WHIRLPOOL

(

CORPORATION

)

Use and Care

Table of Contents

(complete)

..................

oo OI oo Ol

A Note to You

Refrigerator Safety Parts and Features Before Using Your

Refrigerator.....................5

Using Your

Refrigerator.....................7

Caring for Your

Refrigerator...................23

Food Storage

Guide Troubleshooting Requesting Assistance

or Service......................29

Warranty

............................

.................

.........

............

.......................

26 28

2 3 4

2194182

NO-FROST

SIDE BY SIDE REFRIGERATOR

Table of Contents

A Note to You Refrigerator Safety Parts and Features Before Using Your Refrigerator Using Your Refrigerator

Setting the controls..........................

Changing the control settings Removing the door shelf fronts

Removing the drop-in door trim.......

Adjusting the cantilever

refrigerator shelves...............................9

Removing the meat drawer and cover

Adjusting the meat drawer

temperature..........................................io

Removing the crisper and

crisper cover.......................................11

Removing the freezer bin

.........................................

.................................

..............

.....................

..........

.......

............................................

...................

Page

......

.....

......

2 3 4 5

7 7 7

Removing the freezer shelf Using the THIRSTCRUSHER*

dispensing system

Using the automatic ice maker Removing the ice maker storage bin... 16

Attaching the ice maker to a

water supply........................................17

Removing the base grille Changing the light bulbs Understanding the sounds you

may hear.............................................22

Saving energy.....................................22

..............................

....................

.....................

Caring for Your Refrigerator Food Storage Guide

.............................

Troubieshooting....................................28

Requesting Assistance or Service

Warranty

...............................................

................

...........

.................

.........

Page

12 14

20 20

23 26

A Note to You

Thank you for buying an ESTATE* appliance.

ESTATE appliances give you all the functionality of name brand appliances at a value price.

To ensure you enjoy years of trouble-free operation, we developed this Use and Care Guide.

It contains valuable information about how to operate and maintain your appliance properly and safely. Please read it carefully. Also, please complete and mail the Ownership Regis tration Card provided with your appliance. This card helps us notify you about any new information on your appliance.

Please record your model's information.

Whenever you call to request service on your appliance, you need to know your

complete model number and serial number. You can find this information on the model and serial number label (see diagram on page 4 for location of label).

Please also record the purchase date of your appliance and your dealer’s name, address, and telephone number.

Keep this book and the sales slip together in a safe place for future reference.

Our Consumer Assistance Center number is toll free from anywhere in the U.S.A. 24-hours a day.

Model Number _ Serial Number _ Purchase Date _ Dealer Name Dealer Address Dealer Phone

1-800-253-1301

Refrigerator Safety

Your safety is important to us.

This guide contains statements under warning symbols. Please pay special attention to these symbols and follow any

instructions given. Here is a brief explana

tion of the use of the warning symbol.

This symbol alerts you to such

dangers as fire, electrical

shock, or other injuries.

IMPORTANT SAFETY INSTRUCTIONS

AWARNING

• Read all instructions before using the refrigerator.

• Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators are still danger ous ... even if they will “just sit in the garage a few days.”

If you are getting rid of your old refrigerator, do it safely. Please read the enclosed safety booklet from the Association of Home Appliance Manu facturers. Help prevent accidents.

To reduce the risk of fire, electrical shock, or injury when using your refrigerator, follow these basic precautions:

• Never allow children to operate, play with, or crawl inside the refrigerator.

• Never clean refrigerator parts with flam

mable fluids. The fumes can create a fire hazard or explosion.

•FOR YOUR SAFETY»

DO NOT STORE OR USE GASOLINE OR

OTHER FLAMMABLE VAPORS AND

LIOUIDS IN THE VICINITY OF THIS OR

ANY OTHER APPLIANCE. THE FUMES

CAN CREATE A FIRE HAZARD OR EXPLOSION.

- SAVE THESE INSTRUCTIONS -

Help us help you

Please:

• Install and level the refrigerator on a floor that will hold the weight and in an area suitable for its size and use.

• Do not install the refrigerator near an oven, radiator, or other heat source.

• Do not use the refrigerator in an area where the room temperature will fall below 55°F(13°C).

• Keep the refrigerator out of the weather.

• Connect the refrigerator only to the proper kind of outlet, with the correct electrical supply and grounding. (Refer to the Electrical Requirements and Grounding

Instructions Sheet.)

