PMA Prozeß- und Maschinen-Automation GmbH

UNIFLEX

Transmitter UNIFLEX SG45

+ INP -

+SENSE-

EX+

EX-

UNIFLEX

SG 45

Operating manual

English

9499-040-82311

valid from: 10/2009

BlueControl

More efficiency in engineering, more overview in operating:

The projecting environment for the BluePort indicators and rail line - measuring converters / universal controllers, temperature limiters

Mini Version and Updates on

controllers,

ATTENTION!

www.pma-online.de

or on PMA-CD

Explanation of symbols:

g a

© 2008 · PMA Prozeß- und Maschinen-Automation GmbH · Printed in Germany All rights reserved · No part of this document may be reproduced or published in any form or by any means without prior written permission from the copyright owner.

General information

General warning

Caution: ESD-sensitive components

Caution: Read the operating instructions

Read the operating instructions

Note

A publication of PMA Prozeß- und Maschinen Automation P.O.Box 310229 Germany

Content

1. General ............................................5

2. Safety hints ..........................................7

2.1 MAINTENANCE, REPAIR AND MODIFICATION ....................8

2.2 Cleaning .........................................8

2.3 Spare parts .......................................8

3. Mounting ...........................................9

3.1 Connectors .......................................10

4. Electrical connections ..................................11

4.1 Connecting diagram ..................................11

4.2 Terminal connections .................................11

4.3 Connecting diagram ..................................13

4.4 Connection examples .................................14

4.5 Hints for installation ..................................15

4.6 UL approval (optional) .................................15

5. Operation ..........................................16

5.1 Front view .......................................16

5.2 Operating structure ..................................17

5.3 Behaviour after supply voltage switch-on.......................17

5.4 Displays in the operating level ............................18

5.4.1 Display line 1..................................18

5.4.2 Display line 2..................................18

5.4.3 Switch-over with the enter-key ........................18

5.4.4 Slave pointer function .............................19

5.4.5 Selecting the units ...............................19

5.4.6 Extended operating level............................20

6. Functions ..........................................21

6.1 Measuring input INP ..................................21

6.2 Input scaling ......................................22

6.3 Linearization ......................................23

6.4 Filter ..........................................24

6.5 Substitue value for inputs ...............................24

6.6 Input forcing ......................................24

6.7 Set zero ........................................25

6.8 Tare function ......................................25

6.9 Sample&hold amplifier ................................25

6.10 Integrator function ...................................26

6.11 Limit value processing .................................27

6.11.1 Input value monitoring .............................27

6.11.2 Monitoring the number of operating hours and switching cycles ......29

6.12 Analog output configuration ..............................30

6.12.1 Analog output .................................30

6.12.2 Analog output forcing .............................31

6.13 Maintenance manager / error list ...........................31

6.14 Detection and display of sensor and wiring errors ..................32

6.15 Resetting to factory setting ..............................33

SG 45 3

7. Configuration level.....................................34

7.1 Configuration survey ................................34

7.2 Adjustment:

......................................34

7.3 Configurations .....................................35

8. Parameter-level ......................................41

8.1 Parameter-survey ...................................41

8.2 Adjustment:

......................................41

8.3 Parameters .......................................42

9. Installation and calibration................................43

9.1 Initial setting ( SEt) ................................43

9.2 Calibration ( CAL)..................................44

9.3 Scaling (

10.Engineering Tool BlueControl

SCAL) ....................................45

.............................46

11.Versions ...........................................47

12.Technical data .......................................48

13.Index ..........................................51

4 SG 45

1 General

Thank you very much for buying a transmitter for load cells, strain gauges, and melt pressure sensors UNIFLEX SG 45. The UNIFLEX SG 45 transmitters are suitable for precise, cost-efficient contol tasks in all industrial applications. Every SG 45 is equipped with a strain gauge signal input, an universal output and two relays. Optionally the tranmitter can be fitted with various interfaces.

General

Galvanic isolation is provided between inputs and outputs as well as from the supply voltage and the communica

tion interfaces.

Applications

CI 45 is used for measurement, scaling of electrical signals, e.g. for

Strain gauges

Load cells

Melt pressure sensors

Pressure sensors

...

At-a-glance survey of advantages

Compact construction, only 22,5 mm wide Clips onto top-hat DIN rail Plug-in screw terminals or spring clamp connectors Dual-line LC display with additional display elements Process values always in view Convenient 3-key operation Ability for wireless cross-communication with other units mounted on top-hat rail Strain gauge input with high signal resolution (>15 bits) Universal output with high resolution (14 bits) as combined current / voltage output Quick response, only 50 ms cycle time, i.e. also suitable for fast signals Two relay outputs Customer-specific linearization Tare function Min/max indicator (‘slave pointer’) Logical linking of digital outputs, e.g. for common alarms Preset for output value

Further documentation for DMS Messumformer SG 45:

–

This operating manual 9499 040 82318

–

Data sheet SG 45 9498 737 57333

–

Operating note SG 45 9499 040 82441

–

Interface description 9499 040 72018

SG 45 5

General

6 SG 45

2 Safety hints

This unit was built and tested in compliance with VDE 0411-1 / EN 61010-1 and was delivered in safe condition. The unit complies with European guideline 89/336/EWG (EMC) and is provided with CE marking. The unit was tested before delivery and has passed the tests required by the test schedule. To maintain this condition and to ensure safe operation, the user must follow the hints and warnings given in this operating manual and operate this instrument in compliance with the instructions given in this manual.

Safety hints

The unit is intended exclusively for use as a measurement and control instrument in technical installations.

Warning If the unit is damaged to an extent that safe operation seems impossible, the unit must not be taken into operation.

ELECTRICAL CONNECTIONS

The electrical wiring must conform to local standards (e.g. VDE 0100). The input measurement and control leads must be kept separate from signal and power supply leads. Using screened cables is mandatory! The screening must be connected to ground potential. In the installation of the controller a switch or a circuit-breaker must be used and signified. The switch or cir cuit-breaker must be installed near by the controller and the user must have easy access to the controller.

COMMISSIONING

Before instrument switch-on, check that the following information is taken into account:

Ensure that the supply voltage corresponds to the specifications on the type label.

•

All covers required for contact protection must be fitted.

•

If the controller is connected with other units in the same signal loop, check that the equipment in

•

the output circuit is not affected before switch-on. If necessary, suitable protective measures must be taken.

The unit may be operated only in installed condition.

•

Before and during operation, the temperature restrictions specified for controller operation must

•

be met.

a a

Warning During operation, the ventilation slots of the housing must not be covered.

The measurement inputs are designed for measurement of circuits which are not connected directly with the mains supply (CAT I). The measurement inputs are designed for transient voltage peaks up to 800V against PE.

Warning The ventilation slots must not be covered during operation.

SHUT-DOWN

For taking the unit out of operation, disconnect it from all voltage sources and protect it against accidental operation. If the controller is connected with other equipment in the same signal loop, check that other equipment in the output circuit is not affected before switch-off. If necessary, suitable protective measures must be taken.

SG 45 7

Safety hints

2.1 MAINTENANCE, REPAIR AND MODIFICATION

The units do not need particular maintenance. There are no operable elements inside the device, so the user must not open the unit

Modification, maintenance and repair work may be done only by trained and authorized personnel. For this purpose, the PMA service should be contacted.

Warning When opening the units, or when removing covers or components, live parts and terminals may be exposed. Connecting points can also carry voltage.

Caution When opening the units, components which are sensitive to electrostatic discharge (ESD) can be exposed.

You can contact the PMA-Service under:

PMA Prozeß- und Maschinen-Automation GmbH Miramstraße 87 D-34123 Kassel

Tel. +49 (0)561 / 505-1257 Fax +49 (0)561 / 505-1357 e-mail: mailbox@pma-online.de

2.2 Cleaning

The cleaning of the front of the controller should be done with a dry or a wetted (spirit, water) handkerchief.

2.3 Spare parts

As spare parts für the devices the following accessory parts are allowed:

Description Order-No.

