hvm6cii
J Hoip^KAnianBM
Use And Care
A Note To You
important Safety
Instmctions
3
Parts And Features
Before Using Your
Refiigerator
Using Your
Refrigerator
Caring For Your
Refrigerator
Food Storage Guide 17
If You Need
Assistance
Or Service
Warranty
1-800-253-1301
Call us with questions or comments.
4
15
20
24
NO-FROST REFRIGERATOR-FREEZER
MODEL EB21DK
A NOTE TO YOU
A Note To You
Thank you for buying a Whirlpool appliance.
You have purchased a quality, world-class home appliance. Years of engineering experience have gone
into its manufacturing. To ensure that you will enjoy many years of trouble-free operation, we have
developed this Use and Care Guide. It is full of valuable information on how to operate and maintain
your appliance properly and safely. Please read it carefully. Also, please complete and mail the Owner
ship Registration Card provided with your appliance. This will help us notify you about any new informa
tion on your appliance.
Your safety is important to us.
This guide contains safety symbols and statements. Please pay special attention to these symbols and
follow any instructions given. Here is a brief explanation of the use of each symbol.
^WARNING
This symbol will help alert you to such dangers as
personal injury, burns, fire and electrical shock.
This symbol will help you avoid actions which
could cause product damage (scratches, dents,
etc.) and damage to your personal property.
ACAUTION
Our Consumer Assistance Center number, 1-800-253-1301, is toii-free, 24 hours a day.
If you ever have a question concerning your appliance's operation, or if you need service, first see “If
You Need Assistance Or Service” on page 20. If you need further help, feel free to call our Consumer
Assistance Center. When calling, you will need to know your appliance’s complete model number and
serial number. You can find this information on the model and serial number label (see diagram on
page 4). For your convenience, we have included a handy place below for you to record these numbers,
the purchase date from the sales slip and your dealer's name and telephone number. Keep this book
and the sales slip together in a safe place for future reference.
Model Number
Serial Number
Purchase Date
Dealer Name
Dealer Phone
IMPORTANT SAFETY INSTRUCTIONS
Important Safety Instructions
^WARNING
• Read all instructions before using the
refrigerator.
• Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigerators are still dangerous ... even if
they will *^ust sit in the garage a few days.”
If you are getting rid of your old refrigerator,
do it safely. Please read the enclosed safety
booklet from the Association of Home
Appliance Manufacturers. Help prevent
accidents.
To reduce the risk of fire, electrical shock, or injury when using your
refrigerator, follow these basic precautions:
- SAVE THESE INSTRUCTIONS -
Help us help you
Please:
• Install and level the refrigerator on a floor that
will hold the weight and in an area suitable for
its size and use.
• Do not install the refrigerator near an oven,
radiator or other heat source.
• Do not use the refrigerator in an area where the
room temperature will fall below 55"F (IS^C).
• Keep the refrigerator out of the weather.
• Connect the refrigerator only to the proper kind
of outlet, with the correct electrical supply and
grounding. (Refer to the Electrical Require
ments and Grounding Instructions Sheet.)
• Do not load the refrigerator with food before it
has time to get properly cold.
• Use the refrigerator only for the uses described
in this manual.
• Properly maintain the refrigerator.
• Be sure the refrigerator is not used by anyone
unable to operate it properly.
• Never allow children to operate, play with, or
crawl inside the refrigerator.
• Never clean refrigerator parts with flammable
fluids. The fumes can create a fire hazard or
explosion.
• FOR YOUR SAFETY •
DO NOT STORE OR USE GASOLINE OR
OTHER FLAMMABLE VAPORS AND LIQUIDS
IN THE VICINITY OF THIS OR ANY OTHER
APPLIANCE. THE FUMES CAN CREATE A
FIRE HAZARD OR EXPLOSION.
Also, remove tape and any inside labels (except
the model and serial number label) before using
the refrigerator.
To remove any remaining glue:
• Rub briskly with thumb to make a ball, then
remove.
OR
• Soak area with liquid hand dishwashing
detergent before removing glue as described
above. Do not use sharp instruments, rubbing
alcohol, flammable fluids or abrasive cleaners.
These can damage the material. See “Impor
tant Safety Instructions” above.
NOTE: Do not remove any permanent instruction
labels inside your refrigerator. Do not remove the
Tech Sheet fastened under the refrigerator at the
front.
PARTS AND FEATURES
Parts And Features
This section contains captioned illustrations of your appliance. Use them to become familiar with where
all parts and features are located and what they look like.
Ac^ustable
tpillguard
shelvea.
Utility bin.
Meat drawer.
Crisper cover.