' Do not load the refrigerator with food

before it has time to get properly cold.

' Use the refrigerator only for the uses

described in this manual. ' Properly maintain the refrigerator. ’ Be sure the refrigerator is not used by

anyone unable to operate it properly.

Parts and Features

This section contains captioned illustrations of your appliance. Use them to become familiar with where all parts and features are located and what they look like. Page references are included for your convenience.

NOTE: The model you have purchased may have all or some of the parts and features shown and they may not match the illustration exactly. This manual covers several models.

t Number varies with modei

WITH QUESTIONS OR COMMENTS

Before Using Your Refrigerator

It is important to prepare your refrigerator for use. This section tells you how to clean it,

connect it to a power source, install it, and level it.

Cleaning your refrigerator

Removing packaging materials

Remove tape and any inside labels (except the model and serial number label) before using the refrigerator.

NOTE: Do not remove any permanent

instruction labels inside your refrigerator. Do not remove the Tech Sheet fastened under the refrigerator at the front.

To remove any remaining tape or iabei giue:

• Rub briskly with thumb.

• Apply liquid hand-dishwashing detergent to area before removing glue as described above. Do not use sharp instruments, rubbing alcohol, flammable fluids, or abrasive cleaners. These can damage the material. See “Important Safety Instruc tions” on page 3.

Leveling it

Your refrigerator has 2 front leveling screws

- one on the right and one on the left. To

adjust one or both of these, follow the directions below.

1. Remove base grille. (See page 20.)

2. To raise front, turn screw clockwise.

3. To lower front, turn screw counter clockwise.

4. Check with level.

5. Replace base grille. (See page 20.)

Cleaning it before use

After removing all packaging materials, clean

your refrigerator before using it, if necessary. See cleaning instructions on page 23.

BEFORE USING YOUR REFRIGERATOR

Plugging it in

AWARNING

Fire Hazard Do not use an extension cord. Doing so can result in death, fire, or

electrical shock.

Recommended Grounding Method

A 115 Volt, 60 Hz., AC only 15 or 20 ampere fused and properly grounded electrical

supply is required. It is recommended that a separate circuit serving only this appliance be provided. Use a receptacle which cannot be turned off with a switch or pull chain. Do not use an extension cord. See Electrical Requirements and Grounding Instructions Sheet in your Literature Package.

AWARNING

Electrical Shock Hazard Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter. Failure to follow these instructions

can cause death, fire, or electrical shock.

3-prong grounding type wall receptacle

Refrigerator power cord

3-prong grounding plug

Installing it properly

1. Allow V2 inch (1.25 cm) space on each side and at the top of the refrigerator for ease of installation.

2. If a hinge side of the refrigerator is to

be against a wall, you might want to leave extra space so the door can be opened wider.

3. The refrigerator can be flush against the back wall.

1-800-253-1301

WITH OUFSTIONS OR COMMENTS

Using Your Refrigerator

To obtain the best possible results from your refrigerator, it is important that you operate it properly. This section tells you how to set the controls, remove and adjust the features in your refrigerator, and how to save energy.

Setting the controls

Controls for the refrigerator and freezer are in the refrigerator. When you plug in the refrigerator for the first time:

1. Set the Refrigerator Control to 3

(Recommended Setting). Refrigerator

Control settings range from

1 (warmest) to 5 (coldest).

2. Set the Freezer Control to B (Recom

mended Setting). Freezer Control

settings range from A (warmest) to C (coldest).

Give the refrigerator time to cool down completely before adding food. This may take several hours. The settings indicated

above should be correct for normal, house hold refrigerator usage. The controls are set correctly when milk or juice is as cold as you like and when ice cream is firm. If you need to adjust these settings, see “Changing the control settings" below.

NOTE: The Automatic Exterior Moisture

control continuously guards against moisture buildup on the outside of your refrigerator cabinet. This control does not have to be set or adjusted.

Changing the control settings

If you need to adjust temperatures in refrigerator or freezer, use the settings listed in the chart below as a guide. If you

have any questions, call our Consumer Assistance Center number, 1-800-253-1301, from anywhere in the U.S.A.

' Adjust the Refrigerator Control first.

Wait at least 24 hours between adjustments. Then adjust the Freezer Control if needed.