Connector set with screw terminals 9407-998-07101 Connector set with spring-clamp terminals 9407-998-07111 Bus connector for fitting in top-hat rail 9407-998-07121

Connector for bus connector inverted, left side, horizontal cable outlet *1 9407-998-07131

Connector for bus connector inverted,

*1 screw connection

right side, vertical cable outlet *11 9407-998-07141

8 MAINTENANCE, REPAIR AND MODIFICATION SG 45

3 Mounting

Mounting

bmessungen / dimensions

22.5

(0,87”)

max.

117.5 (4,63”)

55°C

-10°Cmin.

111 (4, 37 ”)

max. 95% rel.

Klemme /

1516

terminal

Klemme /

terminal

11 1 2

Montage / mounting

5.5 (0,20”)

2.3

(0,08”)

click

99 (3,90”)

Demontage / dismantling

a a a

l a

The unit is provided for vertical mounting on 35 mm top-hat rails to EN 50022. If possible, the place of installation should be exempt of vibration, aggressive media (e.g. acid, lye), liquid, dust or

aerosol. The instruments of the rail line series can be mounted directly side by side. For mounting and dismounting, min. 8 cm

free space above and below the units should be provided. For mounting, simply clip the unit onto the top-hat rail from top and click it in position.

To dismount the unit, pull the bottom catch down using a screwdriver and remove the unit upwards.

The transmitter SG 45 does not contain any maintenance parts, i.e. the unit need not be opened by the customer.

The unit may be operated only in environments for which it is suitable due to its protection type.

The housing ventilation slots must not be covered.

In plants where transient voltage peaks are susceptible to occur, the instruments must be equipped with additional protective filters or voltage limiters!

Caution! The instrument contains electrostatically sensitive components .

Please, follow the instructions given in the safety hints.

To maintain contamination degree 2 acc. to EN 61010-1, the instrument must not be installed below contactors or similar units from which conducting dust or particles might trickle down.

SG 45 9

Mounting

3.1 Connectors

The four instrument connectors are of the plug-in type. They plug into the housing from top or bottom and click in posi tion (audible latching). Releasing the connectors should be done by means of a screwdriver. Two connector types are available:

Screw terminals for max. 2,5 mm2conductors

•

Spring-clamp terminals for max. 2,5 mm2conductors

•

Before handling the connectors, the unit must be disconnected from the supply voltage.

Tighten the screw terminals with a torque of 0,5 - 0,6 Nm. With spring-clamp terminals, stiff and flexible wires with end crimp can be introduced into

the clamping hole directly. For releasing, actuate the (orange) opening lever.

Contact protection: Terminal blocks which are not connected should remain in the socket.

10 Connectors SG 45

4 Electrical connections

4.1 Connecting diagram

INP1

EX +

INP

+ Sense -

Electrical connections

EX -

di1

1234

4.2

OUT3

PWR

~90-260V

Terminal connections

~24V

System

top

RGND

R-CAL

Data A Data B

RS 485

OUT1

OUT2

RGND

Data A Data B

11 12 13 14

15 16 17 18

Faulty connection might cause destruction of the instrument !

1 Connecting the supply voltage

Dependent on order

90 … 260 V AC terminals: 15,16

•

24 V AC / DC terminals: 15,16

•

For further information, see section "Technical data"

Instruments with optional system interface: Energization is via the bus connector of field bus coupler or power supply module. Terminals 15, 16 must not be used.

2 Connecting input INP1

Input for strain gauge (in 4 and 6-wire connection) or for melt pressure sensors (with/without calibration shunt).

a Excitation voltage for bridge (EXITATION ) terminals: 1, 4 b Excitation voltage measuring signal (Sense) terminals: 2, 3 c Bridge signal (input) terminals: 5, 6

SG 45 Connecting diagram 11

Electrical connections

3 Connecting input di1

Digital input

control input (as a potentialfree contact) terminals: 7, 8

4 Connecting outputs OUT1 / OUT2 (optional)

Relay outputs max. 250V/2A NO contacts with a common terminal.

•

5 Connecting output OUT3

Universal output

d current (0...20mA) terminals: 11, 12 e voltage (0...10V) terminals: 12, 13

6 Connecting the bus interface (optional exept d)

RS 485 interface with MODBUS RTU protocol

* see interface description MODBUS RTU: (9499-040-72011)

OUT1 terminals: 17, 18 OUT2 terminals: 17, 14

12 Terminal connections SG 45

4.3 Connecting diagram

The instrument terminals used for the engineering can be displayed and printed out via BlueControlÒ( menu File \ Print preview - Connection diagram).

Example:

Device1.bct

Connecting plan

Terminal connector 1

Name Description

Electrical connections

Sensor supply

Probe cable

Process value X1

Terminal connector 2

Name Description

0...20 mA continuous, signal source: Process value

Alarm Limit 1, Alarm INP1-Error

Terminal connector 3

Name Description

Alarm INP1-Error

SG 45 Connecting diagram 13

Electrical connections

4.4 Connection examples

Example: Connection load cell with 4 or 6-wire bridge

Sense+

Excitation+

2 SENSE + 1

EX+

+ INP -

Ausgang

Excitation-

Sense-

6INP5INP+

4EX-

3 SENSE -

EX+

+SENSE-

EX-

only with 6-wire bridge

After initialization, a test for connection of the sense signal is made automatically (6-wire connections )

Example: Connection of a (melt) pressure sensor in 4-wire technology with a calibrating resistor

Excitation

EX+

Ausgang

Excitation

R-CAL

Example: RS 485 interface with RS 485-RS 232 converter See documentation 9499-040-72011

RGND

Data A

Data B

6INP-

5INP+

4EX-

3 SENSE -

Data A

Data B

+ INP -

EX+

+SENSE-

EX-

Master z.B. / e.g.

Converter RS 232-RS 485

(ADAM-4520-D)

DATA+ 1

(RS-485)

DATA-

TX+ TXRX+

RX-

(R)+Vs (B)GND 10

(RS-422)

14 Connection examples SG 45

4.5 Hints for installation

Measurement and data lines should be kept separate from control and power supply cables.

Sensor measuring cables should be twisted and screened, with the screening connected to

earth. External contactors, relays, motors, etc. must be fitted with RC snubber circuits to manufacturer

specifications. The unit must not be installed near strong electric and magnetic fields.

The temperature resistance of connecting cables should be selected in accordance with the

local conditions.

Electrical connections

a a

The unit is not suitable for installation in explosion-hazarded areas.

Faulty connection can lead to the destruction of the instrument.

Please, follow the instructions given in the safety hints.

4.6 UL approval (optional)

For compliance with UL regulations, the following points must be taken into account:

Use only copper (Cu) wires for 60 / 75 °C ambient temperature.

The connecting terminals are designed for 0,5 – 2,5 mm2Cu (12-30 AWG) conductors.

The screw terminals must be tightened using a torque of 0,5 – 0,6 Nm.

The instrument must be used exclusively for indoor applications.

Max. ambient temperature: 55°C.

Maximum operating voltage: see technical data.

Max. ratings of relay contacts: 250VAC, 2A (resistive)

SG 45 Hints for installation 15

Electrical connections

16 UL approval (optional) SG 45

Operation

5 Operation

5.1 Front view

1 Line 1: process value display 2 Line 2: display of unit / extended operating level / error list /

Conf and PArA level values

3 Tare / sample & hold activated 4 Error list (2 x ô ), e.g.

· Fbf. x sensor fault INP. X

· Pol. x wrong polarity INP. X

· Lim. x limit value alarm

· ...

5 Increment key / "slave pointer", maximum value 6 Enter key to select extended operating level or error list

Parameter-, Konfigurations-, Installations-Ebene

7 Status indicator LEDs

· green: limit value 1 OK

· green blinking: no data exchange with bus coupler

(only on instruments with optional

system interface)

· red: limit value 1 active

· red blinking: instrument fault, configuration mistake

8 Display elements, active as bars 9 Status of switching output OUT1 active 0 Status of switching output OUT2 active ! Decrement key/ "slave pointer", minimum value

§ PC connection for the BlueControl

engineering tool

+ INP -

EX+

+SENSE-

EX-

17 Front view SG 45

In the first LCD-display line the measured value is shown. The second LCD-line normally shows the setpoint. When changing over to the parameter setting, configuration or calibration level and at the extended operating level, the parameter name and value are displayed alternately.

