTON

Use to select Grill Combi func­tion and select grill power lev­el.

P

RESET BUTTON

Use to set the desired func­tion or time.

+1

BUTTON

Use to increase cooking time
with 1 minute.

S

TOP BUTTON

Press to stop or reset any of the
oven functions.

START PROTECTION / CHILD LOCK

LOCK: In standby mode, press Stop button for 3
seconds, long beep will signal then Child
lock mode will be activated. The keys
will be locked at this mode, display
show current clock or 0:00, Child lock
symbol on.

UNLOCK: In Child lock mode, press Stop button
for 3 seconds, long beep will signal then the
lock is invalid, the keys can be used at this mo­ment and Child lock symbol off.

7

GB

PAUSE OR STOP COOKING

TO PAUSE COO KING:
THE COOKING CAN BE PAUS ED to

check, turn or stir the food
by opening the door. The
setting will be maintained
for 5 minutes.

I

F YOU DON’T WANT TO CONTINUE COOKING:

REMOVE THE FOOD, close the door

and press the STOP button.

T

O CONTIN UE COOKIN G:

CLOSE THE DOOR and press the Start

button ONCE. The cooking is
resumed from where it was
paused.
PRESSING THE START BUTTON TWICE will in­crease the time by 30 seconds.

A

BEEP WILL SIGNAL once the cooking ends, then

it comes to standby mode.

T

HE CLOCK IS SET and in operation.

IF THE CLOCK has not been set after plug in, the clock will shows 0:00.

DURING THE SETTING OF CLOCK, if you press Stop button, the oven will

exit from setting mode and the setting will be invalid.

CLOCK

WHEN THE APPLIANCE IS FIRST PLUGGED IN or after a power failure, the dis­play will show “0:00“ and a beep will signal.

q

PRESS THE CLOCK BUTTON , left-hand digit (hours) flicker.

w

PRESS “+“, ”-” BUTTON to set the hours.

e

PRESS THE CLOCK BUTTON, two right hand digits (minutes) flicker.

r

PRESS “+“, ”-” BUTTON to set the minutes.

t

PRESS THE CLOCK BUTTON AGAIN.

q

e

t

w

r

8

GB

MICROWAVES ONLY

P

RESS THE BUTTON MW PERCENTAGE DISPLAY SUGGESTED USE:

1 T

IME 100 % P100

REHEATING OF BEVERAGES, water, clear soups, co ee, tea
or other food with a high water content. If the food
contains egg or cream choose a lower power.

2 T

IMES 75% P75 COOKING OF  sh, meat, vegetables etc.

3 T

IMES 50% P50

MORE CAREFUL COOKING e.g. high protein sauces, cheese
and egg dishes and to  nish cooking casseroles. Sim­mering stews, melting butter.

4 T

IMES 25% P25

DEFROSTING.

COOK & REHEAT WITH MICROWAVES

USE THIS FUNCTION for normal cooking and reheating, such as vegeta­bles,  sh, potatoes and meat.

O

NCE THE COOKIN G PROCESS HAS BEEN STARTED:

THE TIME CAN EASILY BE INCREASED in 30-second steps by pressing the

Start button or 1-minute steps by pressing “+1“ button. Each press
increases the time with 30 seconds or 1 minute.

THE COOKING CAN BE PAUS ED by pressing Stop button once. If you press
the Stop button again or keep the pause for 5 minutes, the oven
will come back to standby mode. If you press the Start button
within 5 minutes the oven will continue the cooking.

DURING THE COOKI NG PROCEDURE, the MW power can be shown for 3
seconds by pressing the Power button, then the oven will return
to counting down.

CHOOSING POWER LEVEL

q

PRESS THE POWER BUTTON repeatedly to set the power.

w

PRESS “+“, ”-” BUTTON to set the cooking time.

e

PRESS THE START BUTTON.

q

w

e

9

GB

THIS FUNCTION IS USED for quick reheating of food with a high water
content such as clear soups, co ee or tea.

JET START

q

PRESS THE START BUTTON.

THIS FUNCTION AUTOM ATICALLY STARTS with maximum microwave power

level and the cooking time set to 30 seconds. Each additional press
increases the time with 30 seconds.

