AMW 523
1
AMW 5023
INSTALLATION, QUICK START
INSTALLATIE, SNEL AAN DE SLAG
INSTALLATION, HURTIG START
INSTALLASJON, RASK INNFØRING
ASENNUS, PIKAOPAS
ÜZEMBE HELYEZÉS, RÖVID
KEZDÉSI ÚTMUTATÓ
INSTALACE, NÁVOD VE ZKRATCE
INSTALACJA, SKRÓCONA
INSTRUKCJA OBSŁUGI
,
INŠTALÁCIA, ÚVODNÁ PRÍRUČKA
INSTALLATION, DÉMARRAGE RAPIDE
AUFSTELLUNG, KURZANLEITUNG
INSTALLAZIONE, GUIDA RAPIDA
INICIO RÁPIDO PARA LA INSTALACIÓN
INSTALAÇÃO, GUIA DE INICIAÇÃO RÁPIDA
INSTALLATION, SNABBGUIDE
AMW 523 AMW 558
2
INSTALLATION
PRIOR TO CONNECTING
E
NSURE THAT THE APPLIANCE IS NOT DAMAGED. Check
that the oven door closes firmly against the
door support and that the internal door seal is
not damaged. Empty the oven and clean the
interior with a soft, damp cloth.
AFTER CONNECTING
T
HE EARTHING OF THIS APPLIANCE is compulsory. The
manufacturer will accept no responsibility for
injury to persons, animals or damage to objects arising from the non-observance of this
requirement.
The manufacturers are not liable for any
problems caused by the user’s failure to observe these instructions.
D
O NOT OPERATE THIS APPLIANCE if it has a damaged
mains cord or plug, if it is not working properly, or if it has been damaged or dropped. Do
not immerse the mains cord or plug in water.
Keep the cord away from hot surfaces. Electrical shock, fire or other hazards may result.
D
O NOT REMOVE THE MICROWAVE INLET PROTECTION
PLATES located on the side of
the oven cavity wall. They
prevent grease & food particles from entering the microwave inlet channels.
E
NSURE the oven cavity is
empty before mounting.
CHECK THAT THE VOLTAGE on the rating plate corre-
sponds to the voltage in your home.
T
HE OVEN CAN BE OPERATED ONLY if the oven door is
firmly closed.
MOUNTING THE APPLIANCE
FOLLOW THE SUPPLIED separate mounting instructions when installing the appliance.
DO NOT USE EXTENSION CORD:
I
F THE POWER SUPPLY CORD IS TOO SHORT, have a
qualified electrician or serviceman install
an outlet near the appliance.
3
IMPORTANT SAFETY INSTRUCTIONS
DO NOT HEAT, OR USE FLAMMABLE MATERIALS in or
near the oven. Fumes can create a fire hazard
or explosion.
D
O NOT USE YOUR MICROWAVE oven for drying
textiles, paper, spices, herbs, wood, flowers,
fruit or other combustible materials. Fire could
result.
D
O NOT OVER-COO K FOOD. Fire could result.
D
O NOT LEAVE THE OVEN UNATTENDED, especially
when using paper, plastic or other combustible
materials in the cooking process. Paper can
char or burn and some plastics can melt if used
when heating foods.
I
F MATERIAL INSIDE / OUTSIDE THE OVEN SHOULD IGNITE
OR SMOKE IS OBSERVED, keep oven door closed and
turn the oven off. Disconnect the power cord
or shut off power at the fuse or circuit breaker
panel.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
D
O NOT USE YOUR MICROWAVE oven
for heating anything in airtight
sealed containers. The
pressure increases and may
cause damage when opening or may explode.
EGGS
D
O NOT USE YOU R MICROWAVE oven for cooking
or reheating whole eggs with or
without shell since they may
explode even after microwave
heating has ended.
I
F THE MAINS CORD NEEDS REPLACING it should be
replaced by the original mains cord, which is
available via our service organization.