§ : To facilitate withdrawal of the PC connector from the instrument, please, press the cable left.

5.2 Operating structure

The instrument operation is divided into four levels:

Operation

450.3

äüüü

The access to the parameter, configuration and calibrating level can be disabled using the following two methods:

Level disabling by adjustment in the engineering tool (IPar, ICnf, ICal). Display of disabled levels is suppressed.

450.3

InSt äüüü

450.3

PARA äüüü

450.3

CONF äüüü

450.3

END äüüü

PASS

Operating level

Installation and

Calibrating level

See page

Parameter level

See page 45

Calibrating level

See page 38

The access to a level can be disabled by entry of a pass number (0 … 9999). After entry of the

adjusted pass number, all values of the level are available. With faulty input, the unit returns to the operating level. Adjusting the pass number is done via BlueControl

Individual parameters which must be accessible without pass number, or from a disabled parameter level, must be copied into the extended operating level.

Factory-setting:

all levels are accessible without restrictions, pass number PASS = OFF

5.3 Behaviour after supply voltage switch-on

After switching on the supply voltage, the instrument starts with the operating level. The operating status is as before power-off.

PASS

SG 45 Operating structure 18

Operation

5.4 Displays in the operating level

5.4.1 Display line 1

The display value is the value resulting from function.1, function.2, function.3 handling. It is also called process value (see also section/page 23.)

5.4.2 Display line 2

The value to be displayed continuously in the second LCD line can be selected from different values via the

BlueControl

As default, the adjusted engineering unit is displayed.

engineering tool.

450.3

äüü

g g g

5.4.3 Switch-over with the enter-key

The values in display line 2 can only be displayed, but not changed.

Reset to display of the engineering unit is possible by deleting the entry for line 2..

With faulty input values, signals dependent on the inputs (e.g. Inp1, Inp2, display value, Out3) also indicate FAIL.

450.3

55.0

äüüü

1 Default settings as setpoint 2 Display of output OUT3 in % (with corre

sponding scaling)

By using the enter-key, different values can be called in display 2.

1 Displaying the defined display 2 value (via BlueControl

Standard setting is unit

2 Calling up the error list, if messages are supplied.

If there is more than one message with every push of the enter key the next message is displayed.!!!

3 Calling up the extended operating level, if messages

are supplied. If there is more than one message with every push of the enter key the next message is displayed.!!!!

4 Returning to the original displayed value.

If for 30 s no key is pushed, the display automatically returns to the origin.

278.3

°C

äüüä

2FE

278.3

FbF.1 äüüä

12FE

278.3

L.1 дььдь

278.3

°C

äüüä

2FE

19 Displays in the operating level SG 45

5.4.4 Slave pointer function

The minimum and maximum input values are stored in the unit.

Operation

450.3

ûC

äüüü

min

450.3

26.7

äüüü

The minimum input value is displayed as long as key Ì is pressed.

Deleting the minimum value The minimum value is deleted by pressing key È whilst key Ì is kept pressed. Whether the minimum value should be deleted also by the digital input (rES.L) can be determined during configuration. Deleting the maximum value To delete the maximum value, press key Ì whilst keeping key È pressed. Whether the maximum value should be deleted also by the digital input (rES.H) can be determined during configuration.

The maximum input value is displayed as long as key È is pressed.

450.3

ûC

äüüü

max

450.3

502.4

äüüü

Deleting the minimum and maximum values is possible also via interface.

g g

5.4.5 Selecting the units

When de-energizing UNIFLEX SG 45 the minimum and maximum values are deleted.

In case of error of the display value (e.g. input fail behaviour), the minimum and maximum values are also set to FAIL. When a valid value is displayed again, the minimum and maximum value are deleted.

The unit to be displayed is determined via configuration D.Unt. By selecting D.Unt = 22, display of any max. 5-digit unit or text can be determined.

4.5

äüüü

450.3

TI451 äüüü

1 Unit (example): kilogram 2 Text (example): TAG no.

UNIFLEX SG 45 Displays in the operating level 20

Operation

5.4.6 Extended operating level

The operation of important or frequently used parameters and signals can be allocated to the extended operating level. This facilitates the access, e.g. travelling through long menu trees is omitted, or only selected values are operable, the

other data of the parameter level are e.g. disabled. Display of the max. 8 available values of the extended operating level is in the second LCD line. The content of the extended operating level is determined by means of the BlueControl

select entry "Operation level" in the "Mode" selection menu. Further information is given in the on-line help of the engi neering tool.

450.3

äüüü

engineering tool. For this,

Press key ô to display the first value of the extended

operating level (after display of error list, if necessary). The selected parameters can be changed by

pressing keys Ì and È .

450.3

H.I äüüü

ô press to display the next parameter

450.3

500.0

äüüü

450.3

L.I äüüü

ô return to normal display after the last parameter

450.3

100.0

äüüü

Unless a key is pressed within a defined time (timeout = 30 s), the operating level is displayed again.

21 Displays in the operating level SG 45

Operation

SG 45 Displays in the operating level 22

6 Functions

The signal data flow of transmitter SG 45 is shown in the following diagram:

Functions

6.1 Measuring input INP

Measuring range Configuration S.tYP

0.5 mV/V (5 mV) 1 mV/V (10 mV) 2 mV/V (20 mV)

4 mV/V (40 mV) 63

Input for bridge circuit (3 possibilities):

Bridge supply + mV input (4-wire)

Bridge supply + mV input + Sense input (for measuring the bridge voltage applied to the sensor) (6-wire):

Bridge supply + mV input + calibration output (for defined change of the bridge resistance): Using a built-in switch, a known resistor is switched in parallel to one of the 4 bridge resistors, configurable via CAL..M.

Automatic 4 or 6-wire detection after start-up

Automatic detection, if the sense signal is connected: This function is active during start-up (after switch-on or re-con figuration). See circuit example on page 9.

Due to 6-wire connection, errors caused by voltage drops on the supply leads are prevented.

60 61 62

SG 45 Measuring input INP 23

6.2 Input scaling

Scaling of input values is possible. This correction influences the measured value after an eventually executed linearization.

Functions

Specification of the input value of the lower and upper scaling point is in units of the relevant physical quantity.

phys.

quantity

OuH.x

mA / V

OuL.x

InL.x

Example for %

The Parameters InL, OuL, InH and OuH are always visible. These are created during calibration.

Parameters InL and InH determine the input range.

Example with %: InL= 4 and InH = 10 means that measuring from 4 to 10 % is required.

For resetting the input scaling, the settings for InL and OuL as well as InH and OuH must correspond.

InH.x

mA/V

phys. quantity

SG 45 Input scaling 24

6.3 Linearization

The input values of the input can be linearized via a table.

This feature can be used e.g. to realize linearizations to specification for non-linear curves. The “ Lin” table is always used when S.Lin = 1: “Linearization to specification” is set in INPm. The input

signals are filled in in units of the physical quantity (scaling result).

Non-linear signals can be linearized using up to 32 segment points. Each segment point comprises an input (In.1 … In.32) and an output (Ou.1 … Ou.32).

These segment points are interconnected automatically by straight lines. The straight line between the first two segment points is extended downwards and the straight line between the two highest segment points is extended upwards, i.e. a defined output value for each input value is provided.

With an In.x value switched to OFF, all further segments are switched off.

Functions

Required: Condition for the input values is an ascending order.

In.1 < In.2 < ...< In.32.

See also page 44.

Ou.32

. . . . . .

Ou.1

In.1In.32

UNIFLEX SG 45 Linearization 25

Functions

b.F

6.4 Filter

A 1st order mathematical filter with adjustable time constant and bandwidth is built in.

Output

Input

The filter bandwidth b.F1 is the adjustable tolerance around the measured value within which the filter is active. Measurement value changes in excess of the adjusted bandwidth are not filtered.

6.5 Substitue value for inputs

If a substitute value for an input is activated, this value is used for further calculation with a sensor fault, independent of the selected input function. The selected controller output reaction on sensor fault, configuration FAIL, is omitted.

With factory setting, the substitute value is switched off.

Before activation of a substitute value In.F, the effect on the control loop must be considered.

