Page 1
CABINET PARTS
REFRIGERATOR
For Models: ET16JKXBW01, ET16JKXBN01, ET16JKYBW01, ET16JKYBN01
(White) (Almond) (White) (Almond)
12−97 Litho In U.S.A. (sak)
1
Part No. 4379516
Page 2
CABINET PARTS
For Models: ET16JKXBW01, ET16JKXBN01, ET16JKYBW01, ET16JKYBN01
(White) (Almond) (White) (Almond)
Illus. Part
No. No. DESCRIPTION
1 Cabinet (Not A
Serviceable Part)
2 2157591 Hinge (Top)
3 2166108 Roller−Front (2)
5 489385 Clamp, Tube
(Water Supply Line)
12 549193 Clamp−Cord
13 937360 Cord−Service
15 489423 Screw
16 2163758 Hinge, Center
17 2163757 Shim, Hinge
Center
18 489413 Screw
20 2172577 Hinge Butt
23 2172745 Shim, Bottom
Hinge
24 Fitting, Water Tube
(Not Serviced)
27 Hole Plug (6)
2151652 White
2151653 Almond
28 Seal, Front
(Not Serviced)
29 2163763 Cabinet, Wiring
Assembly
30 Seal, Rear
(Not Serviced)
31 2166251 Cover, Valve
35 Corner Filler (2)
2163733 White
2166187 Almond
36 2166134 Grille
38 487576 Washer
39 1123517 Shim
40 Cover−Hinge
2160403 White
2160404 Almond
41 Rail, Center
(Not Serviced)
42 2166205 Corner Filler,
Grille
43 2166160 Pin, Hinge
44 2163814 Cover, Unit
2
4379516
Page 3
DOOR PARTS
For Models: ET16JKXBW01, ET16JKXBN01, ET16JKYBW01, ET16JKYBN01
(White) (Almond) (White) (Almond)
4379516
3
Page 4
DOOR PARTS
For Models: ET16JKXBW01, ET16JKXBN01, ET16JKYBW01, ET16JKYBN01
(White) (Almond) (White) (Almond)
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
Panel
2171269 White
2171270 Almond
2 End Cap
9791773 White
9791774 Almond
3 Hole Plug (2)
534927 White
989197 Almond
4 End Cap, Handle (2)
9791771 White
9791772 Almond
5 Handle Center
2148035 White
2148036 Almond
6 489006 Screw
7 943188 Spacer
8 487909 Screw
9 Door Gasket,
Magnetic
2159057 Mist Beige
Illus. Part
No. No. DESCRIPTION
10 991259 Tape
12 Cover, Screw
9791769 White
9791770 Almond
13 Nameplate
2162781 White Model
2162782 Almond Model
16 2159244 Trim, Door Shelf
17 489028 Screw
18 2159454 Trim, Door
19 Freezer Door
Panel
2159446 White
2159447 Almond
20 Hole Plug
1122653 White
1122654 Almond
23 Door Gasket,
Magnetic
2159056 Mist Beige
25 2159243 Trim, Door Shelf
Illus. Part
No. No. DESCRIPTION
26 2159367 Stop, Door
27 488921 Screw
28 Hole Plug
844478 White
989196 Almond
29 2156007 Plug−Trim (4)
30 2156006 Plug−Trim (4)
31 2171009 Compartment Door
33 Handle, F.C.
2159453 White
2159471 Almond
36 2159364 Stop−Door
37 2159455 Trim−Door (2)
38 943187 Shim
39 Handle End
9791776 White
9791777 Almond
41 2156003 Endcap (4)
42 2159456 Trim, Door
4
4379516
Page 5
LINER PARTS
For Models: ET16JKXBW01, ET16JKXBN01, ET16JKYBW01, ET16JKYBN01
(White) (Almond) (White) (Almond)
4379516
5
Page 6
LINER PARTS
For Models: ET16JKXBW01, ET16JKXBN01, ET16JKYBW01, ET16JKYBN01
(White) (Almond) (White) (Almond)
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 531933 Grommet (2)
3 2166180 Gasket, Evaporator
Cover (Side)
4 2172691 Timer, Defrost
6 941839 Hole Plug
7 2172542 Wire Assy.
Control Box
8 2162085 Socket, Light (2)
9 2172570 Damper, Air
10 2163766 Fan Motor
11 2163777 Fan Blade
12 2172566 Control Box
13 2172690 Thermostat
14 486214 Screw
15 489412 Screw
16 2163816 Cover−Evaporator
17 946059 Light Bulb (2)
18 2163802 Weight, Thermal
19 1108112 Rocker Arm
Switch
20 2163809 Post, Damper
21 2172560 Cover, Air
Diffuser
22 2163800 Control Knob
23 2172574 Air Tower
24 2172564 Air Diffuser,
Bottom
25 2172679 Freezer Floor
26 2172563 Air Diffuser, Top
27 944759 Cover, Hole
28 1103725 Hole Plug
29 2163827 Bracket,
Fan Motor
30 2166192 Gasket, Evaporator
Cover (Top)
31 2174629 Air Return & Foil
Assembly
32 487996 Cap
33 489242 Screw
34 2163801 Knob, Dampener
35 2163810 Bracket,
Damper Knob
36 2172532 Seal, Rear
Thermostat
37 2172594 Gasket, Air
Diffuser
6
4379516
Page 7
UNIT PARTS
For Models: ET16JKXBW01, ET16JKXBN01, ET16JKYBW01, ET16JKYBN01
(White) (Almond) (White) (Almond)
4379516
7
Page 8
UNIT PARTS
For Models: ET16JKXBW01, ET16JKXBN01, ET16JKYBW01, ET16JKYBN01
(White) (Almond) (White) (Almond)
Illus. Part
No. No. DESCRIPTION
1 2176202 Plate, Unit
Mounting
3 2172670 Condenser
4 2172692 Heater, Defrost
5 2172669 Evaporator Assy.
