West Elm Taper Shade Floor Lamp Assembly Instruction
Important Safety Instructions:
• For safety purposes, this lamp is equipped with a polarized plug (one blade is wider than the other). If the
plug does not t securely into your outlet, do not force it-contact a professional electrician. Use the plug
with an extension cord only if it can be fully inserted into the cord’s socket. Never alter the plug in any way.
• The instruction is provided for your safety. It is important that they are read carefully and completely before
assembling xture.
• This xture has been rated for up to 60 Watt TYPE A standard incandescent light bulb (not included) or 13watt compact uorescent bulb (included). To avoid the risk of re, do not exceed the recommended wattage.
• Save this instruction.
WARNING:
• To reduce the risk of re, electrical shock or personal injury, always turn o light xture and unplug, allowing it to cool prior to replacing light bulb.
• Do not touch bulb when xture is turned on.
• Do not look directly at lit bulb. Keep ammable materials away from lit bulb.
Pre-assembly:
•Remove all parts and hardware from box along
with any plastic protective packaging. Do not
discard any contents until after assembly is
complete to avoid accidentally discarding small
parts or hardware.
Parts enclosed:
(1) Top tube (A)
(2) Assembled Arms (B)
(2) Shades (C)
(2) Pivots (D)
(2) Handgrips (E)
(1) Bottom tube (F)
(1) Lamp Base (G)
(4) Adjustment keys (H)
(2) Sockets (I)
To Assemble:
1. Insert the Top Tube (A) through the holes in the Pivots (D) of both the Assembled Arms (B).
2. Attached the Bottom Tube (F) onto the end of Top Tube (A) and turn the Bottom Tube (F) in a clockwise
direction to tighten.
3. Attach the Lamp Base (G) onto the end of Bottom Tube (F) and turn the Lamp Base (G) in a clockwise direction to tighten.
4. Attach the both Handgrips (E) onto the end of Assembled Arms (B) and turn the Handgrips (E) in a clockwise direction to tighten.
5. Insert TWO bulb-Max 60 watt maximum TYPE A standard incandescent light bulb (not included) or 13watt compact uorescent bulb (included) into the Sockets (I). DO NOT EXCEED SPECIFIED WATTAGE.
5. Plug xture into the proper electrical outlet and test xture.
Note:
• The Assembled Arms (B) can move back and forth through the Pivots (D) by unscrewing and screwing the
Adjustment Keys (H).
• The Assembled Arms (B) can move up and down along the Top Tube (A) and Bottom Tube (F) by unscrewing and screwing the Adjustment Keys (H). .
• To adjust the Shade Angle, only hold the bottom edges of Shades (C).
Care instructions:
• Wipe clean with a soft, dry cloth or static duster.
• Always avoid the use of harsh chemicals or abrasive cleaners as they may cause damage to the xture’s
nish.
