Page 1
Soldering - Solderen - Soudage - Löten - Soldadura - Lödning - Juottami nen - Saldatura - Solda
C...
max.
40W
START
1 3
Resistor - Weerstand -
1
Résistance - Widerstand -
Resistencia - Motstand Vastus - Resistenze
R...
◊R1: 1K
◊R2: 1K
2
Brown, Black, Red) -(Bruin, Zwart, Rood) -(Brun, Noir,
Rouge) -(Braun, Schwarz, Rot) -(Brun, Svart, Röd) (Ruskea, Musta, Punainen ) -(Marrón, Negro, Rojo) (Castanho, Preto, Encarnado) - (Marrone, Nero, Rosso)
◊R3: 1K
2
DIODE
◊D1: 1N4148
◊D2:1N4148
◊D3: 1N4007
-Trimpotentiometer -Potentiomètre de réglage -
3
Potentiómetro de regulación Trimmeripotentiometri -Trimme-potentiometer Trimmer potenziometri
◊RV1: 1M PAUSE
CATHODE
CATHODE
D...
7
10
◊ J1 + J2
IC - CI
◊ IC1: 555
8
C1
100n
ELCO
◊C2: 100µF
◊C3: 100µF
Watch the polarity !
!
PULSE
8
5
6
2
4
47K
22K
VCC
CONT
THRE
TRIG
RSES
R1
1K
555
OUT
DIS
GND
IC1
C2
100µ
RV2
3
7
1
D2
1N4148
9
◊ RY1: 1C
R2
1K
RV1
470K
1M
PAUSE
C3
100µ
RELAY
RELAIS
RELE
R3
1K
1N4148
LD1
3mm LED
RY...
D3
1N4007
RY1
D1
VR15M121C
J1
1
2
SCREW02
J2
1
2
3
SCREW03
+12V
GND
NO
COM
NC
Capacitor - Condensateur
4
◊ C1: 100nF (104, µ1)
5
CATHODE
Cathode !
LED
COLOR= 2...5
LD...
◊LD1: 3mm
Watch the polarity !
IC Socket - IC voet Support de CI - IC Fuß -
6
Soporto del CI - IC
Sockel - Mikropiirkanta IC sokkel - Zoccolo IC
NC
NO
A
PULSE
COM
NC
NO
A
PULSE
COM
0.5 .... 5s
A
NC
COM
MAX 24V / 3A
NO
NC
NO
PAUSE
B
COM
B
2.5 .... 60s
12... 15VDC / 100mA