6.6 Input forcing

Setting f.AIx = 1 (only via BlueControl®) can be used for configuring the input for value entry via the interface (=forc ing).

Please, check the effect on the control loop in case of failure of input value / communication and exceeded measuring range.

Tip: The selected unit can be displayed on line 2.

26 Filter SG 45

6.7 Set zero

The function is enabled during configuration (Func r Func.1 =1. Due to its effect, the display is reset to zero, when e.g. small rest quantities are still on the scale and cannot be re moved immediately. To prevent excessive use of the zero setting function, the zero offset (page 30) can be provided with an alarm. After cleaning the scale, zero setting must be repeated. Dependent on configuration, the zero setting function can become effective by a pulse on digital input di1, a limit value, by pressing a combination of keys or via an interface signal (LOGI r tArA). See page 41.

6.8 Tare function

Functions

Switching on the tare function sets the instantaneous input value to zero and measurement is continued with this off set z.B. um ein Leergewicht abzuziehen. By switching off the tare function, the actual measurement value is displayed again.

Measurement value

Effective value

450.3

ûC

äüüü

The tare function is enabled during configuration (Func r Fnc.3 = 1). Dependent on configuration, the tare function can be activated by digital input di1 a limit value, a key combination or interface (LOGI r tArA. . See page 41 An active tare function is displayed as an active bar for display element ‘F’ .

6.9 Sample&hold amplifier

With the sample & hold function activated, the measured value is held on the display. After de-activating the sample & hold function, the actual measurement value is displayed again.

75.9

ûC

äüäü

617.2

ûC

äüüü

Measurement value

Effective value

450.3

ûC

äüüü

450.3

ûC

äüäü

450.3

ûC

äüüü

450.3

ûC

äüäü

The sample&hold amplifier function can be activated during configuration (Func r Fnc.3 = 2). Dependent on configuration, the sample&hold function can be activated by digital input di1 a limit value, a key combi nation or interface (LOGI r HOLd). An active sample&hold amplifier function is displayed as an active bar for display element ‘F’ .

SG 45 Set zero 27

450.3

ûC

äüüü

Functions

6.10 Integrator function

The input signal can be totalized by means of a selectable integrator (ConF \ Func \ Fnc.3 = 3).

Function:

Integrator with adjustable time constant (PArA \ Func \ t.I) [specified in minutes] and adjustable input offset (PArA \ Func \ P.I)

Formula:

With a constant input value, the integrator output reaches the specified value after elapse of the adjusted time con stant t.I.

Reset:

Dependent on selection (ConF\Logi\rES.I), the integrator can be reset via:

y(t) = y(t-Tr) + Tr/t * (x +P.I)

y(t) = integrator output y(t-Tr) = integrator output of the last cycle Tr = cycle time (100ms INP1, 140ms INP1 + INP2) t = time constant x = integrator input P.I = input offset (zero offset)

· Digital input di1

· Key combination Enter + increment key

(keep the Enter key pressed and actuate the increment key)

· Limit values Limit1 to Limit3

Example 1:

A flow in m3/h is measured. The integrator should measure the overall flow quantity. The measured flow is related to time unit hours, i.e. time constant t.I = 1 hour = 60 min must be used. Parameter P.I can be used for zero correction.

Example 2: pulse output

The integrator is activated. The resulting process value is monitored using a limit value (without memory) , e.g. Lim1. Lim.1 is defined as integrator reset function. Limit value Lim.1 is output e.g. on ouput 1 (OUT.1). When exceeding limit value Lim1, there is a signal change at OUT1 during a period (50ms).

H.1

P. I

Lim.1

Out.1

t (cycle)

28 Integrator function SG 45

6.11 Limit value processing

Max. three limit values can be configured for the outputs. Generally, each one of outputs Out.1... Out.2 can be used for limit value or alarm signalling.

Several signals allocated to an output are linked by a logic OR function.

6.11.1 Input value monitoring

Functions

The signal to be monitored can be selected separately for each alarm in the configuration. The following signals are available:

Process value (display value)

•

Measured value INP

•

Zero adjustment

•

Each of the 3 limit values Lim.1 … Lim.3 has 2 trigger points H.x (Max) and L.x (Min), which can be switched off individually (parameter = “OFF”). The hysteresis HYS.x of each limit value is adjustable.

Input value monitoring is as shown below:

operating principle with absolute alarm (Ex. Lim.1)

L.1 = OFF

Display range

-1999

H.1

HYS.1

9999

Limit value 1 Outputs

LED rot / red

H.1 = OFF

-1999

L.1

9999

Display range

Limit value 1

L.1

HYS.1

Outputs

LED rot / red

-1999

L.1

H.1

9999

Display range Limit value 1

H.1

L.1

Outputs

rot / red

HYS.1 HYS.1

LED

rot / red

Normally open: ( ConF / Out.x/O.Act = 0 ) (as shown in the example) Normally closed: ( ConF / Out.x/O.Act = 1 ) (inverted output relay action)

UNIFLEX SG 45 Limit value processing 29

Functions

Alarm delay

An alarm can become effective with a delay: the alarm output is set only after elapse of the adjusted delay time, provided that the limit value is still exceeded. Shorter alarms than the adjusted delay are ignored.

Example: Alarm delay

Signal change monitoring

Another limit value processing function is signal change monitoring (per minute).

Behaviour with signal change (Ex. Lim1)

L.1 = OFF

{{x

rot / red

>H.1

LED

t [min]

Lim.1

{{x

>H.1

LED

rot / red

SG 45 Limit value processing 30

Functions

With measurement value or signal change with latch selected ( ConF / Lim / Fnc.x=2, 4), the alarm relay remains set, until it was reset in the error list, This alarm can be reset via:

di1 or

a limit value a key combination or via interface (Lim1 ... Lim3 = 1). For this, reset value 0 must be specified in the error list or via the interface. ( r page 36).

H.1 = OFF

{

Lim.1

<L.1

{

t [min]

LED

rot / red

After power on or an engineering download an used input filter has an effect on the gradient of the input signal. Therefore a valid alarm monitoring can only be processed after a certain rise up time. This time depends on the value of the filter time constant t.F. For t.F = 0 the monitoring results are valid immediately.

31 Limit value processing SG 45

Functions

6.11.2 Monitoring the number of operating hours and switching cycles

Operating hours

The number of operating hours can be monitored. When reaching or exceeding the adjusted value, signal InF.1 is acti vated (in the error list and via an output, if configured).

The monitoring timer starts when setting limit value C.Std. Reset of signal InF.1 in the error list will start a new moni toring timer. Monitoring can be stopped by switching off limit value C.Std.

Adjusting the limit value for operating hours C.Std can be done only via BlueControl®.

The current counter state can be displayed in the BlueControl

The number of operating hours is saved once per hour. Intermediate values are lost when switching off.

Number of switching cycles

The output number of switching cycles can be monitored. When reaching or exceeding the adjusted limit value, signal InF.2 is activated (in the error list and via an output, if configured).

The monitoring timer starts when setting limit value C.Sch. Reset of signal InF.2 in the error list will start a new moni toring timer. Monitoring can be stopped by switching off limit value C.Sch.

A switching cycle counter is allocated to each output. Limit value C.Sch acts on all switching cycle counters.

Adjusting the limit value for the number of switching cycles C.Sch can be done only via BlueControl®.

The current counter state can be displayed in the BlueControl

The number of switching cycles is saved once per hour. When switching off, intermediate values are lost.

expert version.

32 Limit value processing UNIFLEX SG 45

Functions

6.12 Analog output configuration

6.12.1 Analog output

The two output signals (current and voltage) are available simultaneously. Adjust ConF / Out.3 / O.tYP to se lect the output type which should be calibrated.

ConF / Out.3: O.tYP = 1 Out.3 0...20mA continuous

= 2 Out.3 4...20mA continuous = 3 Out.3 0...10V continuous = 4 Out.3 2...10V continuous

phys.

size

Out.1

phys. size

Out.0

0/4mA

0/2V

Parameter O.Src defines the signal source of the output value. Example:

O.Src = 3 signal source for Out.3 is the process value

Scaling of the output range is done via parameters Out.0 and Out.1. The values are specified in units of the physical quantity.

