Page 1
®
TWO SPEED
AUTOMATIC WASHERS
Use & Care Guide
Table of Contents.................................................................2
8315977A
Models: 3RGSC9455, 3RLBR8543,
3SLSQ7533, 3RLSQ8533
Page 2
TABLE OF CONTENTS
WASHER SAFETY ...................................................................... 3
PARTS AND FEATURES............................................................ 4
WASHER USE............................................................................. 5
Understanding Washer Cycles ....................................................5
Loading.........................................................................................5
Normal Washer Sounds...............................................................5
Starting Your Washer...................................................................6
Selecting a Cycle and Time .........................................................7
Rinse and Spin.............................................................................8
Drain and Spin..............................................................................8
Adding Liquid Chlorine Bleach ....................................................8
Adding Liquid Fabric Softener.....................................................8
Self-Cleaning Lint Filter................................................................8
WASHER CARE......................................................................... 8
Cleaning Your Washer .................................................................8
Water Inlet Hoses.........................................................................8
Vacation, Storage and Moving Care............................................9
TROUBLESHOOTING................................................................. 9
ASSISTANCE OR SERVICE..................................................... 11
2
Page 3
WASHER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all
safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or
“WARNING.” These words mean:
You can be killed or seriously injured if you don't
immediately follow instructions.
You can be killed or seriously injured if you don't
follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you
what can
happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
precautions, including the following:
■
Read all instructions before using the washer.
■
Do not wash articles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry-cleaning solvents, other flammable,
or explosive substances as they give off vapors
that could ignite or explode.
■
Do not add gasoline, dry-cleaning solvents, or
other flammable, or explosive substances to the
wash water. These substances give off vapors
that could ignite or explode.
■
Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for 2 weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not
been used for such a period, before using the
washing machine, turn on all hot water faucets
and let the water flow from each for several
minutes. This will release any accumulated
hydrogen gas. As the gas is flammable, do not
smoke or use an open flame during this time.
To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic
■
Do not allow children to play on or in the washer. Close
supervision of children is necessary when the washer is
used near children.
■
Before the washer is removed from service or
discarded,
remove the door or lid.
■
Do not reach into the washer if the drum, tub or agitator
is moving.
■
Do not install or store the washer where it will be
exposed to the weather.
■
Do not tamper with controls.
■
Do not repair or replace any part of the washer or
attempt any servicing unless specifically recommended
in this Use and Care Guide or in published user-repair
instructions that you understand and have the skills to
carry out.
■
See Installation Instructions for grounding requirements.
■
If the supply cord is damaged, it must be replaced by
the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
SAVE THESE INSTRUCTIONS
3
Page 4
PARTS AND FEATURES
This manual covers several different models. The washer you have purchased may have some or all of the parts and features listed
below.
1. Control panel
2. Model and serial number label
3. Liquid fabric softener dispenser
4. Agitator
5. Lid
6. Liquid chlorine bleach dispenser
7. Basket
8. Tub
Control panel
Other features your washer may have
Self cleaning lint filter
†
†
CLEANTOUCH™ control panel
XTRA ROLL ACTION™ PLUS agitator
DURASMOOTH™ white porcelain basket
Extra rinse selector
†
On some models
4
Page 5
WASHER USE
Understanding Washer Cycles
When the Cycle Control knob is set to a number and pulled out,
the washer fills (to the selected load size) before agitation and
timing start. The washer begins agit ating imm ediately aft er filling;
agitation occurs with the washer lid down.
During agitation, the ag itato r cr e ates a co ntinuo us r ollo ver ac tion
(on some models) that provides a thorough cleaning of the wash
load.
Loading
For rated load capacity, refer to the model and serial label/plate,
located on your washer as shown in “Parts and Features.”
Loading suggestions
For these suggested full-sized loads, set t he LOA D SI ZE selecto r
to the highest load size setting.