“+1

MINUTE“ FUNCTION

IN STANDBY MODE PRESS +1 BUTTON, the oven automatically come to mi-

crowave procedure with maximum power (P100), then press Start
button to work. Each additional press increases the time with one
minute (except for Auto menu)

DEFROST

DEFROST PER TIME

1. PRESS “-“ BUTTON to select “defrost per time“
function.

2. PRESS “+“, “-“ to set cooking time.

3. PRESS START BUTTON to start cooking with de-

frost power (P30).

D

EFROST PER WEIGHT

1. PRESS “+“ BUTTON to select weight.

3. PRESS START BUTTON to start cooking.

During the cooking procedure, the weight can
be shown for 3 seconds by pressing the “+“
button, then the oven will return to counting
down.

q

10

GB

PRESS THE BUTTON GRILL PERCENTAGE DISPLAY

1 TIME 100 % P100

2 T

IMES 50% P50

GRILL COMBI

P

RESS THE BUTTON GRILL PERCENTAGE DISPLAY

1 TIME 100 % C1

2 T

IMES 75% C2

3 T

IMES 50% C3

4 T

IMES 25% C4

GRILL

USE THIS FUNCTION TO quickly give a pleasant brown surface to the
food.

q

PRESS THE GRILL BUTTON repeatedly to set grill power.

w

PRESS “+“, ”-” BUTTON to set the cooking time.

e

PRESS THE START BUTTON.

E

NSURE THAT THE UTENSILS used are heat resistant and ovenproof be-

fore grilling with them.

D

O NOT USE PLASTIC utensils when grilling. They will melt. Items of

wood or paper are not suitable either.

GRILL COMBI

USE THIS FUNCTION TO cook such food as Gratin’s, Lasagne, Poultry and
Baked potatoes.

q

PRESS THE COMBI BUTTON repeatedly to set the Grill combi power.

w

PRESS “+“, ”-” BUTTON to set the cooking time.

e

PRESS THE START BUTTON.

E

NSURE THAT THE UTENSILS used are heat resistant and ovenproof be-

fore grilling with them.

D

O NOT USE PLASTIC utensils when grilling. They will melt. Items of

wood or paper are not suitable either.

e

w

q

w

e

q

11

GB

AUTO COOK AUTO DEFROST

ICON

FUNCTION BEVERAGE POTATO POPCORN REHEAT MEAT CHICKEN FISH

WEIGHT

125G 200G 50G 250G 100G 100G 100G

175G 400G 85G 500G 200G 200G 200G

225G 600G 100G 1000G 300G 300G 300G

450G 450G 450G

AUTO MENU

THIS FUNCTION provides you a convenient menu to defrost or cook
different foods.

T

HIS FUNCTION NEEDS TO KNOW the net weight of the food. The oven will

automatically calculate the time for defrosting or cooking.

FROZEN FOODS:
IF THE FOOD IS WARMER than deep-freeze temperature (-18°C),
choose lower weight of the food.
IF THE FOOD IS COLDE R than deep-freeze temperature (-18°C),

choose higher weight of the food.

q

PRESS THE BUTTONS IN AUTO MENU to select function (Press repeat-

edly to select amount).

w

PRESS THE START BUTTON.

D

URING THE COOKIN G PROCEDURE, the weight can be shown for 3 sec-

onds by pressing the auto button you chose, then the oven will re­turn to counting down.

q

w

12

GB

MEMORY

THE MEMORY FUNCTION PROVIDES you with an easy way to quickly recall
a preferred setting.
THE PRINCIPLE OF THE MEMORY FUNCTION is to store whatever setting that
is currently displayed.

H

OW TO STORE A SETTING:

q

SELECT any function.

w

PROGRAM your settings.

e

PRESS AND KEEP THE MEMO BUTTON PRESSED until an acoustic signal

is heard. The setting is now stored. You may reprogram the
memory as many times as you wish.

D

URING THE COOKIN G PROCEDURE, the MW power can be shown for 3 sec-

onds by pressing the Memo button, then the oven will return to
counting down.

