Wharfedale Twin X Series User Manual
TWIN X SERIES MULTI-PURPOSE LOUDSPEAKER SYSTEMS
TWIN 8X, 10X, 12X & 15X CO-AXIAL FULL RANGE MULTI-PURPOSE LOUDSPEAKER
SYSTEMS
TWIN 15X SUB & TWIN 18X SUB - SUB BASS CABINETS
TWIN 15X ACTIVE SUB & TWIN 18X ACTIVE SUB CABINETS
USER MANUAL
WARNING & SAFETY INSTRUCTIONS
TWIN-8X, -10X, -12X, -15X FULL RANGE AND -15X SUB /-18X SUB BASS CABINETS
1. READ INSTRUCTIONS
carefully before operating this product.
2
.
RETAIN these instructions.
3. COMPLY WITH WARNINGS - All warnings and instructions for this product should be adhered to.
4. USE WITH AMPLIFIERS - In order to avoid damage, it is advisable to establish and follow a pattern for turning on and off
any sound system. With all system parts connected, turn on source equipment, tape decks, instruments, mixers, signal
processors etc., BEFORE turning on your power amplifier. Many products output turn on and turn off transients that can
damage speakers. By turning on your power amplifier LAST and making sure the amplifier’s input controls are at minimum
any transients “upstream” of the amplifier are not amplified and passed to the speaker. Wait until all system parts have
stabilised, then bring up amplifier controls to operating level. This should take no more than a few seconds. Similarly when
shutting systems down, always turn down amplifier input controls and then turn off your amplifier BEFORE shutting down
other components. Professional amplifiers often feature delayed turn on/off circuits to perform these functions for you
automatically.
5. CABLES - Never use shielded or microphone cable for any speaker connection as this will not be heavy enough to handle
the amplifier load and could cause damage to the complete system.
6. RIGGING • SUSPENDING • MOUNTING
The rigging, suspension or mounting of this speaker system can expose members of the public to serious health risks and
even death. UNDER NO CIRCUMSTANCES ATTEMPT TO RIG, SUSPEND OR OTHERWISE MOUNT THIS SYSTEM
UNLESS YOU ARE FULLY QUALIFIED AND CERTIFIED TO DO SO BY RELEVANT LOCAL, STATE AND NATIONAL
AUTHORITIES. ALL RELEVANT SAFETY REGULATIONS MUST BE FOLLOWED. IF YOU ARE NOT PROPERLY
QUALIFIED OR DO NOT KNOW OF PERTINENT REGULATIONS, CONSULT QUALIFIED PERSONNEL FOR ADVICE
AND ASSISTANCE.
7. CAUTION: These professional loudspeaker systems are capable of generating very high sound pressure levels. Use
care with placement and operation to avoid exposure to excessive levels that can cause permanent hearing damage.
8. SERVICING - The user should not attempt to service this product except that mentioned in this manual.
TWIN-15X SUB ACTIVE AND TWIN-18X SUB ACTIVE SUB BASS CABINETS
9. WATER & MOISTURE - This Wharfedale Pro unit should not be used near liquids. It should not have liquids placed
on or in close proximity as there are DANGEROUS VOLTAGES present.
10. VENTILATION/AIR FLOW: This Wharfedale Pro unit should not have its heatsink obstructed from air flow. It should
not be situated in a built-in installation that may hamper air flow to the heat sinks. It should not be placed near heat sources.
11. POWER SUPPLY: This Wharfedale Pro unit should be only connected to a power supply as stated on the unit.
Power supply cables should be routed where they will not be walked on or pinched by objects placed adjacent or upon them.
12. ELECTRIC SHOCK: Care should be taken that the grounding of this unit is NOT defeated. Do not use this units
power cable with an extension cable unless the pins can be fully inserted.
TWIN-X SERIES MULTI-PURPOSE LOUDSPEAKER SYSTEMS
TWIN-8X, -10X, -12X & -15X CO-AXIAL FULL RANGE MULTI-PURPOSE LOUDSPEAKER
SYSTEMS
TWIN-15X SUB & TWIN-18X SUB - SUB BASS CABINETS USER MANUAL
TWIN-15X SUB ACTIVE & TWIN-18X SUB ACTIVE BASS CABINETS USER MANUAL
Unpacking
All Wharfedale Pro products are fully checked before
leaving the factory. After unpacking please inspect
cabinets for any physical damage. Please retain the
shipping carton if possible and internal packing material
in case the unit needs to be returned. Please check as
soon as possible the unit is functioning. In the event of
any damage please contact your dealer immediately so
that a written claim for damages can be made.
Wharfedale Pro Limited Warranty*
Wharfedale Twin-X Series loudspeaker systems are
warranted to be clear of manufacturing or materials defects
for a period of one year from the original date of purchase.
In the event of malfunction, contact your authorised
Wharfedale Professional dealer or distributor for information.
*Be aware that warranty details may differ from country
to country. Contact your dealer or distributor for
information.These terms do not infringe your statutory
rights.