SUPER CAPACITY PLUS W ASHER S
Heavy Work Clothes
3 pair pants
3 shirts
4 pair jeans
1 coverall
1 overall
After agitation starts, the Cycle Control knob turns clockwise until
it points to an OFF area and the cycle ends.
NOTE: The washer pauses briefly throughout each cycle. These
pauses are normal for washer operation.
WASH RINSE
1. Fill 1. Fill
2. Wash
selected
time
3. Drain
No agitation
4. Spin 4. Spin-Spray
†
2. Rinse
3. Drain
No agitation
rinse
5. Spin
Delicates
3 camisoles
1 quilted robe
4 slips
4 panties
Towels
10 bath towels
10 hand towels
Mixed Load
3 double sheets
4 pillowcases
8 T-shirts
6 pair shorts
EXTRA LARGE CAPACITY WA SHERS
Heavy Work Clothes
2 pair pants
3 shirts
Delicates
3 camisoles
4 slips
4 panties
Towels
8 bath towels
8 hand towels
Mixed Load
2 double sheets or
1 king size sheet(s)
4 pillowcases
6 T-shirts
2 bras
2 nighties
1 baby’s dress
14 wash cloths
1 bath mat
2 shirts
2 blouses
8 handkerchiefs
3 pair jeans
1 coverall
2 bras
2 nighties
10 wash cloths
1 bath mat
6 pair shorts
2 shirts
2 blouses
6 handkerchiefs
†
The Synthetics/Permanent
Press cycle partially drains ,
fills, agitates briefly, and
drains.
6. Off
Normal Washer Sounds
Your new washer may make sounds your old one di dn’ t. Because
the sounds might be unfamiliar, you may be concerned about
them. These sounds are normal.
During washing
When you select a small load size setting, your washer has a
lower water level. This can cause a clicking sound from the upper
part of the agitator.
During drain
If water is drained quickly from your washer (depending on your
installation), you may hear air being pulled through the pump
during the end of draining.
After drain and before spin
When the cycle changes from draining to spinning, you may hear
gears engaging.
5
Page 6
Starting Your Washer
Fire Hazard
Never place items in the washer that are
dampened with gasoline or other flammable
fluids.
No washer can completely remove oil.
Do not dry anything that has ever had any type of
oil on it (including cooking oils).
Doing so can result in death, explosion, or fire.
WARNING
■ Load evenly to maintain washer balance. Mix large and small
items.
■ Items should move easily through the wash water.
Overloading can cause poor cleaning.
■ To reduce wrinkling of permanent press clothes and some
synthetic knits, use a large load size to provide more space
(see step 5).
2. (OPTIONAL) Pour measured liquid chlorine bleach into the
liquid chlorine bleach dispenser (on some models). Bleach
will be diluted automatically during the wash part of the cycle.
■ Never use more than 1 cup (250 mL) for a full load. Use
less with a smaller load size.
■ Follow the manufacturer’s directions for safe use.
■ To avoid spilling, use a cup with a pouring spout. Do not
let bleach splash, drip, or run down into the washer
basket.
■ Use only liquid chlorine bleach in this dispenser.
NOTE: On models without a bleach dispenser, see “Adding
Liquid Chlorine Bleach.”
3. (OPTIONAL) Pour measured liquid fabric softener into the
liquid fabric softe ner disp enser (o n some mode ls). Sof tener is
added automatically during the rinse portion of the cycle.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in
death, fire, or electrical shock.
1. Measure deter ge nt and po ur it into th e washer. If desired, add
powdered or liquid color safe bleach. Add extra detergent for
the Super Wash cycle.
Drop a sorted load of clothes loosely into your washer.
Dilute liquid fabric softener by filling the dispenser with warm
water until liquid reaches the crossbar in the opening.
■ Do not spill or drip any fabric softener on the clothes.
■ Use only liquid fabric softener in this dispenser.
NOTE: On models without a fabric softener dispenser, see
“Adding Liquid Fabric Softener.”
4. Close the washer lid.
5. Turn the LOAD SIZE selector to the correct setting for your
wash load and the type of fabric being washed.