The mains cord may only be replaced
by a trained service technician.
D
O NOT USE corrosive chemicals or vapors in
this appliance. This type of oven is specifically
designed to heat or cook food. It is not
designed for industrial or laboratory use.
T
HE APPLIANCE AND ITS ACCESSIB LE PARTS MAY BECOME
HOT during use.
CARE SHOULD BE TAK EN to avoid touching heating
elements.
CHILDREN LESS THAN 8 YEARS OF AGE shall be kept
away unless continuosly supervised.
S
ERVICE ONLY TO BE CARRIED OUT BY A TRAINED
SERVICE TECHNICIAN. It is hazardous for
anyone other than a trained person to
carry out any service or repair operation,
which involves the removal of any cover,
which gives protection against exposure to
microwave energy.
DO NOT REMOVE ANY COVER.
WARNING!
THE DOOR SEALS AND THE DOOR SEAL AREAS must
be regularly inspected for damage. If these
areas are damaged the appliance should not
be operated until it has been repaired by a
trained service technician.
T
HIS APPLIANCE CAN BE USED by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved.
U
SE, CLEANING AND USER MAINTENANCE shall not be
made by children unless they are aged from 8
years and above and supervised.
C
HILDREN SHALL NOT PLAY with the appliance.
4
THE APPLIANCE SHOULD NOT BE OPERATED without food
in the oven when using microwaves. Operation in
this manner is likely to damage the appliance.
I
F YOU PRACT ICE OPERATING the oven, put a glass
of water inside. The water will absorb the microwave energy and the oven will not be damaged.
REMOVE WIRE TWIST-TIES from paper or
plastic bags before placing bag in
the oven.
DEEPFRYING
D
O NOT USE YOUR MICROWAVE oven for deep-frying,
because the oil temperature cannot be
controlled.
LIQUIDS
E.
G. BEVERAGES OR WATER. Overheating the liquid
beyond boiling point can occur
without evidence of bubbling.
This could result in a sudden
boil over of the hot liquid.
To prevent this possibility the
following steps should be taken:
1. Avoid using straight-sided containers with
narrow necks.
2. Stir the liquid before placing the container
in the oven and let the teaspoon remain
in the container.
3. After heating, allow standing for a short
time, stirring again before carefully removing the container from the oven.
CAREFUL
A
LWAYS REFER to a microwave cookbook for de-
tails. Especially, if cooking or reheating food
that contains alcohol.
A
FTER HEATING BABY FOOD or liquids in a
baby bottle or in a baby food
jar, always stir and check the
temperature before serving.
This will ensure that the heat is evenly distributed
and the risk of scalding or burns can be avoided.
Ensure the Lid and the Teat is removed before heating!
U
SE HOT PADS OR OVEN MITTS to prevent burns,
when touching containers, oven parts, and
pan after cooking.
D
O NOT USE THE CAVITY for any storage purposes.
PUSH PUSH KNOBS
T
HE KNOBS OF THIS OVEN are
aligned with the buttons on
the panel, at delivery.
The knobs will slide out if pushed
and their various functions can be
accessed. It is not necessary to
have them petruding from the
panel during operation.
Simply push them back into the panel
when you are done with the setting and continue to operate the oven.
LIQUID
S
GENERAL
T
HIS APPLIANCE IS DESIGNED FOR DOMESTIC USE ONLY!
IMPORTANT PRECAUTIONS
THIS APPLIANCE IS INTENDED for heating food and
beverages. Drying of food or clothing and
heating of warming pads, slippers, sponges,
damp cloth and similar may lead to risk of
injury, ignition or fire.
T
HIS APPLIANCE IS INTENDED to be used built-in. Do
not use it freestanding.
5
ACCESSORIES
GENERAL
I
F ACCESSOR IES CONTAIN ING METAL comes in contact
with the oven interior, while the oven is in operation, sparking can occur and the oven could
be damaged.
