QUICK START GUIDE
Page 2
Usage & Details
Warranty ............................................................................................................................................ 3
Frame Assembly ............................................................................................................................ 4
Attaching Fabrics .......................................................................................................................... 5
Frame Mounting ............................................................................................................................. 6
Build Options ................................................................................................................................... 7
Components & Accessories
Accessories ...................................................................................................................................... 16
Framework........................................................................................................................................ 17
Fabric Options ................................................................................................................................ 18
theC47™ Kits ..................................................................................................................................... 21
WarrantyTable of Contents
For lighting tips, instructional
videos, inspiration, and more,
visit WestcottU.com.
2
One-Year Limited Warranty
Westcott’s warranty obligations for this product are limited to the terms set forth below: The F.J. Westcott Co. (“Westcott”)
warrants this Westcott branded product against defects in materials and workmanship under normal use for a period of
ONE (1) YEAR from the date of retail purchase by the original end-user purchaser (“Warranty Period”). If a defect arises
and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, Westcott will
either (1) repair the defect at no charge, using new or refurbished replacement parts, or (2) exchange the product with
a product that is new or which has been manufactured from new or serviceable used parts and is at least functionally
equivalent to the original product. This Limited Warranty applies only to products manufactured by or for Westcott that
can be identified by the “Westcott” trademark, trade name, or logo affixed to them.
This warranty does not apply: (a) to damage caused by accident, abuse, misuse, flood, fire, earthquake or other external
causes; (b) to damage caused by operating the product outside the permitted or intended uses described by Westcott;
(c) to a product or part that has been modified to alter functionality or capability without the written permission of
Westcott; or (d) to cosmetic damage, including but not limited to scratches, dents and broken plastic.
Please contact Westcott’s Repair Department for a Return Authorization Number “RMA” prior to requesting warranty
service. This RMA must be clearly written on the outside of the box to the left of the shipping label. Items sent in without
pre-authorization or that do not fall under the ONE (1) YEAR limited warranty will be returned at the expense of the sender.
Repair Dept.: 800-886-1689 / 419-243-7311 (International)
E-Mail: [email protected] Subject: Attn: Repair Dept.
Shipping: F.J. Westcott Co, 1425-B Holland Rd, Maumee, OH 43537
FJWESTCOTT.COM
3
Page 3
Frame Assembly
©Curt Pair
Attaching Fabrics
Scrim Jim Cine frame tubes, corner connectors, straight connectors, and fabrics are packaged unassembled and
may be purchased separately or in complete kits. Visit page 17 to see all available components.
1
Locate Components
Begin by locating the included Scrim
Jim Cine frame tubes and connectors.
Refer to the Build Options section
starting on page 7 for configuration
options and required components.
2 3
Arrange Components
On a flat surface, position frame
tubes and connectors next to each
other in the proper order. Align the
connectors’ positive-locking buttons
with the button receptacles on the
frame tubes.
Connect Frame Tubes
Connect any included straight frame
connectors with their corresponding
frame tubes first. Next,
connect each end of a
full frame tube to corner
connectors. Press and
hold the positive-locking
button and slide the
frame tube into place. The button will
‘click’ when connected properly.
4 5
Scrim Jim Cine fabrics are available in a wide variety of materials and sizes to control virtually any lighting. These
fabrics are easily attached to any corresponding Scrim Jim Cine frame. See pages 18-20 for all available fabrics.
1
Select a Fabric
Locate the preferred Scrim Jim Cine
fabric that you want to attach to your
assembled frame.
2
Attach Preferred Fabric
Place the fabric’s loop tape edge
onto the frame’s hook tape. Press to
secure.
3
Secure Fabric Corners
Place the fabric’s loop tape tabs
around the frame and attach to the
rear of the frame (for sizes 4' x 4' and
larger).
Repeat Corner Connections
Connect the open ends of the parallel
frame tubes with 2 corner connectors.