■ Choose a load size that allows the load to mo ve fr e ely for
best fabric care. See "Loading".
■ You may change the load size selection after the washer
has started filling by turning the selector to a different
setting.
6
Page 7
6. Set the TEMPERATURE selector to the corr e ct setti n g for the
type of fabric and soils bein g washed. Use the war mest water
safe for fabric. Follow garment label instructions.
Your washer uses automatic temperature control (on some
models) to maintain a uniform water temperature by
regulating the incoming hot and cold water. This helps
eliminate undissolved deterg ent and ensures consistent
cleaning results. The cold wash is regulated at appr oximately
75°F (24°C) by adding small amounts of hot water during the
cold fill. The warm wash is maintained at approximately
100°F (38°C).
NOTE: Make sure that both the hot and cold water taps are
fully turned on or the automatic temperature control feature
will not work properly.
Water Temp Use For
Hot
111°F (44°C)
or above
Warm
90°-110°F
(32°-43°C)
Whites and pastels
Heavy and greasy soils
Bright colors
Moderate to light soils
Adding softener to models without a fabric softener
dispenser
If desired, add measured liquid fabric softener to the final rinse
water. Always dilute fabric softener with ¹⁄₂ to 1 cup (125 to
250 mL) cup of warm water. Undiluted fabric softener can stain
fabrics. (See “Adding Liquid Fabric Softener.”)
Selecting a Cycle and Time
This section describes the available wash cycles and will help
you make the best cycle selections for your wash loads. Each
cycle is designed for different types of fabric and soil levels.
■ The washer pauses briefly throughout each cycle. These
pauses are normal. Refer to “Normal Washer Sounds” to
learn more about the sounds you may hear during a wash
cycle.
■ Refer to “Understanding Washer Cycles” to learn what
happens during a wash cycle.
NOTE: This manual covers several different washer models. The
washer you have purchased will not have all of the cycles
described.
Cold
70°-90°F
(21°-32°C)
NOTE: In wash water temperatures colder than 70ºF
(21ºC), detergents do not dissolve well. Soils can be difficult
to remove. Some fabrics can retain wear wrinkles and have
increased pilling (the formation of small lint-like balls on the
surface of garments).
7. (OPTIONAL) Some models have an EXTRA RINSE selector.
For an additional rinse and spin at the end of a wash cycle,
set the EXTRA RINSE selector to ON. On some models, the
Extra Rinse feature is part of the cycle.
8. (OPTIONAL ) Some models have an E ND OF CY CLE SIGNAL
selector. Set the END OF CYCLE SIGNAL selector to ON if
you want your washer to alert you when the wash cycle is
complete. The signal is helpful when you are washing items
that should be rem oved from the washer as so on as the cycle
ends.
9. Push in the Cycle Control knob and turn it clockwise to the
wash cycle you want. Reduce the wash time when using a
small load size setting. See “Selecting a Cycle and Time.”
Pull out the Cycle Control knob to start the washer.
To stop or restart your washer
■ To stop the was her at an y time , push in t he Cycle Control
knob.
■ To restart the washer, close the lid (if open) and pull out
the Cycle Control knob.
Colors that bleed or fade
Light soils
Adding bleach to models without a bleach dispenser
If desired, add measured liquid chlorine bleach after the washer
starts agitating. Pour diluted bleach around the agitator, not
directly on the load. Undiluted bleach will damage any fabric it
touches. (See “Adding Liquid Chlorine Bleach.”)
Heavy cycle
This cycle features hig h-speed agita tion followed by b rief perio ds
of low-speed agitation for cleaning sturdy fabrics and heavily
soiled loads that need maximum soil remova l. Select Super Wa sh
or Regular depending on whether your load is moderately or
heavily soiled. For improved cleaning, use twice the amount of
detergent recommended for a wash cycle. The Heavy cycle
features Extra Rinse as part of the cycle.
Cotton cycle
This cycle features high-speed agitation followed by a brief
period of low-speed agitation for cleaning cottons and linens.