USING YOUR REFRIGERATOR

-V > «

CONDITION:

Refrigerator section too warm

Freezer section too warm

Refrigerator section too cold

Ice not made fast enough

Both sections too warm

REASON:

• Door opened often

• Large amount of food added

• Room temperature too warm

• Door opened often

• Large amount of food added

• Very cold room temperature (can’t cycle often enough)

• Controls not set correctly for your conditions

• Heavy ice usage

• Very cold room temperature (can’t cycle often enough)

• Door opened often

• Large amount of food added

• Very warm or very cold room temperatures

Removing the door shelf fronts

(on some models)

Remove the door shelf fronts for easier

cleaning.

To remove shelf fronts:

1. Remove all items from the shelf.

2. Pull out on the inside tab at each end of the shelf fronts.

3. Pull shelf front straight out.

RECOMMENDED SETTINGS:

Refrigerator

Freezer

To replace shelf fronts:

1. Line up ends of the shelf front with the button on the door liner wall.

2. Push shelf front straight back until it snaps securely into place.

3. Replace items on the shelf.

icALLSB:iiliai-)iaKli]ii

WITH QUESTIONS OR COMMENTS

USING YOUR REFRIGERATOR

Removing the drop-in door trim (dispenser area)

(on some models)

Remove the trim above the dispenser area

for easier cleaning.

To remove the trim piece:

1. Remove all items from the shelf.

2. Pull straight up on the trim piece at each end.

To repiace the trim piece:

1. Locate each end of the trim piece above the trim pocket opening.

2. Push the trim piece straight down until it stops.

3. Replace items on the shelf.

Adjusting the cantilever refrigerator shelves

Adjust the shelves to match the way you use your refrigerator. Glass shelves are strong enough to hold bottles, milk, and other heavy food items.

To remove a sheif:

1. Remove items from shelf.

2. Tilt shelf up at front.

3. Lift shelf at back.

4. Pull shelf straight out.

To replace a shelf:

1. Guide the rear shelf hooks into the slots in the shelf supports on the back liner wall.

2. Tilt front of shelf up until hooks drop into slots.

3. Lower front of shelf to a level position.

NOTE: Glass shelves are heavy. Handle

them carefully.

USING YOUR REFRIGERATOR

Removing the meat drawer and cover

To remove the meat drawer:

1. Slide the meat drawer straight out to the stop.

2. Lift the front slightly.

3. Slide out the rest of the way.

4. Replace in reverse order.

To remove the cover:

1. Remove meat drawer and crisper.

2. Lift front of cover off supports.

3. Lift cover out by pulling up and out.

To replace the cover:

1. Fit back of cover into notch supports on walls of refrigerator.

2. Lower front into place.

3. Replace meat drawer and crisper.

Pull out to the stop, lift the front, and pull again.

Adjusting the meat drawer temperature

Cold air flows from the freezer into the meat drawer. This helps keep the meat drawer colder than the rest of the refrigerator for better storage of meats.

Slide the control from side to side to let

more or less cold air through.

WITU miFSTinNS nn COMMENTS

CALL^iBaillBU.IcTOTl

USING YOUR REFRIGERATOR

Removing the crisper and crisper cover

To remove the crisper:

1. Slide crisper straight out to the stop.

2. Lift the front and slide out the rest of the way.

3. Replace in reverse order.

To remove the cover:

1. Hold cover firmly with both hands and lift front of cover off supports.

2. Lift cover out by pulling up and out.

To replace the cover:

1. Fit back of cover into notch supports on walls of refrigerator.

2. Lower front into place.

Remove the glass insert. Lift the cover front, then the back.

NOTE: Handle glass insert with care. It is heavy.

Pull out to the stop, lift the front, and pull again.

Removing the freezer bin

To remove the bin:

1. Slide bin out to the stop.

2. Lift the front to clear the stop.

3. Slide bin out the rest of the way.

To replace the bin:

1. Place bin on the slides.

2. Make sure the wire stops clear the front

of the slides.

3. Slide bin in all the way.

Removing the freezer shelf

To remove the shelf:

1. Lift right side of shelf off supports.

2. Slide shelf out of shelf support holes.

3. Replace in reverse order.

Pull out to the

stop, lift the front, and pull again.

Step Step

USING YOUR REFRIGERATOR

Using the THIRSTCRUSHER* dispensing system

The ice dispenser

Ice dispenses from the ice maker storage bin in the freezer. When you press the dispenser bar, a trapdoor opens in a chute between the dispenser and the ice bin. Ice moves from the bin and falls through the chute. When you release the dispenser bar, a buzzing sound may be heard for a few seconds as the trapdoor closes. The dis penser system will not operate when the freezer door is open.