NOTE: Memory function can’t be used in “Defrost per weight“ or
Auto menu.

H

OW TO USE A STORED SETTING:

q

PRESS THE MEMO BUTTON.

w

PRESS THE START BUTTON.

q

w

13

GB

PRESET

IF THE PRESET TIME COM ES, the beep will signal twice, then the cooking
procedure starts. If the oven door is not close at this moment, the
procedure will pause for it.

DURING THE SETTING OF PRESET, if press the Stop button, the oven will
exit from setting state and the setting will be invalid.

NOTE: ,Preset can’t be done if the clock has not been set. (Preset
can’t be set for “Defrost per weight ” or “Defrost per time “function.)

U

SE THIS FUNCTION to preset desired cooking fuction and time.

q

SET THE COOKI NG PROCEDURE.

w

PRESS THE PRESET BUTTON, shows the current time (The two left

hand digits ”00”(hours) flicker).

e

PRESS THE “+“, “-“ BUTTON to set the hours.

r

PRESS THE CLOCK BUTTON (The two right hand digits “00“ (min-

utes) flicker).

t

PRESS THE “+“, “-“ BUTTON to set the minutes.

y

PRESS THE CLOCK BUTTON to confirm the setting.

q

w

e

r

t

y

14

GB

TYPE OF

FOOD

AMOUNT POWER

LEVEL

TIME STANDING

TIME

HINTS

C

HICKEN

(whole)

1000 G

100 %

18 - 20

MIN. 5 - 10 MIN.

TURN THE CHICKEN midway thru
cooking. Check that the
meatjuice is uncolored when
the cooking is finished.

C

HICKEN

(fillets or
pieces)

500 G 8 - 10 MIN.5 MIN.

CHECK that the meatjuice is
uncolored when the cooking is
finished.

B

ACON 150 G 3 - 4 MIN. 1 - 2 MIN.

PLACE ON KITCHEN PAPER , on a plate,
in 2 or 3 layers and cover with
more kitchen paper.

V

EGETABLES

(fresh)

300 G 3 - 4 MIN. 1 - 2 MIN.

COOK COVERED and add 2 tbs salt.

V

EGETABLES

(frozen)

250 -

400 G

3 - 4 MIN.
5 - 6 MIN.

1 - 2 MIN.

COOK COVERED

JACKET

POTATOES

1 PC

4 PCS

4 - 6 MIN.

12 - 15 MIN.

2 MIN.
5 MIN.

PRICK WITH FORK. (1 pc = 250 g).
Turn midway thru cooking.

M

EAT (loaf )

600 ­700 G

75%

12 - 14

MIN.5 MIN.

F

ISH (whole) 600 G 8 - 9 MIN. 4 - 5 MIN.SCORE THE SKIN and cook covered.

F

ISH (steaks

or fillets)

400 G 5 - 6 MIN. 2 - 3 MIN.

PLACE WITH THINNER PAR TS towards
the center of the plate. Cook
covered.

COOKING CHART

THE MORE FOOD YOU WANT TO COO K the longer it
takes. A rule of thumb is that double amount
of food requires almost double the time.
THE LOWER STARTING TEMPERATURE, the longer cook-
ing time is required. Food at room tem­perature cooks faster than food taken di­rectly from the refrigerator.

I

F YOU ARE COO KING SEVERAL ITEMS of the

same food, such as jacket po-

tatoes, place them in a ring
pattern for uniform cooking.

S

TIRRING AND TURNING OF FOOD ARE techniques

used in conventional cooking as well as in mi­crowave cooking to distribute the heat quick-

ly to the center of the dish and avoids over-

cooking at the outer edges of the food.

W

HEN COOKIN G FOOD OF UNEVEN SHAPE or

thickness, place the thinner area of
food towards the center of the dish,

where it will be heated last.

F

OOD WITH LOT OF FAT AND SUGAR will be

cooked faster than food containing a lot
of water. Fat and sugar will also reach a higher
temperature than water.
ALWAYS ALLOW THE FOOD TO STAND for some time
after cooking. Standing time
always improves the result
since the temperature will
then be evenly distributed
throughout the food.