High spin speeds shorten drying time. Select 6 to 15 minutes of
wash time, depending on your model, for loads that are
moderately or heavily soiled. For lightly soiled loads, use the
shortest time setting.
Super Wash - Select the Super Wash setting to wash heavily
soiled loads that need maximum soil removal. Use twice the
amount of detergent recommended for a wash cycle.
Synthetics/Permanent Press cycle
This cycle starts with high-speed agitation and then steps down
to low-speed agitation for cleaning permanent press blends and
synthetic fabrics. To minimize wrinkling, this cycle features a
cool-down rinse and a low-speed final spin. Select 6 to 10
minutes of wash time, depending on your model, to clean lightly
to moderately soiled loads.
Delicates cycle
This cycle features low-speed agitation for gentle soil removal
from delicate items and washable knits. Low spin speeds
minimize wrinkling. Select 3 to 9 minutes of wash time,
depending on your model, to clean lightly to moderately soiled
loads.
7
Page 8
Hand Washables cycle
This cycle features a series of brief, low-speed agitations and
short soaks to gently clean special-care items. Low spin speeds
minimize wrinkling. Wash small loads. If items appear to be
floating (due to trapped air), stop the washer by pushing in the
Cycle Control knob. Push items down into the washer. Restart
the washer.
Quic k W a s h c ycle
This cycle features low-speed agitation for gentle soil removal,
while providing high spin speeds to shorten drying times. Select
this cycle for small loads of lightly soiled items that you need in a
hurry.
Soak cycle
This cycle features brief periods of agitation and soak time to
remove heavy soils an d stain s that need pretreatment. Use warm
water when soaking laundry. Hot water can set stains. Use the
amount of detergent or presoak additive recommended by the
manufacturer. When the Soak cycle ends, add detergent and
start a new wash cycle.
Prewash cycle
This cycle features a brief period of high-speed agitation to help
remove heavy soils an d stains that need pr etreatment. Use warm
water for prewashing stained laundry. Hot water can set some
stains. After the P r ewa sh cycle ends, add det ergent and select a
new wash cycle.
Adding Liquid Fabric Softener
Always dilute fabric softener with ½ to 1 cup (125 to 250 mL)
warm water. Undiluted fabric softener can stain fabrics.
■ Add diluted fabric softener only in the final rinse.
■ Fabric softener should not be mixed with other laundry
products. Greasy stains can form. To remove greasy stains,
wet the stain and rub with liquid detergent or a bar of soap.
Rewash.
■ Too much fabric softener can make some items (diapers and
towels) nonabsorbent. If this happens, use less fabric
softener, or do not use it every time.
Self-Cleaning Lint Filter
Your washer has a self-cleaning lint filter at the bottom of the
basket. Was h and r inse wat er flo w over the filt er du ring a gitat ion,
separating the lint from the water. The lint spins out of the system
during the spin part of the cycle. If your washer drains into a tub,
remove any lint collected in the tub or strainer.
WASHER CARE
Rinse and Spin
When using extra deterg ent for he avily soiled clothes, o r washing
special-care items, you may find an extra rinse and spin is
needed.
Push in the Cycle Control knob and turn it clockwise to any of
1.
the Rinse settings.
Pull out the Cycle Control knob. The washer fills to the
2.
selected load size, agitates, drains, and spins.
An EXTRA RINSE option is available (on some models).
NOTE:
See “Starting Your Washer.”
Drain and Spin
A drain and spin may help shorten drying times for some heavy
fabrics or special-care items by removing excess water.
Push in the Cycle Control knob and turn it clockwise to any of
1.
the Spin settings.
Pull out the Cycle Control knob. The washer drains, then
2.
spins.
Adding Liquid Chlorine Bleach
Always measure liquid chlorine bleach. Do not guess. Never use
more than 1 cup (250 mL) for a full load. Follow manufacturer’s
directions for safe use. Use a cup with a pouring spout to avoid
spilling.
Let the washer fill and begin agitating the load.