4
Frame Creation
Connect the 2 remaining straight
frame tubes to the remaining open
ends of the connected corner
connectors to create your frame.
FJWESTCOTT.COM
5
Page 4
Frame Mounting
Build Options: 1' x 1' and 1' x 2'
A Scrim Jim Cine frame can be mounted to a light stand or c-stand with a Center Jaw Vise Grip (#1980), or using a
Universal Stud (#8539) and Dual-Socket Magic Arm (#2199) or Grip Head (#1881).
See page 16 or visit fjwestcott.com for product details.
Mounting with Center Jaw Vise Grip
1 2 3
Attach Vise Grip to Mount
Securely mount the Vise Grip’s shaft
in the open socket of the DualSocket Magic Arm or Grip Head while
attached to a light stand or c-stand.
Loosen the Wing Nut
Loosen the Center Jaw Vise Grip’s
wing nut and separate the vise grip’s
center jaws.
Secure the Frame
Place your Scrim Jim Cine frame
between the jaws, ensuring that the
frame is aligned with the jaws’ grip
material and tighten the wing nut to
secure.
Mounting with Universal Stud
See page 17-19 or visit fjwestcott.com for additional frame and fabric options.
1' x 1' Cine Frames
Fabrics (pages 18-20)
FU L L-STO P
DIFFUSER
1/4-STOP
GRID CLOTH
1' x 1' Frame Kit
(4) 10" TUBES - #2000
(4) 2D CORNERS - #2024
1/2-STOP
GRID CLOTH
#1885
Mounts (page 16)
CENTER JAW
VISE GRIP
UNIVERSAL
STUD
1' x 2' Cine Frames
GRIP
HEAD
DUAL-SOCKET
MAGIC ARM
KEY
10" TUBE #2000
22" TUBE #2020
46" TUBE #2022
Flex (page 23)
FLEX LED
DAY LIG H T
D
FLEX LED
BI-COLOR
B
1 2 3
Attach Mount to Stand
Attach the Dual-Socket Magic Arm or
Grip Head to light stand or c-stand.
6
Attach Stud to Frame
Locate the 3/8"-16 receptacle on your
Scrim Jim Cine frame and screw the
3/8"-16-end of the Universal Stud into
this receptacle.
Attach Stud to Mount
Place this mounted stud into the
open socket of the Dual-Socket
Magic Arm or Grip Head and tighten
knob to secure.
1' x 2' Frame Kit
(2) 10" TUBES - #2000
(2) 22" TUBES - #2020
(4) 2D CORNERS - #2024
Fabrics (pages 18-20)
FU L L-STO P
DIFFUSER
1/4-STOP
GRID CLOTH
FJWESTCOTT.COM
#1886
1/2-STOP
GRID CLOTH
1' x 2' Build Option #2
(6) 10" TUBES - #2000
(2) 2" STR AIGHTS - #2023
(4) 2D CORNERS - #2024
Mounts (page 16)
CENTER JAW
VISE GRIP
UNIVERSAL
STUD
GRIP
HEAD
DUAL-SOCKET
MAGIC ARM
Flex (page 23)
FLEX LED
DAY LIG H T
D
FLEX LED
BI-COLOR
B
7
Page 5
KEY
10" TUBE #2000
22" TUBE #2020
46" TUBE #2022
Build Options: 2' x 2'Build Options: 1' x 3'
See page 17-19 or visit fjwestcott.com for additional frame and fabric options.See page 17-19 or visit fjwestcott.com for additional frame and fabric options.
