Catalogues:
1 Safety and Efficient Operation Guide ….28
1.1 EMI………………………………………….28
1.2
Safety Instruction……………………………29
2 Brief Introduction…………………………….. .29
2.1
Bluetooth Technology ……………………….29
2.2 Bluetooth Headset…………………………...29
2.3
Stuff in the Package ............................30
3 Using Your Headset...................... 31
3.1 Overview……………………………………. 31
3.2
Attention before Use………………………....31
3.3 Choosing Wearing Preference………………. 32
3.4
Adjusting Hanging Angle……………………32
3.5 Battery Charge …………………………32
3.6
Turn On or Off Your Headset …………….33
3.7
Pairing Y our Headset and Phone……………..34
3.8 Making a Call……………………………….. 34
3.9 Answering an Incoming Call ………………..35
3.10 Ending a Call………………………….........36
3.11 Call Divert ………………………….36
3.12 Headset Volume Adjustment ……………....36
3.13 Tone Off …………………………….....37
3.14
Low Power Alert ………………….......37
4
Important Notices........................37
4.1 Maintenance ……………………….37
4.2
Battery…………………………………….....38
4.3
Power Supply………………………………..38
4.4
Frequently Asked Questions………………...38
4.5 Other Instructions ……………………….......40
4.6 Contact Us ……………………………….40
1
Safety General Guide.
1. Safety and Efficient Operation
Guide
Note: Please Read This Handbook before Using
Goer GBH100 Bluetooth Headset
Users do not have the right to enjoy the service after
sale if they are not permitted by the manufacturer to
make changes or modify the device in any way.
1.1 EMI
Note: Nearly every modern electronic device is
susceptible to electromagnetic interference (EMI) if
inadequately shielded, designed, or otherwise
configured for electromagnetic compatibility.
Electronic Devices
To avoid electromagnetic interference, please turn
off your Bluetooth headset in any places where
posted notices instruct you to do so.
Aircraft
Turn off your Bluetooth headset when on board an
aircraft. The use of Bluetooth headset might interfere
the telecommunication system of an aircraft.
Medical Instruments
Please keep away from the medical instruments in
the hospital or medical units when using Bluetooth
headset without being allowed. If you use any other
personal medical device, such as pacemaker, please
consult the manufacturer of your device to determine
if it is adequately shielded from electromagnetic
interference. Your physician might assist you in
obtaining this information.
1.2 Safety Instruction
Placement
You are advised to put the Bluetooth headset in the
place where no extrusion happened when it is not be
used. Extrusion may lead to headset damage or body
hurt.
2
Children
Keep the Bluetooth headset away from children.
Some small knockdown parts might be swallowed
and result in danger.
2. Brief Introduction
2.1 Bluetooth T echnology
Bluetooth technology is a short-distance wireless
communication technology. Bluetooth products are
used in the frequencies of industry, science and
medical industry (ISM). It applies technology of
frequency-jump in order to avoid interference, the
frequency band of 2.4GHz～2.4835GHz is divided
into 79 channels and transfer data by the frequency
of 1600 times per second with the transmission
distance of about 10m(Class II).
2.2 Bluetooth Headset
Bluetooth headset is a wireless headset developed
with Bluetooth technology. Your Bluetooth wireless
headset can communicate with other Bluetooth
devices such as mobile phone, PDA, and PC etc.,
within a range of approximately 10 meters (33 feet).
3
2.3 Stuff in the Package
－Bluetooth headset
－ear-hook
－charging adapter
－charging cradle
－silicon rubber holder
－user’s manual
－hanging line
3. Using the Headset
3.1Overview
1-Multi-function Button
To turn on /off the headset, answering call or ending
call, To indicate operating mode by the inside
indicator light
2-Ear-hook
3-Microphone
To transfer sound into electronic signal
4- V olume-Incr ease Button
To increase the volume during conver sation
5- V olume-Decr ease Button
To decrease the volume during conversation
6- Ornament Hole
7-Receiver
To transfer electronic into sound
8-Charging Interface
3.2
Attention Before Use
4
1. Goer GBH 100 Bluetooth Headset accords with
Bluetooth Ver. 1.1 and supports Bluetooth Headset
Profile and Bluetooth Hand-free Profile）.
2. Goer GBH 100 headset must be fully charged (at
least 2.5 hours) before you use it for the first time.
3. Pairing Goer GBH100 headset signal with your
Bluetooth phone or other Bluetooth devices as 3.7
before use the headset.
4. Make sure the distance between headset and phone
or other Bluetooth devices is less than 10m.
Distance should be shortened if there is any barrier
in between.
3.3 Adjust the Headset to Your Ear
The weight of GBH100 is just 10g. Wearing
positions could be adjusted referring to the following
figures.
