Whirlpool AKZ 398 WH PROGRAM CHART
3gb66015.fm5 Page 1 Monday, March 11, 2002 4:00 PM
AKZ 398 PRODUCT DESCRIPTION SHEET
FR
First......Last: shelf positions
1.
Control panel
2.
Cooling fan* (not visible)
3.
Top heating element
4.
Last
First
Catalyst
5.
Oven light
6.
Seat for turnspit
7.
Fan
8.
Round heating element (not visible)
9.
Bottom heating element (not visible)
10.
Door hinge
11.
Oven cool door
ACCESSORIES
Grid
Baking tray
Turnspit
OVEN FUNCTIONS TABLE
Function
symbol
OVEN OFF -
OVEN LIGHT -
Function
DEFROSTING -
FAN 200 °C
STATIC 225 °C
TURBOGRILL
(Grill + Fan)
GRILL 3
GRILL + TURNSPIT 3
BOOSTER 225 °C
Preset
temperature/
level
3
*N.B.:
After the oven switches off, the
cooling fan may, however, continue to
run for a certain time to ensure proper
cooling.
Function description
(see details in the users manual)
-
To switch on the oven light.
To defrost.
To cook on more than one shelf level, at
the same temperature.
To cook food at one shelf level.
Preheating.
To grill large pieces of meat.
To grill small pieces of meat, toasts, etc.
To cook roast meats, poultry.
For fast preheating of the oven.
5019 310 66015
ECONOMIC SELF
CLEANING
SELF CLEANING -
-
For self cleaning with fixed time of 1h 30.
For self cleaning.
Time can be adjusted.
3gb66015.fm5 Page 2 Monday, March 11, 2002 4:00 PM
1. Selector knob: to choose the oven functions.
2. Knob to set: time of day, cooking time, the time at which cooking should terminate,
the temperatures and the power levels.
3. Button to select and confirm the different operations (operate by single presses only).
4. Button to select special Keeping Warm function.
SWITCHING ON THE OVEN
When the oven is connected to the power supply for the first time, or re-connected after a
power failure, the display shows .
To start the oven:
turn knob 1 with index at the top.
press button 2.
Attention: When the temperature inside the oven is more than about 320°C, the door is
locked for safety reasons, during both pyrolysis and cooking. It is also locked when the oven
is first switched on, to position the mechanism correctly.
FOR A DESCRIPTION ON HOW TO USE THE OVEN, PLEASE REFER TO THE PROGRAMMER
DESCRIPTION SHEET.
IMPORTANT
CAUTION
This oven model is fitted with a stay-cool door. Nevertheless, when the self-cleaning
function is in operation, some parts of the appliance can become very hot: children must
be kept away.
Do not line your oven with aluminium foil: the resultant build-up of heat could impair cooking.
When the self-cleaning function is in operation, all non enamelled accessories, must be removed
from the oven. The stay-cool door means that the temperature on the front glass panel will be
about 40 °C when the temperature inside the oven is 200 °C.
Since this temperature on the front of the appliance is only a little higher than the temperature
of the human body it ensures total user safety.
This type of door also substantially reduces the temperature on the front of the appliance when
the self-cleaning function is in operation (a reduction of about 40% compared with a
conventional door). Nevertheless, the oven temperatures reached during operation of this
function mean that children must be supervised with particular care.
