West Penn AUDIO CABLES User Manual
AUDIO CABLES
PUSH
PUSH
3.5mm
STEREO MINI
1/4”
TRS
XLR
B
C
A
Analog Audio
LEFT RIGHT
D
SPEAKON
BINDING POST
E
F
LINE LEVEL AUDIO SPEAKER LEVEL AUDIO
3.5mm - Stereo Mini Jack or Plug
Application: Audio from computer to output - Line Level Small Size
1/4” - Phone Jack or Plug
Application: Microphone inputs - Nurse Call Systems
XLR- 3 Pin Cannon “X” Series Latched Rubber Connector
Application: Most common audio connector used in Professional, Commercial and music.
Line level balanced audio signalling
RCA- Phono - Audio Style
Application: L/R stereo audio
SPEAKON - Locking Analog Audio Speaker Connector - Neutrik Branded
Binding Post (Banana Plugs) - Single Conductor Audio Connector
A
B
C
D
PRODUCT INDEX: LINE LEVEL AUDIO
Professional Line Level CMR ...........................................................
Conformable Professional Rack Cable CMR..................................
Professional Line Level CMP ................................................................
Professional Line Level Dual CMR ......................................................
Broadcast Quality CMR .................. .....................................................
Broadcast Quality CMP .................. .....................................................
Snake Line Level CMR ....... .................. .....................................................
Snake Line Level CMP ....... .................. .....................................................
Aquaseal Indoor/Outdoor Audio ...................................................
Aquaseal Snake Line Level CM............................................................
AES/EBU Digital Audio Cables .......... ..............................................
Wireless Mic 50Ohm Coax .......... ......... ..........................................
Line Level Connectors XLR,3.5mm, 1/4”, RCA.............................
Line Level Assemblies ..........................................................................
Audio Panels and Plates ..................................................................
PRODUCT INDEX: SPEAKER LEVEL
PRODUCT INDEX:
2
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15-26
27-32
E
F
WEST PENN WEST PENN
WIRE
AV, SECURITY & NETWORKING SOLUTIONS
Since 1971
www.westpenn-wpw.com | 800-245-4964 | Specifications subject to change 1
Part Number Builder
Catalog Number Color
Put Up
Length
Order Part Number
454 BK 1000
454BK1000
1a.AUDIO1-32_Layout 1 5/18/15 4:16 PM Page 1
Broadcast Audio
Miniature Audio /
22 Awg. Shielded
Catalog
No.
No. of
Pairs
Conductor
Type & Nom.
D.C.R
Insulation Type
& Thickness
Shield &
% Coverage
Drain Wire
Jacket Type &
Thickness
Nom.
O.D.
NEC
Type
Nom.
Capacitance
Jacket
Color
454
1 pair
22 AWG
(7x30)
17 Ω/Mft
PP
.008
Al. Foil
100%
22 Strd.
PVC
.020
.135
CMCMR
R
34pf/ft*
67pf/ft**
See
Color Code
Chart
Standard spool size 1000ft.
The Aluminum polyester shield is bonded to the jacket so both
can be removed with automatic stripping
equipment
Color Code
Jacket Color Jacket Color
Brown Violet
Red Gray
Orange White
Yellow Black
Green Tan
Blue Pink
Inches
Inches Inches
* Capacitance between conductors.
** Capacitance between one conductor and the
other connected to the shield
Catalog
No.
No. of
Pairs
Conductor
Type & Nom.
D.C.R
Insulation Type
& Thickness
Shield &
% Coverage
Jacket Type &
Thickness
Nom.
O.D.
NEC
Type
Nom.
Capacitance
Jacket
Color
455*
1 pair
Overcoat
22 AWG
(7x30)
17 Ω/Mft
PP
.008
Al. Foil
100%
22 Strd.
drain
PVC
.020
.138
CM R
CM R
34pf/ft*
67pf/ft**
Black
Broadcast Audio
Miniature Conformable Rack Cable /
Shielded
Description:
• ASTM Overcoat Tinned Copper • Polypropylene insulation
• Overall shield 100% coverage of aluminum polyester foil
with drain wire • Twisted pair construction
• Overall PVC jacket - Black
Applications:
Indoor for:
• Audio Circuits
• Low Voltage Power
• Line Level Audio
• Audio Rack Cabling
• Division 27 41 00
• Division 27 51 00
Inches
Inches Inches
BELDEN WPW
9451 454
Applications:
Indoor for:
• Audio Circuits
• Low Voltage Power
• Line Level Audio
• Audio Rack Cabling
• Division 27 41 00
• Division 27 51 00
COMMERCIAL/ PROFESSIONAL GRADE
Description:
• ASTM Tinned Copper • Polypropylene insulation
• Overall shield 100% coverage of aluminum polyester foil
with drain wire • Twisted pair construction
• Overall Flex PVC jacket
Rating:
• NEC Type CMR
• (UL) - C(UL) Listed
• Meets 300V requirements as specified in the NEC
• Flame Rating: UL1666
2 www.westpenn-wpw.com | 800-245-4964 | Specifications subject to change
BULK CABLES: Professional Line-Mic Level
GRAY, BLACK AND WHITE ARE STANDARD
STOCKED ITEMS.