6 489414 Screw
7 2172618 Drain Pan
10 2163780 Extension, Air
Baffle
11 Clamp
2162400 Production
938384 Service
12 1108115 Cover
(Service
Compressor Only)
13 2154759 Overload
14 Grommet (4)
2163786 Production
1100826 Service
15 2163893 Module
17 2163782 Roller (2)
18 981126 Rivet
19 2166244 Clip, Heater
21 Nut
(Not Serviced)
Illus. Part
No. No. DESCRIPTION
28 2162352 Compressor
(Includes Items
11, 12, 13, 29,
32, 38 & 56)
(Also Order
482801
Installation Kit
& 876765
Tube Kit)
29 2164409 Drier
30 2155774 Clamp
32 2169137 Capacitor
37 2163787 Clip, Compressor (4)
38 1127675 Wire Assembly
39 2172697 Air Baffle
40 2166191 Motor, Condenser
42 2172600 Wire Assy. Unit
43 851732 Fan Blade
44 486692 Nut
46 2172673 Tube, Discharge
47 2172677 Tube, Suction
48 2154109 Tube, Process
49 2174670 Tube, Condenser
To Heat Loop
56 487240 Screw
58 2163795 Evap. Tray
Illus. Part
No. No. DESCRIPTION
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
482278 Start Kit
REFRIGERANT CHARGE
4.0 Ozs.
(R134A)
8
4379516
Page 9
SHELF PARTS
For Models: ET16JKXBW01, ET16JKXBN01, ET16JKYBW01, ET16JKYBN01
(White) (Almond) (White) (Almond)
Illus. Part
No. No. DESCRIPTION
1 841180 Ice Tray (2)
2 2166147 Shelf (2)
3 2163833 Cover, Crisper
4 2166256 Crisper Pan
5 2166255 Plug, Shelf Cup
6 2172541 Support, Crisper
Cover
7 2163835 Track, Crisper
8 483210 Shelf, Ice Tray
9 2166257 Crisper Pan
10 2166149 Insert
11 489242 Screw (2)
12 489415 Screw (2)
13 Spacer, Ice
Tray Shelf
(Not Required)
4379516
9
Page 10
LITERATURE AND OPTIONAL PARTS
For Models: ET16JKXBW01, ET16JKXBN01, ET16JKYBW01, ET16JKYBN01
(White) (Almond) (White) (Almond)
Illus. Part
No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
Miscellaneous
978941 Insulation,
Fiberglass
(63−1/2" x 35−1/2"
x 2−5/8")
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4" x 108")
876305 Kit, Insulation
(14 Pcs.
3" x 24" x 48")
876370 Kit, Insulation
(2 Pcs.
3" x 24 " x 48")
876029 Kit, Foam Slab
(30" x 32−1/2" x
1−1/2")
505587 Sealer, Mastic
(1 Qt.)
511873 Touch−Up, White
Porcelain (2 Oz.)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
606755 Bag, Insulation
(36−5/8" x 46")
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
799832 Kit, Porcelain
Repair (White)
503695 Cork Sealer
(1/4 Pound)
2172516 Door Reversal
Instructions
Illus. Part
No. No. DESCRIPTION
Customer Touch−Up Material
350942 Primer, White
(13 Oz. Spray Can)
350939 Enamel, Black
(13 Oz. Spray Can)
350930 Enamel, White
(13 Oz. Spray Can)
350956 Enamel, Almond
(13 Oz. Spray Can)
72017 Brush Touch−Up Kit
(White)
72032 Brush Touch−Up Kit
(Black)
72107 Brush Touch−Up Kit
(Almond)
Caution: The Spray Paint Is Not
To Be Used Where The Paint
May Make Contact With The
Door Gaskets
Illus. Part
No. No. DESCRIPTION
Refinishing Material
799344 Enamel, White
(1 Qt. Uncut)
978883 Enamel, Almond
(1 Qt. Uncut)
833938 Kit, Terminal
Connector
LITERATURE PARTS
LIT2169460 Service &
Wiring Sheet
LIT2170974 Energy Label
LIT2166259 Use & Care Guide
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
LIT677969 Do−It−Yourself
Manual Ref./Fzr.
LIT677971 Do−It−Yourself
Manual, Icemaker
ICE MAKER
FIELD INSTALLABLE
ECKMF94
TORX SCREW WRENCH
1117510 Torx Key
10
4379516