1' x 3' Cine Frames 2' x 2' Cine Frames
KEY
10" TUBE #2000
22" TUBE #2020
46" TUBE #2022
1' x 3' Frame Kit
(4) 10" TUBES - #2000
(2) 22" TUBES - #2020
(2) 2" STR AIGHTS - #2023
(4) 2D CORNERS - #2024
Fabrics (pages 18-20)
FU L L-STO P
DIFFUSER
1/4-STOP
GRID CLOTH
#1887
1/2-STOP
GRID CLOTH
1' x 3' Build Option #2
(8) 10" TUBES - #2000
(4) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
Mounts (page 16)
CENTER JAW
VISE GRIP
UNIVERSAL
STUD
GRIP
HEAD
DUAL-SOCKET
MAGIC ARM
Flex (page 23)
FLEX LED
DAY LIG H T
D
2' x 2' Frame Kit
(4) 22" TUBES - #2020
(4) 2D CORNERS - #2024
Fabrics (pages 18-20)
1/4-STOP
SILK
1/4-STOP
GRID CLOTH
SUN L IGHT/
SILVE R
BOUNCE
Mounts (page 16)
#1889
3/4-STOP
DIFFUSER
1/2-STOP
GRID CLOTH
SILVER/WHITE
BOUNCE
2' x 2' Build Option #2
(8) 10" TUBES - #2000
(4) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
FU L L-STO P
DIFFUSER
SINGLE
NET
GOLD/WHITE
BOUNCE
Flex (page 23)
2' x 2' Build Option #3
(4) 10" TUBES - #2000
(2) 22" TUBES - #2020
(2) 2" STR AIGHTS - #2023
(4) 2D CORNERS - #2024
1 1/4-STOP
DIFFUSER
DOUBLE
NET
BLACK
BLOCK
CENTER JAW
VISE GRIP
UNIVERSAL
STUD
8
FJWESTCOTT.COM
GRIP
HEAD
DUAL-SOCKET
MAGIC ARM
D
FLEX LED
DAY LIG H T
9
Page 6
Build Options: 4' x 4'
KEY
10" TUBE #2000
22" TUBE #2020
46" TUBE #2022
Build Options: 4' x 6'
See page 17-19 or visit fjwestcott.com for additional frame and fabric options.See page 17-19 or visit fjwestcott.com for additional frame and fabric options.
4' x 4' Cine Frames 4' x 6' Cine Frames
KEY
10" TUBE #2000
22" TUBE #2020
46" TUBE #2022
4' x 4' Frame Kit
(4) 46" TUBES - #2022
(4) 2D CORNERS - #2024
Fabrics (pages 18-20)
1/4-STOP
SILK
1/4-STOP
GRID CLOTH
SUN L IGHT/
SILVE R
BOUNCE
Mounts (page 16)
CENTER JAW
VISE GRIP
#1897
3/4-STOP
DIFFUSER
1/2-STOP
GRID CLOTH
SILVER/WHITE
BOUNCE
GRIP
HEAD
4' x 4' Build Option #2
(8) 22" TUBES - #2020
(4) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
FU L L-STO P
DIFFUSER
SINGLE
NET
GOLD/WHITE
BOUNCE
4' x 4' Build Option #3
(16) 10" TUBES - #2000
(12) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
1 1/4-STOP
DIFFUSER
DOUBLE
NET
BLACK
BLOCK
UNBLEACHED/
BLACK
FLOPPY
CUTTER
4' x 6' Frame Kit
(4) 46" TUBES - #2022
(2) 22" TUBES - #2020
(2) 2" STR AIGHTS - #2023
(4) 2D CORNERS - #2024
Fabrics (pages 18-20)
1/4-STOP
SILK
1/4-STOP
GRID CLOTH
SUN L IGHT/
SILVE R
BOUNCE
#1820
3/4-STOP
DIFFUSER
1/2-STOP
GRID CLOTH
SILVER/WHITE
BOUNCE
4' x 6' Build Option #2
(10) 22 " TUBES - #2020
(6) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
FU L L-STO P
DIFFUSER
SINGLE
NET
GOLD/WHITE
BOUNCE
4' x 6' Build Option #3
(2) 46" TUBES - #2022
(6) 22" TUBES - #2020
(4) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
1 1/4-STOP
DIFFUSER
DOUBLE
NET
BLACK
BLOCK
UNBLEACHED/
BLACK
10
UNIVERSAL
STUD
DUAL-SOCKET
MAGIC ARM
Mounts (page 16)
CENTER JAW
VISE GRIP
FJWESTCOTT.COM
GRIP
HEAD
11
Page 7
Build Options: 6' x 6'
KEY
10" TUBE #2000
22" TUBE #2020
46" TUBE #2022
Build Options: 8' x 8'
See page 17-19 or visit fjwestcott.com for additional frame and fabric options.See page 17-19 or visit fjwestcott.com for additional frame and fabric options.