TURNTABLE SUPPORT
USE THE TURNTABLE SUPPORT under the
Glass turntable. Never put any other utensils on the turntable support.
Fit the turntable support in the oven.
GLASS TURNTABLE
U
SE THE GLASS TURNTABLE with all cooking meth-
ods. It collects the dripping juices and food particles that otherwise would stain and soil the interior of the oven.
Place the Glass turntable on the turntable
support.
E
NSURE THAT THE UTENSILS YOU USE are oven proof
and allow microwaves to
pass through them before
cooking.
W
HEN YOU PUT FOOD AND ACCE SSORIES in the micro-
wave oven, ensure that they do not come in
contact with the interior of the oven.
This is especially important with accessories made of metal or metal parts.
A
LWAYS ENSURE that the turntable is able to turn
freely before starting the oven.
CRISP HANDLE
U
SE THE SUPPLIED SPECIAL CRISP HAN-
DLE to remove the hot Crisp plate
from the oven.
CRISP-PLATE
P
LACE THE FOOD DIRECTLY ON THE CRISP-PLATE.
Always use the Glass turntable as support when using the Crisp-plate.
DO NOT PLACE ANY UTENSILS on the
Crisp-plate since it will quickly become very hot and is likely to cause
damage to the utensil.
T
HE CRISP-PLATE may be preheated before use
(max. 3 min..). Always use the Crisp function
when preheating the crisp-plate.
T
HERE ARE a number of accessories available on
the market. Before you buy, ensure they are
suitable for microwave use.
WIRE RACK
U
SE THE WIRE RACK when cooking
and baking.
START PROTECTION / KEY LOCK
THIS AUTOMATIC SAFETY FU NCTION IS ACTIVATED ONE
MINUTE AFTER the oven has returned to
“stand by mode“. (The oven is in
“stand by” when the 24-hour clock is
displayed or if the clock has not been
set, when the display is blank).
THE DOOR MUST BE OPENED AND CLOSED e.g. putting
food into it, before the safety lock is released.
Else the display will show “DOOR”.
W
HEN GRILLING WITHOUT MICRO-
WAVES, place the wire rack
on the baking plate in order to elevate the food
closer to the grill element
in the ceiling.
BAKING PLATE
USE THE BAKINGPLATE when
cooking in forced air only
or when grilling. Never use
it in combination with microwaves.
6
DONENESS (AUTO FUNCTIONS ONLY)
D
ONENESS IS AVAILA BLE in most of the auto func-
tions. You have the possibility to personally
control the end result through the Adjust doneness feature. This feature enables you to
achieve higher or lower end temperature compared to the default standard setting.
WHEN USING one of these functions the oven
chooses the default standard setting. This setting normally gives you the best result. But if
the food you heated became too warm to eat
at once, you can easily adjust this before you
use that function the next time.
N
OTE:
THE DONENESS can only be set or altered during
the first 20 seconds of operation.
W
HEN USING SOME OF THE AUTO FUNCTIONS the oven
may stop (depending on the chosen program
and food class) and prompt you to STIR FOOD
or TURN FOOD.
STIR OR TURN FOOD (AUTO FUNC TIONS ONLY)
T
HIS IS DONE BY SELECTING A DONENESS LEVEL with the
adjust knob right after you have pressed the
Start button.
N
OTE: IN AUTO DEFROST MODE, THE OVEN CONTIN -
UES AUTOMATIC ALLY AFTER 2 MIN. if the food hasn’t
been turned / stirred. The defrost time will be
longer in this case.
T
O CONTIN UE COOKIN G:
Open the door.
Stir or turn the food.
Close the door and restart by pressing the
Start button.
DONENESS
L
EVEL EFFECT
HIGH +2 YIELDS HIGHEST END TEMPERATURE
HIGH +1 YIELDS HIGHER END TEMPERATURE
MED 0 DEFAULT STANDARD SETTING
LOW -1 YIELDS LOWER END TEMPERATURE
LOW -2 YIELDS LOWEST END TEMPERATURE
7
FOOD
TRY POUL (100g -
(100g - 2.0Kg) MEAT
WHEN USING THE AUTO FUNCTIONS the oven needs
to know which food class it is to use to reach
proper results. The word FOOD and a food
class digit is displayed when you are choosing
a food class with the adjust knob.
