Page 1
INSTALLATION SPEAKER SERIES
WCM-65 | WCM-80 | WWS-65 | WWS-80 | WOS-53 | WOS-65
WCM-65 | WCM-80
In-Ceiling Speakers
WWS-65 | WWS-80
In-Wall Speakers
WOS-53 | WOS-65
All-Weather Outdoor
Speakers
Wharfedale proudly introduce 6 new highly durable, high delity
speaker models for discreet indoor and outdoor sound reproduction.
The new line of speakers include 2 in-ceiling mounted models (WCM-65, WCM-80), 2 in-wall mounted models (WWS-65, WWS-80) and two all-weather outdoor
speakers (WOS-53, WOS-65). Each speaker demonstrates Wharfedale’s lifetime lasting build, with a musically thrilling sound.
The edgeless exterior design on WCM and WWS models with magnetic micro-perforated grilles guarantee a seamless blend between wall, ceiling and speaker.
While externally the speakers are simplistic and discreet, advanced drivers and crossover networks are housed within. The rigid polypropylene LF cone paired with
an ultra-durable, high-excursion rubber surround guarantees stability under high pressure and extensive bass output. Titanium dome tweeters with highly ecient
neodymium motor systems complete each speakers’ wide frequency response with a scintillating high frequency and wide dispersion (with a rotatable tweeter on
WCM models for optimised positioning).
The WOS-53 and WOS-65 are all-weather outdoor speakers. With an IP67 rating, both speakers implement technology to withstand tough outdoor conditions
including electroplated mylar coated polypropylene woofers for moisture rejection and rust-proof hardware including aluminium grilles and rotatable U-shaped
brackets. With a high power handling and a molded, paintable PVC enclosure, these speakers are built for resilient performance with formidable sound output.
IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK
Tel: +44(0) 1480 452 461 | www.wharfedale.co.uk
Page 2
WCM & WWS Key Features:
· In-Wall / In-Ceiling Speakers
· Edgeless Design for discreet installation
· Magnetically attached grilles
· Optional square grilles (WCW)
· 1-inch Titaninum swivel NEO tweeter
· Gold Plated Spring Loaded Terminals
· Easy Install Safe Lock Mechanism
· PP Cone with high excursion rubber surround
· Thermal tweeter protection
· +/- 3dB bass & treble controls
· 6.5” and 8” Models
WOS Key Features:
· All-Weather Outdoor Speakers
· All rust proof Aluminium screws, brackets & grilles
· Extremely versatile molded PVC enclosure with UV protection
· 3/4” hard dome tweeters
· Two mounting options: bookshelf or bracket
· Directional positioning for better sound dispersion
· Electroplated mylar woofer cones with UV protection
· Paintable to match any decor, indoor or outdoor
· High power handling
· Gold plated binding posts
· IP67 - Excellent for all applications including marine
· 5.25” and 6.5” models
IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK
Tel: +44(0) 1480 452 461 | www.wharfedale.co.uk
Page 3
IP67-6.5
227mm
292mm
250mm
196mm
IP67-5
WCM-65
WCM-80
268
Φ
245
Φ
108
103
42
32
250mm
WWS-65
196mm
WOS-53
WWS-80
246
224
348
326
237mm
188mm
104
99
40
30
292mm
227mm
WOS-65
249mm
219mm
IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK
Tel: +44(0) 1480 452 461 | www.wharfedale.co.uk
Page 4
Specications
WCM-65 WCM-80 WWS-65 WWS-80 WOS-53 WOS-65
General description In-Ceiling Mounted In-Ceiling Mounted In-Wall Speaker In-Wall Speaker
Transducer
complement
Bass driver
Treble driver 1” Titanium Dome 1” Titanium Dome 1” Titanium Dome 1” Titanium Dome
HF Adjust +/- 3dB +/- 3dB +/- 3dB +/- 3dB n/a n/a
LF Adjust +/- 3dB +/- 3dB +/- 3dB +/- 3dB n/a n/a
Terminals
Grille & hardware
Protection
IP Rating n/a n/a n/a n/a IP67 IP67
Sensitivity (2.83V @ 1m) 87dB 88dB 88dB 89dB 88dB 89dB
Power (RMS / Peak) 30W / 80W 40W / 100W 30W / 80W 40W / 100W 30W / 80W 40W / 100W
Recommended
amplier power
Peak SPL 97dB 98dB 98dB 99dB 98dB 99dB
Nominal impedance 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms 8 Ohms
Frequency response
(+/-3dB)
Crossover 12dB Per Octave 12dB Per Octave 12dB Per Octave 12dB Per Octave 12dB Per Octave 12dB Per Octave
Cut-Out Dimensions 201mm Inner Diameter 245mm Inner Diameter 191mm x 278mm 326 x 224 mm n/a n/a
Mounting Depth 100mm 103mm 99mm 99mm n/a n/a
Dimensions
Net weight 1.23kg 1.8kg 1.5kg 2.0kg 3.66kg 5.3kg
Finish
2-Way 2-Way 2-Way 2-Way 2-Way 2-Way
6.5” / 165mm
Polypropylene
Gold Plated, Spring
Loaded
Magnetic Micro-perf
Grille
Auto Protect Reset
Switch / Over Power
Protection
20W - 120W 30W - 140W 20W - 120W 30W - 140W 20W - 120W 30W - 140W
65Hz - 20kHz 45Hz - 20kHz 63Hz - 20kHz 43Hz - 20kHz 70Hz - 20kHz 65Hz - 20kHz
225mm (Diameter) x
97mm
Black polypropylene
body with white
sprayable grille
8” / 200mm
Polypropylene
Gold Plated, Spring
Loaded
Magnetic Micro-perf
Grille
Auto Protect Reset
Switch / Over Power
Protection
268mm (Diameter) x
108mm
Black polypropylene
body with white
sprayable grille
6.5” / 165mm
Polypropylene
Gold Plated, Spring
Loaded
Magnetic Micro-perf
Grille
Auto Protect Reset
Switch / Over Power
Protection
298mm x 211mm x
86mm
Black polypropylene
body with white
sprayable grille
8” / 200mm
Polypropylene
Gold Plated, Spring
Loaded
Magnetic Micro-perf
Grille
Auto Protect Reset
Switch / Over Power
Protection
348mm x 246mm x
104mm
Black polypropylene
body with white
sprayable grille
All Weather Outdoor
Speaker
5.25” / 135mm
Polypropylene
1” Hard Dome, Ferro-
uid cooled
Gold Plated Gold Plated
Rust-free Aluminum
Grille
Rotatable Steel
U-Shaped Bracket
Auto Protect Reset
Switch / Over Power
Protection
250mm x 196mm x
237mm
White polypropylene
with aluminum grille &
hardware
All Weather Outdoor
Speaker
6.5” / 165mm
Polypropylene
1” Hard Dome, Ferro-
uid cooled
Rust-free Aluminum
Grille
Rotatable Steel
U-Shaped Bracket
Auto Protect Reset
Switch / Over Power
Protection
292mm x 227mm x
249mm
White polypropylene
with aluminum grille &
hardware
IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK
Tel: +44(0) 1480 452 461 | www.wharfedale.co.uk