Humiditycontrolled
criapera-
Ice cube
trays
Ice bin
Slide-out
baskets '
Leveling
rollers _
(behind base
grille)
Control Light Egg
panel I bin
Utility
compartment
Butter
compartment
Adjustable
door bins
. Bin glides
Deep
adjustable
door bins
Shelf glide
Light
Model and
number
label
side wall)
Control panel
Refrigerator control
COLDEST 5
ÍP/
REFRIGERATOR
Exterior moisture control
HI
EXTERIOR
MOISTURE
CONTROL
Freezer control
COLDER C
W0/'
B
FREEZER
BEFORE USING YOUR REFRIGERATOR
Before Using Your
Refrigerator
In This Section
Cleaning it.............................................................. 5
Plugging it in
It is important to prepare your refrigerator for use. This section will tell you how to clean it, connect it to
a power source, install it and level it.
..........................................................
Page
Inatalling it properly..............................................5
Leveling it............................................................6
5
Page
Cleaning it
Clean your refrigerator before using it, if neces
sary. See cleaning instructions on page 15.
Plugging it in
Recommended Grounding Method
A 115 Volt, 60 Hz., AC only 15 or 20 ampere
fused and properly grounded electrical supply is
required. It is recommended that a separate
circuit serving only this appliance be provided.
Use a receptacle which cannot be turned off with
a switch or pull chain. Do not use an extension
cord.
See Electrical Requirements and Grounding
Instructions Sheet in your Literature Package.
3-prong grounding
type wall receptacle
i
Refrigerator
power cord
3-prong
grounding plug
Installing it properly
1. Allow 'A inch (1.25 cm) space on each side
and at the top of the refrigerator for ease of
installation.
2. If the hinge side of the refrigerator is to be
against a wall, you might want to leave extra
space so the door can be opened wider.
3. The refrigerator can be flush against the wall.
BEFORE USING YOUR REFRIGERATOR
Leveling it
Your refrigerator has 2 front leveling screws-one
on the right and one on the left. To adjust one or
both of these, follow the directions below.
1. Remove base grille. (See page 13.)
2. To raise front, turn screw clockwise.
3. To lower front, turn screw counterclockwise.
4. Check with level.
5. Replace base grille. (See page 13.)
Front
roller
Right to raise;
left to lower
USING YOUR REFRIGERATOR
Using Your Refrigerator
In This Section
Setting the controls
Changing the control settings...........................
Adjusting the door bins
Adjusting the bin/shelf glides
Adjusting the refrigerator shelves
Removing the meat drawer and cover..............
Removing the crispers and crisper cover
Adjusting the crisper humidity control....
In order to obtain the best possible results from your refrigerator, it is important that you operate it
properly. This section will tell you how to do just that.
.........................................
...................................
...........................
....................
Page
......
......
......
......
......
......
....
....
Removing the freezer baskets..........................
7
Using the ice cube trays
8
Using the cptional automatic ice maker...
8
Changing the light bulbe..................................
9
Removing the base grille
9
Reversing the door swing
9
Understanding the sounds you may hear
10
Saving energy.................................................
10
..................................
.................................
................................
Setting the controls
Temperature controls
Controls for the refrigerator and freezer are in the
refrigerator. When the refrigerator is plugged in
for the first time:
1. Set the Refrigerator Control to 3.
Refrigerator Control adjustments range from
1 (warmest) to 5 (coldest).
Page
....
....
....
....
....
....
....
....
11
11
12
13
13
14
14
14
2. Set the Freezer Control to B.
Freezer Control adjustments range from
A (warmest) to C (coldest).
3. Give the refrigerator time to cool down
completely before adding food. This may take
several hours.
The settings indicated above should be
correct for normal, household refrigerator
usage. The controls will be set correctly when
milk or juice is as cold as you like and when
ice cream is firm. If you need to adjust these
settings, see “Changing the control settings”
on page 8.
Exterior moisture control
The Exterior Moisture Control operates electric
heaters around the door openings. These heaters
help keep moisture from forming on the outside
of the refrigerator cabinet.
1. Use the OFF setting when humidity is low.
2. Use the ON setting if moisture forms on the
outside of the refrigerator cabinet.
COLDER C
B
FREEZER
run
EXTERIOR
MOISTURE
CONTROL
USING YOUR REFRIGERATOR
Changing the control settings
If you need to adjust temperatures in refrigerator
or freezer, use the settings listed in the chart
below as a guide. If you have questions, call our
Consumer Assistance Center number. (See
page 21.)
• Adjust the Refrigerator Control first.
• Wait at least 24 hours between adjustments.
• Then adjust the Freezer Control if needed.