1.
Add bleach to the wash cycle so it can be removed in the
2.
rinse cycle. Pour bleach around the agitator, not directly on
the load.
■ Follow directions on the care labels. Do not use chlorine
bleach on wool, silk, spandex, acetates, or some flameretardant fabrics.
■ When soaking with chlorine bleach, add detergent to
soak water.
Undiluted bleach will damage any fabric it touches. The
NOTE:
damage appears as rips, holes, tears, or color loss and may not
show up until several washings later.
Cleaning Your Washer
Cleaning the exterior
Use a soft, damp cloth or sponge to wipe up any spills such as
detergent or bleach. Occasionally wipe the outside of your
washer to keep it looking new.
Cleaning the interior
Clean your washer interior by mixing 1 cup (250 mL) of chlorine
bleach and 2 cups (500 mL) of detergent. Pour this into your
washer and run it through a complete cycle using hot water.
Repeat this process if necessary.
Remove any hard water deposits using only cleaners
NOTE:
labeled as washer safe.
Cleaning the liquid fabric softener dispenser
Flush dispenser per iodic ally with warm water, as shown. Remove
the dispenser by grasping the top of the dispenser with both
hands and squeezing and pushing upwards with thumbs. Clean
the dispenser by rinsing it under a water faucet. Replace it after
cleaning.
Do not wash clothes with this dispenser removed. Do not
NOTE:
add detergent or bleach to this dispenser; it is for liquid fabric
softener use only.
Water Inlet Hoses
Replace inlet hoses after five years of use to reduce the risk of
hose failure. Periodically inspect and replace inlet hoses if
bulges, kinks, cuts, wear or leaks are found.
When replacing your inlet hoses, mark the date of replacement
on the label with a permanent marker.
8
Page 9
Vacation, Storage and Moving Care
Install and store your washer where it will not freeze. Because
some water may stay in the hoses, freezing can damage your
washer. If storing or moving your washer durin g fr eezing weat her,
winterize it.
Non-use or vacation care
Operate your washer only when you are at home. If you will be on
vacation or not using your w asher for an extended perio d of time,
you should:
■ Unplug washer or disconnect power.
■ Turn off the water supply to the washer. This helps avoid
accidental flooding (due to a water pressure surge) while you
are away.
To winterize washer
Shut off both water faucets.
1.
Disconnect and drain water inlet hoses.
2.
Put 1 quart (1 L) of R.V.-type antifreeze in the basket.
3.
Run washer on a dr ain and spin setting (see “Drain an d Spin”)
4.
for about 30 seconds to mix the antifreeze and water.
Unplug washer or disconnect power.
5.
To use washer again
Flush water pipes and hoses.
1.
Reconnect water inlet hoses.
2.
Turn on both water faucets.
3.
Plug in washer or reconnect power.
4.
Run the washer throug h a complete cycle with 1 cup (250 mL )
5.
of detergent to clean out antifreeze.
TROUBLESHOOTING
First try the solutions suggested here and possibly avoid
the cost of a service call...
Washer won’t fill, rinse or agitate
■
Check the following:
Is the power cord plugged into a grounded 3 prong outlet?
Is the indicator on the Cycle Control knob properly lined up
with a cycle? Turn the Cycle Control knob to the right slightly
and
pull to start.
Are the water inlet valve screens clogged?
Are both the hot and cold water faucets turned on?
Is the water inlet hose kinked?
■
Does the water level seem too low, or does the washer
appear to not fill completely?
The top of the agitator is much higher than the highest water
level. This creates a perception that the washer is not filling
completely. This is normal.
■
Is the lid open?
The lid must be closed during operation.
Washer stops
■
Check the following:
Is the power cord plugged into a grounded 3 prong outlet?
Is the indicator on the Cycle Control knob properly lined up
with a cycle? Turn the Cycle Control knob to the right slightly
and
pull to start.
Are the water inlet valve screens clogged?
Are both the hot and cold water faucets turned on?
Is the water inlet hose kinked?
