West Elm Hudson Armoire Assembly Instruction

hudson armoire

assembly instructions

! Tools required:

! Do not throw away packaging materials until assembly is complete.

! Assemble this item on a soft surface, such as cardboard or carpet, to protect nish.

! Proper assembly of this item requires 2 people.

A

short bolt 6x screw 8x

C

shelf pin 12x

B

D

allen key 1x

Page 1 of 48400731/ 8400707/ 8687121 - 11/06

hudson armoire

assembly instructions

1. Before starting assembly, take out all accessories inside large bottom drawer. Then place the chest upside down on a smooth,
scratch-free surface.

2. Attached each metal leg by aligning it on the pre-drilled holes underneath the chest . Insert bolts (A) into the leg beam as
shown and tighten using the allen key (D). Then insert screws (B) into the plate and tighten using a phillips head screwdriver.

Page 2 of 48400731/ 8400707/ 8687121 - 11/06
