Weil-McLain Gold 2 User Manual
Gas-fired
Water boiler
Series 2
NOTICE:
Series 1/Series 2 identification
Read the boiler rating plate to
determine the series number. The
rating plate is located on the right
side of the boiler.
User’s
Information
Manual
Ultra-80, -105, -155, -230 & -310
with
If the information in this manual is not followed exactly, a fire or
explosion may result, causing property damage, personal injury or
loss of life.
Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service
technician or the gas supplier.
Part No. 550-100-027/0404
GAS-FIRED WATER BOILER SERIES 2 — User’s Information Manual
Please read this page first
Hazard definitions
Boiler service and
maintenance
The following defined terms are used throughout this manual to bring attention to the presence
of hazards of various risk levels or to important information concerning the life of the product.
Indicates presence of hazards that will cause severe personal injury, death or
substantial property damage.
Indicates presence of hazards that can cause severe personal injury, death or
substantial property damage.
Indicates presence of hazards that will or can cause minor personal injury or
property damage.
Indicates special instructions on installation, operation or maintenance that are
important but not related to personal injury or property damage.
The Boiler manual is for use only by a qualified heating installer/service
technician. Refer only to this User’s Information Manual for your reference.
Improper installation, adjustment, alteration, service or maintenance can cause
property damage, personal injury (exposure to hazardous materials) or loss of
life. Installation and service must be performed by a qualified installer, service
agency or the gas supplier (who must read and follow the supplied instructions
before installing, servicing, or removing this boiler. This boiler contains materials
that have been identified as carcinogenic, or possibly carcinogenic, to humans).
When calling or writing about the boiler— Please have the boiler model number
from the boiler rating label and the CP number from the boiler jacket.
How to use this
manual . . .
2
Part number 550-100-027/0404
GAS-FIRED WATER BOILER SERIES 2 — User’s Information Manual
STOP!! — Read before proceeding
Failure to adhere to the guidelines on this page can result in severe
personal injury, death or substantial property damage.
Boiler service and maintenance —
• To avoid electric shock, disconnect electrical supply before
performing maintenance.
• To avoid severe burns, allow boiler to cool before performing
maintenance.
• You must maintain the boiler as outlined in this manual and have the
boiler started up and serviced at least annually by a qualified
service technician
Boiler operation —
• Do not block flow of combustion or ventilation air to boiler. This
boiler is equipped with a control which will automatically shut down
the boiler should air or vent be blocked. If vent or air blockage is
easily accessible and removable, remove it. The boiler should attempt
to restart. If blockage is not obvious or cannot be removed, have the
boiler and system checked by a qualified service technician.
to ensure boiler/system reliability.
• Do not allow contaminated air to enter the boiler air inlet pipe. See
page 4 for details.
• Should overheating occur or gas supply fail to shut off, do not
turn off or disconnect electrical supply to boiler. Instead, shut off the
gas supply
• Do not use this boiler if any part has been under water.
Immediately call a qualified service technician to inspect the boiler
and to replace any part of the control system and any gas control, which
has been under water.
at a location external to the appliance.
Boiler water —
• Have boiler water chemistry checked at least annually by a qualified
service technician.
• DO NOT use petroleum-based cleaning or sealing compounds in
boiler system. Gaskets and seals in the system may be damaged. This
can result in substantial property damage.
• DO NOT use "homemade cures" or "boiler patent medicines".
Serious damage to boiler, personnel and/or property may result.
• Continual fresh makeup water will reduce boiler life. Mineral buildup in boiler heat exchanger reduces heat transfer, overheats the metal,
and causes heat exchanger failure. Addition of oxygen can cause internal
corrosion in system components. Leaks in boiler or piping must be
repaired at once to prevent makeup water.
Part number 550-100-027/0404
• Do not add cold water to hot boiler. Thermal shock can cause boiler
heat exchanger to crack.
3
GAS-FIRED WATER BOILER SERIES 2 — User’s Information Manual
Prevent combustion air contamination
If the boiler combustion air inlet is located in any area
likely to cause contamination
would contaminate the air cannot be removed, you
must have the combustion air and vent repiped
and terminated to another location
combustion air will damage the boiler, resulting in
possible severe personal injury, death or substantial
property damage.
Do not operate an Ultra boiler if its combustion
air inlet is located in a laundry room or pool facility,
for example. These areas will always contain hazardous
contaminants.
, or if products which
. Contaminated
Pool and laundry products and common household
and hobby products often contain fluorine or chlorine
compounds. When these chemicals pass through the
boiler, they can form strong acids. The acid can eat
through the boiler wall, causing serious damage and
presenting a possible threat of flue gas spillage or boiler
water leakage into the building.
Please read the information listed below. If
contaminating chemicals will be present near the
location of the boiler combustion air inlet, have your
installer pipe the boiler combustion air and vent to
another location, per the Boiler manual.
4
Part number 550-100-027/0404