6' x 6' Cine Frames 8' x 8' Cine Frames
KEY
10" TUBE #2000
22" TUBE #2020
46" TUBE #2022
6' x 6' Frame Kit
(4) 46" TUBES - #2022
(4) 22" TUBES - #2020
(4) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
Fabrics (pages 18-20)
1/4-STOP
SILK
1/4-STOP
GRID CLOTH
SUN L IGHT/
SILVE R
BOUNCE
Mounts (page 16)
CENTER JAW
VISE GRIP
#1833
3/4-STOP
DIFFUSER
1/2-STOP
GRID CLOTH
SILVER/WHITE
BOUNCE
GRIP
HEAD
6' x 6' Build Option #2
(12) 22" TUBES - #2020
(8) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
FU L L-STO P
DIFFUSER
SINGLE
NET
GOLD/WHITE
BOUNCE
For compatibility with original 71" x 71" Scrim Jim fabrics.
6' x 6' Build Option #3
(3) 46" TUBES - #2022
(6) 22" TUBES - #2020
(5) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
1 1/4-STOP
DIFFUSER
DOUBLE
NET
BLACK
BLOCK
6' x 6' Build Option with
1" Straight Connectors
(4) 46" TUBES - #2022
(4) 22" TUBES - #2020
(4) 1" STRAIGHTS - #2029
(4) 2D CORNERS - #2024
UNBLEACHED/
BLACK
8' x 8' Frame Kit
(8) 46" TUBES - #2022
(4) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
Fabrics (pages 18-20)
1/4-STOP
SILK
1/4-STOP
GRID CLOTH
SUN L IGHT/
SILVE R
BOUNCE
Mounts (page 16)
CENTER JAW
VISE GRIP
#1834
3/4-STOP
DIFFUSER
1/2-STOP
GRID CLOTH
SILVER/WHITE
BOUNCE
GRIP
HEAD
FU L L-STO P
DIFFUSER
SINGLE
NET
GOLD/WHITE
BOUNCE
1 1/4-STOP
DIFFUSER
DOUBLE
NET
BLACK
BLOCK
12
FJWESTCOTT.COM
13
Page 8
Build Options: Floppy Cutter
4' x 4' Cine Frames
KEY
10" TUBE #2000
22" TUBE #2020
46" TUBE #2022
Build Options: Book Light
See page 17-19 or visit fjwestcott.com for additional frame and fabric options.See page 17-19 or visit fjwestcott.com for additional frame and fabric options.