S

OME FOODS ARE COVER ED BY A SKIN OR MEMBRANE

e.g. potatoes, apples and egg yolks.
These food should be pricked with
a fork or cocktail stick to relieve the
pressure and to prevent bursting.
SMALLER PIECES OF FOOD WILL COOK FAS TER than larg­er pieces and uniform pieces of food cook
more evenly than irregularly shaped foods.

15

GB

TYPE OF

FOOD

AMOUNT POWER

LEVEL

TIME STANDING

TIME

HINTS

P

LATED MEAL

300 G
450 G

100 %

3 - 5

MIN.

4 - 5 MIN.

1 - 2 MIN.

COVER THE PLATE

RICE

2 DL
6 DL

1 - 2 MIN.
3 - 4 MIN.

1 MIN.

2 MIN

COVER THE DISH

MEAT BALLS 250 G 2 MIN. 1 - 2 MIN.HEAT UNCOVERED

BEVERAGE 2 DL 1 - 2 ½ MIN.1 MIN.

PUT A METAL SPOON in the cup to
prevent overcooking.

S

OUP (clear) 2½ DL 2 - 2 ½ MIN.1 MIN.

REHEAT UNCOVERED in a soup plate
or bowl.

M

ILKBASED

SOUPS OR

SAUCES

2 ½ DL 3 - 4 MIN.1 MIN.

DO NOT FILL the container more
than 3/4. Stir once during
heating.

H

OT DOGS

1 PC

2 PCS

75%

½ - 1

MIN.

1 - 1 ½ MIN.

1 MIN.

L

ASAGNA 500 G 5 - 6 MIN. 2 - 3 MIN.

REHEATING CHART

AS IN TRADITIONAL COOK ING METHODS, food reheat­ed in a microwave oven must always be heat­ed until piping hot.
THE BEST RESULTS ARE ACHIEVED if the food
is arranged with the thicker food to the
outside of the plate and the thinner
food in the centre.

P

LACE THIN SLICES OF MEAT on top of each

other or interlace them. Thicker slic­es such as meat loaf and sausages have to be
placed close to each other.

W

HEN REHEATING STEWS OR SAUCES it is better to stir

once to distribute the heat evenly.

C

OVERIN G THE FOOD helps to keep the moisture

inside the food, reduces spattering and
shortens the reheating time.

W

HEN REHEATING FROZEN FOOD portions

follow the manufactures instruction

on the package.

FOOD WHICH CANNOT BE STIRRED, like gratin is

best reheated on P75.
SOME MINUTES STANDING TIME will make sure the
temperature is evenly distributed throughout
the food.

16

GB

TYPE OF

FOOD

AMOUNT POWER

LEVEL

TIME STANDING

TIME

HINTS

R

OAST

800 -

1000 G

25%

20 - 22 MIN. 10 - 15 MIN.TURN halfway thru defrosting.

M

INCED MEAT 500 G 8 - 10 MIN.5 MIN.

TURN halfway thru defrosting.
Separate thawed parts.

C

HOPS, CUTLETS,

STEAKS

500 G 7 - 9 MIN. 5 - 10 MIN.TURN halfway thru defrosting.

C

HICKEN

(whole)

120 0 G 25 MIN. 10 - 15 MIN.TURN halfway thru defrosting.

C

HICKEN pieces

or fillets

500 G 7 - 9 MIN. 5 - 10 MIN.

TURN / SEPARATE halfway thru
defrosting. Shield wingtips
and legs with foil to prevent
overheating.

F

ISH (whole) 600 G 8 - 10 MIN. 5 - 10 MIN.

TURN halfway thru defrosting
and shield the tail with foil to
prevent overheating.

F

ISH (steaks or

fillets)

400 G 6 - 7 MIN.5 MIN.

TURN halfway thru defrosting.
Separate thawed parts.

L

OAF OF BREAD 500 G 4 - 6 MIN.5 MIN.TURN halfway thru defrosting.

R

OLLS & BUNS

4 PCS (150

- 200 G)

1 ½ - 2 MIN. 2 - 3 MIN.PLACE in a ring pattern.