Out.0 = -1999...9999 scaling Out.3for 0/4mA or 0/2V Out.1 = -1999...9999 scaling Out.3for 20mA or 10V

Example: Output of the full input range (0 … 100)

Out.0 = -100 Out.1 = 1200

Example: output of a limited input range, e.g. 60.5 … 63.7 °C)

Out.0 = 60.5 Out.1 = 63.7

The output behaviour in the event of an input value error can be determined using O.FAI .

20mA

10V

mA / V

g g g

33 Analog output configuration SG 45

Please, note: the smaller the span, the higher the effect of input variations and resolution.

Using current and voltage output in parallel is possible only in galvanically isolated circuits.

Configuration O.tYP = 2 (4 … 20mA) or 4 (2...10V) means only allocation of the reference value (4 mA or 2V) for scaling of output configuration Out.0. Therefore, output of smaller values is also possible rather than output limiting by reference value 4mA / 2V.

Configuration O.tYP = 0/1 (0/4...20mA) or 2/3 (0/2...10V) determines, which output should be used as a calibrated reference output.

6.12.2 Analog output forcing

By adjusting f.Out = 1 (only via BlueControlÒ), the output can be configured for value input via interface, or by means of an input value at extended operating level (=Forcing).

Functions

g g

This setting can be used also for e.g. testing the cables and units connected in the output circuit.

This function can also realize a setpoint potentiometer.

SG 45 Analog output configuration 34

Functions

6.13 Maintenance manager / error list

In case of one or several errors, the error list is always displayed at the beginning of the extended operating level .

A current input in the error list (alarm or error) is always indicated by display of letter E .

For display of the error list, press key ô once.

E- display element Description Possible remedial action

blinks

off

Error list:

Alarm due to existing error - Determine the error type in the error list via the error number

Error removed, Alarm not ac knowledged

no error, all alarm entrys deleted

450.3

ûC

äüüä

- remove error

- acknowledge alarm in the error list by pressing the È -or

the Ì -key

- the alarm entry is deleted by doing so

Name

E.1

E.2

E.3

E.4

FbF.1

POL.1 Lim.1

Lim.2 Lim.3

Inf.1

Inf.2

*) “ FAIL” is shown on the process value display.

Internal error, cannot be corrected

Internal error, resettable E.g. EMC trouble Keep measuring and supply cables separate.

Configuration error, resettable

Hardware error Code number and hardware

INP*) sensor break Defective sensor Replace INP sensor

INP*) polarity error Wiring error Change INP polarity Latched limit value alarm

1/2/3

Time limit value message Preset number of operating

Switching cycle messa ge(digital outputs)

Description Cause Possible remedial action

E.g. defective EEPROM Contact PMA service

Missing or faulty configuration

not identical

Wiring error Check INP connection Overshoot Change the measuring range

Adjusted limit value 1/2/3 exceeded

hours reached

Preset number of switching cycles reached

Return device to manufacturer

Protect contactors by means of RC snubber circuits

Check interdependencies for configurations and parameters

Contact PMA service

Check process

Application-specific

35 Maintenance manager / error list SG 45

Functions

Latched alarms Lim1/2/3 (E-element displayed) can be acknowledged, i.e. reset via digital alarm di1.

For Configuration, see page 41: ConF / LOGI / Err.r

When an alarm is still pending, i.e. unless the error cause was removed ( E display blinks), latched alarms cannot be acknowledged and reset.

Error-state Signification 2 Pending error Change to error status 1after error removal 1 Stored error Change to error status 0 after acknowledgement in error list 0 0 no error/message Not visible, except during acknowledgement

If sensor errors should not be on the error list any more after error correction without manual reset in the error list, suppression via BlueControl

CONF / othr / ILat 1 blocked

This setting is without effect on limit values Lim.1 … 3 configured for storage.

is possible by means of setting ILat.

6.14 Detection and display of sensor and wiring errors

Break of the supply-1), measuring or sense lines: "FAIL" on the process value display and

•

FbF.1" in the error list are displayed.

Wrong polarity of supply, sense and input signal lines: "FAIL" on process value display and

•

POL.1" in error list are displayed. Detection of wrong polarity of sense takes place during

instrument start-up.

Subsequent correction of the sense wiring is detected only after instrument re-start. (i.e. the instrument must be switched off and on again.)

Short circuit of supply and sense lines ==> behaviour as with break of the supply lines: " FAIL"

•

on the process value display and "

Short circuit of measuring lines: measuring signal = 0

•

Overshoot of measurement input: “FAIL” on process value display and "FbF.1" in the error list

•

are displayed.

Entry of a substitute value ( In.F ) effective in the event of a sensor error is possible.

FbF.1" in the error list are shown.

With 4-wire connection, the EX+ line is monitored in addition to the measurement lines.

After a break of the EX minus line, the measured value is not plausible.

SG 45 Detection and display of sensor and wiring errors 36

Functions

6.15 Resetting to factory setting

In case of faulty configuration, the SG 45 can be reset to the default manufacturers condition.

For this, the operator must keep the keys increment and

decrement pressed during power-on. Then, press key increment to select YES.

Confirm factory resetting with Enter and the copy

procedure is started (display

Afterwards the device restarts.

In all other cases, no reset will occur (timeout abortion).

COPY).

+ Power on

FAC

torY

FAC

yEs

switch on power supply

FAC

COPY

8.8.8.8

#:#:#:#:# ääää

g g

If one of the operating levels was blocked in BlueControlÒ, reset to factory setting is not possible.

If a pass number was defined (via BlueControl® ), but no operating level was blocked, enter the correct pass number when prompted with the text PASS in 3. A wrong pass number aborts the reset action.

The copy procedure ( COPY) can take some seconds.

Now, the transmitter is in normal operation.

37 Resetting to factory setting SG 45

Configuration level

7 Configuration level

7.1 Configuration survey

Dependent on the device version and further adjusted configurations, configurationdata can be hidden. The data which can be operated via the front panel are shown below.

Func

Fnc.1 Fnc.2

Fnc.3

Inp.1

StYP S.Lin

In.F

Lim

Fnc.1 Src.1 Fnc.2 Src.2 Fnc.3 Src.3

OUt.1

0.Act Lim.1

Lim.2 Lim.3

FAi.1

Sb.Er

OUt.2

0.Act Lim.1 Lim.2

Lim.3 FAi.1

Sb.Er

OUt.3

O.tYP Out.0

Out.1 O.src

O.FAI

LOGI

di.Fn L_r

Err.r

tArA HOLd

rES.L rES.H rES.I CAL.t ZEro

othr

S.If Addr bAud

PrtY dELY FrEq

D.Unt

CAL.M

C.dEL

End

7.2 Adjustment:

The configuratiuons can be adjusted by means of keys ÈÌ .

•

Transition to the next configurationelement is by pressing key ô .

•

After the last configuration of a group, donE is displayed and followed by automatic change to the

•

next group

g g

Return to the beginning of a group is by pressing the ô key for 3 sec.

Please check all interdependent parameters for their validity.

38 Configuration survey SG 45

Configuration level

7.3 Configurations

Dependent on device version und adjusted configurations values not needed become hidden.

µ Entrys marked with this symbol are selectable only with existing device-option.

Selection of functions Func

Name Value range Description

Fnc1

Fnc.2

Fnc.3

Function 1

0 1

0 3

0 2 3

No function

Zero setting

Function 2 No function

Tare

Function 3 No function

Sample & Hold Integrator

Input INP

Name Value range Description

S.tYp

60 61 62 63

S.Lin

0 1

In.F

Sensor type

0,5 mV/V 1 mV/V 2 mV/V 4 mV/V (the selection for sensors with 3,33mV/V) Linearization No linearization Special linearization Alternative value

Limit values Lim1 … Lim3

Name Value range Description

Fnc.1

(Fnc.2) (Fnc.3)

Src.1

(Src.2) (Src.3)

C.Std

C.Sch

0 1 2

3 4

0 3

OFF; 1 …

9999999

OFF; 1 …

9999999

Function of limit 1 (2, 3)

Switched off Measurement value Measured value monitoring + alarm status latch. A stored limit value can be reset

via error list or a digital input (® LOGI/ Err.r). Signal change (in minutes). Signal monitoring for rate of change (per minute) + storage of the alarm status. A sto

red limit value can be reset via error list or a digital input (® LOGI/ Err.r).

