INSTRUCTIONS FOR USE

1.Lid handle.

2.Lock (if provided).

3.Seal.

4.Divider (if provided).

5.Defrost water drain plug.

6.Control panel.

7.Side motor cooling grille.

8.Upper edge.

9.Condenser (located at the rear)

Climatic Class	Amb. T. (°C)	Amb. T. (°F)
SN	From 10 to 32	From 50 to 90
N	From 16 to 32	From 61 to 90
ST	From 16 to 38	From 61 to 100
T	From 16 to 43	From 61 to 110

INSTALLATION

•Please refer to the chapter "BEFORE USING THE APPLIANCE".

•Unpack the appliance.

•Remove the 4 protection pieces inserted between lid and appliance.

•Ensure that the defrosting water drainage plug (if provided) is correctly positioned (5).

•For best operation of the appliance and in order to avoid damage when the lid is opened, leave a space of at least 7 cm from the rear wall and 7 cm at the sides.

•Fit the accessories (if provided).

1.Temperature adjustment thermostat.

2.Red LED (if provided) : Indicates that the appliance temperature is not sufficiently low.

3.Green LED (if provided): indicates that the appliance is on.

4.Yellow/orange illuminated button (if provided): activates/deactivates the fast freeze function. It lights up when the fast freeze function is active.

The exact configuration of the controls may vary according to the model.

Switching on the appliance

•The appliance is factory set for optimum operation at a temperature of -18°C.

•Plug in the appliance.

•The green LED lights up (if provided).

•Also the red LED (if provided) will switch on because the temperature inside the appliance is not yet sufficiently low for food storage. The red LED will normally switch off within the first six hours after the appliance is switched on.

•After connecting the appliance to the mains supply and when the optimal temperature has been reached (this phase takes about 1 hour during which the lid will not open), ensure that the fast freeze button is not pressed (the yellow LED, if provided, is off).

•Place food inside the product only when the red LED (if provided) has switched off.

•Thanks to the efficient lid seal, the appliance lid will not reopen easily immediately after closing. Wait a few minutes before re-opening the lid of the appliance.

Temperature Adjustment

Use the thermostat to select the ideal storage temperature. To adjust the internal temperature, proceed as follows:

•Turn the thermostat knob to 1 for a storage temperature that is less cold.

•Turn the thermostat knob to 6 / for a colder storage temperature.

•For partial loads, or when the load indicator is below the "e" symbol inside the appliance, it is advisable to move the thermostat to the lower position (on "e", if present on the thermostat scale)

CO Big

INSTRUCTIONS FOR USE

BEFORE USING THE APPLIANCE	2. Wait at least two hours before switching the appliance
Your new appliance is designed exclusively for domestic use	on in order to ensure the refrigerant circuit is fully
and for storing frozen food, freezing fresh food and making	efficient.
ice cubes.	3. Installation of the appliance and electrical connections
Regulations require that the appliance is earthed.	must be carried out by a qualified electrician, in
The manufacturer declines all liability for injury to	accordance with the manufacturer's instructions and
persons or animals and for damage to property	local safety regulations.
resulting from failure to observe the above	4. Clean the inside of the appliance before using it.
procedures and reminders.
1. After unpacking, make sure that the appliance is	• Before connecting the appliance to the mains supply,
undamaged and that the lid closes perfectly tight. Any	ensure that the voltage corresponds to that given on the
damage must be reported to your dealer within 24	rating plate located on the rear of the appliance.
hours after delivery of the appliance.	• Electrical connections must be made in accordance
	with local regulations.

FREEZING FOOD

Preparation of fresh food for freezing

•Before freezing, wrap and seal fresh food in: aluminium foil, cling film, air and water-tight plastic bags, polyethylene containers with lids, provided they are suitable for freezing foods.

•Food must be fresh, mature and of prime quality in order to obtain high quality frozen food.

•Fresh vegetables and fruit should preferably be frozen as soon as they are picked to maintain the full original nutritional value, consistency, colour and flavour.

•Always leave hot food to cool before placing in the appliance.

Freezing fresh food

•Place foods to be frozen in direct contact with the walls of appliance:

A)- foods to be frozen,

B)- foods already frozen.

•Avoid placing foods to be frozen in direct contact with food already frozen.

•For best and fastest freezing, foods should be split into small portions; this will also be useful when the frozen items are to be used.

1.At least 24 hours before storing fresh food in the appliance, press the fast freeze button. For appliances without this button, turn the thermostat to .

2.Place the food to be frozen and keep the lid of the appliance closed for 24 hours. At the end of this period, switch off the fast freeze button (if provided).

FOOD STORAGE

Refer to the table on the appliance (if provided).

Classification of frozen MONTHS FOOD foods

Put the frozen products into the appliance and classify them; The storage date should be indicated on the packs, to allow use within expiry dates.

Advice for storing frozen food

When purchasing frozen food products:

•Ensure that the packaging is not damaged (frozen food in damaged packaging may have deteriorated). If the package is swollen or has damp patches, it may not have been stored under optimal conditions and defrosting may have already begun.

•When shopping, leave frozen food purchases until last and transport the products in a thermally insulated cool bag.

•Once at home, place the frozen foods immediately in the appliance.

•Avoid, or reduce temperature variations to the minimum. Respect the best-before date on the package.

•Always observe the storage information on the package.

Note:

Eat fully or partially defrosted foods immediately. Do not refreeze unless the food is cooked after it has

thawed. Once cooked, the thawed food can be refrozen. If there is a long power failure:

•Do not open the appliance lid except to place ice packs (if provided) over the frozen foods on the right and left of the appliance. This will slow down the rise in temperature.