3.4
Adjust Earhook Angle
Adjust earhook angle as shown in the figure below:
Note: Intensive care should be taken during this
process in order not to break it.
Using the Headset
5
3.5 Battery Charge
To char ge the battery:
1. Plug the charging adapter into the headset’s
charging cradle.
2. Plug the charging adapter into an AC outlet. The red
indicator light is on when connected.
3. Insert Goer GBH 100 Bluetooth headset into the
charging cradle as shown in the below figures：
1) Open up the lid of charging cradle;
2) Insert headset to charging cradle;
3) Press down the lid of charging cradle slightly.
4. The red indicator light flashes twice a second
during charging.
5. Headset is fully charged when red indicator light
stops flash to continuous light.
6. Unplug the charging adapter from outlet.
7. Remove the Bluetooth headset from charging
cradle.
Note 1: The headset will be fully charged more
than 2.5 hours before you use the headset for the
first time.
Note 2: The red indicator light on headset will
flash once every three seconds and make a
caution alert when the battery is running out of
power.
① ② ③
6
3.6 Turning on or off Bluetooth Headset
1. Turn he ad se t O N: Press multi-function button
for 5 seconds until blue light blinks 5 times and
headset beeps twice, then release the
multifunction button. The power is on.
2. Turn headset OFF: Press the multi-function
button for 3 seconds until red light blinks
quickly and headset beeps twice, then release the
key. The power is off.
Pairing Your Headset and Phone
3.7
Before using the headset, make sure that the headset
is paired to your phone or other Bluetooth devices.
1. Ensure the headset power is off before pairing.
2. Press the multi-function button until red and blue
lights blink alternately; this process takes about 7
seconds, then release. The headset starts pairing.
The blue light blinks first and please don’t
release the button until red and blue lights blink
alternately. The headset beeps two times during
paring if you wore the headset.
3. Set your Bluetooth phone to discover the headset
by the phone’s instruction guide. It will take
several seconds to pair headset to your phone.
4. Your phone will display blue-tooth’s name after
pairing. Choose “GBH 100” and confirm.
5. PIN=0000 is required to be entered; pairing is
started after PIN confirmation.
6. Blue light is on instead of red and blue lights
blinking alternately until pairing is done.
Note 1: Your phone cannot find the headset when
your headset is not in the function of pairing.
7
Note 2：If pairing is unsuccessful in about one
minute, the headset will automatically transfer to
the function of “waiting”.
Note 3：Pairing is necessary because it guarantees
communication security. Pin exchange can assure
connection between your phone and headset
merely.
3.8 Making a Call
Make sure the headset is connected to your phone
before you make a call. The headset can support the
function of “voice dialing” if your phone had this
function too. For details on voice-dialing, see your
phone’s user’s guide.
1.
Voice dialing
Press multi-function button until headset beeps,
indicating that you can say the name.
Note: Suggest using headset to record your
dialing voice.
2. Using phone’s keyboard
Dial numbers in the normal way. Your can hear on
the headset when the call is connected.
3. Re-dialing the last dialed number
Press “volume increase” or “volume decrease” key.
Note: Your phone’ setting determines whether
there is keypad tone or not. Adjust volume during
your call is connected as shown 3.12
3.9 Answering An Incoming Call
Before using the headset to answer an incoming call,
make sure that your headset is connected to your
phone or phone has stored the pairing information of
Bluetooth headset.
1. When there is an incoming call, the ring tone is
8
heard from the headset and the blue indicator
light blinks quickly. Press the multi-function key
and then release to answer the phone.
2. If “automatic answer” function is set on your
phone, the headset automatically answers the
call when it rings.
3. If the headset is off when there is an incoming
call, press the multi-function key to turn on the
headset, and then press it again to answer a call.
Note 1：After being paired to the headset, some
brands of phones don’t ring when there is an
incoming call; the headset rings only, press the
multi-function key to answer a call.
Note 2 ： Some brand of phones, e.g.
SonyEricsson/P800, don’t have the function of
incoming call signal notice on the headset, just
press the multi-function key to answer a call
when the phone rings.
3.10 Ending a Call
When using Goer GBH 100 Bluetooth headset, you
can end a call as following:
1.
Press the multi-function key on the headset;
2.
Press the end key on the phone;
3.
Automatically end a call when the caller hangs
up.
3.11 Call transferring from phone to
headset
1. Press the multi-function key on the headset or the
relevant key on the phone to transfer a call from
phone to headset.
2. Turn off the headset or use relevant function on
the phone to transfer a call from headset to
phone.
9
Note: This mobile function is different from
brand to brand.
3.12 V olume Adjustment
When having a call，you can control volume through
volume button.
