USER MANUAL

WHE6170, WHE6270

REFRIGERATOR

2 www.westinghouse.com

Contents

1. SAFETY INFORMATION ........................................................................................................................ 3

2. DESCRIPTION OF THE APPLIANCE .................................................................................................. 5

3. ABOUT THE USER INTERFACE ........................................................................................................... 6

4. INSTALLING YOUR NEW APPLIANCE .............................................................................................. 9

5. USING YOUR REFRIGERATOR ...........................................................................................................13

6. CLEANING YOUR REFRIGERATOR ................................................................................................... 18

7. FOOD STORAGE GUIDE ......................................................................................................................20

8. TROUBLESHOOTING ............................................................................................................................21

WE’RE THINKING OF YOU

Thank you for choosing Westinghouse. We have designed this product to make your life simpler and deliver impeccable performance for many years. Please spend a few minutes reading this document to get the best from your new Electrolux appliance.

Visit our website to:

Get usage advice or service information: www.westinghouse.com

www.westinghouse.com/support/register-warranty

Buy Accessories, Consumables and Original spare parts for your appliance: www.westinghouse/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts. When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number. The information can be found on the rating plate which is located inside the product.

Warning / Caution-Safety information.

General information and tips. Environmental information.

Subject to change without notice.

1. SAFETY INFORMATION

Note: You must read these warnings carefully before installing or using the refrigerator. If you need assistance, contact your customer care centre. The manufacturer will not accept liability, should these instructions or any other safety instructions incorporated in this book be ignored.

WARNING

• It is essential the electric outlet is properly earthed to ground. Consult a qualiﬁed electrician if you are unsure.

• Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

• Unplug the refrigerator before cleaning or moving it to avoid electric shock.

• Never unplug the refrigerator by pulling the electrical cord as this may damage it. Grip the plug ﬁrmly and pull straight out.

• If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualiﬁed persons in order to avoid a hazard.

• Don’t use a steam cleaner. If live components come into contact with condensing steam, they may short-circuit or cause an electric shock.

• Do not store explosive substances such as aerosol cans with a ﬂammable propellant this appliance. If pressurised aerosol containers bear the word ‘ﬂammable’ and/ or a small ﬂame symbol, do not store them inside any refrigerator or freezer.If you do so you may cause an explosion.

• Do not damage the refrigerant circuit.

• This appliance contains insulation formed with ﬂammable blowing gases. Avoid safety hazards by carefully disposing of this appliance.

• If you wish to discard this refrigerator, please contact your local authorities and ask for the correct method of disposal.

• When you dispose of your old refrigerators and freezers, remove any doors. Children can suocate if they get trapped inside.

• When positioning the appliance, ensure the supply cord is not trapped or damaged.

• Do not locate multiple portable socket outlets or portable power supplies at the rear of the appliance.

WARNING R600a refrigerant warning

This appliance contains ﬂammable R600a refrigerant. Avoid safety hazards by carefully installing, handling, servicing and disposing of this appliance.

• Ensure that the tubing of the refrigerant circuit is not damaged during transportation and installation.

• Leaking refrigerant may cause eye injuries or ignite.

• The room for installing appliance must be at least 1m3 per 8g of refrigerant. The amount of refrigerant in the appliance can be found on the rating plate inside the appliance.

• If you are unsure of the refrigerant check the rating plate inside the refrigerator compartment.

• It is hazardous for anyone other than an Authorised Service Person to service this appliance. In Queensland Australia the Authorisation Service Person MUST hold a Gas Work Authorisation for hydrocarbon refrigerants to carry out servicing or repairs which involve the removal of covers.

• Keep ventilation openings in the appliance enclosure or in the built-in structure, clear of obstruction.

• Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

WARNING

Stable Footing When your refrigerator is in place, you need to stabilise it. Lift the front of the refrigerator to take the weight o each stability foot and make small quarter turns to each foot until it is in ﬁrm contact with the ﬂoor. If you intend to move the refrigerator, remember to wind up each foot so that you can move it freely. Repeat the process of the foot adjustment once you have settled on the new location of the refrigerator.

4 www.westinghouse.com

Side View

Stabilising foot wound down

GENERAL WARNINGS Read the following carefully to avoid damage or injury. It is important to use your refrigerator safely. Check these safety points before using your refrigerator.

• The appliance must be plugged into its own dedicated electrical outlet.

• The plug must be accessible when the refrigerator is in position.

• It is essential the powerpoint is properly earthed to ground. Consult a qualiﬁed electrician if you are unsure.

• Don’t use extension cords or adapter plugs with this refrigerator.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualiﬁed persons in order to avoid a hazard.

• Unplug the appliance before cleaning and before changing the light bulb (when ﬁtted) to avoid electric shock.

• Never unplug the refrigerator by pulling the electrical cord as this may damage it. Grip the plug ﬁrmly and pull straight out.

• Choose a location for your refrigerator that isn’t too cold. The ambient room temperature should be above 10°C.

• Stand your refrigerator in a dry place avoid areas of high moisture or humidity.

• Don’t put the refrigerator in frosty or unprotected areas like a garage or on the verandah.

• Don’t plug your refrigerator into a timer ﬁtted to the powerpoint.

• Do not put the refrigerator in direct sunlight, near stoves, ﬁres or heaters.

• Do not put the refrigerator on an uneven surface.

• Do not store ﬂammable materials on or under the appliance, e.g. aerosols.

• Do not store explosive substances such as aerosol cans with a ﬂammable propellant in this appliance.

• Never store ﬁzzy drinks in the freezer compartment.

• Never try to repair the refrigerator yourself, only use a qualiﬁed or authorised service person for repairs.

• Never use electric heaters or dryers to defrost the freezer because you can receive an electric shock

• When transporting and installing the refrigerator, care should be taken to ensure that no parts of the refrigerating circuit are damaged.

• Keep ventilation openings in the appliance enclosure or in the built-in structure clear of obstruction.

• When installed correctly, your refrigerator should: – Have adequate space at the back and sides for air circulation. – Be vertically aligned to the surrouning cupboards. – Have doors that will self-close from a partially open position.

• The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.

• Children being supervised not to play with the appliance.

NOTE: You must read these warnings carefully before installing or using the refrigerator. If you need assistance, contact your Customer Care Department. The manufacturer will not accept liability, should these instructions or any other safety instructions incorporated in this book be ignored.

Environmental information.