4' x 4' Cine Frames
KEY
10" TUBE #2000
22" TUBE #2020
46" TUBE #2022
Floppy Cutter Build
Option #1
(4) 46" TUBES - #2022
(1) FLOPPY CUTTER - #1997
(4) 2D CORNERS - #2024
Floppy Cutter Build
Option #2 - Travel
(8) 22" TUBE - #2020
(1) FLOPPY CUTTER - #1997
(4) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
Floppy Cutter Build
Option #3 - Compact Travel
(16) 10" TUBES - #2000
(1) FLOPPY CUTTER - #1997
(12) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
4' x 4' Book Light
Build Option #1
(8) 46" TUBES - #2022
(2) SWING HINGES - #2091
(4) 2D CORNERS - #2024
4' x 6' Cine Frames
4' x 6' Book Light
Build Option #1
(8) 46" TUBES - #2022
(4) 22" TUBES - #2020
(2) SWING HINGES - #2091
(12) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
4' x 4' Book Light
Build Option #2 Travel
(16) 22" TUBES - #2020
(2) SWING HINGES - #2091
(8) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
4' x 6' Book Light
Build Option #2 Travel
(20) 22” TUBES - #2020
(2) SWING HINGES - #2091
(12) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
14
6' x 6' Cine Frames 8' x 8' Cine Frames
6' x 6' Book Light
Build Option #1
(8) 46" TUBES - #2022
(4) 22" TUBES - #2020
(2) SWING HINGES - #2091
(4) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
FJWESTCOTT.COM
8' x 8' Book Light
Build Option #2 Travel
(16) 46" TUBES - #2022
(2) SWING HINGES - #2091
(4) 2" STRAIGHTS - #2023
(4) 2D CORNERS - #2024
15
Page 9
Scrim Jim Cine Accessories
Mounting Hardware
Scrim Jim Cine Framework
The Scrim Jim Cine is a complete modular system designed to bounce, block, diffuse, subtract,
and shape light. This system’s frame pieces are designed to configure in sizes from 1' x 1' up to 8' x 8'. Frame pieces
vary in size from 10" tubes and upward. All Scrim Jim Cine pieces are available separately or in kits.
Scrim Jim Cine Frames Frame Connectors
Center Jaw Vise Grip #1980
The Center Jaw Vise Grip quickly
clamps onto any point of the Scrim
Jim Cine frame for placement in grip
heads and arms.
Grip Head #1881
This grip head features a heavy-duty
design with a torque-locking washer
for versatile use with virtually all
lighting and grip gear.
Dual-Socket Magic Arm #2199
The Dual-Socket Magic Arm
mounts effortlessly to any light
stand or c-stand and can be used in
conjunction with the Universal Stud
or Vise Grip.
Compact Light Stand #7425
This lightweight stand is designed
to pair perfectly with Scrim Jim
Cine frames up to 2' x 2'.
Universal Stud #8539
The Universal Stud’s 3/8"-16 thread
screws directly into Scrim Jim Cine
frame tubes for precise placement of
Flex mats and Scrim Jim Cine frames
up to 4' x 4'.
13' Heavy-Duty AirCushioned Light Stand #9914
This durable air-cushioned stand
is an essential stand for large or
elevated scrim mounting.
10" Tube
#2000
22" Tube
#2020
46" Tube
#2022
Scrim Jim Cine™ Frame Sets
Frame sets are available in sizes from 1' x 1' up to 8' x 8'
and include all of the necessary connectors to construct
each frame size.
FRAM E SIZE SKU COMPONENTS
1' x 1' Frame Set
1' x 2' Frame Set
1' x 3' Frame Set
2' x 2' Frame Set
4' x 4' Frame Set
4' x 6' Frame Set
6' x 6' Frame Set
8' x 8' Frame Set
1885 (4) 10" Tubes, (4) 2D Corners, (1) Strap
1886 (2) 10" Tubes, (2) 22 " Tubes, (4) 2D Corners, (1) Strap
1887 (4) 10" Tubes, (2) 22" Tubes, (2) 2" Straights, (4) 2D Corners, (1) Strap
1889 (4) 22" Tubes, (4) 2D Corners, (1) Strap
1897 (4) 46" Tubes, (4) 2D Corners, (1) Strap
1820 (4) 46" Tubes, (2) 22" Tubes, (2) 2" Straights, (4) 2D Corners, (1) Strap
1833 (4) 46" Tubes, (4) 22" Tubes, (4) 2" Straights, (4) 2D Corners, (1) Strap
1834 (8) 46" Tubes, (4) 2" Straights, (4) 2D Corners, ( 1) Strap
2" Straight
#2023
3D Corner
#2090
1" Straight *
#2029
(2) Swing Hinges
2D Corner
#2024
#2091
16
*1" Straight Connector for 6' x 6' Scrim Jim Cine compatibility with original 71" x 71" Scrim Jim fabrics.