CONDITION:
If Refrigerator
Section is
TOO WARM
If Freezer
Section is
TOO WARM
If Refrigerator
Section is
TOO COLD
If ICE isn’t
MADE FAST
ENOUGH
If BOTH
SECTIONS
are TOO WARM
REASON:
Door opened often
Large amount of food added
Room temperature too warm
Door opened often
Large amount of food added Freezer
Very cold room temperature
(can’t cycle often enough)
Controls not set correctly
for your conditions Freezer B
Heavy ice usage Refrigerator 3
Very cold room temperature Freezer
(can’t cycle often enough)
Door opened often Refrigerator 4
Large amount of food added Freezer
Very warm or very cold room
temperatures
Adjusting the door bins
To remove door bins:
1. Lift bin up.
2. Pull bin straight out.
To replace door bins:
1. Slide bin in above desired support button.
2. Push down until it stops.
RECOMMENDED
CONTROL SETTINGS:
Refrigerator 4
Freezer
Refrigerator 3
Refrigerator
B
Between
B and C
2
Between
B and C
Between
B and C
USING YOUR REFRIGERATOR
Adjusting the bin/shelf glides
The bin/shelf glides can be used to secure odd
shaped items or to separate other items.
1. Grasp glide.
2. Slide glide along binArack.
NOTE: Bin glides can be rennoved. Shelf
glides cannot be removed.
Adjusting the refrigerator shelves
Shelves can be adjusted to match the way you
use your refrigerator. Glass shelves are strong
enough to hold bottles, milk and other heavy food
items.
To remove glass shelves:
1. Remove items from shelf.
2. Tilt sheH up at front.
3. Lift back of shelf.
4. Pull shelf straight out.
To replace glass shelves:
1. Guide the rear shelf hooks into the slots in the
shelf supports on cabinet wall.
2. Tilt shelf up at front until hooks drop into slots.
Lower front of shelf to level position.
Glass shelves are heavy.
Be careful.
Removing the meat drawer and cover
To remove the meat drawer:
1. Slide meat drawer out to the stop.
2. Lift front of meat drawer.
3. Slide meat drawer out the rest of the way.
4. Replace in reverse order.
To remove the cover:
1. Tilt front of cover up.
2. Lift back of cover.
3. Pull cover straight out.
4. Replace cover in reverse order.
Pull out to the stop, lift
the front and pull again.
USING YOUR REFRIGERATOR
Removing the crispers and crisper cover
To remove the crispere:
1. Slide the crisper straight out to the stop.
2. Lift the front.
3. Slide out the rest of the way.
4. Replace in reverse order.
To remove the cover:
1. Push up glass insert from the bottom, then
slide it out with both hands.
2. Lift front of cover frame.
3. Pull cover frame up and out.
4. Remove metal cover support.
To replace the cover:
1. Replace metal cover support on wall supports
in front section of cabinet.
2. Fit back corner of cover frame into notch
supports on walls of refrigerator, then lower
front onto metal cover support.
3. Slide back of glass insert into cover frame.
Then lower front to level position.
Remove the
glass insert
Lift front of
cover frame,
then the back.
Pull out to the stop,
lift the front
and pull again.
Adjusting the crisper humidity control
You can control the amount of humidity in the
moisture-sealed crisper.
• The controi can be adjusted to any setting
between LOW and HiGH.
• LOW (open) lets moist air out of the crisper for
best storage of fruits and vegetables with skins.
• HIGH (closed) keeps moist air in the crisper for
best storage of fresh, leafy vegetables.
10
USING YOUR REFRIGERATOR
Removing the freezer baskets
The freezer baskets can be removed for easier
cleaning.
To remove the baskets:
1. Slide basket out to the stop.
2. Lift front of basket slightly.
3. Slide basket out the rest of the way.
To replace the baskets:
1. Place basket on slides in liner wall.
2. Make sure the wire stops on basket clear the
front of the slides.
3. Slide basket in all of the way.
Using the ice cube trays
If cubes are not used, they may shrink. The
moving cold air starts a slow evaporation. The
longer cubes are stored, the smaller they get.
To remove Ice:
1. Hold tray at both ends.
2. Twist slightly.
11
USING YOUR REFRIGERATOR
Using the optional automatic ice maker
If you have an automatic ice maker, or if you pian
to add one iater (Part No. ECKMF-90), there are
a few things you will want to know;
• The ON/OFF lever is a wire signai arm.
Down ... to make ice automaticaiiy.
Up ... to shut off the ice maker.
NOTE: Do not turn ice maker on until it is
connected to the water supply. Instructiona for
• supply.
ice maker water eupply hook up are at
tached to the back of the refrigerator
cabinet.
• The dial or lever on the side of the ice maker
changes the size of the cubes.
• Shake the bin occasionally to keep cubes
separated and to obtain increased storage
capacity.
• It is normal for ice crescents to be attached by
a comer. They will break apart easily.
• You will hear water running when ice maker is
working. You’ll hear ice fall into the bin. Don’t
let these sounds bother you.
• The ice maker will not operate until the freezer
is cold enough to make ice. This can take
overnight.
• Because of new plumbing connections, the first
ice may be discolored or off-flavored. Discard
the first few batches of ice.