1. Press the “volume increase” button to increase
volume.
2. Press the “volume decrease” button to decrease
volume.
Note 1:There will be low and short sound each
time pressing the volume button, and the same
time volume will be higher and lower .
Note 2: Please tune your Bluetooth headset to a
suitable volume between max. and min.
Note 3:
to control the volume of Bluetooth headset.
You can tune the volume of mobile phone
3.13 Silence
1.When having a call, press the volume control
button until hearing inflexion，then microphone
will be in whist state. The other side will not hear
your voice.
2.When having a call，press the volume control
button to bring to the normal state from whist
state.
3.14 Low Battery Alert
When the battery is running out of power，the
headset indicator will flash from blue to red and
beep sound will be heard every 20 seconds
indicating that the battery needs to be charged.
10
4. Important Information
4.1 Maintenance
1. Please keep the headset in a dry place, clean it
with soft cloth.
2. Please do not keep the headset in a dusty place,
neither with very high nor low air temperature.
3. Please do not disassemble the headset by yourself.
The headset will be damaged in an unprofessional
way.
4. Please do not have rough operation like dropping,
knocking or shaking the headset to the Bluetooth
headset.like drop, knock or shake the headset
5. Please do not short circuit the charging interface
to protect the battery from being damaged.
4.2 Battery
1. Before the headset is being used for the first time，
please make sure the battery is fully charged at
least 2.5 hours.
2.
Battery maintenance:
- Only professional can change battery.
- When the headset is not used for a long time, it
needs to be charged at least once every two
months.
- Never dispose of batteries in a fire in case of
explosion.
3. The headset call duration is up to about
5 hours, and standby time is up to 150 hours
4.3 Power Supply
1. Alternative power adapter can only connect with
its compatible power source.
11
2. Hold the adapter not the cable when you remove
the adapter from power socket.
3.
Please do not use liquid or spray cleanser when
cleaning the headset, and it must be removed
from the power socket.
4.4 Frequently Asked Questions
1. Does Bluetooth headset can be used for all
mobile phones?
－No，it is only suitable to mobile phones which
have function of Bluetooth.
2. How long is effective distance from the handset
to mobile phones?
－Effective distance is 10 meters (30 feet,Class II)，
with no barriers.
3. Can other Bluetooth phone user hear my
conversation?
－No. You create a private link between the headset
to Bluetooth phone after they got being paired.
4.
Why does red light turn on and flash?
－It shows that the battery is running out of power.
Please charge it.
5.
Why can not mobile phone sea rch the headset
when the is under pairing?
－Bluetooth headset can be searched only when it is
in the function under pairing, please refer to 3.7
for the details.
6. Is pairing needed each time when you use the
Bluetooth headset?
－No. They will store the paired information even
one or two of them are power off after two
Bluetooth devices have paired.
7. Is it needed to reconnect when there is
interruption between mobile phones and the
headset?
－Different brand handset has different requirement.
12
Some handsets can be connected automatically if
the headset is in the effective distance. While
some mobile phones are needed to input password
to reconnect it.
8. Why is there noise in my Bluetooth headset？
－When the distance between mobile phones and
headset exceeds operating range or in the area of
limit, the noise will be louder.
－If the signal for mobile phone is not very good in
your region，the headset will have bad calling
quality either.
9.What to do if the handset is not clear？
－Tune the phone volume or the handset volume, at
the same time please check if your mobile phone
is in the region with good signal.
4.5 Other instructions
Different mobile phones have different functions;
the above instructions may not cover all the matters.
For further information please refer to mobile
phone’s manual, or consult with GoerTek.
The copyright and brand name are owned by
the register. All information in this
manual is subjected to change without
prior notice. GoerTek has the authority
to explain the above information.
Our website：www.goertek.com
13
4.6 Contact us
If you need other help, please contact us by the
following means.
1.
Qingdao GoerTek
Qingdao GoerTek Electronics Co., Ltd.
Tel: 86-532-8997277
Fax: 86-532-8997217
E-mail: market_qd@goertek.com
Add: Room 605, Innovation Building, Hi-tech
Industrial Park, Qingdao, China
2.
Taiwan GoerTek
GoerTek Electronics Inc.
Tel: 886-3-3398912
Fax: 886-3-3393216
E-mail:market_tw@goertek.com
Add: 7F.-8, No.51, Fuxing Rd., Taoyuan City,
Taoyuan County 330, Taiwan
FCC Statement
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. End
users must follow the specific operating instructions for
satisfying RF exposure compliance. This transmitter
must not be co-located or operating in conjunction with
any other antenna or transmitter.
Notice: Any changes or modification not expressly
approved by the party responsible could void the user's
authority to operate the device.
14
Loading...
