Page 1
Trust orthy
14 to 16 SEER Air Conditioners, Heat Pumps, Air Handlers and Coils
Page 2
Split System Air Conditioners and Heat Pumps
Engineered for Quality
More than just better indoor comfort, we want you to feel
comfortable investing in a product that will perform when you
need it most. Each Westinghouse air conditioner and heat pump
is checked approximately 144 times during the manufacturing
process then run-tested to check operation performance. In the
final analysis, computer-automated testing is performed to
capture operation data for future reference should your contractor
ever need it.
Westinghouse air conditioners and heat pumps are built with
proven components to provide safe, clean and reliable comfort
year-round. For example, our products offer a reliable scroll
compressor warranted for 10 years.
Page 3
Up to 16 SEER, 9.0 HSPF
Split System Air Conditioners and Heat Pumps
Westinghouse two-stage air conditioners and heat
pumps operate at lower capacity during mild summer
STA GE
days, then full capacity during hotter days. Because
they idle down to a reduced capacity, Westinghouse
two-stage cooling products provide better comfort
and perform quieter than a standard air conditioner
or heat pump. Longer cycles improve air circulation,
minimizing temperature swings to a couple of degrees,
while reducing hot and cold spots.
Engineered for reliable performance, our up to 16
SEER products offer a reliable Copeland Ultra-Scroll®
Compressor warranted for 10 years. These units are
designed with the most reliable compressors for quiet,
dependable operation.
The one-piece top design provides maximum airflow
and quiet operation to increase your indoor comfort.
A full metal jacket protects the coil from damage by
weather and flying debris. It is finished with a Siliconeprotective polyurethane coating that passed a 950
hour salt spray test for harsher climates. It protects
your unit from corrosion 50% more than standard
outdoor finishes.
All air conditioner models feature all-aluminum
Micro-Channel coils for increased resistance to
corrosion.
ANNUAL OPERATING COSTS*
$432
$360
$332
$309
$270
$254
101213
SEASONAL ENERGY EFFICIENCY RATIO
* Annual costs based on
36,000 Btu unit, 1500
cooling load hours, and
.08/kwh. Actual costs
may vary depending
on climate conditions,
energy rates and
patterns of usage.
14
15
16
Westinghouse two-stage, variable-speed split
system products are energy-efficient, environmentally
responsible products. Look for the
ecoLogic® seal.
Page 4
Up to 15 SEER, 8.5 HSPF
Split System Air Conditioners and Heat Pumps
When a 14 SEER outdoor section is installed with
an indoor section (furnace and coil, or air handler)
featuring an energy-efficient blower motor, you
can increase the efficiency levels up to 15 SEER.
To learn more about the additional benefits, ask
your contractor about Westinghouse variable-speed
furnaces or air handlers.
A full metal jacket protects the coil from damage by
weather and flying debris. It is finished with a Siliconeprotective polyurethane coating that passed a 950
hour salt spray test for harsher climates. It protects
your unit from corrosion 50% more than standard
outdoor finishes.
Engineered for reliable performance, these products
offer a 10 year compressor warranty. These units are
designed with the most reliable compressors.
The one-piece top design provides maximum airflow
and quiet operation to increase your indoor comfort.
SEER – Seasonal
Energy Efficiency Ratio
measures cooling
performance on air
conditioners, heat
pumps and gas/electric
packaged products.
HSPF – Heating Seasonal
Performance Factor is a
measure of the average
number of Btu of heat
delivered for every Watthour of electricity used
by the heat pump over
the heating season.
ANNUAL OPERATING COSTS*
$432
$360
$332
$309
$270
10
12
13
14
15
SEASONAL ENERGY EFFICIENCY RATIO
All air conditioner and up to 15 SEER heat pump
models feature all-aluminum Micro-Channel coils for
increased resistance to corrosion.
If allergens, dust, mold, pet odor, dry air,
temperature control etc. is a problem for you or
your family members, ask your contractor how he can
design a Westinghouse system to reduce common
irritants, and increase comfort throughout the home
for everyone.
* Annual costs based on
36,000 Btu unit, 1500
cooling load hours, and
.08/kwh. Actual costs
may vary depending
on climate conditions,
energy rates and
patterns of usage.
Page 5
Heat Pump vs. Air Conditioner
A “split” system is the most common heating and cooling
central system used. Your split system air conditioner or heat
pump is the outdoor component of a total system. The indoor
component is a matched coil, which typically sits on top of the
furnace, or in warmer climates, an indoor air handler is used.