FJWESTCOTT.COM
17
Page 10
Scrim Jim Cine Fabric Options Scrim Jim Cine Fabric Options
Diffusers
Perfect for softening and diffusing sunlight, ambient lighting, and studio lighting. These high-end
fabrics will not alter color temperature or skin tones.
1/4-Stop 3/4-Stop Full-Stop 1 1/4-Stop
SIZE
1' x 1'
1' x 2'
1' x 3'
2' x 2'
4' x 4'
4' x 6'
6' x 6'
8' x 8'
1/4
STOP
1830 1842 1904 1907
1831 1843 1905 1908
1832 1844 1906 1909
1771 1772 1 774 1770
1781 1782 1784 1780
3/4
STOP
- - 1837 -
- - 1838 -
- - 1839 -
Grid Cloths
These innovative fabrics simultaneously direct and diffuse ambient and artificial lighting. Grid
cloths are perfect for large or main light sources and when shooting in bright outdoor lighting.
FULL
STOP
1-1/4
STOP
Nets
These fabric nets are essentials for run-and-gun filmmakers and on-location sets, giving users the
ability to cut busy or bright backgrounds by 1 or 2 stops.
Single Net Double Net
SIZE
2' x 2'
4' x 4'
4' x 6'
6' x 6'
8' x 8'
SINGLE
NET
1816 1825
1817 1826
1818 1827
1777 1773
1786 1783
DOUBLE
NET
Black Blocks
These black blocks are virtually reflection-free and can be used to block ambient light. Blocks can also be
used to add shadows to your subject for added dimension, flag unwanted light, and prevent light spill.
1/4-Stop 1/2-Stop
18
SIZE 1/4 STOP 1/2 STO P
1' x 1'
1' x 2'
1' x 3'
2' x 2'
4' x 4'
4' x 6'
6' x 6'
8' x 8'
1900 1926
1901 1911
1902 1912
1923 1929
1943 1914
1944 1915
1945 1916
1946 1917
Black Block
FJWESTCOTT.COM
SIZE SKU
2' x 2'
4' x 4'
4' x 6'
6' x 6'
8' x 8'
1994
1996
1995
1778
1787
Floppy Cutter
The 4' x 8' Floppy Cutter fabric
is an essential light control tool
for run-and-gun filmmakers,
directors of photography, and
on-the-go cinematographers.
This versatile fabric can be used
to block light and flag both
studio and ambient lighting.
SIZE SKU
4' x 8'
1997
19
Page 11
Scrim Jim Cine Reversible Fabrics
Sunlight Bounce
This sunlight bounce fabric is interwoven silver
and gold, adding a slight warmth to subjects
with specular highlights.
Gold Bounce
SIZE
2' x 2'
4' x 4'
4' x 6'
6' x 6'
8' x 8'
SILVER &
SUNLIGHT
1983 1987 1990 -
1984 1988 1991 1948
1985 1989 1992 1949
1779 1776 1775 1950
1986 1785 1993 -
SILVER &
WHITE
Silver Bounce
GOLD &
WHITE
UNBLEACHED
MUSLIN &
BLACK
the
C47 Book Light Kit #2092
Create a soft output with an amazing wrap-around quality by
positioning a light source at a 45° angle with the reflective
interior of the book light. The adjustable diffusion front can
easily be moved closer to or further away from the light source.
Kit Components: (6) 46" Frame Tubes, (8) 22" Frame Tubes,
(8) 2D Corners, (8) 2" Straight Connectors, (2) Swing Hinge
Connectors, (1) 4' x 6' Unbleached Muslin/Black, (1) 4' x 6'
3/4-Stop Diffusion, (1) 4' x 6' 1/2-Stop Grid Cloth, (1) 4' x 6'
Silver/White Bounce, (1) Wheeled Travel Case
See page 15 for all Book Light build options.
Book Light Legs #2094
(2) 3D CORNERS
(2) 10" SCRIM JIM CINE TUBES
For added stability of any Scrim Jim Cine book light build
This silver bounce fabric adds bright, specular
highlights with cooling tones to your subject.
