True-Fit Earphones
User’s Guide
Insertion Instructions
Care and Maintenance
Hearing Care Information
Warranty
Earpiece Care and Maintenance
Congratulations on your choice of Westone True-Fit Earphones! The information in this
booklet will help you achieve and maintain the best possible performance.
Earphone Care and Maintenance
Here are a few simple guidelines that can greatly increase both your listening enjoyment
and the lifespan of your Westone True-Fit Earphones:
• Always store your earphones in the provided case.
• Earwax build-up in the sound tube may cause decreased sound quality. Use the
included wax removal loop to carefully clean the sound tube. Never attempt to
remove earwax with any other object as this may result in damage to the earphones
and will void the warranty.
• Do not use the cord to remove the earphones from your ears. This may damage the
cord and result in poor performance. Damage of this nature is not covered by
the warranty.
• Do not expose your earphones to extreme temperatures.
• Avoid strong impacts to your earphones.
• Wipe down your earphones after each use.
• Never immerse your earphones in water.
Please Note: Moisture in your earphones can cause temporary performance issues. Do not
insert your earphones if your ears are wet. Always dry your ears completely before inserting
your earphones. Should the earphones quit working due to water or perspiration, allow them
to dry completely before attempting to use again. Minor moisture build-up should dry out
and not aect long-term performance. Ex tended exposure to moisture or submersion will
result in permanent damage (not covered by the warranty).
Insertion Instructions
IMPORTANT - Before using the earphones, be sure to turn
down the volume on your sound source.
Your True-Fit Earphones are marked with an “R” for the right
ear and an “L” for the left. A variety of ear tip styles and sizes
are provided. Some experimentation may be necessar y to
determine which provides you the most comfortable t and
best seal. When using a foam eartip, compress the foam by
rolling it between your ngers (g.1). It is not necessary to
compress any of the other eartips before insertion.
With the body of the earphone toward the back of your ear
and the cord pointing forward, insert the eartip into your ear
canal (g.2). If you have any trouble inser ting the earphone,
reach over your head with your opposite hand and gently pull
up and back on the top of your ear. This will slightly straighten
your ear canal and may allow for easier insertion. Rotate the
earphone backward slightly until seated in your ear (g.3).
If using a foam eartip, hold the earphone in place for 5 to 10
seconds to allow the foam to expand and conform to the shape
of your ear canal.
The cords should run up, over and behind your ears. The
remaining cord can either be routed behind your head and down your back or under
your chin. If routed behind your head, slide the “cord zipper” up to the base of your skull
to help limit cord movement.
Hearing Care Information
Please read this important information before using your
Westone True-Fit Earphones.
If, after using your Westone True-Fit Earphones, everything
sounds mued, or if you hear ringing or buzzing, your
ears are trying to give you a warning! These symptoms are
normally associated with a condition known as Temporary
Threshold Shift and are an indication of conditions that could
lead to permanent hearing loss.
While no two individuals’ hearing sensitivity is exactly the
same, there are established safety guidelines for sound
levels versus time of exposure. The chart to the right is based
on OSHA’s (Occupational Safety and Health Administration)
exposure information for industry. Remember that these
guidelines are based on average hearing sensitivity – your
sensitivity may be above or below these levels.
The use of any earphone oers benets and risks. Westone True-Fit Earphones can lower
ambient sound levels approximately 25 dB when properly worn. However, the performance
capabilities of the earphones can allow the user to negate the benets of hearing protection
from ambient sound. We want you listening for a lifetime!
Remember, personal hearing protection is your responsibility!
Maximum
dB level exposure time
85 8 hr.
90 4 hr.
95 2 hr.
100 1 hr.
105 30 min.
110 15 min.
115 7.5 min.
Important Information
Important:
Used wisely, your new earphones will provide years of enjoyment.
Noise-induced hearing loss is preventable but often undetected until it is too late. Westone
and the Electronic Industries Association’s Consumer Electronics Group recommend you
avoid prolonged exposure to excessive noise. Used responsibly, your True-Fit Earphones can
help prevent noise-induced hearing loss. If you have questions, contact your audiologist or
hearing care professional.
Be sure to observe the following guidelines:
• Do not turn up the volume so high that you can’t hear what’s around you.
• You should use extreme caution or temporarily discontinue use in potentially
hazardous situations.
• Do not use while operating a motorized vehicle as it may create a trac hazard
and is illegal in many areas.
For more information or to purchase additional Westone products and accessories, please
visit our website at www.westone.com or call 1-800-525-5071.
Limited Product Warranty
Westone warrants this product to be free of defec ts in material or workmanship for a period of
one year from the date of original retail purchase. If your product is found to be defective during
the warranty period, Westone will, at its sole option, either repair the product or replace the
product with a new or factory reconditioned or equivalent model. This limited warranty does not
apply to any defects attributable to damage beyond the reasonable control of Westone including
damage caused by abuse, misuse, misapplication or modications performed by anyone other than
Westone.
Requesting a Warranty Repair
If your product is not functioning properly, rst ensure that the sound bore is not blocked by earwax
and that the unit is completely dry. Performing these simple troubleshooting steps could solve
the problem and eliminate the need for a factory repair. If it is necessary to return your product to
Westone for warranty or post-warranty service, please email music@westone.com or call 1-800525-5071 for additional instructions and to obtain a return authorization number.
IMPORTANT:
Please include a description of the problem, the address to which the product should be returned,
your name, phone number, email address and a copy of the purchase receipt.
Limitation of Liability
Westone disclaims any and all implied warranties, warranties of merchantability and tness for a
particular purpose to the maximum extent permissible by law. Westone shall not be liable for any
special, incidental or consequential damages caused by the use, misuse, or inability to use this
product. If purchased under a government contract, those contrac t terms supersede terms stated
herein.
At Westone, we value your satisfaction.
If you have any questions, please contact us by
email at music@westone.com or call 1-800-525-5071.
© Westone Laboratories, Inc.
PN 92381 10/08