This appliance is intended to be used in household and similar applications such as:

• The kitchen areas in shops, oﬃces and other working enviroments

• Farm house and by clients in hotels, motels and other residential type enviroments

• Bed and breakfast type environments

• Catering and similar non-retail applications

2. DESCRIPTION OF THE APPLIANCE

The details of the refrigerator feature:

Ice Maker

Air distributor - Multiﬂow

Air ﬁlter

Water ﬁlter

Flip up glass shelf

Slide/fold glass shelf

Left Glass shelf

Right Glass shelf

Crisper shelf cover

Left crisper

Right crisper

Left Snack Zone compartment

Right Snack Zone compartment

Egg Tray

Upper ﬁxed door bin

Left ﬁxed door bin

FlexStorTM dairy bin

22 23

10 11

12 13

Adjustable Door 1/3 bin

Adjustable Door 2/3 bin

Adjustable Expandable bin

Bottle storage bin

Adjustable left hinge

Adjustable right hinge

Drawer

Drawer divider

Upper freezer drawer

Lower freezer basket

Lower freezer basket divider

Refrigerator Door Handles

Drawer Door handles

Refrigerator/Freezer control panel

Water and Ice Dispenser Trigger

Drawer control panel

6 www.westinghouse.com

3. ABOUT THE USER INTERFACE

3.1 External user interface

BUTTON/

DESCRIPTION PRIMARY FUNCTION

ICON

1 Quick Freeze

(on/o)

Activates a faster rate for freezing food in the freezer. Deactivates after 12 hours.

2 Drinks Chill Quickly chills a drink inside the freezer compartment.

Touch the Drinks Chill Key, a time value will display on the freezer temp display (in minutes) and can be changed using the +/- buttons. A tone will sound when the time has been input. Range is from 20-45 minutes in 5 minute intervals.

3 Ice Maker When LED is lit, the ice maker is on. When ice maker is

in OFF state, the indicator will blink when dispensing ice. Press and hold for 3 seconds to turn ice maker on/o.

4 Lock Press and hold for 3 seconds to enable/disable. While

in the locked state, you will not be able to change any settings on the display nor dispense ice and water. The indicator will ﬂash and an audible warning tone is played.

5 Adjusting Temp Press either the + or - to adjust to desired temperature

setting. Freezer temp - Control temperatures range From -23°C to -15°C. Refrigerator temp - Control temperatures range From +1°C to +7°C. How to change the °F/°C Mode: Press and hold for 5 seconds + and - on the refrigerator side. A tone will be heard. The display will then revert to either °F/°C mode

6 Door Open Illuminates and sounds an alarm when the door is left

open for 5 minutes or more. It stays illuminated as long as the door is open. Pressing any key will mute and reset the alarm.

7 Replace Water

Filter

Display illuminates every 6 months or when ﬁlter needs replacing. Press and hold ‘Reset Water Filter’ for 3 seconds to reset.

BUTTON/

DESCRIPTION PRIMARY FUNCTION

ICON

8 Replace Air Filter Display illuminates every 6 months or when ﬁlter needs

replacing. Press and hold ‘Reset Air Filter’ for 3 seconds to reset.

9 Water Press the “water” key to select water. An indicator light will

be illuminated above the active feature.

10 Cubed Ice Press the “cube” key to select cubed ice. An indicator light

will be illuminated above the active feature.

11 Crushed Ice Press the “crush” key to select crushed ice. An indicator

light will be illuminated above the active feature.

12 Quick Chill Quick chill is a faster rate for chilling food in the

refrigerator compartment. Deactivates after 6 hours.

13 Reset Air Filter After replacing ﬁlter, press and hold for 3 seconds to reset.

14 Reset Water Filter After replacing ﬁlter, press and hold for 3 seconds to reset.

15 Lighting Press the light button to turn on/o the dispenser light.

If you press and hold it for 3 sec. it will toggle on/o the handles ambient lighting.

3.2 Internal user interface

BUTTON/

DESCRIPTION PRIMARY FUNCTION

2 3 4 5 6

ICON

1 Unlock The interface will automatically lock after 3 seconds

without any interaction. Press and hold 3 seconds to unlock the interface. A tone will sound to conﬁrm your choice.

2 Freezer Choosing Freezer will set drawer temperature to the same

temperature as the freezer compartment. A tone will sound to conﬁrm your choice.

3 Ultra Chill Choosing Ultra Chill will set drawer temperature to -2°C. A

tone will sound to conﬁrm your choice.

4 Cold Drinks Choosing Cold Drinks will set drawer temperature to 0°C.

A tone will sound to conﬁrm your choice.

5 Deli Snacks Choosing Deli Snacks will set drawer temperature to 3°C.

A tone will sound to conﬁrm your choice.

6 Chilled Wine Choosing Chilled Wine will set drawer temperature to 7°C.

A tone will sound to conﬁrm your choice.

8 www.westinghouse.com

3.3 Setting cooling temperatures

Note: The recommended settings for a product installed in a kitchen is 3˚C for the fresh food compartment and -17˚C for the freezer.

IMPORTANT

If your product has food freezing in the fresh food compartment, increase the temperature setting 1 or 2 degrees Celsius.

If you place food within 2 cm in front of the air ports, there may be the chance of freezing food.

Air Port

Note: Control features and alarms may vary by model.

Alerts and Alarms

Water Filter

When illuminated, the water ﬁlter needs to be replaced. Change the water ﬁlter every 6 months or when 454 litres of water has been dispensed. To reset, press and hold button for 3 seconds. Tone will sound once it has been reset.

Door Open

If a door has been left open for 5 minutes or more, an alarm will sound and the door open indicator will illuminate on the display. The alarm can be turned o by closing the door or pressing any key. Control panel will return to normal operation after the door is closed.

Error Tone

An alarm will sound if the user tries to make a selection that is not available.

Sabbath Mode

The Sabbath Mode is a feature that disables portions of the refrigerator and its controls in accordance with observance of the weekly Sabbath and religious holidays within the Orthodox Jewish community.

Sabbath Mode is turned ON and OFF by simultaneously pressing and holding both the “-” (freezer side) and “+” (refrigerator side) for ﬁve seconds. Other than the High Temp alarm, no audible sounds will occur until the user exits the Sabbath mode. The display shows “Sb” while in Sabbath mode.

In the Sabbath Mode, the High Temp alarm is active for health reasons. For example,

If the door is left ajar the High Temp alarm is activated. The refrigerator will function normally once the door is closed, without any violation of the Sabbath/Holidays. The High Temp alarm is permitted when cabinet temperature is outside the safe zone for 20 minutes. The alarm silences itself after 10 minutes while the High Temp icon stays lit until the Sabbath mode is exited.