For crushed ice, cubes are crushed before being dispensed. This may cause a slight delay when dispensing crushed ice. Noise from the ice crusher is normal, and pieces of ice may vary in size.

When changing from CRUSHED to CUBED, a few ounces of crushed ice will be dispensed along with the first cubes.

ÀWARNING

Cut Hazard

Use a sturdy giass when dispensing ice or water.

Faiiure to do so can resuit in cuts.

To dispense ice:

1. For cubed ice, move Ice Selector Switch

to CUBED position.

For crushed ice, move Ice Selector

Switch to CRUSHED position.

2. Press a sturdy glass against the ice

dispenser bar. Hold glass close to dispenser opening so ice does not fall outside of glass.

3. Remove the glass to stop dispensing.

NOTE: The first few batches of ice may

have an off-flavor from new plumbing and parts. Throw the ice away. Also, take large amounts of ice from the ice bin, not through the dispenser.

CUBED CRUSHED

• •

ICE

CUBED CRUSHED

m •

ICE

call:

aBiiiiigwcfltcjin

uiiTu niiceTinus rni

The water dispenser

Chilled water comes from a tank behind

the meat drawer. It holds approximately

Vh quarts (1.5 L).

When the refrigerator is first hooked up,

press the water dispenser bar with a glass or

jar until you draw and discard 2 or 3 quarts

(1.9 to 2.8 L). The water you draw and discard rinses the tank and pipes.

Allow several hours to chill a new tankful.

NOTE: The small tray beneath the dispenser

is designed to evaporate small spills. There is no drain in this tray. Do not pour water into it.

To dispense water:

1. Press a sturdy glass against the water

dispenser bar.

2. Remove the glass to stop dispensing.

NOTE: Dispense enough water every week

to maintain a fresh supply.

USING YOUR REFRIGERATOR

The dispenser light

To turn on night light, slide dispenser

LIGHT switch to the left. See page 21 for

directions for changing the dispenser

light bulb.

WATER

Solving common ice dispenser problems

PROBLEM POSSIBLE CAUSE/SOLUTION

Ice dispenser will not work

Ice dispenser stops working

• Freezer door is open.

• Ice bin not properly installed. Make sure the bin is pushed in all the way.

• Wrong ice in bin. Only use crescents from the ice maker. Shake the bin occasionally to separate cubes and increase storage room.

• Dispenser not used for extended periods of time, causing ice cubes to melt together. Dump old ice and make a new supply.

• Ice dispenser bar held in too long. Wait about 3 minutes for dispenser motor to reset.

• Large amounts of ice should be taken from the bin, not through the dispenser.

USING YOUR REFRIGERATOR

Using the automatic ice maker

Here are a few things you will want to know about your automatic ice maker:

• The ON/OFF lever is a wire signal arm. DOWN to make ice automatically.

UP to shut off the ice maker.

NOTE: Do not turn ice maker on until it is

connected to the water supply. Instruc

tions for ice maker water supply hookup are attached to the back of the refrigerator cabinet.

• It is normal for ice crescents to be attached

by a corner. They break apart easily.

• The ice maker will not operate until the

freezer is cold enough to make ice. This can take overnight.

• If ice is not being made fast enough and

more ice is needed, turn the Refrigerator Control toward a higher number. Wait a day and, if necessary, turn the Freezer Control toward C.

• Good water quality is important for good ice quality. Try to avoid connecting the ice maker to a softened water supply. Water softener chemicals (such as salt from a malfunctioning softener) can damage the ice maker mold and lead to poor ice quality. If a softened water supply cannot be avoided, make sure the water softener is operating properly and is well maintained.

UP to

stop ice

maker.

DOWN to

start ice

maker.

CAL^ II

MiTU rMiccTir\ikje rtn /«rttiiicMxe

USING YOUR REFRIGERATOR

Solving common ice maker/dispenser problems

PROBLEM Ice crescents attached

at corners

Ice maker will not operate or ice is not made fast enough

Off-taste or odor in ice

Ice dispenser wiii not work

Ice dispenser stops working

POSSIBLE CAUSE/SOLUTION

• This is normal. They break apart easily. Shake bin occasionally to keep cubes separated.

• ON/OFF lever is in the OFF (up) position. Lower lever to the ON (down) position.

