terra platform bedframe
Note: These bedframe instructions are for all sizes except twin!
assembly instructions
! Tools supplied:
! Do not throw away packaging materials until assembly is complete.
! Assemble this item on a soft surface, such as cardboard or carpet, to protect finish.
! Proper assembly of this item requires 2 people.
Hardware
AB
lock washer 18x
m6 x 45mm long bolt 8x
C
m6 x 30mm short bolts 10x
D
flat washer 18x
Page 1 of 41576586/1576578/1576552/1576545 9-23-09
terra platform bedframe
assembly instructions
headboard 1x
side Rails 2x support rail 1x
footboard 1x
foot blocks 3x
Page 2 of 41576586/1576578/1576552/1576545 9-23-09
terra platform bedframe
assembly instructions
1. Assemble all parts upside down on a clean, smooth surface. Align and insert the tenon on the end of the
side rails into the cuttouts in the side of the headboard and footboard like the drawing shows. Insert
long bolt (D), lock washer (B), and at washer (C) thru the holes shown in the drawing. Tighten with
supplied hex key. Do Not Overtighten! With help turn assembled bedframe over.
D
B
C
Page 3 of 41576586/1576578/1576552/1576545 9-23-09
terra platform bedframe
assembly instructions
2. Attach the foot blocks to the support rail and secure with short bolts (A), lock washer (B), and at washer
(C). Tighten with supplied hex key.
A
B
C
3. Place the assembled support rail onto the cleats located on the side of the headboard and footboard.
Insert bolt (A), lock washer (B), and at washer (C). Tighten with suppplied hex key.
A
B
C
CARE INSTRUCTIONS
Hardware may loosen overtime. Periodically check that all connections are tight.
Wipe with a soft, dry cloth. To protect nish, avoid the use of chemicals and household cleaners.
Upholstery: Spot clean only.
Page 4 of 41576586/1576578/1576552/1576545 9-23-09