Air Filter Installation

First operation the refrigerator need to installation the air ﬁlter which storage at crisper left side and follow installation method as below. Carbon activated air ﬁlter

1) Remove plastic wrap.

2) Install ﬁlter according to your refrigerator’s use&care guide.

3) Reset ﬁlter reminder light on your refrigerator.

4) Replace ﬁlter every 6 months. When illuminated, air ﬁlter needs to be replaced. Change the air ﬁlter every 6 months. To reset, press and hold button for 3 seconds. Tone will sounds once it has been reset.

Note: While in Sabbath Mode, neither the lights, dispenser, nor the control panel will work until Sabbath Mode is deactivated.

Refrigerator stays in Sabbath Mode after power failure recovery. It must be deactivated with the buttons on the control panel.

Although you have entered the Sabbath Mode, the ice maker will complete the cycle it had already initiated. The ice cube compartment will remain cold and new ice cubes can be made with standard trays.

4. INSTALLING YOUR NEW APPLIANCE

Front face of bench

aligned to front corner

edge of cabinet.

35 mm

Front face of bench

aligned to front corner

edge of cabinet.

913

749

1782

35 mm

25 mm

Unpacking

ENVIRONMENT

Most of the packing materials are recyclable. Please dispose of those materials through your local recycling depot or by placing them in appropriate collection containers.

Important – check for any damages or marks. If you ﬁnd the refrigerator is damaged or marked, you must report it within 7 days should you wish to claim for damage/marks under the manufacturers warranty. This does not aect your statutory rights.

Clean your refrigerator thoroughly following the instructions in the “Cleaning” section and wipe o any dust that has accumulated during shipping.

Locating the refrigerator

CAUTION

Automatic aerosol systems (such as insect control) should not be located adjacent to the product as the spray may cause long term damage to the external plastics of the appliance.

Do not put the refrigerator in a location that is too cold or is unprotected, for example in a garage or on a veranda. The ambient temperature should be above 10°C.

When positioned in a corner area, spacing of right side at least 260 mm and left side at least 355 mm on the hinge side will allow the doors to open enough to enable the removal of bins and shelves.

35 mm

Front face of bench

aligned to front corner

edge of cabinet.

Note: Doors are designed to sit proud of cabinetry (not ﬂush). The clearances shown above are the recommended minimum clearances.

Installing your refrigerator

Allow the following clearances for ease of installation, proper air circulation, and plumbing and electrical connections:

913

1782

749

Put the refrigerator in a dry place avoiding areas of high moisture or humidity. Ensure the refrigerator is located on an even surface.

Adequate ventilation around your refrigerator

Note: If your refrigerator is placed with the door hinge side against a wall, you may have to allow additional space so the door can be

opened wider. The diagram below shows the recommened airspace to allow for ventilation of your refrigerator.

10 www.westinghouse.com

Door opening

Your refrigerator should be positioned to allow easy access to a counter when removing food. For best use of refrigerator drawers and freezer baskets, the refrigerator should be in a position where both can be fully opened.

CAUTION

LED lighting Your appliance is ﬁtted with long life LED lighting. In the unlikely event the LED lights should fail, then the LED lights should be serviced by the service agent, to avoid a safety hazard. Refer to the warranty page for contact details.

Cabinet Leveling & Refrigerator Door Alignment (if necessary)

Guidelines for ﬁnal positioning of your refrigerator:

• All four corners of the cabinet must rest ﬁrmly on the ﬂoor.

• The front should be slightly elevated to ensure that doors close and seal properly.

• Doors should align with each other and be level. Most of these conditions can be met by raising or lowering the adjustable front rollers.

To level the cabinet using the front rollers:

1. Slightly open freezer drawer if the toe grill is installed. Lift the toe grille and gently pull forward.

2. Make initial cabinet adjustments by using the front roller height adjusting screws. Use a 3/8 inch socket wrench to turn the adjustment screws (1 per side). To raise: turn adjustment screw clockwise. To lower: turn adjustment screw counter clockwise.

3. Ensure both doors are bind-free with their seals touching the cabinet on all four sides and that cabinet is stable.

4. After unit is leveled, lower anti-tip leg using a 3/8 inch socket wrench until it ﬁrmly contacts the ﬂoor.

Door

Anti-tip

legs

To make ﬁnal door height adjustments:

1. Open freezer drawer to make lower hinge visible.

2. Insert 6mm Allen wrench into the shaft of the lower hinge.

3. Adjust the height by turning clockwise or counterclockwise. Turning wise will lower the door. Turning counterclockwise will raise the door. Default setting is to the lowest height when you receive your appliance.

Raise

Flipper Mullion

Adjust Flipper Mullion for proper connection with the mullion guide by ensuring the ﬂipper mullion is folded and perpendicular to the fresh food door. If the mullion guide is not in the correct position, it could prevent the door from closing completely.

WRONG

Connecting the water supply

WARNING

To avoid electric shock, which can cause death or severe personal injury, disconnect the refrigerator from electrical power before connecting a water supply line to the refrigerator.

WARNING

To Avoid Property Damage:

• DO NOT install water supply tubing in areas where temperatures fall below freezing.

• Chemicals from a malfunctioning water softener can damage the ice maker. If your home has a water softening system, ensure the softener is maintained and working properly.

Before Installing the Water Supply Line, You Will Need:

• Basic Tools: adjustable wrench, ﬂatblade screwdriver, and PhillipsTM screwdriver

• The water dispenser and automatic ice maker require a drinkable water supply with a pressure range of between 206kPa and 689kPa (30PSI and 100PSI). If the water supply is above 100psi a pressure limiting valve should be installed.

• A water supply to suit a ½” tap ﬁtting is required adjacent to the refrigerator. It is recommended that a licensed plumber install a new water supply outlet nearer to the appliance should the tubing supplied not be long enough. It is not recommended that the tubing be extended as this could adversely aect the ﬂow of water to the ice maker or water dispenser. If there is a risk of ﬂow rate higher than the maximum ﬂow rate 2.46 L/min, a ﬂow controller should be installed.

WARNING

Connect to potable water supply only. If using tank or bore water it is recommended to also use an external ﬁlter (not supplied).

The new hose-sets supplied with the appliances must be used and old hose-sets should not be reused.

WARNING

Never connect the appliance to a hot water supply.

Do not use with water that is microbiologically unsafe or with water of unknown quality without adequate disinfection.

IMPORTANT

Ensure that your water supply line connections comply with all local plumbing codes.