COOLING DOWN
WHEN A FUNCTION IS FIN ISHED, the oven may carry
out a cooling procedure. This is normal.
After this procedure the oven switches off automatically.
IF THE TEMPERATURE IS HIGHER THAN 100°C, “HOT”
and the current cavity temperature is displayed. Be careful not to touch the cavity inside when removing food. Use oven mittens.
IF THE TEMPERATURE IS LESS THAN 50°C, the 24 hour
clock is displayed.
PRESS THE BACK BUTTON to temporarily
view the 24 hour clock when “HOT” is
displayed.
THE COOLING PROCEDU RE can be interrupted without any harm to the oven
by opening the door.
FOOD CLASSES (AUTO FUNC TIONS ONLY)
F
OR FOOD NOT LISTED IN THE TABL ES and if the
weight is lesser or greater than recommended
weights, you should follow the procedure for
”Cook & Reheat with microwaves”.
T
HE FOOD CLASSES are listed in the tables placed
with each Auto function.
8
CLOCK SETTING
W
HEN THE APPLIANCE IS FIRST PLUGGED
IN it will ask you to set the Clock.
AFTER A POWER FAILUR E the Clock will
flash and needs to be reset.
YOUR OVEN HAS a number of functions which can be adjusted to
your personal taste.
CHANGING SETTINGS
TURN THE MULTIFUNCTION KNOB until Setting is shown.
USE THE ADJUST KNOB to choose one of the following settings to adjust.
Clock
Sound
ECO
Brightness
PRESS THE STOP BUTTON TO EXIT the settings function and save
all your changes when you are done.
PRESS THE OK BUTTON . (The left right hand digits (hours) flicker).
TURN THE ADJUST KNOB to set the hours.
PRESS THE OK BUTTON. (The two right hand digits (minutes) flicker).
TURN THE ADJUST KNOB to set the minutes.
PRESS THE OK BUTTON again to confirm the change.
T
HE CLOCK IS SET AND IN OPERATION.
IF YOU WISH TO REMOVE THE CLOCK from the display once it has been set,
simply enter the clock setting mode again and press the Stop button while the digits flicker.
9
SOUND SETTING
PRESS THE OK BUTTON .
TURN THE ADJUST KNOB to turn the buzzer ON or OFF.
PRESS THE OK BUTTON again to confirm the change.
ECO
PRESS THE OK BUTTON .
TURN THE ADJUST KNOB to turn the ECO setting ON or OFF.
PRESS THE OK BUTTON again to confirm the change.
W
HEN ECO IS ON, the display will automatically turn off after a while
to save energy. It will automatically light up again when a button is
pressed or the door is opened.
WHEN OFF IS SET, the display will not turn off and the 24 h clock will
always be visible.
CHANGING SETTINGS
10
USE THIS FUNCTION when you need
a kitchen timer to measure exact
time for various purposes such
as cooking eggs or letting the
dough rise before baking etc.
KITCHEN TIMER
TURN THE ADJUST KNOB to set the desired length of the timer.
PRESS THE OK BUTTON .
A
N ACOUSTI C SIGNAL will be heard when the timer has finished to
count down.
PRESSING THE STOP BUTTON before the timer has finished will reset the
timer to zero.
CHANGING SETTINGS
BRIGHTNESS
PRESS THE OK BUTTON .
TURN THE ADJUST KNOB to set the level of brightness suitable to your preference.
PRESS THE OK BUTTON again to confirm your selection.
LANGUAGE
PRESS THE OK BUTTON .
TURN THE ADJUST KNOB to choose one of the available languages.
PRESS THE OK BUTTON again to confirm the change.
Loading...
