WELLS

W ELLS MANUFACTURING

H-63, H-65 AND H-70

HOTPLATES

H-70

H-65

Specifications

Dimensions: Inches MM

Overall Dimensions (H-63):
Width 14 3/4 375

Depth 23 1/2 597

Height (incl. 4” legs) 12 3/8 314
Overall Dimensions (H-65):

Width 13 330
Depth 29 9/16 751
Height (incl. 4" legs) 12 3/8 314

Overall Dimensions (H-70):
Width 14 3/4 375
Depth 23 1/2 597

Height (incl. 4” legs) 12 3/8 314

Temperature Settings:

Number of Controls: 2
Weights: Lbs. KG

H-63:
Installed 26 12
Shipping 30 14
H-65:
Installed 22 10
Shipping 26 13
H-70:
Installed 32 15

Shipping 35 16

OFF/LO to HI

ITEM NO.

H-63, H-65 AND H-70 HOTPLATES

Wells Hotplates H-63, H-65 and H-70 have a
reliable, functional design. The H-63 and H-65 have
a wider element to allow for more surface contact
and removable drip trays for easy clean-up. The
H-70 is engineered for uniform heat distribution,
which is ideal for heating large stock pots.

Features

• H-63 and H-65 have eight inch diameter,
one-piece, self-cleaning, spiral-pattern elements

that are individually controlled by an infinite control
with a positive-off position.

• H-70 has french-plate elements that are nine
inches in diameter. The larger surface area allows
even heat distribution that is ideal for heating
large stock pots.

• Control knobs are front-mounted with a
protective guard ring to help prevent
accidental temperature changes.

• Drip Trays are stainless steel and removable
for easy cleaning (H-63 and H-65 only).

• The H-63, H-65 and H-70 Hotplates are
Underwriters Laboratories, Inc. LISTED and
meet the National Sanitation Foundation
and Canadian standards.

• A one-year warranty against defects covers
parts and labor.

Accessories / Options

Legs, set of four, 4” adjustable, metal, 20563
Cordset, 30 AMP, 1Ø, NEMA 6-30P, 20141
H-63 with Cordset, 21622

Export

The following models are available for export
and meet the standards for CE:

• H-70EU, 220-240V, 1Ø, 4 KW

RAISING THE STANDARD