The appliance complies with the relevant backﬂow prevention requirements speciﬁed in AS/NZS

2845.1

12 www.westinghouse.com

Figure 3

Connector to connect the water supply line to the refrigerator tube

Adapter to connect the

water supply

Figure 3

To Connect Water Supply Line to Ice Maker Inlet Valve

Installation kit supplied with Refrigerator:

Figure 1

A - Adapter ½ to ¼ inch to connect the water supply outlet to the water supply line.

B - Water supply line ¼ inch with 3 meters in length.

C - ¼ inch connector to connect the water supply line to the refrigerator tube.

1. Disconnect the refrigerator from the power source.

2. Attach the adapter (item A above) to the water line, connect the water supply line (item B) to the adapter (item A) while holding the other end of the water supply line in a bucket or sink Turn on the water supply to eliminate air and clean the water supply line. Turn o the water supply.

3. Remove the plastic protector from the refrigerator tube and connect the water supply line (item B) to the refrigerator tube using the connector (item C) as shown in ﬁg. Make sure the tubes are inserted completely into the connections. Lock the tubes in the clamp to keep the correct position

4. Wrap excess water supply line behind refrigerator so that it does not vibrate with refrigerator operation. Do not twist the pipe.

5. Turn on the water supply, check that there are no leaks in the connections.

6. Reconnect the refrigerator to the power source.

7. The Ice Maker is factory-switched, within 24 hours your refrigerator will have produced ice, discard the ﬁrst production.

Note: Expect the ﬁrst ice harvest within ﬁrst 24 hours of unit operation. To prevent any issues concerning ice production, please ensure that all water lines are

primed. See “Priming the water supply system “in the “AUTOMATIC ICE & WATER DISPENSER” section.

Remove the cap from the

Figure

water supply

inlet tube

inch

water valve

plaﬆic

tube

Plastic cap

Adapter to connect the

Connector to connect the water supply line to the refrigerator tube

IMPORTANT

Your refrigerator’s water supply system includes several tubing lines, a water ﬁlter, and a water valve. To ensure that your water dispenser works properly, this system must be completely ﬁlled with water when your refrigerator is ﬁrst connected to the household water supply line.

Water Filter The water ﬁlter should not be used on

water that is micro biologically unsafe or with water of unknown quality. The service life of the ﬁlter may be reduced in water supplies that contain an excess of particles or other impurities. Reduced ﬂow rate is an indication that a new ﬁlter is required. Failure to replace the ﬁlter when required can aect the function of the ice maker. Service calls caused by a failure to replace the ﬁlter are not covered by warranty. Replacement water ﬁlters are available from Electrolux Home Products Spare Parts Centres and can be posted to you for your convenience (refer to spare parts contact numbers on the warranty page).

5. USING YOUR REFRIGERATOR

AUTOMATIC ICE & WATER DISPENSER

Using the ice maker after installation

Before making ice for the ﬁrst time, be sure to prime the water supply system. Air in new plumbing lines can result in two or three empty ice maker cycles. Furthermore, if the system is not ﬂushed, the ﬁrst ice cubes may be discolored or have an odd ﬂavor.

Priming the water supply system

CAUTION

For proper dispenser operation, recommended water supply pressure should fall between 30 psi and 100 psi. Excessive pressure may cause the system to malfunction.

1. Begin ﬁlling the system by pressing and holding a drinking glass against the dispenser.

2. Keep the glass in this position until water comes out of the dispenser. It may take about 1½ minutes.

3. Continue dispensing water for about four minutes to ﬂush the system and plumbing connections of any impurities (stopping to empty the glass as necessary).

WARNING

Flushing system about 2 minutes after period of non-use exceeding 30 days

Ice maker operation & care

After the refrigerator is installed properly and has cooled for several hours, the ice maker can produce ice within 24 hours. The ice maker will ﬁll the ice bin from the rear. You must dispense some ice to force the ice forward in the bin. This will allow the bin to ﬁll completely.

Ice Maker and Storage Bin Capacity

This ice maker should produce 1,2 to 1,5 Kg of ice per 24 hours. The ice bin will hold about

1.8 Kg of ice.

Turning the ice maker on and o

IMPORTANT

Your ice maker is turned on at the factory so it can work as soon as you install your refrigerator. If you cannot connect a water supply, set the ice maker’s On/O feature to O; otherwise, the ice maker’s ﬁll valve may make a loud chattering noise when it attempts to operate without water.

Ice production is controlled by the ice maker’s On/O feature on the control panel. Pressing the On/O feature turns the ice maker on & o.

Dispenser

Note: The water dispenser has a built-in device that shuts o the water ﬂow after two minutes of continuous use. To reset this shut-o device, simply release the dispenser paddle.

Only the ﬁrst 26 ounces (750 ml) of dispensed water is chilled.

Note: The ice maker also has a built-in plastic signal arm that automatically stops ice production when the ice bin is full. This signal arm should not be used to manually stop the ice maker.

IMPORTANT

Turning o the ice maker simply disables ice making. You will still be able to dispense existing ice, and you will still be able to dispense water.

On occasion, unusually small ice cubes may be noticed in the bucket or in dispensed ice. This could occur in normal operation of the ice maker. If you start seeing these more frequently, it may be an indication of low water pressure, or that the water ﬁlter needs to be replaced. As the water ﬁlter nears the end of its useful life and becomes clogged

14 www.westinghouse.com

with particles, less water is delivered to the ice maker during each cycle. Remember, if it has been six months or longer since you last changed your water ﬁlter, replace the water ﬁlter with a new one. Poor quality household water may require the ﬁlter to be changed more frequently.

Ice maker/dispenser tips

• If your refrigerator is not connected to a

water supply or the water supply is turned o, turn o the ice maker as described in the previous section.

• The following sounds are normal when the

ice maker is operating:

- Motor running

- Ice dropping into ice bin

- Water valve opening or closing

- Running water

• If you need a large quantity of ice at one

time, it is best to get cubes directly from the ice bin.

• Ice cubes stored too long may develop an

odd ﬂavor. Empty the ice bin as explained below.

• When dispensing cubed ice, it is normal

to have a small quantity of little pieces along with the whole cubes.

• To avoid splashing, dispense ice into your

container before adding liquids.

• It is normal for ice to ﬁll to the top of the

ice bin.

Remove and empty the ice bin if:

• An extended power failure (one hour or longer) causes ice cubes in the ice bin to melt and refreeze together after power is restored, jamming the dispenser mechanism.

• You do not use the ice dispenser frequently. Ice cubes will freeze together in the bin, jamming the dispenser mechanism.

Removing Ice Bin

Remove the ice bin and shake to loosen the cubes or clean as explained above.

CAUTION

If the water supply to your refrigerator is softened, be sure the softener is properly maintained. Chemicals from a water softener can damage the ice maker.