Source of limit 1 (2, 3)

process value = displayed value Measured value INP Zero offset (difference between the calibrated zero and the value at the time of

zero setting) Control operating hours (only visible with BlueControlÒ!)

Control switching cycles (only visible with BlueControlÒ!)

39 Configurations SG 45

Configuration level

Outputs Out.1 and Out.2 (relay)

Name Value range Description

O.Act

0 1

Lim.1

0 1

Lim.2

0 1

Lim.3

0 1

FAi.1

0 1

Sb.Er System bus error message µ (only visible with BlueControlÒ!)

0 not active 1 active

Inf.1 Status message for operating hours (only visible with BlueControlÒ!)

0 1

Inf.2 Status message for number of switching cycles (only visible with BlueControlÒ!)

0 1

fOut Forcing of the output (only visible with BlueControlÒ!)

0 1

Direction of operation OUT1

Direct / normally open Inverse / normally closed

Signal limit 1

not active active

Signal limit 2

not active active

Signal limit 3

not active active

Signal INP fail

not active active

not active

active

not active The value for this analog output is defined via interface.

Output Out.3 (analog)

Name Value range Description

O.tYP

1 2 3 4

Out.0

Out.1

-1999

...9999

-1999

...9999

O.Src

3 7

O.FAI

0 1

fOut Forcing of the output (only visible with BlueControlÒ!)

0 1

Signal type OUT3

0 ... 20 mA continuous 4 ... 20 mA continuous

0...10V continuous

2...10V continuous

Skaling of analog output for 0% (0/4mA e.g.. 0/2V )

Skaling of analog output for 100% (20mA e.g. 10V)

Signal source for analog output OUT3

Process value (scaled and corrected) Measured value (raw value of bridge signal) Fail behaviour upscale downscale

not active the value for this analog input is defined via interface.

SG 45 Configurations 40

Configuration level

Signal definition LOGI

Name Value range Description

di.Fn

Err.r

tArA

HoLd

rES.L

L_r

10 11

Function of inputs (valid for all inputs)

0 1 2

0 1 2 7 8 9

0 2 7 8 9

direct inverse toggle key function (adjustable for 2-point-operation with interface and di1) Local / remote switchover

(Remote: Adjustment of all values via the front panel is blocked) Interface only (local, value adjustment via front-panel controls is possible) always active (remote) di1 switches Limit 1 switches Limit 2 switches Limit 3 switches Resetting of all stored entrys of the error list Interface only di1 switches Limit 1 switches Limit 2 switches Limit 3 switches Enter/Inc keys switch Ü Enter/Dec key switch Ü Tare-function (Function must be akctivated (CONF /FUNC / Fnc.2= 3)) Interface only di1 switches Limit 1 switches Limit 2 switches Limit 3 switches Enter/Inc keys switch Ü Enter/Dec key switch Ü Sample & Hold-Fctn. (Function must be akctivated (CONF /FUNC / Fnc.2 = 2)) Interface only di1 switches Limit 1 switches Limit 2 switches Limit 3 switches Enter/Inc keys switch Ü Enter/Dec key switch Ü

Reset minimum value

Interface only di1 switches Limit 1 switches Limit 2 switches Limit 3 switches Enter/Inc keys switch Ü Enter/Dec key switch Ü

41 Configurations SG 45

Name Value range Description

rES.H

0 2 7 8

9 10 11

rES.I

9 10 11

CAL.t

9 10 11

ZEro

9 10 11

fDI1 Forcing of the digital input (only visible with BlueControlÒ!)

Reset maximum value

Interface only di1 switches Limit 1 switches Limit 2 switches Limit 3 switches Enter/Inc keys switch Ü Enter/Dec key switch Ü

Reset Integrator

Interface only di1 switches Limit 1 switches Limit 2 switches Limit 3 switches Enter/Inc keys switch Ü Enter/Dec key switch Ü Calibration test (activation bridge resistance change) Interface only di1 switches Limit 1 switches Limit 2 switches Limit 3 switches Enter/Inc keys switch Ü Enter/Dec key switch Ü Zero setting Interface only di1 switches Limit 1 switches Limit 2 switches Limit 3 switches Enter/Inc keys switch Ü Enter/Dec key switch Ü

not active The value for this input is defined via interface.

Configuration level

SG 45 Configurations 42

Miscellaneous (other)

Name Value range Description

S.IF

Addr bAud

PrtY

dELY

FrEq

D.Unt

CAL.M

C.dEl

IExo

0 1

1...247

0 1 2 3 4

0 1 2 3

0...200

0 1

0 3 4 5 6 7

8 18 19 20 21 22 23 24 25

0..200

System interfaceµ

switched off switched on

Address on the interface µ Baudrate on the interface µ

2400 Baud 4800 Baud 9600 Baud 19200 Baud 38400 Baud

Parity of data on the interface µ

No parity (2 Stoppbits) even parity odd parity no parity with 1 stopbit

Response delay [ms] µ Switch over 50/60 Hz

Netfrequency 50 Hz Netfrequency 60 Hz

Anzeigeeinheit (Darstellung auf Display)

no unit % bar mbar Pa kPa psi mV kg g t Text of phys. Unit / preset via BlueControl lb N kN

Decimal point (max. no of decimals)

no decimal points 1 digit behind the decimal point 2 digits behind the decimal point 3 digits behind the decimal point

Calibration mode

without shunt calibration with shunt calibration

Modem delay [ms] Block extended operating level (only visible with BlueControl

Released Blocked

Configuration level

SG 45 Configurations 43

Configuration level

Name Value range Description

ILat

0 1

Pass OFF...9999

IPar

0 1

ICnf

0 1

IInst

0 1

T.Dis2

Block error memory (only visible with BlueControl Released Blocked

Password (only visible with BlueControl Block parameter level (only visible with BlueControl

Released Blocked Block configuration level (only visible with BlueControl Released Blocked Block installation level (only visible with BlueControl Released Blocked

Settings for text in display 2 (max. 5 digits) (only visible with BlueControl

Enter the corresponding number of spaces for right-adjusted

display of less than 5 characters.

Hold down the Enter key first and then press the increment or decrement key.

Linearization Lin

Only when INP.1 S.Lin=1 (only visible with BlueControlÒ!)

Name Value range Description

In.1 … In.32 OFF (ab In.3) -1999...9999

Ou.1 … Ou.32

-999.0 … 9999 Output 1 … Output 32

· The input signals are entered in %.

Resetting to factory setting (default)

r See page 3736

Input 1 … Input 32

44 Configurations SG 45

8 Parameter-level

8.1 Parameter-survey

Dependent on device version und adjusted configurations values not needed become hidden. The data which can be operated via the front panel are shown below.

Parameter-level

8.2 Adjustment:

Parameters can be adjusted with ÈÌ - keys.

•

Stepping to the next parameter by pressing the ô - key.

•

After the last parameter of a group donE appears in the display and the controller steps

•

automatically to the next group.

SG 45 Parameter-survey 45

Stepping back to the beginning of a group is done by pressing the ô - key for 3 s. If, for 30 s no key is pressed, the controller returns to the operating level (Timeout = 30 s).

Parameter-level

8.3 Parameters

Name Value range Description

Selection of functions Func

t.I P.I

0,1...9999

-1999...9999

Inputs InP.1

InL.1 Oul.1 InH.1 OuH.1

t.F1 b.F1

-1999...9999

0...999.9

0...9999

Limit values Lim1 … Lim 3

Integrator timeconstant (in minutes) Integrator-Offset

Lower input value (Span start) Lower output value Upper input value (Span end) Upper output value Filter time [s] Filterbandwidth

Name Value range Description

L.1

H.1 HYS.1 dEL.1

L.2

H.2 HYS.2 dEL.2

L.3

H.3 HYS.3 dEL.3

Resetting to factory setting (default)

r Page 36

-1999...9999

0...9999

-1999...9999

0...9999

-1999...9999

0...9999

lower limit 1 (L.1< -1999 = off) upper limit 1 (H.1< -1999 = off) Hysteresis of limit value 1 Alarm 1 delay lower limit 2 (L.2< -1999 = off) upper limit 2 (H.2< -1999 = off) Hysteresis of limit value 2 Alarm 2 delay lower limit 3 (L.3< -1999 = off) upper limit 3 (H.3< -1999 = off) Hysteresis of limit value 3 Alarm 3 delay

46 UNIFLEX SG 45

Installation and calibration

9 Installation and calibration

When the operating voltage is applied to SG45 after connecting e.g. the load cells, the unit starts running. An automatic check for connection of the Sense lines takes place. This check is done also after configuration changes. For installation, press

Select SEt

ô during 3 sec to change over to installation mode InSt .