• If ice is not being made fast enough and more
ice is needed, turn the Refrigerator Control
toward a higher number. Wait a day and, if
necessary, turn the Freezer Control toward C.
• If you remove the ice bin, raise the signal arm
to shut off the ice maker. When you return the
bin, push it in all the way and lower the signal
arm to the ON position.
• If cubes are stored too long, they may develop
an off-flavor... like stale water. Throw them
away. Ice maker will make new ice. Cubes in
the ice bin can also become smaller by
evaporation.
• Good water quality is important for good ice
quality. It is not recommended that the ice
maker be connected to a softened water
supply. Water softener chemicals, such as salt
from a malfunctioning softener, can damage the
ice maker mold and lead to poor ice quality. If a
softened water supply cannot be avoided, it is
important that the water softener be well
maintained and operating properly.
Raise
signal
arm to
stop ice.
Lower
signal
arm to
start it
12
Changing the light bulbs
^WARNING
Electrical Shock Hazard
Before removing a light bulb, either unplug
the refrigerator or disconnect the electricity
leading to the refrigerator at the main
power supply.
Failure to do so could result in electrical
shock or personal injury.
To change the refrigerator light:
1. Disconnect refrigerator from power supply.
2. Push lightly on the top, center of the light
shield until the notched tab unhooks from the
Control Panel.
3. Pull down on the light shield until the tab
clears the Control Panel.
4. Lift back hooks of light shield out of their slots.
5. Replace with a 40-watt appliance bulb.
6. Replace light shield in reverse order.
7. Reconnect refrigerator to power supply.
To change the freezer light:
1. Disconnect refrigerator from power supply.
2. Push in sides of light shield until they snap
free.
3. Replace with a 25-watt appliance bulb.
4. Snap light shield into place.
5. Reconnect refrigerator to power supply.
USING YOUR REFRIGERATOR
w
NOTE: Not all commercial appliance bulbs will fit
your refrigerator. Be sure to replace a bulb wKh
one of the same size and shape.
Removing the base grille
To remove the grille:
1. Open freezer door.
2. Pull base grille forward to release the support
tabs from the metal clips.
3. Do not remove Tech Sheet fastened behind
the grille.
To replace the grille:
1. Line up grille support tabs with metal clips.
2. Push firmly to snap into place.
3. Close freezer door.
See cleaning instructions for defrost pan and
condenser coils on page 16.
Condenser coils
13
USING YOUR REFRIGERATOR
Reversing the door swing
You can change the hinges on your refrigerator
so the doors open the other way. Refer to the
instruction sheet included with your refrigerator.
Understanding the sounds you may hear
Your new refrigerator may make sounds that your
old one didn't. Because the sounds are new to
you, you might be concerned about them. Don’t
be. Most of the new sounds are normal. Hard
surfaces like the floor, walls and cabinets can
make the sounds seem louder.
The following describes the kinds of sounds
that might be new to you, and what may be
making them.
Slight hum, soft hiss
You may hear the refrigerator’s fan motor and
moving air.
Water sounds
When the refrigerator stops running, you may
hear gurgling in the tubing for a few minutes after
it stops. You may also hear defrost water running
into the defrost water pan.
Ice maker sounds
• trickling water
• thud (clatter of ice)
If your refrigerator has an ice maker, you may
hear buzzing (from the water valve), trickling
water and the clatter of ice dumped into the bin.
Clicking or snapping sounds Running sounds
The thermostat makes a definite click when the
refrigerator stops running. It also makes a sound
when the refrigerator starts. The defrost timer will
click when the defrost cycle starts.
Your refrigerator has a high-efficiency compres
sor and motor. It will run longer than older
designs. It may even seem to run most of the
time.
Saving energy
You can help your refrigerator use less electricity.
• Check door gaskets for a tight seal. Level the
cabinet to be sure of a good seal.
• Clean the condenser coils regularly.
• Open the door as few times as possible. Think
about what you need before you open the door.
Get everything out at one time. Keep food
organized so you won’t have to search for what
you want. Close door as soon as food is
removed.
• Go ahead and fill up the refrigerator, but don’t
overcrowd it so air movement is blocked.
• It is a waste of electricity to set the refrigerator
and freezer to temperatures colder than they
need to be. If ice cream is firm in the freezer
and drinks are as cold as your family likes
them, that’s cold enough.
• Make sure your refrigerator is not next to a heat
source such as a range, water heater, furnace,
radiator or in direct sunlight.
14
CARING FOR YOUR REFRIGERATOR
Caring For Your Refrigerator
In This Section
Cleaning your rsfrigorator
Vacation and moving care
Your refrigerator is built to give you many years of dependable service. However, there are a few things
you can do to help extend its product life. This section will tell you how to clean your refrigerator and
what to do when going on vacation, moving or during a power outage.
...................
...................
.................
Page
.....................