Cleaning the ice maker

Clean the ice maker and ice bin at regular intervals, especially prior to vacation or moving.

1. Turn o the icemaker.

2. Remove the ice bin by pulling straight out.

3. Empty and carefully clean the ice bin with

mild detergent. Do not use harsh or abrasive cleaners. Do not place in dishwasher. Rinse with clear water.

4. Allow the ice bin to dry completely before

placing it back into the freezer.

5. Place ice bin back into position. Turn the

ice maker on.

CAUTION

NEVER use an ice pick or similar sharp instrument to break up the ice. This could damage the ice bin and dispenser mechanism.

To loosen stuck ice, use warm water. Before replacing the ice bin, make sure it is completely dry.

IMPORTANT

When removing or replacing the ice bin, avoid rotating the auger in the ice bin. If the auger is accidentally rotated, you must realign the auger by turning it in 45 degree turns (see below) until the ice bin ﬁts into place with the drive mechanism. If the auger is not properly aligned when replacing the ice bin, the refrigerator will not dispense ice. The fresh food door also may not close properly causing warm air to leak into the fresh food compartment.

Auger

To adjust the slide-under/ﬂip shelf:

1. Pull front half shelf forward until its back drops down, then gently push front half shelf back and under back half shelf.

Adjusting the Ice Bin Auger

STORAGE FEATURES

CAUTION

To avoid personal injury or property damage, handle tempered glass shelves carefully. Shelves may break suddenly if nicked, scratched, or exposed to sudden temperature change. Allow the glass shelves to stabilize to room temperature before cleaning. Do not wash in dishwasher.

You can easily adjust shelf positions in the fresh food compartments to suit your needs. The shelves have mounting brackets that attach to slotted supports at the rear of each compartment.

To change a shelf position:

1. Remove all food from shelf.

2. Lift the front edge up and pull the shelf out.

3. Replace by inserting the mounting bracket hooks into the desired support slots.

4. Lower the shelf and lock into position.

To adjust the ﬂip shelf:

1. Remove food from shelf.

2. Lift the right side edge of shelf upwards and push to the left towards ice maker

Slide-Under/Flip Shelf

2. With front half fully below back half, lift front of shelf to ﬂip it upwards toward the back of the cabinet.

Slide-Under/Flip Shelf

Drawers

Your refrigerator includes a variety of storage drawers.

FreshSealTM Crisper (with automatic humidity control)

Crisper drawers are designed for storing fruits, vegetables, and other fresh produce. Crispers have an auto humidity control (with replaceable membrane) on the side of each crisper under the humidity control cover.

To remove the auto humidity control membrane:

1. Reach to back of humidity control cover.

2. Pull up on cover.

3. Pull cover towards back of cabinet and remove.

4. Replace humidity membrane.

5. Replace cover by reversing the steps above. Repeat for both crispers.

Flip Shelf

16 www.westinghouse.com

Auto

Humidity

Membrane

Crisper

Doors Storage bins

The doors to your fresh food compartment use a system of modular storage bins. All of these bins are removable for easy cleaning. Bins can be adjusted to your needs. Door bins are ideal for storing jars, bottles, cans, and large drink containers. They also enable quick selection of frequently used items.

Opening the Crisper Drawer

To remove the FreshSealTM Crisper for cleaning:

1. Pull the drawer out until it stops.

2. Lift the front slightly and remove the

drawer.

Removing the FreshSealTM Crisper

Recessed SnackZone

This drawer is ideal for storage of deli meats and cheese.

Slide back the cover to allow access to the drawers.

Adjustable door bins

Some models have adjustable door bins that can be moved to suit individual needs. To adjust the collapsible door bin:

1. Make sure bin is securely seated on rail in door.

2. Grab one side of bin and place other hand on adjustable side.

3. Pull on side of bin until the bin is adjusted to desired width.

Note: It can be diﬃcult to pull out the collapsible bin. Some force may be required.

To move door bin along a rail:

1. Tilt bin up so the back of the bin is o the door but the hook is still engaged.

2. Slide bin along rail to desired position.

3. Lower bin back into place.

To move door bin from rail to rail:

1. Lift bin up disengaging the hook.

2. Move bin to desired rail location.

3. Push bin hook into rail engaging the hook.

Opening the SnackZone

Adjustable Door Bins

Freezer Features (varies by model)

Freezer Basket

To remove upper freezer basket:

1. Open freezer compartment completely.

2. Lift up and out to remove upper freezer basket. Reverse the steps to reinstall basket.

IMPORTANT

There are wheels on the bottom of the drawer. Make sure all wheels are aligned on their respective tracks for proper function. If drawer is not aligned properly, it will cause problems with the door operation.

Note: If basket is not resting on stabilizer bar retainer clips, the drawer will not close properly.

To remove lower freezer basket:

1. Open freezer compartment completely.

2. Lift the basket up and remove. Reverse the steps to reinstall drawer.

Dividers

Grab hand hold on lower divider and pull up slightly to slide to next position. (The divider cannot be removed.)

Lower Basket Divider

18 www.westinghouse.com

6. CLEANING YOUR REFRIGERATOR

WARNING

BEFORE CLEANING: Turn the refrigerator o at the power point and unplug the cord to prevent any chance of electrocuting yourself.

Doors and exterior (white and silver):

You should only clean the doors with lukewarm soapy water and a soft cloth.

Stainless Steel:

Your stainless steel refrigerator is manufactured from mark-resistant stainless steel. This stainless steel has a special advanced protective coating that eases the removal of marks such as ﬁngerprints and water spots. To keep its appearance, clean it regularly with lukewarm soapy water and a soft cloth.

CAUTION

Never use stainless steel cleaners, abrasive pads or other cleaners that will scratch the surface. Damage to the appliance after delivery is not covered by your warranty.

Interior

Clean the inside of your refrigerator regularly with a soft cloth, unscented mild soap and lukewarm water. Thoroughly dry all surfaces and removable parts and avoid getting water on the controls. Replace removable parts, plug power cord in and switch the power on before returning the food.

Door seals

Always keep door seals clean by washing them with a mild detergent and warm water, followed by a thorough drying. Sticky food and drink can cause seals to stick to the cabinet and tear when you open the door.

Never use hot water, solvents, commercial kitchen cleaners, aerosol cleaners, metal polishes, caustic or abrasive cleaners, or scourers to clean your refrigerator. Many commercially available cleaning products and detergents contain solvents that will damage your refrigerator. Use only a soft cloth with an unscented mild soap and lukewarm water.

