STEALTH 10
CORE
WIRED PASSIVE SOUNDBAR
USER MANUAL
wetsounds.com
1.
PASSION. PERFORMANCE. RUGGED FOR THE GREAT OUTDOORS!
Thank you for choosing Wet Sounds for your high performance Audio system!
We build every product with Unsurpassed PASSION so we can deliver
the HIGHEST PERFORMING Products to you! We live and breathe high
performance audio. So you can enjoy the very best system options available for
your vehicle.
The STEALTH Series Sound bars are designed to give every owner of a Boat,
UTV, Golf Cart and virtually any vehicle the ability to add high performance Audio
in a SIMPLE to use design. Made for the great outdoors the STEALTH Series
Sound Bars are designed to be simple & easy audio options for your vehicle.
We appreciate your passion for great audio! Thank you for choosing Wet Sounds
for your high performance audio needs.
www.wetsounds.com
Thank You.
For further questions, please call 1-877-938-7757 or check us out on the web.
STEALTH 6/10 CORE SOUND BAR SPECIFICATIONS
Easy mounting with multiple options
• Includes direct mounting bolts and L Brackets
• Optional Round & Square Pipe Mounting Brackets Available
Passive / Non Amplied Sound Bar
• 4 ohms per channel
• 75 watts RMS x 2 Minimum
• 100 watts RMS x 2 Suggested (STEALTH 6 CORE)
• 150 Watts RMS x 2 Suggested (STEALTH 10 CORE)
• 14 Gauge OFC Copper Speaker Wire Recommended
• Weight - 19 lbs
Recommended Wet Sounds Amps
• STEALTH 6 CORE – SYN Micro or HT 4 (on 2 channels)
• STEALTH 10 CORE – HT-2
• Recommended Amplier crossover settings – High pass @ 100Hz
Other recommendations
• Loc-tite all hardware to prevent loosening of bolts
• Use protective wire loom on all wiring to prevent shorts
2.
STEALTH 10 CORE SOUND BAR SPECIFICATIONS
INSTALLATION
A. Instructions
1. Fit the appropriate tube clamp around the front strut in the desired location.
*Note: you may need to remove bolts connecting the top to the front
strut to complete this step.
2. If a sliding adapter was supplied in your kit, you will need to loosely fasten it to
the soundbar, and then to the round tube clamps installed in step 1.
3. Ensure that the sound bar is in the desired location, then tighten all hardware.
B. Wiring
STEALTH 10 & 6 CORE Sound Bars are designed to be connected to a
source unit or amplier.
1. Mount & wire the power amp/source unit according to the manufacturer’s
specications.
2. Run the appropriate sized speaker wire (suggested minimum 18 Gauge) to the
sound bar.
Wiring Color Codes for both units are as follows:
Red w/ White Stripe: Right + (positive) Speaker Connection
Black w/ White Stripe: Right – (negative) Speaker Connection
Solid Red: Left + (positive) Speaker Connection
Solid Black: Left – (negative) Speaker Connection
3. Tie up all excess wires.
3.
LIMITED WARRANTY
How to Obtain Warranty Service
Contact Wet Sounds, Inc. either by phone at 877-938-7757 or by email at
warranty@wetsounds.com. A service representative will assist you in the
necessary actions to verify that the problem that you are experiencing is covered
under warranty. If it is in fact a warranty issue, Wet Sounds will issue an RA
number for tracking purposes and give instructions on sending the product in for
evaluation. Wet Sounds™, Inc. How State Law Applies This warranty gives you
specic legal rights, and you may also have other rights which vary from
state to state.
Internet Warning
Wet Sounds, Inc. products sold on any non authorized web site or internet
auction site are void of any and all manufacturer’s warranty. Please contact
Wet Sounds™ at 877-938- 7757 or visit our web site at www.wetsounds.com to
search for an authorized site and/or an authorized retailer near you.
Caution & Respect
Wet Sounds™ speakers can achieve very high sound pressure levels. Please
use this product responsibly. Be aware that sound travels great distances so
please respect others. Wet Sounds, Inc. is not responsible for any violations of
the law that may be a direct result of excessive volume. Please abide by the rules
but have fun doing it.
4.
LIMITED WARRANTY
What This Warranty Covers
This is a “Limited” warranty. This warranty covers any defects in materials and
workmanship and warranty only applies to the original purchaser and is not
transferable. This warranty is also only valid if the original purchase was made
from an authorized Wet Sounds™ dealer.
How Long Coverage Lasts
This warranty runs for one year from the date of the purchase.
It is recommended to REGISTER your warranty online within 45 days of your
purchase at www.wetsounds.com – click on “warranty registration”.
What Is Not Covered
This warranty does not cover fading or discoloration caused by exposure to
sunlight or chemicals such as ammonia, household bleach, or any cleaning
material that contains abrasive substances. (For information on how to prevent
fading or discoloration, consult for recommendations on cleaning products) Wet
Sounds, Inc. does not cover the cost for removal and reinstallation of any kind.
Additionally, shipping TO Wet Sounds, Inc. is covered by the purchaser This
warranty is void and inapplicable if Wet Sounds™ deems that the product was
abused or misused; including but not limited to Speaker product that has been
improperly-powered (under or over powered), causing thermal (burnt voice
coil) and/or mechanical failure (torn surrounds or spiders), damage caused by
accident, mishandling, improper installation, negligence, normal wear and tear,
excessive water or heat damage, freight damage or products that have been
altered in any way. Product owned by anyone other than the original purchaser
from an authorized Wet Sounds dealer. (The warranty is not transferable and
will not apply to products purchased from unauthorized dealers.) Wet Sounds is
not responsible for any damages to a consumer’s boat or person from a product
failure. The warranty is void if Wet Sounds deems the product was installed
or used improperly. Wet Sounds shall not be responsible for any incidental
or consequential damages, except to the extent provided (or prohibited) by
applicable law. This warranty gives you specic legal rights, and you may also
have other rights which vary from state.
What Wet Sounds™, Inc. Will Do
Wet Sounds, Inc will repair any part of your product that proves to be defective
in materials or workmanship. In the event repair is not possible, Wet Sounds, Inc
will replace the product in question. If it is deemed necessary Wet Sounds, Inc.
will either replace the entire product with a refurbished unit or it will be replaced
with a model that is similar in price if that model is no longer available. Labor
cost and materials needed to complete this service will be at no charge to the
purchaser. Additionally, the cost of shipping TO the consumer is also covered
under this warranty.
Optional Accessories
Please visit www.wetsounds.com for more information
Stealth Clamp Square 1.25” (ST-ADP-SQ 1.25)
Stealth Clamp Square 1.0” (ST-ADP-SQ 1.0)
Stealth Clamp Square .75” (ST-ADP-SQ .75)
5.
Stealth Adapter Side Bracket (ST-ADP-SIDE BRACKET)
Stealth Clamp Round 1.75” (ST-ADP-SQ 1.75)
Stealth Clamp Round 1.5” (ST-ADP-SQ 1.5)
Wet Sounds Inc..
www.wetsounds.com
877-938-7757
9330 West Airport Blvd. Suite 170
Houston, TX 77031 - USA