* Some West Penn Wire items are subject to
manufacturing minimums.
1a.AUDIO1-32_Layout 1 5/18/15 4:16 PM Page 2
Catalog
No.
No. of
Pairs
Conductor
Type & Nom.
D.C.R
Insulation Type
& Thickness
Shielding
& % Coverage
Drain Wire
Jacket Type &
Thickness
Nom.
O.D.
NEC
Type
Nom.
Capacitance
Jacket
Color
D25454
1 pair
22 AWG
(7x30)
17 Ω/Mft
FEP
.007
Al. Foil
100%
22 Strd.
Flex
Plenum
.018
.130
CMCMP
P
35pf/ft*
67pf/ft**
BLACK
Description:
• ASTM Tinned Copper • FEP Insulation • Overall shield 100%
coverage of aluminum polyester foil with drain wire • Twisted
Pair Construction • Overall Flexible Plenum Jacket
Rating:
• NEC Type CMP
• (UL) - C(UL) Listed
• Meets 300 Volt
• Flame Rating: NFPA-262 Smoke & Flame Test
The Aluminum polyester shield is bonded to the jacket so both
can be removed with automatic stripping
equipment
Broadcast Audio - Plenecon II® Extra Flex
Miniature Audio / 22 Awg. Shielded Plenum
Inches
Inches Inches
Special Notes:
• The drain wire on these products
are on the inside of the foil shield
• Minimum order quantities may apply
on select jacket colors.
Color Code
D25454
1. Black, 2. Red
JACKET: Black, Red, Gray, White
Applications:
Indoor for:
• Audio Circuits
• Low Voltage Power
• Line Level Audio
• Audio Rack Cabling
• Division 27 41 00
• Division 27 51 00
Broadcast Audio
Miniature Dual Audio /
Shielded
Catalog
No.
No. of
Pairs
Conductor
Type & Nom.
D.C.R
Insulation Type
& Thickness
Shield &
% Coverage
Jacket Type &
Thickness
Nom.
O.D.
NEC
Type
Nom.
Capacitance
Jacket
Color
210454*
2 pair
22 AWG
(7x30)
17 Ω/Mft
PP
.008
Each Pair
Al. Foil
100%
22 Strd.
drain
PVC
.020
.135
x
.280
CM R
CM R
34pf/ft*
67pf/ft**
Gray
Description:
• ASTM Tinned Copper • Polypropylene insulation
• Each Pair shield 100% coverage of aluminum polyester
foil with 22 AWG TC drain wire • Figure 8 ZIP
CONSTRUCTION • Twisted pair construction
• Overall PVC jacket
Rating:
• NEC Type CMR
• (UL) - C(UL) Listed
• Meets 300V requirements as specified in the NEC
• Flame Rating: UL1685
Standard spool size 1000ft.
* Capacitance between conductors.
** Capacitance between one conductor and the
other connected to the shield
Color Code
210454
1. Black, Red 2. Black, White
JACKET: Gray
Special Notes:
• The Aluminum polyester foil is bonded to
the jacket- 210454 only
• 210454 Overall jacket is Gray with one
channel imprinted for identification
Inches
Inches Inches
BELDEN WPW
9451P D25454
BELDEN WPW
9451D 210454
www.westpenn-wpw.com | 800-245-4964 | Specifications subject to change 3
BULK CABLES: Professional Line-Mic Level
* Some West Penn Wire items are subject to
manufacturing minimums.
1a.AUDIO1-32_Layout 1 5/18/15 4:16 PM Page 3
Applications:
Indoor for:
• Audio Circuits
• Low Voltage Power
• Line Level Audio
• Audio Rack Cabling
• Division 27 41 00
• Division 27 51 00
BROADCAST QUALITY
Professional Audio
Twisted Pair /
Overall Shielded
Catalog
No.
No. of
Pairs
Conductor
Type & Nom.
D.C.R
Insulation Type
& Thickness
Shield &
% Coverage
Drain Wire
Jacket Type &
Thickness
Nom.
O.D.
NEC
Type
Nom.
Capacitance
Jacket
Color
77291
1 Pair
22 AWG
(7x30)
17 Ω/Mft
PE
.016
Al. Foil
100%
22 Strd.
PVC
.025
.175
CM
CM 24pf/ft*
47pf/ft **
Gray
77292
1 Pair
20 AWG
(7x28)
10.5 Ω/Mft
PE
.016
Al. Foil
100%
20 Strd.
PVC
.028
.204
CM
CM 27pf/ft*
49pf/ft**
Gray
77293
1 Pair
18 AWG
(16x30)
6.2 Ω/Mft
PE
.018
100%
Al. Foil 20
Strd.