CAUTION

To clean a crisper or freezer bin with telescopic extension slides, simply wipe with a damp cloth and warm soapy water. Never immerse the cover in water, as this could aect the operation of the slide.

Switching o your refrigerator

If you switch o your refrigerator for an extended period, follow these steps to reduce the chances of mould.

1. Remove all food.

2. Remove the power plug from the power point.

3. Thoroughly clean and dry the Interior.

4. Ensure that all the doors are wedged open slightly for air circulation.

CHANGING THE FILTER Air Filter

The air ﬁlter is located in the top center of the fresh food compartment.

Replacing your Air Filter

To ensure optimal ﬁltering of refrigerator odors, you should change the air ﬁlter six months (The ﬁlter status light on the Touch Panel prompts you to replace the ﬁlter after six month)

1. Remove the air ﬁlter cover by squeezing the sides of the cover together and removing from liner

2. Remove the old ﬁlter and discard it.

3. Unpack the new ﬁlter and slide it into the housing. The open face must (carbon media) of the ﬁlter should be installed facing the air port (hole) in the multiﬂow.

4. Replace the air ﬁlter cover by squeezing the sides and snapping it back into place.

5. Press and hold the “Reset Air Filter” button on the control panel for three seconds. When the LED turns o, the status has been reset.

Water Filter

Your refrigerator is equipped with a water ﬁltering system. The water ﬁltering system ﬁlters all dispensed drinking water, as well as the water used to produce ice. The water ﬁlter is located at the top right side of the fresh food compartment.

In general, you should change the water ﬁlter every six months to ensure the highest possible water quality. Water ﬁlter status on the user interface prompts you to replace the ﬁlter after a standard amount of water (125 gallons/473 litres) has ﬂowed through the system.

If your refrigerator has not been used for a period of time (during moving for example), change the ﬁlter before reinstalling the refrigerator

Note: When ordering your replacement ﬁlter, please reorder the same ﬁlter type that is currently in your refrigerator.

WARNING

Use the appliance with water ﬁlter supplied by Electrolux Home Products Pty Ltd or its authorised service agent only.

For correct operation of this appliance it is essential to observe the manufacturer’s instructions.

Replacing the Water Filter To Remove: Pull cover towards you and cover

will drop down and allow access to ﬁlter. To Reinstall: Push cover up towards liner

and then push towards rear of cabinet. Filter cover will snap back into place.

It is not necessary to turn the water supply o to change the ﬁlter. Be ready to wipe up any small amounts of water released during the ﬁlter replacement.

1. Ensure that the ice maker is turned o

2. Remove the ﬁlter by turning anti-clockwise 180˚

3. Slide the old water ﬁlter cartridge straight out of the housing and discard it.

4. Unwrap the new ﬁlter cartridge and using the alignment guide, slide it gently into ﬁlter housing until it stops against the ﬁlter connection at the back of the housing.

5. Engage the ﬁlter by ﬁrmly rotating clockwise until the ﬁlter snaps into position (once engaged the ﬁlter cannot be rotated further).

6. Press a drinking glass against the water dispenser while checking for any leaks at the ﬁlter housing. Any spurts and sputters that occur as the system purges air out of the dispenser system are normal.

7. After ﬁlling one glass of water, continue ﬂushing the system for about four minutes.

8. Turn on the ice maker.

9. When the ﬁlter has been replaced press and hold the ‘Reset Water Filter’ button for three seconds to reset the ﬁlter replace timer.

10.Replace ﬁlter cover by pushing up and snapping into place.

20 www.westinghouse.com

7. FOOD STORAGE GUIDE

RECOMMENDED STORAGE TIMES FOR FRESH

CATEGORY PRODUCT

MEAT Sausages and

POULTRY Chicken 1-2 Days 5-7 Days 2 Months If poultry takes on a smell or

SEAFOOD Whole ﬁsh and

DAIRY Milk Until Expiry

FRUIT & VEGETABLES

Mince

Chops and Steak 3-4 Days 5-7 Days 4-6 Months

Cold Meats 3-5 Days 5-7 Days 4-6 Months

Roasts 3-5 Days 1 week 12 Months

Roast Chicken 3-5 Days 1 week 12 Months

Eggs 6 Weeks Not Suitable Not Suitable

ﬁllets

Lobster and Crab 1-2 Days 3-5 Days 2 Months

Prawns 1-2 Days 3-5 Days 2 Months

Yoghurt 7- 10 Days Not Suitable Not Suitable

Hard Cheeses 2 Weeks – 2

Soft Cheeses 1-2 Weeks 2-4 Weeks * Not Suitable * Texture may change

Butter 8 Weeks 3-4 Months 12 Months

Every fruit and vegetable has a dierent shelf life. Some stay fresh for a couple of days e.g. beans, others can last for a couple of months e.g. onions.

FOODS *

REFRIGERATOR

1-2 Days 3-5 Days 2-3 Months Keep cold meat at the back

2-3 Days 5-7 Days 2 Months Store in an airtight container

Date

Months

ULTRA CHILL

Not Suitable Not Suitable If dairy takes on a smell or

1-2 Months 2 Months

Not Suitable 8-12 Months

FREEZER

(Grated)

When freezing chop and blanch in small portions.

STORAGE TIPS

of the refrigerator where it is coldest. Plastic can cause meat to sweat if stored in refrigerator for more than a day. Roast can take up to 48 hours to defrost properly, transfer frozen roast to the refrigerator 2 days before use.

colour you are unsure about it is best to throw it out. Whole eggs are not suitable for freezing, slightly beaten eggs may be frozen for four months.

or foil.

Never freeze prawns in salty water as this will dehydrate the ﬂesh.

colour and you are unsure about it, it is best to throw it out.

Depending on the variety hard cheese can last from 2 weeks to 2 months.

depending of the type of soft cheese

Keep vegetables in the crisper and away from the air vents to avoid freezing.

If you wash fruit and vegetables before storing them make sure they are dry or wrap in absorbent paper before storing in the refrigerator as this can make them susceptible to rotting.

Try to keep fruit and vegetables separated as fruits that give o high levels of ethylene (the ripening agent) can prematurely ripen and spoil surrounding vegetables

IMPROTANT

* Please note, use this information as a guide only, actual storage times will vary depending on how you use your refrigerator.

8. TROUBLESHOOTING

Concern Potential Cause Common Solution

Automatic Ice Maker

Ice maker is not making any ice.

Ice maker is not making enough ice.

Ice cubes are freezing together.

Dispenser (Ice & Water)

Dispenser (Ice & water) not dispensing ice.

Ice dispenser is jammed.