■
Is there power at the plug?
Check your electrical source or call an electrician.
■
Has a fuse blown or is the circuit breaker open?
If problem continues, call an electrician.
■
Are you using an extension cord?
Do not use an extension cord.
■
Is the washer in a normal pause in the Synthetics/
Permanent Press (or Hand Washables) cycle?
The washer pauses for about 2 minutes in the Synthetics/
Permanent Press cycle. Allow the cycle to continue.
The Hand Washables cycle (on some models) features
periods of agitation and soak.
■
Is the washer overloaded?
Wash smaller loads.
Washer won’t drain or spin
■
Is the drain hose clogged, or the end of the drain hose
more than 72 inches (183 cm) above the floor?
See the Installation Instr uctions for prope r installa tion of drain
hose.
■
Is the lid open?
The lid must be closed during operation.
9
Page 10
■ Is there excessive sudsing?
Always measure detergent. Follow manufacturer’s directions.
If you have very soft water, you might need to use less
detergent.
■ Is your voltage low?
Check your electrical source or call an electri cian. Do not use
an extension cord.
Washer continues to fill or drain, or the cycle seems
stuck
■ The washer basket moves while washing.
This is normal.
Agitator operation
■ The top of the agitator is loose, or moves in only one
direction.
This is normal.
Dispensers clogged or bleach leaking
■ Is the top of drain hose lower than the water level in
washer?
The top of the ho se m ust b e h igher tha n th e wat er lev el in t he
washer for proper operation. See the Installation Instructions.
■ Does the dra in h ose fit t oo tig htl y in th e st and pi pe, or i s it
taped to the standpipe?
The drain hose should be loose yet fit securely. Do not seal
the drain hose with tape. The hose needs an air gap. See the
Installation Instructions.
Washer makes noise
■ Is the load balanced and the washer level?
The wash load should be balanced and not overloaded.
The washer must be level. The front feet should be properly
installed and the nuts tightened. Reset the rear leveling legs
(if needed). See the Installation Instructions.
■ Did you completely remove the yellow shipping strap with
cotter pins?
See the Installation Instructions.
■ Are t he gea rs engaging af te r t he dr ain an d b ef ore spin, or
is the upper part of agitator clicking during wash?
These are normal washer noises.
Washer leaks
■ Check the following:
Are the fill hoses tight? Are the fill hose washers properly
seated? Is the drain hose clamp properly installed? See the
Installation Instructions.
■ Is the sink or drain clogged?
Sink and standpipe must be able to handle 17 gallons (64 L)
of water per minute.
■ Is water deflecting off the tub ring or the load?
Center the tub before starting the washer.
The wash load should be balanced and not overloaded. The
fill or spray rinses can deflect off the load.
The washer must be level. The front feet should be properly
installed and the nuts tightened. Reset the rear leveling legs
(if needed). See the Installation Instructions.
■ Check household plumbing for leaks.
Washer basket is crooked
■ Was the washer basket pulled forward during loading?
The wash load should be balanced and not overlo aded. Push
the basket to the center before starting wash.
■ Is the load balanced and the washer level?
The wash load should be balanced and not overloaded.
The washer must be level. The front feet should be properly
installed and the nuts tightened. Reset the rear leveling legs
(if needed). See the Installation Instructions.
■ Did you follo w the man ufact ur er’s directions wh en ad ding
detergent and fabric softener to the dispensers?
Measure deter gen t and fabr ic softener. Carefully pour into the
dispensers. Wipe up all spills.
Dilute fabric softener in the fabric softener dispenser.
■ Did you put powdered or color-safe bleach in the liquid
chlori ne bleach dispenser?
Add powdered or liquid color-safe bleach directly to the
basket. Do not use the chlorine bleach dispenser for colorsafe bleach.
Load too wet
■ Did you use the right cycle for the load being washed?
Select a cycle with a higher spin speed (if available).
■ Did you use a cold rinse?
Cold rinses leave loads wetter than warm rinses. This is
normal.