• Freezer is not cold enough. Adjust temperature controls and wait 24 hours. (See “Changing the control settings” on page 7.)

• New plumbing connections can cause discolored or offflavored ice. Discard the first few batches of ice.

• Cubes are stored too long. Throw them away and make a new supply.

• Food is not wrapped properly. See page 27.

• Freezer and ice bin need to be cleaned. See page 23.

• Water may contain minerals (such as sulfur). A filter may be required to remove them.

• Freezer door is open.

• Ice bin not properly installed. Make sure the bin is pushed in all the way.

• Wrong ice in bin. Only use crescents from the ice maker. Shake the bin occasionally to separate cubes and increase storage room.

• Dispenser not used for extended periods of time, causing ice cubes to melt together. Dump old ice and make a new supply.

• Ice dispenser bar held in too long. Wait about 3 minutes for dispenser motor to reset.

• Large amounts of ice should be taken from the bin, not

through the dispenser.

USING YOUR REFRIGERATOR

Removing the ice maker storage bin

Remove, empty, and clean the storage bin if:

• the ice dispenser has not, or will not, be used for a week or more.

• a power failure causes ice in the bin to melt and freeze together.

• the ice dispenser is not used regularly.

To remove ice bin:

1. Pull the covering panel out from the bottom and slide it to the rear.

2. Lift the signal arm so it clicks into the OFF (up) position. Ice can still be dispensed, but no more can be made.

3. Lift the front of the storage bin and pull

it out.

4. Empty the ice bin. Use hot or warm water to melt the ice if necessary. Never use

anything sharp to break up ice in the

bin. This can damage the bin and dis penser mechanism.

5. Wash with mild detergent. Rinse well.

Do not use harsh or abrasive cleaners

or solvents.

6. When replacing the bin, make sure it is pushed in all the way. Then push the signal arm down to the ON position to

restart ice production.

calC SI

USING YOUR REFRIGERATOR

Attaching the ice maker to a water supply

Read all directions carefully before you begin.

Cold water supply

AWARNING

Electrical Shock Hazard

Unplug the refrigerator before installing ice maker.

Failure to do so can result in death or electrical shock.

IMPORTANT:

• Use copper tubing only and check for leaks.

• Install ice maker tubing in areas where temperatures are above freezing.

Tools required:

• Standard screwdriver

• yi6-inch and y2-inch open-end wrenches or 2 adjustable wrenches

• V4-inch nut driver

• V4-inch drill bit

• Hand drill or electric drill (properly grounded)

Ice maker water valve contains a flow washer which is used as a water pressure regulator. The ice maker needs to be connected to a cold water line with water pressure limitations of 20-120 PSI. If a

problem occurs, call your utility company.

IMPORTANT:

• It may take up to 24 hours for your ice

maker to begin producing ice.

• If operating the refrigerator before install

ing the water connection, turn ice maker to the OFF position to prevent operation without water.

• All installations must be in accordance with local plumbing code requirements.

INSTALLATION IS NOT WARRANTED

BY REFRIGERATOR OR ICE MAKER

MANUFACTURER.

NOTE: Your appliance dealer has a kit

available with a V4-inch saddle type shut-off

valve, a union, and copper tubing. Before

purchasing, make sure a saddle type valve

complies with your local plumbing codes.

Do not use piercing type or yis-inch saddle

valve which reduces water flow and clogs

more easily.

USING YOUR REFRIGERATOR

Connecting to water line

1. Find a V2-inch to VA-mch vertical COLD water pipe near the refrigerator.

NOTE: Horizontal pipe will work, but the

following precaution must be taken: Drill on the top side of the pipe, not the

bottom. This will help keep water away

from the drill. This also keeps normal

sediment from collecting in the valve.

2. Measure from connection on rear of refrigerator to water pipe. Add 7 feet (2.1 m) to allow for moving refrigerator for cleaning. This is the length of V4-inch O.D. copper tubing you will need for the job (length from connection to water pipe PLUS 7 feet [2.1 m]). Be sure both ends of copper tubing are cut square.

3. Turn OFF main water supply. Turn ON nearest faucet long enough to clear line of water.

4. Using a grounded drill, drill a V4-inch hole on the cold water pipe you have selected.

5. Fasten shut-off valve to cold water pipe with pipe clamp. Be sure outlet end is solidly in the '/4-inch drilled hole in the water pipe and that washer is under the pipe clamp. Tighten packing nut. Tighten the pipe clamp screws carefully and evenly so washer makes a watertight seal. Do not overtighten or you may crush the copper tubing, especially if soft

(coiled) copper tubing is used. Now you

are ready to connect the copper tubing.

