Westinghouse up to 25.5 SEER iQ Drive, iQ Drive B6VMAI, FG7TC, iQ Drive 97% AFUE Modulating, FG7TL Brochure

A ard- inning

UP TO 25.5 SEER iQ Drive® Air Conditioners, Heat Pumps and Air Handlers/Furnaces

iQ Drive® Complete Comfort System

So Smart, Its iQ Delivers Ultra-High Energy Efficiency

The Westinghouse iQ Drive® Complete-Comfort System is quite
simply one of the smartest comfort systems available. It not
only controls temperature, but also achieves consistent levels of
humidity, air quality and ventilation. And all at some of the lowest
sound levels in the industry.

The iQ Drive Comfort System

The Westinghouse iQ Drive Comfort System, like all standard
central cooling systems, has three major components. The outdoor
component (the iQ Drive air conditioner or heat pump) works with
the indoor component (the iQ Drive air handler or gas furnace
and coil) to circulate cool air throughout the home. The third
component, the controller, allows you to manage total indoor
comfort. This entire system is designed to deliver better efficiency,
improved air quality and more reliable comfort for years to come.

So Smart, Its iQ Delivers

Ultra-High Energy Efficiency

The Westinghouse iQ Drive® Air Conditioner and
iQ Drive Heat Pump utilize inverter rotary technology

to achieve ultra-high efficiency levels. Traditional
compressors just turn on and off – operating at 60
hertz when running. But iQ Drive inverter technology
has almost infinite modulation for a perfectly even
variance. It runs as low as 15 hertz, so it uses less
power. So while today’s compressors kick on at
full speed to compensate for a small change in
temperature, iQ Drive inverter technology alters
the compressor speed just enough to match the
slightest change in air temperature. So in addition to
minimal power utilization, you get a more consistent
temperature level – and fewer hot and cold spots.

Westinghouse iQ Drive
Systems are energy­efficient, environmentally
responsible products.
Look for the ecoLogic®
seal.

DA Y

The up to 25.5 SEER iQ Drive air conditioner and up to 22
SEER iQ Drive heat pump come with programmable

communicating controllers.* As a secondary function,
the iQ Drive system will control humidity in your home
better than a traditional single-stage air conditioner.
You can even set a target dehumidification level.
Just know that the iQ Drive system is not a true
dehumidifier, and in areas where precise control is
needed, you should add a whole-home dehumidifier.
Ask your Westinghouse contractor for details.

You can program a seven-day comfort schedule to
control up to four specific events at precise times of
the day, such as wake-up time, work time, home arrival
or sleep time. You can even set a vacation mode for
ultimate energy efficiency even while you’re away.*

* Optional on 20 SEER
iQ Drive air conditioner
and up to 19 SEER iQ Drive
heat pump models.

Making Your iQ Drive®

Complete-Comfort System Truly Complete

iQ Drive with Air Handler

- Up to 25.5 SEER Air Conditioner

- Up to 22 SEER/10.0 HSPF Heat Pump

- 40-118% modulation

- 59-72 dBA sound levels

- 20 SEER Air Conditioner

- Up to 19 SEER/10.0 HSPF Heat Pump

- 49-118% modulation

- 59-73 dBA sound levels

iQ Drive with Gas Furnace

- Up to 23 SEER Air Conditioner

- Up to 20 SEER/10.0 HSPF Heat Pump

Westinghouse

®

iQ Drive

Conditioner

FS4BI

Air

Westinghouse

Heat Pump

iQ Drive

FT4BI

®

- 40-118% modulation

- 59-72 dBA sound levels

- 20 SEER Air Conditioner

- Up to 19 SEER/10.0 HSPF Heat Pump

- 49-118% modulation

- 59-73 dBA sound levels

Available with:

97+% AFUE iQ Drive Modulating Gas Furnace

95.1% AFUE Two-Stage, Variable-Speed Gas Furnace

80% AFUE Two-Stage, Variable-Speed Gas Furnace

Both the Westinghouse up to 25.5 SEER
iQ Drive air conditioner and the
Westinghouse up to
22 SEER iQ Drive
heat pump received

a Consumers Digest
Best Buy award.

The iQ Drive controller
is optional on 20 SEER
iQ Drive air conditioner
and up to 19 SEER
iQ Drive heat pump
models.

The Best Buy Seal and other licensed materials are registered
certification marks and trademarks of Consumers Digest
Communications, LLC, used under license. For award
information, visit ConsumersDigest.com.

Heat Pump vs. Air Conditioner

A “split” system is the most common heating and cooling
central system used. Your split system air conditioner or heat
pump is the outdoor component of a total system. The indoor
component is a matched coil, which typically sits on top of the
furnace or, in warmer climates, an indoor air handler is used.
When you replace your outdoor system, it is extremely important
to replace the indoor portion as well in order to meet energy
efficiency performance and not void important warranties. Not
changing your indoor component is like buying a new car and
then placing old, worn tires on it.