Unbleached Muslin
This unbleached fabric adds soft, natural
looking illumination to the scene.
This gold bounce fabric adds smooth,
warming tones to your subject or scene.
White Bounce
This white bounce fabric adds neutral and
bright highlights to your subject or scene.
the
C47 DP Kit #2093
DP Kit
collapses
to 22"
Featuring a unique and customizable design, this kit
provides the ultimate light control for on-the-go filmmakers,
directors of photography, run-and-gun shooters, gaffers, and
cinematographers.
Kit Components: (8) 22" Frame Tubes, (4) 2 Corners, (4) 2”
Straight Connectors, (1) 4' x 8' Floppy Cutter, (1) 4' x 4' FullStop Diffusion, (1) 4' x 4' Silver/White Bounce, (1) Center Jaw
Vise Grip, (1) Travel Case
See page 14 for all Floppy Cutter build options.
20
FJWESTCOTT.COM
21
Page 12
Flex™ Mat Options
Includes Flex LED Mat with Dimmer and Power Adapter
NEW
FLEX™ LED MATS
DIMMABLE, PLIABLE, & FLICKER-FREE
Lightweight and moldable 1/4" thin design
High-output LEDs with pristine 95-98 CRI
Available in bi-color, daylight, or tungsten
Multiple sizes including 1' x 1' and 1' x 2'
Durable IP 64 weatherproof housing
Dynamic light spread up to 360°
Optional battery, mounts, and framework
Flex™ Pairs Perfectly with
Scrim Jim Cine® Frames
Cutting-edge Westcott Flex mats pair
perfectly with Westcott’s new Scrim
Jim Cine system, offering the ultimate
in lighting control. Flex and Scrim Jim
Cine Frame combinations offer many
output options, sizes, and fabrics.
Flex 10" x 3" Mat
D
#745 2
B
#7493
Flex 1' x 3' Mat
D
#7470
FLEX MAT SKU COLOR CRI
10" x 3" Daylight
10" x 3" Bi-Color
1' x 1' Daylight
1' x 1' Bi-Color
1' x 2' Daylight
1' x 2' Bi-Color
1' x 3' Daylight
2' x 2' Daylight
745 2
749 3
743 0
749 2
745 0
749 4
7470
749 0
D
B
D
B
D
B
D
D
Flex 1' x 1' Mat
D
#7430
B
#7492
Flex 1' x 2' Mat
D
#7450
B
#749 4
Flex 2' x 2' Mat
D
#749 0
LU X AT 1MFC AT
95 500 46 5600 15w AC Dial, 5-100%
95-98 ~500 ~46
95 2000 186 5600 55w AC Digital, 0-100%
95-98 2000 ~186
95 3900 362 5600 100w AC Digital, 0-100%
95-98 ~3900 ~362
95 6000 557 5600 150w AC w/Dimmer Digital, 5 -100%
95 9100 845 5600 200w AC w/Dimmer Digital, 5-100%
KELV I N POWER DIMMER
1M
2800-
6000
2800-
6000
2800-
6000
15w AC Digital, 0-100%
55w AC Digital, 0 -100%
100w AC Digital, 0-100%
22
22
Visit fjwestcott.com for complete Flex offering, including complete kits with Scrim Jim Cine!
FJWESTCOTT.COM
23
Page 13
Thank You!
for purchasing this Westcott® product.
Our promise to you is supported by a commitment to offer the most innovative
solutions, exceptional product quality and first class service and support.
Register your purchase.
We have a simple form
for registering your
Westcott purchase that
provides you with added
assurance for your gear:
fjwestcott.com/warranty
Visit fjwestcott.com
Video Tips
Product Support
Knowledge Base
Product Reviews
Contests & More!
FJWESTCOTT.COM
® and ™ designate tradema rks of the F.J. Westcott Co. © F.J. Westcott Co. All rights reser ved.
Loading...