16
Page
17
Cleaning your refrigerator
Both the refrigerator and freezer sections defrost
automatically. But both should be cleaned about
once a month to help prevent odors from building
up. Spills should be wiped up right away.
To clean your refrigerator, turn the Refrigerator
Control to OFF, unplug it, take out all removable
parts and clean the refrigerator according to the
following directions.
PART
Removable parts
(shelves, crisper, etc.)
Outside
Inside walls
(freezer should be
allowed to warm up
so cloth won’t stick)
Door liners and
gaskets
Plastic parts
(covers and panels)
WHAT TO USE
Sponge or cloth with mild
detergent and warm water
Sponge, cloth or paper towel
with mild detergent, warm
water and an appliance wax
(or good auto paste wax)
Sponge, soft cloth or paper
towel with baking soda or
mild detergent and warm
water
Sponge, soft cloth or paper
towel wKh mild detergent
and warm water
Soft, clean sponge or soft,
clean cloth with mild
detergent and warm water
Refrigeration system tubes are located near
the defrost pan and can become hot.
Remove and install defrost pan carefully.
Failure to do so could result in personal
injury.
^WARNING
Personal Injury Hazard
HOW TO CLEAN
• Hand wash, rinse and dry thoroughly.
• Wash outside of cabinet. Do not use
abrasive or harsh cleaners.
• Rinse and dry thoroughly.
• Wax painted metal surfaces at least
twice a year. Apply wax with a clean,
soft cloth. Waxing painted metal
surfaces provides rust protection.
Do not wax plastic parts.
• Wash with mixture of warm water and
- mild detergent, or
- baking soda (2 tablespoons [26 g]
to 1 quart [.95 L] of water).
• Rinse and dry thoroughly.
• Wash, rinse and dry thoroughly.
DO NOT USE cleaning waxes,
concentrated detergents, bleaches or
cleaners containing petroleum on
plastic parts.
• Wash, rinse and dry thoroughly.
DO NOT USE paper towels, window
sprays, scouring cleansers or
flammable fluids. These can scratch
or damage material. See “Important
Safety Instructions" on page 3.
continued on next page
15
CARING FOR YOUR REFRIGERATOR
PART
Defrost pan
(behind refrigerator
on top of motor)
Condenser coils
Floor under
refrigerator
WHAT TO USE
Sponge or cloth wHh
mild detergent and
warm water
Vacuum cleaner with
extended narrow
attachment
Floor cleaners
HOW TO CLEAN
• Remove base grille. (See page 13.)
• To remove defrost pan, lift pan over wire brace
(remove tape; if any).
• Wash, rinse and dry thoroughly.
• Replace wHh notched corner to the rear. Push it
in all the way.
• Make sure defrost pan drain tube is pointing
into pan.
• Replace base grille.
• Remove base grille.
• Vacuum coils when dusty or dirty. Coils may
need to be cleaned as often as every other
month.
• Replace base grille.
• Roll refrigerator out only as far as the water
supply line allows.
• Clean floor.
• Roll refrigerator back into place.
• Check to see if the refrigerator is level.
Vacation and moving care
Long vacations
Remove all the food if you are going for a month
or more, if your refrigerator is equipped with an
automatic ice maker, turn off the water supply to
the ice maker at least one day ahead. When the
last load of ice drops, turn off the ice maker.
Make sure all ice is dispensed out of mechanism.
Unplug the refrigerator. Clean it, rinse well and
dry. Tape rubber or wood blocks to the tops of
both doors to prop them open far enough for air
to get in. This will keep odor and mold from
building up.
^WARNING
Personal Injury Hazard
Do not allow children to climb on, play near
or climb inside the refrigerator when the
doors are blocked open.
They may become injured or trapped.
To restart refrigerator, see ‘Using Your Refrigera
tor" on page 7.
Short vacations
No need to shut off the refrigerator if you will be
away for less than four weeks. Use up perish
ables; freeze other Hems. If you have an
automatic ice maker
1. Turn off your ice maker by raising signal
arm.
2. Shut off the water supply to the ice maker.
3. Empty the ice bin.
Moving
If your refrigerator is equipped wHh an auto
matic ice maker, shut off the ice maker water
supply at least a day ahead. Disconnect the
water line. After the last load of ice drops, lift
the signal arm to turn off the ice maker.
Remove all food. Pack frozen food in dry ice.
Unplug the refrigerator and clean H thoroughly.
Take out all removable parts. Wrap all parts
well and tape them together so they don’t shift
and rattle. Screw in the ieveling legs; tape the
doors shut; and tape the electric cord to the
cabinet.
When you get to your new home, put every
thing back and refer to page 5. Also, if you
have an automatic ice maker, remember to
reconnect the water supply line.
16
CARING FOR YOUR REFRIGERATOR
Power interruptions
If electricity goes off, caii the power company.