Dispenser (Ice & Water)

Dispenser (Ice & water) not dispensing water.

• Ice maker is turned o.

• Refrigerator is not connected to water line or water valve is not open.

• The water supply line is kinked.

• The water ﬁlter is not seated properly.

• The water ﬁlter may be clogged with foreign material.

• Ice maker is producing less ice than you expect.

• The water ﬁlter may be clogged with foreign material.

• The water supply line is kinked.

• Water pressure is extremely low. Cut-o and cut-on pressures are too low (well systems only).

• Reverse osmosis system is in regenerative phase.

• Ice cubes are not being used frequently enough or interruption of power for prolonged time.

• Ice cubes are hollow (shells of ice with water inside). The hollow cubes break open in the bin and leak their water onto existing ice, which causes it to freeze together.

• There is no ice in the bin to be dispensed.

• The refrigerator doors are not completely closed.

• Dispenser paddle has been pressed too long and the dispenser motor has overheated.

• Ice has melted and frozen around auger due to infrequent use, temperature ﬂuctuations, and/or power outages.

• Ice cubes are jammed between ice maker and back of ice container.

• Dispenser (Ice & water) not dispensing water.

• Turn on ice maker. For the fresh food ice maker, press ice maker on-o button once.

• Connect the unit to the household water supply and ensure the water valve is open.

• Ensure that the supply line does not kink when the refrigerator is pushed into place against the wall.

• Remove and re-install the water ﬁlter. Be sure to seat it fully into the locked position.

• If water dispenses slowly or not at all, or if the ﬁlter is six months old or older, it should be replaced.

• The ice maker will produce approximately 1 kg of ice every 24 hours depending on usage conditions.

• If water dispenses slower than normal, or if the ﬁlter is six months old or older, it should be replaced.

• Ensure that the supply line does not kink when the refrigerator is pushed into place against the wall.

• Have someone turn up the cut-o and cut-on pressure on the water pump system (well systems only).

• It is normal for a reverse osmosis system to be below 137 kPa (20 psi) during the regenerative phase.

• Remove ice container and discard ice. The ice maker will produce fresh supply. Ice should be used at least twice weekly to keep the cubes separated.

• This generally occurs when the ice maker does not get enough water. This is usually the result of a clogged water ﬁlter or restricted water supply. Replace the water ﬁlter and if the condition still occurs, check to see if the water valve is not turned on all the way or if there is a kinked water supply line.

• See the “Ice maker is not making any ice” section.

• Be sure the refrigerator doors are completely closed.

• The motor overload protector will reset in about three minutes and then ice can be dispensed.

• Remove ice container, thaw, and empty the contents. Clean container, wipe dry, and replace in proper position. When new ice is made, dispenser should operate.

• Remove ice cubes that are jamming the dispenser.

• Remove and reinstall the water ﬁlter. Be sure to rotate it to the right until it stops and the grip end is vertical.

• Replace ﬁlter cartridge. Be sure to rotate it to the right until it stops and the grip end is vertical.

• Open household water line valve. See CONCERN column AUTOMATIC ICE MAKER.

22 www.westinghouse.com

Concern Potential Cause Common Solution

Water not cold enough. • As warmer tap water goes

Water has an odd taste and/or odor.

Opening/Closing Of Doors/Drawer

Door(s) will not close. • Door was closed too hard,

Drawers are diﬃcult to move.

Running of Refrigerator

Compressor does not run.

Refrigerator seems to run too much or too long.

Digital Temperature Setting Display

Digital temperature displays an error.

Water/Moisture/Frost Inside Refrigerator

Moisture collects on inside of refrigerator walls.

Water collects on bottom side of drawer cover.

through the ﬁlter and enters the water supply system, the chilled water is pushed through to the dispenser. Once the chilled water is used up, it will take several hours to bring the freshly replaced water to a cooler temperature.

• Water has not been dispensed for an extended period of time.

• Unit not properly connected to cold water line.

causing other door to open slightly.

• Refrigerator is not level. It rocks on the ﬂoor when moved slightly.

• Refrigerator is touching a wall or cabinet.

• Check gasket and cabinet interface for any obstructions.

• Food is touching shelf on top of drawer.

• Track that drawers slide on is dirty.

• Refrigerator is in defrost cycle.

• Plug at electrical outlet is disconnected.

• House fuse blown or tripped circuit breaker.

• Power outage.

• Your variable speed compressor is designed to run 100% of the time except during the defrost cycle. At times it will run faster, such as after a defrost cycle.

• Electronic control system has detected a performance problem.

• Weather is hot and humid.

• Flipper mullion

• Vegetables contain and give o moisture.

• Add ice to cup or container before dispensing water.

• Draw and discard 10-12 glasses of water to freshen the supply.

• Connect unit to cold water line that supplies water to the kitchen faucet.

• Close both doors gently.

• Ensure ﬂoor is level and solid, and can adequately support the refrigerator. Contact a carpenter to correct a sagging or sloping ﬂoor.

• Clean the refrigerator door gaskets and interface with warm, soapy water to remove any grease, dirt and grime from the surface. Wipe clean with a dry cloth. Inspect the gasket to make sure it is thoroughly clean.

• Remove top layer of items in drawer.

• Ensure drawer is properly installed on track.

• Clean drawer, rollers, and track.

• See Care & Cleaning.

• This is normal for a fully automatic defrost refrigerator. The defrost cycle occurs periodically, lasting about 30 minutes.

• Ensure plug is tightly pushed into outlet.

• Check/replace fuse with a 15 amp time-delay fuse. Reset circuit breaker.

• Check house lights. Call local electric company.

• It is normal for the compressor to run continuously except during defrost mode.

• Call your Electrolux service representative, who can interpret any messages or number codes ﬂashing on the digital displays.

• The rate of frost buildup and internal sweating increases.

• Adjust ﬂipper mullion. (See “To adjust the ﬂipper mullion” in the Installation section.)

• It is not unusual to have moisture on the bottom side of the cover.

Concern Potential Cause Common Solution

Water/Moisture/Frost Inside Refrigerator

Water collects in bottom of drawer.

Water/Moisture/Frost Outside Refrigerator

Moisture collects on outside of refrigerator or between doors.

Food in Fresh Food Compartment

Food is freezing. • Temperature setting is too low.

• Washed vegetables and fruit drain while in the drawer

• Weather is humid. • This is normal in humid weather. When humidity is

• Temperature sensor is covered by food (right side of fresh food area).

• Food is covering the air ports.

• Dry items before putting them in the drawer. Water collecting in bottom of drawer is normal

lower, the moisture should disappear.