6. Slip compression sleeve and compres sion nut on copper tubing as shown in diagram. Insert end of tubing into outlet end squarely as far as It will go. Screw compression nut onto outlet end with adjustable wrench. Do not overtighten. Turn ON main water supply and flush out tubing until water is clear. Turn OFF shut-off valve on the water pipe. Coil copper tubing.

Vertical cold water pipe

Washer

Packing nut

Water shut-off valve

Compression Compression sleeve nuts *

* Some models may not feature the second

compression nut and sleeve.

Pipe clamp water pipe plus 7

TO REFRIGERATOR -*

'/4-inch O.D.

copper tubing

(length from inlet

on rear of

refrigerator to

feet [2.1m])

Compression

sleeve

CALLaBMIlIgWcTOn

Connecting to refrigerator

NOTE: The first step for connecting the

water line to your refrigerator is different depending on the type of water valve

provided with your refrigerator. See the

diagrams at right to determine the style of

valve you have. (On kit models, assemble

water valve to refrigerator per kit instructions.)

1. For style #1, disconnect the tube clamp

on the back of the product and insert the copper tubing through the clamp, as shown at the right. Remove the tape label from the valve inlet and insert copper tubing until it bottoms out (ap proximately % inch). Tighten nut by hand as much as possible; then turn the nut an additional '/2 turn using a wrench. Do not overtighten. Reattach the tube clamp and tube to the back of the cabinet. Skip to step 2.

USING YOUR REFRIGERATOR

For style #2, disconnect the tube clamp

on the back of the product and insert copper tubing through the clamp as

shown at the right. Attach the copper tube

to the valve inlet using a compression nut

and sleeve as shown. Tighten the com pression nut. Do not overtighten. Reattach the tube clamp and tube to the back of the cabinet. Move to step 2.

Turn shut-off valve ON. CHECK FOR LEAKS. TIGHTEN ANY CONNECTIONS (INCLUDING CONNECTIONS AT THE VALVE) OR NUTS THAT LEAK.

The ice maker is equipped with a built-in water strainer. If local water conditions require periodic cleaning or a well is your source of water supply, a second water strainer should be installed in the V^-inch water line. Obtain a water strainer from your nearest appliance dealer. Install at either tube connection.

Reconnect electrical supply to refrigerator.

Style #2 valve

USING YOUR REFRIGERATOR

Removing the base grille

To remove the grille:

1. Open both doors.

2. Pull base grille forward to release the support tabs from the metal clips.

3. Do not remove Tech Sheet fastened behind the grille.

To replace the grille:

1. Line up grille support tabs with metal clips.

2. Push firmly to snap into place.

3. Close the doors.

See cleaning instructions for defrost pan and condenser coils on page 24.

Changing the light bulbs

AWARNING

Condenser coils

Metal

clips

Base grille

Support tabs

Electrical Shock Hazard

Unplug the refrigerator before changing light bulb.

Failure to do so can result in death or electrical shock.

To change refrigerator light:

1. Unplug the refrigerator.

2. Reach behind the Control Console to remove bulb.

3. Replace bulb with a 40-watt appliance bulb.

4. Plug in the refrigerator.

CALLaBMIllB-A-lintin

To change crisper light:

1. Unplug the refrigerator.

2. Pull top of light shield forward until it snaps free.

3. Lower light shield to clear bottom supports.

4. Pull light shield straight out to remove.

5. Replace bulb with a 40-watt appliance bulb.

6. Replace light shield in reverse order.

7. Plug in the refrigerator.

To change light below ice bin:

1. Unplug the refrigerator.

2. Push in sides of light shield and pull forward until shield snaps free.

3. Replace bulb with a 40-watt appliance bulb.

4. Replace light shield.

5. Plug in the refrigerator.

To change dispenser area light:

1. Disconnect refrigerator from power supply.

2. Reach through dispenser area to remove bulb.

3. Replace with a heavy-duty 10-watt bulb, which can be purchased from your Whirlpool dealer.

4. Reconnect refrigerator to power supply.

USING YOUR REFRIGERATOR

Light

below

ice bin

NOTE: Not all commercial appliance bulbs

will fit your refrigerator. Be sure to replace a

bulb with one of the same size and shape.

+ 47 hidden pages
