WEN 5182 User Manual
TABLE OF CONTENTS
Specifications….................................................................................. 2
Safety Instructions............................................................................. 3
Specific Safety Rules for Cordless Drill Driver................................ 5
Know Your Drill/Driver……………………………………………. 7
Assembly............................................................................................ 8
Operation............................................................................................ 9
Maintenance...................................................................................... 15
Warranty ............................................................................................. 16
SPECIFICATIONS
Model: 5182
Motor: 18Volt DC
No Load Speed: 0-550 RPM
Number of Clutch Positions: 19+1
Max torque: 115 in. lbs
Chuck Capacity: 3/8"
Battery Type: Ni-Cd
Battery Voltage: 18Volt DC
Battery Capacity: 1Ah
Charger Input: 120-Volts, 60 Hz AC only
Optimum Charging Temperature: 41°F (5°C) -104°F (40°C)
Driver Weight (without battery): 2LBS 3 OZ
WARNING: Read all safety warnings and instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.
2
SAFETY INSTRUCTIONS
GENRAL SAFETY RULES
WARNING! Read all safety warnings and instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and / or serious injury.
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
3. Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
ELECTRICAL SAFETY
1. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
2. Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
4. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of electric shock.
PERSONAL SAFETY
1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use tool while tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating power tools may result in serious personal injury.
2. Use personal protective equipment. Always wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
3. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and / or battery pack, picking up or carrying the tool. Carrying power tools
3
4. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
5. Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
7. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of these devices can reduce dust-related hazards.
POWER TOOL USE AND CARE
1. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
2. Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
5. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly maintained power tools.
6. Use the power tool, accessories and tool bits etc., in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
BATTERY TOOL USE AND CARE
1. Recharge only with the charger specified by the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of fire when used with another battery pack.
2. Use power tools only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
3. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects that can make a connection from one terminal
to another. Shorting the battery terminals together may cause burns or a fire.
4
4. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
SERVICE
Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
SPECIFIC SAFETY RULES FOR CORDLESS DRILL DRIVER
1. Use protective gloves when removing the bit from the tool, or first allow the clamp to cool
down. The bit may be hot after prolonged use.
2. Use protective gloves when operating the tool. Protective gloves can help to keep you from
being burnt and hurt.
3. Keep your hands away from the motor-housing vents. Hot gas comes from the vents during
operation.
4. Do not operate the tool at full-load for more than 30 seconds, as this can cause the motor to
become too hot, which may damage the motor.
5. Release the trigger immediately when the screws are tightened to avoid breaking the screw.
6. For best results, your battery tool should be charged in a location where the temperature is
more that 41 °F (5 °C) but less that 104 °F (40 °C). Do not store outside or in vehicles.
SAFETY RULES FOR CHARGER
WARNING! Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire, and/or serious personal injury.
1. Before using the battery charger, read all instructions and cautionary markings in this manua
and on the battery charger, the battery, and the product using the battery to prevent misuse
the products and possible injury or damage.
CAUTION: To reduce the risk of electric shock or damage to the charger and battery, charge
only these rechargeable batteries specifically designated for your tool. Other types of batteries
may burst, causing personal injury or damage.
2. Do not use the charger outdoors or expose it to wet or damp conditions. Water entering the
charger will increase the risk of electric shock.
of
l
5