ô and adjust S.typ (cell type) to select calibrating method CAL.M.

45.6

InSt

SEt

S.tyP

CAL.M

Out.1

D.Unt

O.tyP

donE

9.1 Initial setting ( SEt)

S.tyP for selecting the sensor type, see page 39.

CAL

InL.1

InH.1

OuH.1

donE

SCAL

InL.1

OuL.1

InH.1

OuH.1

donE

SEt see 9.1

End

CAL see 9.2 Page 43

SCAL see 9.3 Page 49

CAL.M shunt calibration

When connecting load cells, set CAL.M= 0 (without shunt calibration).

CAL.M=1 (with shunt calibration Ü)

During calibration, the calibrating resistor at the sense connection of the upper calibration point (InH.1 / OuH.1 )

Only purposeful for melt pressure sensors with integrated calibrating resistor. The specifications of the sensor manufacturer related to the operating temperature must be taken into account..

Simulates a bridge load

Execute the other entries accordingly.

DP decimal point Out.1 analog output scaling D.Unt unit of display shown on the 2nd display line O.tyP output signal type OUT3

donE Subsequently, calibration ( CAL) takes place.

¡is included automatically during calibration

47 Initial setting ( SEt) SG 45

Installation and calibration

9.2 Calibration ( CAL)

Before calibration, allow the unit to warm up (see Technical Data on page 54).

After delivery, a % value is displayed as a measured value (related to the adjusted measuring range). For this reason, the Uniflex SG 45 must be adapted to its measuring task accordingly. To adapt the unit, realize the cal ibration correctly. If necessary, the required display unit (D.Unt) must be selected accordingly.

g g

Load cells: the dead load (raw value) provides a signal. Set InL.1 = 0 to set this signal to zero (span start).

With pressure sensors, the sensor should be de-pressurized, or pressure setting for span start:

Calibration 1. step: Define span start

Display:

InL.1 = OFF

Calibration 2. step: Define calibration value

InH.1 = OFF Press keys p/q to display the instantaneous measured value. InH.1 = swaps with the

Calibration 3. step: Calculation of the upper calibrationpoint

OuH.1

Press keys p/q to display the current measurement value. InL.1 = % measured value (display changes between InL.1 and instantaneous mea

sured value). With related display value OuL.1 = 0

When the enter key ô is pressed immediately, without pressing p/q the increment / decre ment keys, InL.1=0%,OuL.1 = 0 is taken over as standard value.

ô followed by storage of InL.1 = instantaneous measured value,

Load cell melt pressure sensors:

Load load cells with a defined load (reference weight; e.g. 75kg)

display of the measured value With the enter key

When the enter key

crement keys

With OuH.1

the calculated value

ô the instantaneous mesured value is taken over to InH.1

ô is pressed immediately, without pressing p/q the increment / de-

, InH.1 = 100 %, OuH.1 = Out.1 is taken over.

the upper calibrating point is realized using the p/q keys according to

Enter pressure for span end or a defined known calibration value.

For sensors with integrated calibration resistor an automatic switching of the calibration resistor is done.

For the first calibration SEtit is recommended to configure CAL.M =1,->S.47

(The calibrating resistor is switched off automatically)

Calculation for calibrating resistor (e.g. 80% ) Example:

Bar; the calibrating resistor simulates 80% of the endvalue, 80% of 400 results 320. OuH.1is adjusted to 320.

The calibrating resistor has a range from 0..400

Press ô to store OuH.1 = adjusted upper calibration point

g DonE

A tare function activated before calibration must be de-activated. Normally, it is not purposeful to keep the old tare condition. If necessary, the tare function can be re-activated. The zero offset is deleted automatically.

The InL.1 and InH.1 values stored during calibration are stored with full resolution.

48 Calibration ( CAL) SG 45

donE (duration 1s) storage of InL.1, OuL.1, InH.1, OuH.1 takes place. Additionally, any previously realized zero setting (function 1) is deleted.

9.3 Scaling (SCAL)

Installation and calibration

(Menu with

q Þ

SEt – CAL – SCAL – End)

possibility for read out of the scaling determined under CAL or for direct input of scaling parameters

InL.1 ¿ OuL.1 ¿ InH.1 ¿ OuH.1 ¿ donE .

End

Operating level

Note related to melt pressure sensor

Adjust gradient 4mV/V for 3,33mV/V of the sensor.

Please note that the InL.1 and InH.1 values are displayed with a resolution of 4 digits. The lossless transfer to another device can only be managed via serial interface (Front or Bus) e.g. by means of BlueControl

SG 45 Scaling (SCAL) 49

10 Engineering Tool BlueControl

The Engineering Tool BlueControlÒis the projecting environment for the BluePortâcontroller series as for the rail line family of PMA. The following 3 versions with graded functionality are available:

Functionality Mini Basic Expert*

parameter and configuration setting yes yes yes download: transfer of an engineering to the controller yes yes yes online-mode / visualization SIM only yes yes defining an application specific linearization SIM only yes yes configuration in the extended operating level yes yes yes upload: reading an engineering from the controller SIM only yes yes basic diagnostic functions no no yes saving data file and engineering no yes yes printer function no yes yes online documentation, help yes yes yes implementation of measurement value correction yes yes yes data acquisition and trend display SIM only yes yes net- / multiple licence no nein yes wizard function yes yes yes Personal assistant function

Engineering Tool BlueControl

* on request

The mini version is - free of charge - at your disposal as download at PMA homepage www.pma-online.de or on the PMA-CD (please ask for).

At the end of the installation the licence number has to be stated or DEMO mode must be chosen.

At DEMO mode the licence number can be stated subsequently under Help r Licence r Change.

SG 45 50

Versions

11 Versions

Transmitter

UNIFLEX SG 45

1 measuring input, 1 digital input with display and BluePort -interface

without plug-in connector terminals

with screw-terminal connectors

90..260V AC, mA/V/logic + 2 relays

18...30VAC/18..31VDC, mA/V/logic+2 relays

no option RS 485 / MODBUS - protocol

Systeminterface (24V versions only)

Standard configuration Configuration to order

Standard (CE-certification) cULus - certified

4 5

0 1

0 9

Accessories delivered with the controller:

Operating note

•

Rail-to-bus connector for the interface option

•

Documentation

operation manual SG 45 german 9499-040-82318 operation manual SG 45 english 9499-040-82311 interface description MODBUS rail line german 9499-040-72018 interface description MODBUS rail line english 9499-040-72011

Additional devices:

Description Order-No.

PC-Adapter for BluePort® interface 9407-998-00001 BlueControl BlueControl BlueControl

Mini www.pma-online.de

with Basic - licence rail line 9407-999-12001

with Expert - licence rail line 9407-999-12011

(Please order the corresponding documentation)

51 SG 45

Technical data

12 Technical data

INPUTS

SIGNAL INPUT INP

Accuracy: 0,01% at 25°C Decimal point: 0 bis 3 decimals Input filter: adjustable 0.0...999.9 s Scanning cycle: 50 ms with 19 bit Linearization: 31 Segments, adaptable with

BlueControl Calibration: with/without shunt calibration Measurement value cor rection: Limiting frequency 1.7Hz Measurement value cor rection:

Connection technology: 4-wire bridge

Input range Span start, span end any, within measuring range

Scaling any, -1999 ...9999

2-point

Sensor break, short circuit and po

larity

6-wire bridge (Sense line)

Measurement span:

Slope/ sensitivity 0.5 mV/V 5 mV

with Us = 10V

1 mV/V 10 mV 2 mV/V 20 mV 4 mV/V 40 mV

OUTPUTS

RELAY OUTPUTS OUT1, OUT2

Contact type: 2 normally open with common

contact connection

Max. contact rating: 500 VA, max. 250 V, max. 2A

at 48...62 Hz, ohmic load Min. contact rating: 6V, 1 mA DC Swithing cycles (electrical): for I=1A/2A: ?