F

RUIT & BERRIES 200 G 2 - 3 MIN. 2 - 3 MIN.SEPARATE during defrosting.

DEFROSTING CHART

FROZEN FOOD IN PLASTIC BAGS , plastic  lms or card­board packages can be placed directly in the
oven as long as the package has no metal
parts (e.g. metal twist ties).
THE SHAPE OF THE PACK AGE alters the defrost-
ing time. Shallow packets defrost more
quickly than a deep block.

S

EPARATE PIECES as they begin to defrost.

Individual slices defrost more easily.
SHIELD AREAS OF FOOD with small pieces of
aluminiumfoil if they start to become warm
(e.g. chicken legs and wing tips).

T

URN LARGE JOINTS halfway through the defrost-

ing process.
BOILED FOOD, STEWS AND MEAT SAUCES defrost better

if stirred during defrosting time.

WHEN DEFROSTING it is better to under-

thaw the food slightly and allow the

process to  nish during standing time.

S

TANDING TIME AFTER DEFROSTING always im-

proves the result since the temperature

will then be evenly distributed through-

out the food.

17

GB

TYPE OF FOOD AMOUNT SETTING TIME HINTS

C

HEESE TOAST 3 PCS

GRILL

4 - 5 MIN.PLACE on wire rack

P

OMMES DUCHESSE 2 PORTIONS 6 - 8 MIN.PLACE dish on the wire rack.

S

AUSAGES

(100 g / pc)

2 - 3 PCS 10 - 12 MIN.

PLACE on the wire rack. Turn midway
thru cooking.

C

HICKEN PIECES 1000 G

100 % MW

THEN

100%

GRILL

13 - 15 MIN.

8 - 9 MIN.

PLACE with skin up in a dish.

P

OTATOE GRATIN 4 PORTIONS

18 - 20 MIN.

5 - 6 MIN.

PLACE vessle on the turntable.

L

ASAGNA (frozen) 500 G

75% MW

THEN

100%

GRILL

18 - 20 MIN.

5 - 6 MIN.

PLACE vessle on the turntable.

F

ISH GRATIN

(frozen)

600 G

15 - 18 MIN.

5 - 7 MIN.

PLACE vessle on the turntable.

GRILLING CHART

THE GRILL FUNCTION IS EXCELLENT for browning the
food after cooking with microwaves.

T

HICKER FOODS such as gratins and chicken; Cook

with microwaves  rst and then allow the grill

to brown the top surface in order to put

some colour to it.

T

HE WIRE RACK may be used to move

foods closer to the grill element for
quicker browning.

P

LACE THIN FOODS such as toasts and sausages

on the wire rack and cook with grill only.

Y

OU MAY PLACE vessels or gratins directly

on the Glass turntable.

18

GB

THE OVEN should be cleaned regularly and
any food deposits removed.

MAINTENANCE & CLEANING

CLEANING IS THE ONLY MAINTENANCE normally re-
quired. It must be carried out with the micro­wave oven disconnected.
FAILURE TO MAINTAIN THE OVEN in a clean condition
could lead to deterioration of the surface that
could adversely a ect the life of the appliance
and possibly result in a hazardous situation.

D

O NOT USE METAL SCOURING PADS ,

ABRASIVE CLEANSERS, steel-

wool pads, gritty wash­cloths, etc. which can
damage the control pan­el, and the interior and ex terior oven sur­faces. Use a cloth with a mild detergent
or a paper towel with spray glass cleaner.
Apply spray glass cleaner to a paper towel.
DO NOT SPRAY directly on the oven.

AT REGULAR INTERVALS, especially
if spill overs have occurred, re­move the turntable, the turnta­ble support and wipe the base of
the oven clean.
THIS OVEN IS DESIGNED to operate with the turnta­ble in place.

DO NOT operate the microwave oven
when the turntable has been removed
for cleaning.

DISHWASHER SAFE:

T

URNTABLE SUPPORT.

G

LASS TURNTABLE.

D

O NOT USE STEAM CLEANING APPLIANCES when

cleaning your microwave oven.