PVC
.028
.222
CM
CM
24pf/ft*
44pf/ft**
Gray
77294
1 Pair
16 AWG
(19x29)
4.2 Ω/Mft
PE
.032
Al. Foil
100%
18 Strd.
PVC
.032
.315
CL 2
CL 2 23pf/ft*
44pf/ft**
Gray
77295
1 Pair
14 AWG
(19x27)
2.7 Ω/Mft
PE
.032
Al. Foil
100%
16 Strd.
PVC
.035
.355
CL 2
CL 2 24pf/ft*
47pf/ft**
Gray
77510†
2 Pair
22 AWG
(7x30)
17 Ω/Mft
PP
.008
Ind. Shielded
Al. Foil 100%
with 1 drain
wire
PVC
.020
.189
CM
CM 35pf/ft*
62pf/ft**
Gray
Description:
• ASTM Tinned Copper • Polyethylene or Polypropylene insulation
• Overall shield 100% coverage of aluminum polyester foil with drain
wire • Twisted pair construction • Overall PVC jacket
Rating:
• NEC Type CM or CL2
• (UL) Listed
• Meets 300V requirements as specified in the NEC
• Flame Rating: UL1685
Standard spool size 1000ft.
* Capacitance between conductors.
** Capacitance between one conductor and the
other connected to the shield
Color Code
Catalog
No.
77291, 77292, 77293, 77294, 77295 77510
Primary
Color Code
1. Black, 2. Clear 1. Black-Red, 2.White-Green
JACKET: Gray JACKET: Gray
Notes:
† - Employs individually shielded pairs with one drain
wire common to all shields.
Inches
Inches Inches
Special Notes:
• PE- Polyethylene
• PP- Polypropylene
BELDEN WPW
8761 77291
8762 77292
8760 77293
8723 77510
4 www.westpenn-wpw.com | 800-245-4964 | Specifications subject to change
BULK CABLES: Broadcast Line-Mic Level
• 500ft. Lengths may be available upon request.
Minimum quantities apply.
• Custom colored jackets may be available.
Minimum quantities apply.
* Some West Penn Wire items are subject to
manufacturing minimums.
1a.AUDIO1-32_Layout 1 5/18/15 4:16 PM Page 4
Applications:
Indoor for: Plenum Spaces
• Audio Circuits
• Low Voltage Power
• Line Level Audio
• Audio Rack Cabling
• Division 27 41 00
• Division 27 51 00
BROADCAST QUALITY
Professional Audio Plenum Cable
Twisted Pair /
Overall Shielded - Plenecon II® Extra Flex
Catalog
No.
No. of
Pairs
Conductor
Type & Nom.
D.C.R
Insulation Type
& Thickness
Shield &
& Coverage
Jacket Type &
Thickness
Nom.
O.D.
NEC
Type
Nom.
Capacitance
Jacket
Color
D25291
1 Pair
22 AWG
(7x30)
17 Ω/Mft
Teflon
.010
Al. Foil 100%
24 Strd.
Flexible
Plenum
.017
.134
CMCMP
P
25 pf/ft*
45 pf/ft **
Gray
Description:
• ASTM Tinned Copper • Teflon insulation • Overall shield
100% coverage of aluminum polyester foil with drain wire
• Twisted Pair Construction • Flexible plenum jacket
Rating:
• NEC Type CMP
• (UL)-C(UL) Listed
• Meets 300V requirements as specified in the NEC
• Flame Rating: NFPA-262 Smoke & Flame Test
Standard spool size 1000ft.
Color Code
Pair No. Colors
1 Black/ Red
JACKET: Gray
D25292
1 Pair
20 AWG
(7x28)
10.5 Ω/Mft
Teflon
.010
Al. Foil 100%
22 Strd.
Flexible
Plenum
.017
.148
CMCMP
P 27 pf/ft*
49 pf/ft **
Gray
D25293
1 Pair
18 AWG
(7x26)
6.6 Ω/Mft
Teflon
.010
Al. Foil 100%
22 Strd.
Flexible
Plenum
.017
.168
CMCMP
P 30 pf/ft*
54 pf/ft **
Gray
D25294*
1 Pair
16 AWG
(19x29)
4.4 Ω/Mft
Teflon
.010
Al. Foil 100%
22 Strd.
Flexible
Plenum
.017
.188
CMCMP
P 36 pf/ft*
65 pf/ft **
Gray
* Capacitance between conductors.
** Capacitance between one conductor and the
other connected to the shield
Inches
Inches Inches
Special Notes:
• Teflon®- Dupont Tradename for
FEP-Fluorinated Ethylene Propylene
BELDEN WPW
82761 D25291
82760 D25293
Electrical Characteristics
Nom. Vel of Propagation - 69%
Nom. Impedance Ω D25291- 55Ω
Nom. Impedance Ω D25292- 50Ω
Nom. Impedance Ω D25293- 45Ω
Nom. Impedance Ω D25294- 40Ω
www.westpenn-wpw.com | 800-245-4964 | Specifications subject to change 5
BULK CABLES: Broadcast Line-Mic Level
Part Number Builder
Catalog Number Color
Put Up
Length
Order Part Number
D25292 GY 1000
D25291GY1000
• 500ft. Lengths may be available upon request.
Minimum quantities apply.
• Custom colored jackets may be available.
Minimum quantities apply.
* Some West Penn Wire items are subject to
manufacturing minimums.
1a.AUDIO1-32_Layout 1 5/18/15 4:16 PM Page 5
Loading...