The iQ Drive® air conditioner is an excellent choice for geographies
where maximum cooling efficiency is needed. In areas where
heating efficiency is also desired, consider one of the iQ Drive
heat pumps. They operate in the summer the same as an air
conditioner, but also provide heat in the winter. And with an
HSPF (Heating Season Performance Factor) up to 10.0, they’re
incredibly efficient no matter what the weather.

The Importance of Being

up to 25.5 SEER

Most homes built in the last 10 years have 8 to 10
SEER cooling systems. With an iQ Drive® system, you

should see significant savings over your existing air
conditioner or heat pump. The iQ Drive air conditioner
is rated up to 25.5 SEER, and the iQ Drive heat pump
is rated up to 22 SEER/10.0 HSPF.

8 SEER
10 SEER
13 SEER
16 SEER
19 SEER
20 SEER
22 SEER

$254

$216

$206

$196

$540

$432

$332

Estimated Annual

Operating Costs

Annual costs based on
36,000 Btu unit, 1500
cooling load hours, and
.08/kwh. Actual costs
may vary depending
on climate conditions,
energy rates and
patterns of usage.

SAVINGS

25.5 SEER

SEER (Seasonal Energy Efficiency Ratio) measures

cooling performance on air conditioners, heat pumps
and gas/electric packaged products. In the world of
cooling, the higher the SEER, the better the efficiency,
and the lower your power bill.

HSPF (Heating Seasonal Performance Factor) is
a measure of the average number of Btu of heat
delivered for every Watt-hour of electricity used by
the heat pump over the heating season.

AFUE (Annual Fuel Utilization Efficiency) measures
the amount of heat actually delivered to your house
compared to the amount of fuel that you must supply
to the furnace. Thus, a furnace that has an 80% AFUE
rating converts 80% of the fuel that you supply to
heat—the other 20% is lost out of the chimney.

As ratings increase, so does unit efficiency.

$163

Up to 25.5 SEER

iQ Drive® Split System Air Conditioners and Heat Pumps

A full metal jacket protects the coil from damage by
weather and flying debris. It is finished with a Silicone
protective polyurethane coating that passed a 950­hour salt spray test for harsher climates. It protects
your unit from corrosion 50% more than standard
outdoor finishes.

The Westinghouse iQ Drive® System is designed to
work with other Westinghouse accessories such as

whole-home humidifiers, air cleaners, HEPA systems
and more. If allergens, dust, mold, pet odor, dry air,
temperature control or other irritants are a problem
for you or your family, ask us how we can design a
Westinghouse system to reduce common irritants and
increase comfort throughout the home.

ZONE

Westinghouse iQ Drive systems are energy-efficient,
environmentally responsible products. Look for the
ecoLogic® seal.

For ultimate comfort, consider .

iQ ZoneTM works hand-in-hand with your up to 25.5
SEER iQ Drive air conditioner and up to 22 SEER iQ
Drive heat pump to create separate comfort zones in
your home. Now you can easily have the bedrooms
cooler than the kitchen, or the rarely used den a
different temperature than the family room. It’s your
home. Customize it to your comfort.

iQ Zone offers these benefits.

  ~ 8]ST_T]ST]ccT\_TaPcdaTR^]ca^[X]d_c^

8 zones served by one unit.

  ~ <PhX]RaTPbTT]TaVhbPeX]Vb
  ~ Bd_TaX^aR^\U^ac
  ~ 4[TVP]cc^dRW_P]T[R^]ca^[
  ~ 4Pbhc^dbT

Ask your Westinghouse contractor for details on iQ Zone
or visit www.westinghousehvac.com.

Leading arranty

10-YEAR

WARR ANTY

PLEDGE

QUALITY

When a complete heating and
cooling system is truly built to
exacting standards of quality and
durability, the manufacturer’s
confidence shows in its warranty.

The Westinghouse iQ Drive® System offers a
10-year limited warranty on all parts, 10-year
compressor warranty and a 10-year Quality
Pledge (when product is registered as part of a
complete Westinghouse system). With our
10-year Quality Pledge, we will replace the entire
unit should the compressor fail within the first
10 years (must be installed with a Westinghouse
matched indoor coil or air handler).

To learn more about our product warranties, ask
your Westinghouse contractor, or visit us on the
web at www.westinghousehvac.com for details.

Proper sizing and installation of equipment is critical to achieve optimal
performance. Split system air conditioners and heat pumps must be
matched with appropriate coil components to meet ENERGY STAR
criteria. Ask your contractor for details or visit www.energystar.gov.

ENERGY STAR® certification is awarded to products designed to
reduce energy consumption and utility costs. To qualify, split system air
conditioners and heat pumps must have a Seasonal Energy Efficiency
Ratio (SEER) rating of 14.5 or higher and an Energy Efficiency Ratio
(EER) of 12.0 or higher. Split system heat pumps are also rated by a
Heating Seasonal Performance Factor (HSPF) and must have a rating of

8.2 or higher.

ecoLogic and iQ Drive are registered trademarks of NORDYNE.
iQ Zone is a trademark of NORDYNE.

, WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF are
trademarks of Westinghouse Electric Corporation. Used under license.
All Rights Reserved. © 2015 NORDYNE. All rights reserved.

www.westinghousehvac.com 952D-0115