When you replace your outdoor system it is extremely important
to replace the indoor portion as well, in order to meet energy
efficiency performance and not void important warranties. Not
changing your indoor component is like buying a new car then
placing old, worn tires on it.
Choosing a heat pump as a comfort solution is typically driven by
the climate you live in and is relative to your comfort needs. A
heat pump works like an air conditioner in the summer, but is also
designed to provide economical heat in the winter and is best in
environments that do not drop below freezing. Your Westinghouse
contractor can recommend the right choice for you _ a choice
that could save you money during the winter months.
Page 6
VARIABLE-SPEED AIR HANDLERS
Selecting a variable-speed delivery air handler instead
of a standard unit can keep you even more comfortable
and significantly improve overall system efficiency,
indoor air quality and sound levels. The energy-efficient
ECM variable-speed blower motor automatically
compensates for reduced duct volume, dirty air filters,
zoning changes, obstructed registers, etc. to improve
indoor air quality, and precise humidity control.
Select models feature all-aluminum Anteater MC®
Mirco-Channel coils that resist formicary corrosion
better than traditional copper tube-in-fin coils.
This air handler is designed for ease-of-serviceability
and flexible installation configurations. Its Silicone-
protective polyurethane coating resists scratching and
prevents rusting to keep your air handler looking new
for years to come.
If allergens, dust, mold, pet odor, dry air,
temperature control etc. is a problem for you or
your family members, ask your contractor how he can
design a Westinghouse system to reduce common
irritants, and increase comfort throughout the home
for everyone.
Reduce energy costs with a programmable
thermostat. By programming the thermostat to your
schedule, you can reduce the operating costs.
Page 7
FIXED-SPEED AIR HANDLERS AND INDOOR COILS
Westinghouse air handlers are built with proven
components to provide safe, clean and reliable
comfort year-round. They are designed for ease-ofserviceability and flexible installation configurations.
The Silicone-protective polyurethane coating resists
scratching and prevents rusting to keep your air
handler looking new for years to come.
Select models feature an all-aluminum Anteater MC®
Micro-Channel coil that resists formicary corrosion,
the number one cause of coil leaks.
Reduce energy costs with a programmable
thermostat. By programming the thermostat to your
schedule you can reduce the operating costs.
Indoor coils are designed to match your Westinghouse
outdoor unit (split system) to maximize efficiency
performance. An uncased indoor coil, is used for
upflow and downflow applications. The coil is encased
by the ductwork during installation.
A cased indoor coil is installed on top of a furnace.
An Anteater MC® Micro-Channel coil is made of all
aluminum. Eliminating copper helps these coils resist
formicary corrosion, the number one cause of coil leaks.
Page 8
Leading arranty
10-YEAR
WARR ANTY
PLEDGE
QUALITY
When an air conditioner and heat
pump are truly built to exacting
standards of quality and durability, the
manufacturer’s confidence shows in
its warranty.
Westinghouse products offer a 10-year limited
warranty on all parts, and a 10-year Quality Pledge
at no extra cost (when product is registered
as part of a complete Westinghouse system).
With our 10-year Quality Pledge, we will replace
the entire unit should the compressor fail
within the first 10 years (must be installed with a
Westinghouse matched indoor coil or air handler).
Westinghouse air handlers and coils carry a 5-year
all parts limited warranty and, when installed with
a matched outdoor unit, will carry the outdoor
system warranty.
To learn more about our product warranties, ask
your Westinghouse contractor, or visit us on the
web at www.westinghousehvac.com for details.
Proper sizing and installation of equipment is critical to achieve optimal performance. Split system air
conditioners and heat pumps must be matched with appropriate coil components to meet ENERGY STAR
criteria. Ask your contractor for details or visit www.energystar.gov.
ENERGY STAR® certification is awarded to products designed to reduce energy consumption and utility costs. To
qualify, split system air conditioners and heat pumps must have a Seasonal Energy Efficiency Ratio (SEER) rating
of 14.5 or higher and an Energy Efficiency Ratio (EER) of 12.0 or higher. Split system heat pumps are also rated
by a Heating Seasonal Performance Factor (HSPF) and must have a rating of 8.2 or higher.
ecoLogic and Anteater MC are registered trademarks of Nortek Global HVAC LLC.
, WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF are
trademarks of Westinghouse Electric Corporation. Used under license.
All Rights Reserved. © 2015 Nortek Global HVAC LLC. All rights reserved.
www.westinghousehvac.com 350E-02 15