Ask how iong power will be off.
1. If service is to be interrupted 24 hours or less,
keep both doors closed. This will help foods
stay frozen.
2. If service is to be interrupted longer than
24 hours:
(a) Remove all frozen food and store in a
frozen food locker.
OR
(b) Place 2 lbs. (0.9 kg) of dry Ice in freezer for
every cubic foot of freezer space. This will
keep food frozen for 2 to 4 days. Wear
gloves to protect your hands from dry Ice
bums.
OR
(c) If neither a food iocker or dry ice is avail
able, use or can perishable food at once.
3. A full freezer will stay cold longer than a partly
filled one. A freezer full of meat will stay cold
longer than a freezer full of baked goods. If
food contains ice crystals, it may be safely
refrozen, although the quality and flavor may
be affected. If the condition of the food is poor
or if you feel it is unsafe, dispose of it.
Questions 7
Call our Consumer Assistance Center telephone
number, 1-800-253-1301.
Food Storage Guide
In This Section
Storirtg fresh food
There is a correct way to package and store refrigerated or frozen food. To keep food fresher, longer,
take the time to study these recommended steps.
.................
Storing fresh food
Food placed in the refrigerator should be
wrapped or stored In air and moisture proof
material. This prevents food odor and taste
transfer throughout the refrigerator. For dated
products, check code date to ensure freshness.
Leafy vegetables
Remove store wrapping and trim or tear off
bruised and discolored areas. Wash in cold water
and drain. Place In plastic bag or piastic con
tainer and store in crisper.
Vegetables with skins (carrots, peppers)
Store in crisper, plastic bags or plastic container.
Page
.....
17 Storing frozen food.
Fruit
Wash, let dry and store in refrigerator in plastic
bags or crisper. Do not wash or huil berries untii
they are ready to use. Sort and keep berries in
their store container in a crisper, or store in a
loosely closed paper bag on a refrigerator shelf.
Eggs
Store without washing in the original carton on
interior shelf.
Milk
Wipe milk cartons. For best storage, place milk
on interior shelf.
Page
.....
IB
17
FOOD STORAGE GUIDE
Butter or margarine
Keep opened butter in covered dish or closed
compartment. When storing an extra supply,
wrap in freezer packaging and freeze.
Cheese
Store in the original wrapping until you are ready
to use it. Once opened, rewrap tightly in plastic
wrap or aluminum foil.
Leftovers
Cover leftovers with plastic wrap or aluminum foil.
Plastic containers with tight lids can also be used.
Meat
Most meat can be stored in original wrapping as
long as it is air and moisture proof. Rewrap if
necessary. See the following chart for storage
times.
Storing frozen food
The freezer section is designed for storage of
commercially frozen food and for freezing food at
home. For further information about preparing
food for freezing, contact your local Cooperative
Extension Service or check a freezer guide or
cookbook.
Packaging
The secret of successful freezing is in the
packaging. The way you close and seal the
package must not allow air or moisture in or out.
Packaging done in any other way could cause
food odor and taste transfer throughout the
refrigerator and drying of frozen food.
Packaging recommended for use:
• Rigid plastic containers with tight-fitting lids
• Straight-sided canning/freezing jars
• Heavy-duty aluminum foil
• Plastic-coated paper
• Non-permeable plastic wraps (made from a
saran film)
Follow package or container instructions for
proper freezing methods.
APPROXIMATE TIME
TYPE
Chicken
Ground beef
Steaks and roasts
Cured meats
Bacon
Cold cuts
Variety meats
*lf meat is to be stored longer than the times
given, follow the directions for freezing.
NOTE: Fresh fish and shellfish should be used
the same day as purchased.
Do not use:
• Bread wrappers
• Non-polyethylene plastic containers
• Containers without tight lids
• Waxed paper
• Waxed-coated freezer wrap
• Thin, semi-permeable wrap
The use of these wrappings could cause food
odor, taste transfer and drying of frozen food.
(DAYS)*
1 to 2
1 to 2
3to5
7to 10
5 to 7
3 to 5
1 to 2
Freezing
Do not expect your freezer to quick-freeze any
large quantity of food. Put no more unfrozen food
into the freezer than will freeze within 24 hours.
(No more than 2 to 3 pounds of food per cubic
foot of freezer space.) Leave enough space for
air to circulate around packages. Be careful to
leave enough room at the front so the door can
close tightly.
18
FOOD STORAGE GUIDE
Freezer food storage chart
Storage times will vary according to the quality of
the food, the type of packaging or wrap used (air
and moisture proof) and the storage temperature
(which should be 0®F [-17.8*C]).
