Soldering - Solderen - Soudage - Löten - Soldadura - Lödning - Juottami nen - Saldatura - Solda
START
4
◊ SW1
max.
40W
1
PUSHBUTTON
1 3
Resistor - Weerstand -
Résistance - W i derstand -
Resistencia - Motstand Vastus - Resistenze
CAPACITOR
2
R...
◊ R1,R2:
◊ R3, ...,
◊ R15 : 0
c...
◊ C1 : 100nF (104) µ1
IC SOCKET
5
◊ IC1 : 14P
◊ IC2 : 6P
2
(Yellow, Purple, Orange) -(Geel, Paars, Oranje) -(Jaune, Violet, Orange) -(Gelb, Violet,
Orange) -(Gul, Lila, Orange) -(Keltainen, Purppura, Oranssi) - (Amarillo, Morado,
47K
Naranjado) -(Amarelo, Violeta, Laranja) - (Giallo, Viola, Aranciato)
(Red, Red, Brown) -(Rood, Rood, Bruin) -(Rouge, Rouge, Brun) -(Rot, Rot, Braun) (Röd, Röd, Brun) -(Punainen, Punainen, Ruskea) -(Rojo, Rojo, Marrón) -(Encarnado,
R14 :
Encarnado, Castanho) -(Rosso, Rosso, Marrone)
220
(Black) -(zwart) -(noir) -(Schwarz) -(Svart) -(Musta) -(Negro) (Preto) -(Nero)
LEDs
0 :
3
CATHODE
TRANSISTOR
6
◊ T1 : BC557
Yellow/Geel/Jaune/Gelb/Gul/Keltainen/
Amarillo/Amarelo/Giallo
32,19,21,25,34,27,36,30,23,5,16,1,14,9,18,7,
12,3 :
Red/Rood/Rouge/Rot/Röd/Punainen/Rojo/
Encarnado/Rosso
15,4,2,17,6,13,11,8,10,24,33,20,31,22,29,28,
35,26 :
Green/Groen/Vert/Grün/Grön/Vihreä/Verde
Watch the polarity !
Att. à la polarité !
7
◊ BUZ1
8
IC
9
BATTERY HOLDER
3
1
2
Watch the position of the
Attention à la position de
notch !
l'encoche !
+V
VDD
1
C1
IC1
100n
GND
4
RB3/MCLR/Vpp
R1
47K
3 x AA Battery
RB4/OSC2/CLKOUT
PIC16C505-20/P
+
GND
RB5/OSC1/CLKIN
RC5/T0CKI
VSS
14
GND
GND
13
RB0
12
RB1
11
RB2
3
2
10
RC0
9
RC1
8
RC2
7
RC3
6
RC4
5
+V
◊ IC1 : VMK119 (prog. PIC16C505)
◊ IC2 : 4N33 or eq.
BUZZER
+V
+V
+
R2
47K
T1
R14
BC557
220
5 4
+
BUZ1
GND
GND
START
SW1
R3
220
29
7
R4
220
28
12
R5
35
220
R6
220
R7
220
R8
220
R9
220
R10
220
R11
220
R12
220
R13
220
R15
1 2
6
IC2
4N27
3
26
DIAGRAM
0
32
15
19
4
21
2
25
17
34
6
27
13
36
11
30
8
23
10
5
24
16
33
1
20
14
31
9
22
0
18