Residue or lint on load
■ Did you sort properly?
Sort lint givers (towels, chenille) from lint takers (corduroy,
synthetics). Also sort by color.
■ Did you overload the washer?
The wash load must be balanced and not overloaded. Lint
can be trapped in the load if overloaded. Wash smaller loads.
■ Check the following:
Was paper or tissue left in the pockets?
Did you use enough detergent? Follow manufacturer’s
directions. Use enough detergent to hold the lint in the water.
Is your water colder than 70°F (21°C)? Wash water colder
than 70°F (21°C) may not completely dissolve the detergent.
Stains on load
■ Did you follo w the man ufact ur er’s directions wh en ad ding
detergent and fabric softener?
Measure deter g ent and fabric softene r. Use enough deter gent
to remove soil and hold it in suspension.
Dilute fabric softener and add to the rinse portion of a cycle
only. Do not drip fabric softener on clothes.
■ Is there above average iron (rust) in water?
You may need to install an iron filter.
■ Did you properly sort the load?
Sort dark clothes from whites and lights.
■ Did you unload the washer promptly?
To avoid dye transfer, unload the washer as soon as it stops.
10
Page 11
Load is wrinkled
■
Did you unload the washer promptly?
Unload the washer as soon as it stops.
■
Did you use the right cy cle for the load being washed?
Use the Synthetics/Permanent Press cycle or another cycle
with low spin speeds (if available) to reduce wrinkling.
■
Did you overload the washer?
The wash load must be balanced and not overloaded. Loads
should move freely during washing.
■
Was the wash water warm enough to relax wrinkles, or
are you using warm rinses?
If safe for the load, use warm or hot wash water. Use cold
rinse water.
■
Are the hot and cold water hoses reversed?
Check to be sur e the hot and co ld water hoses ar e conn ected
to the right faucets. See the Installation Instructions.
Load is tangled or twisted
■
Did you overload the washer?
The wash load must be balanced and not overloaded. Loads
should move freely during washing.
■
Did you wrap items around the agitator?
Drop items loo sely into the wash er. Do not wrap items around
the agitator.
ASSISTANCE OR SERVICE
Before calling for assistance or service, please check
“Troubleshooting.” It may save you the cost of a service call. If
you still need help, contact the dealer fr o m whom you purchased
the washer, or a Whirlpool designated service company.
When calling, please know the purchase date and the complete
model and serial number of your appliance. This information will
help us to better resp ond to your request.
If you need replacement parts
If you need to order replacement parts, we recommend that you
only us e FSP
and work right because they are made with the same precision
used to build every new WHIRLPOOL
To locate FSP replacement parts in your area:
Contact the dealer from whom you purchased the washer, or a
Whirlpool designated service company.
®
factory specified parts. These parts will fit right
®
appliance.
Gray whites, dingy colors
■
Did you properly sort the load?
Dye transfer can occur when mixing whites and colors in a
load. Sort dark clothes from whites and lights.
■
Was the wash temperature too low?
Use hot or warm washes if safe for the load. Hot water should
be at least 111°F (44°C) to clean heavy or greasy soils.
■
Did you use enough detergent, or do you have hard
water?
Use more detergent for washing heavy soils in cold or hard
water.
■
Are the hot and cold water hoses reversed?
Check to be sur e the hot and co ld water hoses ar e conn ected
to the right faucets. See the Installation Instructions.
Garment damage
■
Check the following:
Were sharp items removed from pockets before washing?
Empty pockets, zip zippers, snap or hook fasteners before
washing.
Were strings and sashes tied to prevent tangling?
Were items damaged before washing? Mend rips and broken
threads in seams before washing.
■
Did you overload the washer?
The wash load must be balanced and not overloaded. Loads
should move freely during washing.
■
Did you properly add chlorine bleach?
Do not pour chlorine bleach directly on load. Wipe up bleach
spills. Undiluted bleach will damage fabrics.
■■■■
Did you follow the manufacturer’s care label instructions?
11
Loading...