FOOD
Fruita
• Citrus
• Commercially frozen
• Juice concentrates
• Others
Vegetables
• Commercially frozen
• Home frozen
Meats
• Bacon*
• Corned beef*
• Frankfurters
• Ground beef, veal and
lamb
• Roasts;
-Beef
-Lamb & veal
-Pork
• Sausage (fresh)
• Steaks & chops:
-Beef
-Lamb, veal & pork
Fish
• Alaskan king crab
• Blue fish & salmon
• Breaded fish
(purchased)
• Clams, oysters.
cooked fish, crab &
scallops
• Cod, flounder, sole &
haddock
• Mackerel & perch
• Shrimp (uncooked)
PouKty
• Chicken or turkey
(whole or parts)
• Cooked (w/ gravy)
• Duck
• Giblets
• Slices (no gravy)
STORAGE TIME
4 to 6 months
12 months
12 months
8 to 12 months
8 months
8 to 12 months
4 weeks or less
4 weeks or less
1 month
2 to 3 months
6 to 12 months
6 to 9 months
4 to 8 months
1 to 2 months
8 to 12 months
3 to 4 months
10 months
2 to 3 months
3 months
3 to 4 months
6 months
2 to 3 months
12 months
12 months
6 months
6 months
2 to 3 months
1 month
FCX3D STORAGE TIME
Main dishes
• Casseroles (meat. 2 to 3 months
poultry & fish)
• Stews 2 to 3 months
• TV dinners 3 to 6 months
Dairy products
• Butter
• Margarine
• Cheese:**
-Camembert,
Farmer’s &
Mozzarella
-Creamed cottage
-Cheddar, Edam,
Gouda, Swiss,
Brick, etc. 6 to 8 weeks
• Ice cream, ice milk &
sherbet 2 months
6 to 9 months
12 months
3 months
do not freeze
Eggs
• Whole (mixed) 12 months
• Whites 12 months
• Yolks 12 months
NOTE: Add sugar or salt
to yolks or whole mixed
eggs.
Baked goods
• Brown ‘N Serve rolls
(baked)
• Cakes (frosted)
• Cakes (unfrosted)
• Cookies (baked)
• Cookie dough
• Fruitcakes
• Pies (baked)
• Pies dough
• Quick breads
• Unbaked breads
• Yeast breads & rolls
*Salting meat shortens freezer life.
^‘Freezing can change texture of cheese.
Based on U.S.D.A. and Michigan Cooperative
Extension Service suggested storage times.
3 months
8 to 12 months
2 to 4 months
8 to 12 months
3 months
12 months
1 to 2 months
4 to 6 months
2 to 3 months
1 months
3 months
19
IF YOU NEED ASSISTANCE OR SERVICE
If You Need Assistance
Or Service
This section is designed to help you save the cost of a service call. Part 1 of this section outlines
possible problems, their causes, and actions you can take to solve each problem. Parts 2 and 3 tell you
what to do if you still need assistance or service. When calling our Consumer Assistance Center for help
or calling for service, please provide a detailed description of the problem, your appliance's complete
model and serial nurribers and the purchase date. (See page 2.) This information will help us respond
properly to your request.
1. Before calling for assistance ...
Performance problems often result from little things you can find and fix without tools of any kind. Please
check the chart below for problems you can fix. It could save you the cost of a service call.
PROBLEM
Your refrigerator
will not operate
POSSIBLE CAUSE SOLUTION
The power supply cord is not
plugged into a live circuit with
proper voltage.
A household fuse has blown or
circuit breaker tripped.
The Refrigerator Control is not
set correctly.
Firmly plug power cord into a live circuit
with proper voltage. (See page 5.)
Replace household fuse or reset circuit
breaker.
Set Refrigerator Control to a numbered
setting. (See page 7.)
Unfamiliar
sounds or a
rattling/jingling
noise
There is water in
the defrost pan
The lights do
not work
The optional ice
maker will not
operate
The motor
seems to run
too much
There is something on top of or
behind the refrigerator.
The sounds are normal.
This is normal in hot, muggy
weather. The pan may even be
half full.
A household fuse has blown or
circuit breaker tripped.
The power supply cord is not
plugged into a live circuit with
proper voltage.
The bulb is burned out.
The freezer has not had
enough time to get cold.
The signal arm is in the OFF
(up) position.
The water valve is turned off.
Water is not getting to the ice
maker.
The condenser coils are dirty.
It is hot outside or in the room.
The door has been opened
frequently.
A large amount of food has
been put in at one time.
Remove item from on top of or behind
the refrigerator.
New features on your new refrigerator
make new sounds. (See “Understanding
the sounds you may hear” on page 14.)
Make sure the refrigerator is level so the
pan does not overflow.
Replace household fuse or reset circuit
breaker.
Firmly plug power cord into a live circuit
with proper voltage. (See page 5.)
Replace bulb. (See page 13.)
Allow the freezer time to get cold-this
could take overnight.
Push signal arm down to the ON
position. (See page 12.)
Turn the water valve on.
Check the water line for clogs or leaks.