• Move the setting to a higher degree.

• Allow space for air ﬂow to the sensor.

• Allow space between the air ports and the food.

24 www.westinghouse.com

FOR SALES IN AUSTRALIA AND NEW ZEALAND

Warranty

APPLIANCE: WESTINGHOUSE REFRIGERATORS AND FREEZERS

This document sets out the terms and conditions of the product warranties for Westinghouse Appliances. It is an important document. Please keep it with your proof of purchase documents in a safe place for future reference should there be a manufacturing defect in your Appliance. This warranty is in addition to other rights you may have under the Australian Consumer Law.

1. In this warranty:

(a) ‘ACL’ or ‘Australian Consumer Law’ means Schedule 2 to the

Competition and Consumer Act 2010;

(b) ‘Appliance’ means any Electrolux product purchased by you and

accompanied by this document;

(d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products

Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004 762 341 in respect of Appliances purchased in Australia and Electrolux (NZ) Limited (collectively “Electrolux”) of 3-5 Niall Burgess Road, Mount Wellington, in respect of Appliances purchased in New Zealand;

 (e) ‘WarrantyPeriod’meanstheperiodspeciedinclause3ofthis

warranty;

(f) ‘you’ means the purchaser of the Appliance not having purchased

the Appliance for re-sale, and ‘your’ has a corresponding meaning.

2. Application: This warranty only applies to new Appliances, purchased

and used in Australia or New Zealand and is in addition to (and does not exclude, restrict, or modify in any way) other rights and remedies under a law to which the Appliances or services relate, including any nonexcludable statutory guarantees in Australia and New Zealand.

3. Warranty Period: Subject to these terms and conditions, this warranty

continues for in Australia for a period of 24 months and in New Zealand for a period of 24 months, following the date of original purchase of the

Appliance.Speciccomponentsarewarrantedagainstmanufacturing

defects in Australia and New Zealand for the periods listed below;

• Compressor – Further 3 years

• Exter nal Condenser – Further 3 years

• Evaporator – Further 3 years

• Drier – Further 3 years

4. Repair or replace warranty: During the Warranty Period, Electrolux

or its ASC will, at no extra charge if your Appliance is readily accessible for service, without special equipment and subject to these terms and conditions, repair or replace any parts which it considers to be defective. Electrolux may, in its absolute discretion, choose whether the remedy

oeredforavalidwarrantyclaimisrepairorreplacement.Electroluxorits

ASC may use refurbished parts to repair your Appliance. You agree that any replaced Appliances or parts become the property of Electrolux.

5. Travel and transportation costs: Subject to clause 7, Electrolux will

bear the reasonable cost of transportation, travel and delivery of the Appliance to and from Electrolux or its ASC. Travel and transportation will be arranged by Electrolux as part of any valid warranty claim.

6. Proof of purchase is required before you can make a claim under this

warranty.

7. Exclusions: You may not make a claim under this warranty unless the

defect claimed is due to faulty or defective parts or workmanship. This warranty does not cover:

 (a) lightglobes,batteries,ltersorsimilarperishableparts;

(b) parts and Appliances not supplied by Electrolux;

 (c) cosmeticdamagewhichdoesnotaecttheoperationofthe

Appliance;

(d) damage to the Appliance caused by: (i) negligence or accident;

(ii) misuse or abuse, including failure to properly maintain or service;

(iii) improper, negligent or faulty servicing or repair works done by

anyone other than an Electrolux authorised repairer or ASC;

(iv) normal wear and tear;

(v) power surges, electrical storm damage or incorrect power supply;

(vi) incomplete or improper installation;

(vii) incorrect, improper or inappropriate operation;

(viii) insect or vermin infestation;

(ix) failure to comply with any additional instructions supplied with

the Appliance;

In addition, Electrolux is not liable under this warranty if:

(a) the Appliance has been, or Electrolux reasonably believes that the

Appliance has been, used for purposes other than those for which the Appliance was intended, including where the Appliance has been used for any non-domestic purpose;

 (b) theApplianceismodiedwithoutauthorityfromElectroluxinwriting;

or defaced.

8. How to claim under this warranty: To enquire about claiming under

this warranty, please follow these steps:

(a) carefully check the operating instructions, user manual and the

terms of this warranty;

(b) have the model and serial number of the Appliance available;

(d) telephone the numbers shown below.

9. Australia: For Appliances and services provided by Electrolux in

Australia: Electrolux goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the Appliance repaired or replaced if the Appliance fails to be of acceptable quality and the failure does not amount to a major failure. ‘Acceptable quality’ and ‘major failure’ have the same meaning as referred to in the ACL.

10. New Zealand: For Appliances and services provided by Electrolux

in New Zealand, the Appliances come with a guarantee by Electrolux pursuant to the provisions of the Consumer Guarantees Act, the Sale of Goods Act and the Fair Trading Act. Where the Appliance was purchased in New Zealand for commercial purposes the Consumer Guarantee Act does not apply.

11.Condentiality: You accept that if you make a warranty claim, Electrolux

and its agents including ASC may exchange information in relation to you to enable Electrolux to meet its obligations under this warranty.

Before calling for service, please ensure that the steps listed in clause 8 above have been followed.

AUSTRALIA

NEW ZEALAND

WFridgeFreezer_Warr_May19

Important Notice

FOR SERVICE

ortondtheaddressofyournearest

authorised service centre in Australia

PLEASE CALL 13 13 49

For the cost of a local call

FOR SERVICE

ortondtheaddressofyournearest

authorised service centre in New Zealand

PLEASE CALL 0800 10 66 10

FOR SPARE PARTS

ortondtheaddressofyournearest

spare parts centre in Australia

PLEASE CALL 13 13 50

For the cost of a local call

FOR SPARE PARTS

ortondtheaddressofyournearest

spare parts centre in New Zealand

PLEASE CALL 0800 10 66 20

Notes

28 www.westinghouse.com

For more information on all Westinghouse appliances, or for dimension and installation information, call into your retailer, phone or email our customer care team or visit our website:

AUSTRALIA

phone: 1300 363 640 fax: 1800 350 067 email: web:

customercare@electrolux.com.au

westinghouse.com.au

NEW ZEALAND

phone: 0800 436 245 fax: 0800 225 088 email: web:

customercare@electrolux.co.nz westinghouse.co.nz

A10883154-A-232021

TOP SERVICE

Top Service encompasses the after sales service provided by The Electrolux Group to consumers including delivery, home service and spare parts.

and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation.

Westinghouse WHE6170BB, WHE6170SB, WHE6270SB, WHE6170, WHE6270 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