USE A SOFT AND DAMP CLOTH with mild detergent
to clean the interior surfaces, front and rear of
the door and the door opening.

DO NOT ALLOW GREASE or food particles to

build up around the door.
FOR STUBBORN STAINS, boil a cup of water in the
oven for 2 or 3 minutes. Steam will soften the
marks.
ADDING SOME LEMON JUICE to a cup of water, plac­ing this on the turntable and boiling for a few
minutes can eliminate odors inside the oven.

T

HE GRILL ELEMENT does not need cleaning since

the intense heat will burn o any splashes, but
the ceiling beneath it may need regular clean­ing. This should be done with a soft and damp
cloth with mild detergent.
If the Grill is not used regularly, it should be
run for 10 minutes a month to burn off any
splashes, in order to reduce the risk of fire.

W

IRE RACK.

19

GB

TROUBLE SHOOTING GUIDE

IF THE OVEN DOES NOT WORK, do not make a service
call until you have made the following checks:

The Turntable and turntable support is in
place.
The Plug is properly inserted in the wall
socket.
The Door is properly closed.
Check your Fuses and ensure that there is
power available.
Check that the oven has ample ventilation.
Wait for 10 minutes, then try to operate the
oven once more.
Open and then close the door before you
try again.

T

HIS IS TO AVOID unnecessary calls for which you

will be charged.
When calling for Service, please give the serial
number and type number of the oven (see Ser­vice label). Consult your warranty booklet for
further advice.











IF THE MAINS CORD NEEDS REPLACING it should
be replaced by the original
mains cord, which is avail­able via our service organi­zation. The mains cord may
only be replaced by a trained
service technician.

S

ERVICE ONLY TO BE CARRIED OUT BY

A TRAINED SERVICE TECHNICIAN. It

is hazardous for anyone oth­er than a trained person to carry
out any service or repair oper­ation, which involves the re­moval of any cover, which gives pro­tection against exposure to microwave
energy.

DO NOT REMOVE ANY COVER.

ENVIRONMENTAL HINTS

THE PACKIN G BOX may be fully re­cycled as con rmed by the re­cycling symbol. Follow lo­cal disposal regulations. Keep
potentially hazardous pack­aging (plastic bags, polysty­rene etc.) out of the reach of chil­dren.
THIS APPLIANCE is marked according to the Euro­pean directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE). By ensuring
this product is disposed of correctly, you will
help prevent potential negative consequences
for the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product.

THE SYMBOL on the product, or on the docu-
ments accompanying the
product, indicates that this
appliance may not be treat­ed as household waste. In­stead it shall be handed over
to the applicable collection
point for the recycling of elec­trical and electronic equip­ment.
DISPOSAL must be carried
out in accordance with lo­cal environmental regula­tions for waste disposal.
FOR MORE DETAILED INFORMATION about treatment,
recovery and recycling of this product, please
contact your local city o ce, your household
waste disposal service or the shop where you
purchased the product.
BEFORE SCRAPPING, cut o the mains cord so that
the appliance cannot be connected to the
mains.

20

GB

SUPPLY VOLTAGE 230 V/50 HZ

RATE D POWER INPUT 1100 W

F

USE 10 A

MW

OUTPUT POWER 700 W

O

UTER DIMENSIONS (HXWXD) 285 X 456 X 359

I

NNER DIMENSIONS (HXWXD) 196 X 292 X 295

TEST AMOUNT APPROX. TIME POWER LEVEL CONTAINER

12. 3 .1 75 0

G 10 MIN.100% PYREX 3.220

12. 3 .2 4 75

G 5 MIN.100% PYREX 3.827

12.3.3 900

G 14 MIN.100% PYREX 3.838

13. 3 50 0

G AUTODEFROST PLACE ON TURNTABLE

GB

461965275291

IN ACCORDANCE WITH IEC 60705.
THE INTERNATIONAL ELECTROTECHNICAL COMMISSION has developed a standard for comparative testing
of heating performance of di erent microwave ovens. We recommend the following for this oven:

TECHNICAL SPECIFICATION

Whirlpool is a registered trademark of Whirlpool, USA