Clean the coils (See page 16.)
On hot days, or if the room is too warm,
the motor naturally runs longer.
Open the door as few times as possible.
The motor will run longer in order to cool
down the interior when food is added.
20
IF YOU NEED ASSISTANCE OR SERVICE
Remember:
Motor running time depends on different things:
number of door openings, amount of food stored,
temperature of the room, setting of controls, etc.
Your new refrigerator may be larger than your
old one so it has more space to be cooled. It also
has a regular freezer instead of a frozen food
compartment. All this means better refrigeration
and may require more running time than your old
one.
2. If you need assistance ...
Call Whirlpool Coneumer Assistance Center
telephone number. Dial free from anywhere in
the U.S.:
1-800-253-1301
and talk with one of our trained consultants. The
consuhant can instruct you in how to obtain
satisfactory operation from your appliance or, if
service is necessary, recommend a qualified
service company in your area.
If you prefer, write to:
Mr. William Clark
Consumer Assistance Representative
Whirlpool Corporation
2000 M-63
Benton Harbor, Ml 49022
Please include a daytime phone number in your
correspondence.
4. If you need FSP* replace
ment parts ...
FSP is a registered trademark of Whirlpool
Corporation for quality parts. Look for this symbol
of quality whenever you need a replacement part
for your Whirlpool appliance. FSP replacement
parts will fit right and work right, because they
are made to the same exacting specifications
used to build every new Whirlpool appliance.
To locate FSP replacement parts in your area,
refer to Step 3 above or call the Whirlpool
Consumer Assistance Center number in Step 2.
5. If you are not satisfied with how the problem was solved ...
• Contact the Major Appliance Consumer Action
Panel (MACAP). MACAP is a group of indepen
dent consumer experts that voices consumer
views at the highest levels of the major appli
ance industry.
• Contact MACAP only when the dealer, author
ized servicer and Whirlpool have failed to
resolve your problem.
Major Appliance Consumer Action Panel
20 North Wacker Drive
Chicago, IL 60606
• MACAP will in turn inform us of your action.
3. If you need service ...
Whirlpool has a nationwide
network of authorized
^Whirlpool®“servicecompa-
nies. Whirlpool senrice
fulfill the product warranty and provide after
warranty service, anywhere in the United States.
To locate the authorized Whirlpool service
company in your area, call our Consumer
Assistance Center telephone number (see
Step 2) or look in your telephone directory Yellow
Pages under:
•APPUANCE-HOUSEHOLD-
MAJOR, SERVICE S REPAIR
- SasL* WNrtpool Applancas or
Authorized Whirlpool Service
(Exarniplis.'XYZ Service Co.)
technicians are trained to
•WASHINQ MACHINES A
DRYERS, SERVICE A REPAIR
- 5ml* WNrIpool Applances or
Authorized Whirlpool Service
(Examph: XYZ Service Co.)
21
22
23
WHIRLPOOL*
Refrigerator Warranty
LENGTH OF WARRANTY
FULL ONE-YEAR WARRANTY
From Date of Purchase
FULL FIVE-YEAR
WARRANTY
From Date of Purchase
WHIRLPOOL WILL NOT PAY FOR
A. Sen/ice calls to:
1. Correct the Installation of the refrigerator.
2. Instruct you how to use the refrigerator.
3. Replace house fuses or correct house wiring or plumbing.
4. Replace light bulbs.
B. Repairs when refrigerator is used in other than normal, single-family household use.
C. Pickup and delivery. This product is designed to be repaired in the home.
D. Damage to refrigerator caused by accident, misuse, fire, flood, acts of God or use of products not
approved by Whirlpool.
E. Any food loss due to product failure.
F. Repairs to parts or systems caused by unauthorized modifications made to the appliance.
WHIRLPOOL WILL PAY FOR
FSP* replacement parts and repair labor to correct defects in
materials or workmanship. Service must be provided by an
authorized Whirlpool®“ service company.
FSP replacement parts and repair labor to correct defects in
materials or workmanship in the sealed refrigeration system.
These parts are:
1. Compressor
2. Evaporator
3. Condenser
4. Drier
5. Connecting tubing
Service must be provided by an authorized Whirlpool®“ service
company.
8-92
WHIRLPOOL CORPORATION SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES. Some states do not allow the exclusion or limitation of incidental or consequential damages,
so this limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state.
Outside the United States, a different warranty may apply. For details, please contact your
authorized Whirlpool distributor or military exchange.
If you need service, first see the “Assistance or Service" section of this book. After checking
“Assistance or Service," additional help can be found by calling our Consumer Assistance Center
telephone number, 1-800-253-1301, from anywhere in the U.S.
PART NO. 2160158 Rev. A
01992 WNrIpool Corporation • Rogislored Trademark / SM Service Mark of Whirtpoot Corporation.
Printed In U.SA
Loading...
