upholstered block platform headboard
full, king, queen, california king
assembly instructions
! Tools required:
! Do not throw away packaging materials until assembly is complete.
! Assemble this item on a soft surface, such as cardboard or carpet, to protect nish.
! Proper assembly of this item requires 2 people.
BA
bent bracket 3x L bracket 2x
C D
E F
short screw 17xangle bracket 2x
8400954/8400996/8400970/8400939/8400947/8400988/8400962/8400921 - 07/06
rubber pad 6xlong screw 16x
Page 1 of 38401010/8401002/8400954/8400996/8400970/8400939/8400947/8400988/8400962/8400921 - 07/06
upholstered block platform headboard
1. Fasten bent brackets (A) to headboard using long screws (E) as shown.
2. Aplly rubber pads (F) to bottom as shown.
full, king, queen, california king
assembly instructions
A
E
Step: 1
G
F
8400954/8400996/8400970/8400939/8400947/8400988/8400962/8400921 - 07/06
Page 2 of 3
upholstered block platform headboard
full, king, queen, california king
assembly instructions
3. Place headboard upright on bed frame and fasten angle brackets (C) and bent brackets (A) to top bed corners using short
screws (D) as shown.
4. Fasten L brackets (B) to headboard using long screws (E) as shown.
D
C
A
D
B
E
CARE INSTRUCTIONS
Hardware may loosen over time. Periodically check that all connections are tight.
Regularly vacuum or brush with nonmetallic sti-bristle brush to remove dust and grime.
Protect from direct sunlight to prevent fading.
8400954/8400996/8400970/8400939/8400947/8400988/8400962/8400921 - 07/06
Page 3 of 3