800,000/500,000 (at~250V

(ohmic load))

Note:

If the relays OUT1, 2 and 3 are used to operate external contac tors, these must be fitted with RC snubber circuits to manufactu rer specifications to prevent excessive voltage peaks at

switch-off.

OUT3 AS UNIVERSAL OUTPUT

Parallel current/voltage output with common ‘minus’ terminal (combined use only in galvanically isolated circuits).

Freely scalable Resolution: 14 Bit Dynamic response

(step change of input signal) T

Tracking error I/U: Residual ripple:

(rel. to range end)

Current output

Output follows the input within 300 ms

£ 2%

ß_1%

0...130 kHz

DIGITALINPUT DI1

Operation as

Contact input

Connection of a potential-free contact that is suitable for switching ‘dry’ circuits.

Switched voltage: 5V Current: 0.5 mA

Function

Configurable as direct or inverse switch or push button!

Functions: Operation disabling, reset of stored alarms and the

min/max indicator (slave pointer), the integrator, enabling the tare function,Sample&Hold amplifier function, Cal-Test , and zero setting.

0/4...20 mA, configurable, short-circuit proof.

Control range: -0.5....23 mA

Load: £ 600 [ Load effect: ß0.02% Resolution: ß 1.5 úA Error: ß 0.1%

Voltage output

0/2...10V, configurable, not permanently short-circuit proof Control range: 0.15...11.5 V Load: ? 2k[ Load effect: ß0.06% Resolution: ß 0.75 mV Error:

Additional error when using simultaneous ly the current output

ß 0.1%

ß+0.09%

Output values can be preset via interface (Forcing)

UNIFLEX SG 45 52

Technical data

GALVANIC ISOLATION

System

relay OUT1

relay OUT2

Galvanic isolation between inputs and outputs as well as from the supply voltage is provided.

Test voltages:

Between power supply and inputs/outputs: 2.3 kV AC, 1 min Between inputs and outputs: 500 V AC; 1min

Max. permissible voltages:

Between inputs/outputs against earth:

RS 485

Power

safety isolation functional isolation

Input INP

di 1 (contact)

Front interface

Output OUT3

ß 33VAC

BLUEPORT®FRONT INTERFACE

Connection to the controller front via a PC adapter (see ‘Additional

Accessories’). The BlueControl configured, parameters set, and operated.

software enables the KS 45 to be

BUS INTERFACE (OPTIONAL)

RS 485

Connection via bus connector fitted in the top-hat rail. Screened cables should be used.

Type: RS 485, copper Transmission speed: 2,400, 4,800, 9,600, 19,200,

38,400 Bit/sec Parity: even, odd, none Address range: 1...247 Number of controllers per bus segment: Moreover, repeaters must be used.

Protocol

MODBUS RTU

SYSTEM INTERFACE

For connection to fieldbus couplers (see system components) Connection via bus connector fitted in the top-hat rail.

Technical data see data sheet 9498-737-50911.

POWER SUPPLY

Depending on ordered version:

AC supply

Voltage: 90...260 V AC Frequency: 48...62 Hz Consumption: approx. 11.5 VA max.

Universal supply 24 V UC

AC supply: 18...30 V AC Frequency: 48...62 Hz DC supply: 18...31 V DC Consumption: approx. 8.5 VA / 5.8 W max.

* Instruments with optional system interface: energization is via the bus connector from field bus coupler or power supply module

cULus: class 2 only!

Behaviour with power failure

Configuration and parameter settings:Permanent storage in EEPROM

53 UNIFLEX SG 45

Technical data

ENVIRONMENTAL CONDITIONS

Protection mode

Front panel: IP 20 Housing: IP 20 Terminals: IP 20

Permissible temperatures

For specified accuracy: -10...55°C Warm-up time: < 20 minutes Temperature effect: ß 0.02%/10K add. influence to coldjunction compensation: Operating limits: -20...60°C Storage: -30...70°C

Humidity

Max. 95%, 75% yearly average, no condensation

Shock and vibration

Vibration test Fc (DIN EN 60 068-2-6)

Frequency: 10...150 Hz Unit in operation: 1g or 0.075 mm Unit not in operation: 2g or 0.15 mm

Shock test Ea (DIN EN 60 068-2-27)

Shock: 15 g Duration: 11 ms

Electromagnetic compatibility

Meets the test requirements for instruments in industrial areas. Interference radiation:

ß 0.05%/10K

GENERAL

Housing front

Material: Polyamide PA 6.6 Flammability class: VO (UL 94)

Connecting terminals

Material: Polyamide PA Flammability class: V2 (UL 94) for screw terminals

V0 (UL 94) for spring-clamp terminals and bus connector

Electrical safety

Complies with EN 61 010-1

Over-voltage category II Contamination degree 2 Protection class II

Certifications

CE marking

Meets the EuropeanDirectives regarding „Electromagnetic Com patibility“ and „Low-voltage equipment“ (see also „Safety tests“)

cUL certification

(Type 1, indoor use) File: E 208286 For compliance with UL certificate, the following information must be taken into account:

• Use only 60/75°C copper (Cu, 12-30 AWG) conductors .

• Tighten the terminal-screws with a torque of 0.5 – 0.6 Nm.

• Max. ambient temperature: 55 °C

•

Max. ratings of relay contacts: 250VAC, 2A (resistive)

•

Power supply from class II

•

Within the limits for class A instruments.

Immunity to interference:

•

Meets EN 61326-1 for continuous, unattended operation.

Electrical connections

Plug-in connector strips: Screw terminals for lead cross-sections from 0.2 to 2.5 mm (AWG24-12)

Mounting method

Clip-on rail mounting (35 mm top-hat rail to EN 50 022).

Locked by means of metal catch in housing base. Close-packed mounting possible.

Mounting position: vertical Weight: 0.18 kg

Standard accessories:

Operating notes

•

Devices with ‘Interface’ option: bus connector for fitting into

•

top-hat rail

54 UNIFLEX SG 45

Index

13 Index

Accessories ......................47

Alarm delay ......................28

Analog output ..................30-31

Applications ......................5

BlueControl ......................46

Calibration (CAL)...................44

Cleaning ........................8

Configuration level

Parameter survey 34

Configuration-level (

Configuration parameter 35 - 40

Connecting

Bus interface 12

di1 12

- Inp1 11

- Out1, Out2 12

- Out3 12

Connecting diagram................11,13

Connectors ......................10

ConF)

Detection of sensor and wiring errors ........32

Dismounting ......................9

maximum value ....................19

minimum value ....................19

Mounting .....................9-10

Number of switching cycles .............29

Operating hours ....................29

Operating level ..................18-20

Operating structure ..................17

Operation .....................16-20

Order numbers ....................47

Parameter-level (PArA)

Parameter-survey 41

Safety hints .....................7-8

Sample & Hold Amplifier ...............25

Scaling ........................45

Signal change monitoring...............28

Slave pointer .....................19

slave pointer function .................19

Spare parts .......................8

Substitute value for inputs ..............24

System interface ...................39

Filter ..........................24

Forcing.........................31

Forcing of the inputs .................24

Front view .......................16

Functions .....................21-33

Input scaling......................22

Input value monitoring ................27

Installation hints ...................15

Limit values....................27-29

Linearization......................40

Maintenance ......................8

Maintenance manager ................31

TAG-No........................19

tare function......................25

UL - Approval .....................15

units ..........................19

Versions ........................47

UNIFLEX SG 45 55

9499- 040- 82311

Subject to alterations without notice © PMA Prozeß- und Maschinen-Automation GmbH Änderungen vorbehalten P.O.B. 310 229, D-34058 Kassel, Germany Sous réserve de toutes modifications Printed in Germany 9499-040-82311 (10/2009)

A4, unibind, SW-Druck, Normalpapier 80g weiß

West Control Solutions SG 45 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
