WEIKING TECHNOLOGY BT201 User Manual

BT201 - Bluetooth Speaker

User Manual

Accessories:

1. Micro USB Cable ( for charging )

2. 3.5mm Audio cable ( AUX-in cable )

3. User Manual

Highlights :

BT201 is a compact Bluetooth speaker that can be wirelessly connected to Bluetooth

devices such as smart phones, tablets and computers to playback any music collection

stored on them. Thanks to its powerful battery, the system delivers full stereo sound,

separated from any mains supply, for up to 6-8 hours and is the perfect companion for you

in the park, whilst camping or on the beach. Process control, can get rid of complicated

connections and wiring distance constraints, users can enjoy high-quality music .

Bluetooth Connection:

Turn the speaker on by pressing the power for several seconds, then the blue led flashes

quickly. The speaker now has entered the Bluetooth pairing mode.

Connect to mobile phones/tablet PCs/computers:

1. Activate your phone's Bluetooth

2. Go to your phone's Bluetooth settings , scan for new Bluetooth devices

3. Upon device found (BT201), click the device name and pair with it

4. If your phone ask for pairing code , please enter ”0000” and confirm it.

5. After successful pairing, your speaker will sound a prompt tone and the LED

lights blue.

Note: Pairing time is varied with different mobile phones. It only need to pair at the first

time and it will auto connect the devices which already paired before( Speaker only can

remember the last 8 paired devices name)

Bluetooth Connection:

Speaker will have the voice instruction for incoming call.Short Press

call and talk to the speaker directly. Short press

status. Long press
dialed phone, but it will be invalid if there is no phone conversation.

AUX audio-in connector:

The speaker also features 1x AUX audio in port, simply connect the speaker with your

non-Bluetooth mobile phone/MP3 player/PC/laptop with the 3.5mm jack audio cable. The

green and blue indicator light will be on, then you can play music via wired connection

Low power indication: Speaker will have voice hint to remind you to charge if battery is

to reject the incoming call.Long press to dial back the last

to end the call and back to play

to answer the

low( battery only left 10%). Users need to charge the speaker timely.

Charging and computer connection :

Connect the micro USB charging cable to a computer or USB charger, red Led
indication for charging status.

Red LED goes off upon charging finished. (5-6 hours for charging)

Specifications:

Speaker Interfaces:

Audio input connector: 3.5mm

AUX cable : support aux external audio input.

Charging interface: Micro USB

Dimensions And Basic Parameters:
