Weider WEBE11880 User Manual

QUESTIONS?

As a manufacturer, we are com­mitted to providing complete
customer satisfaction. If you have
questions, or find that there are
missing or damaged parts, we
will guarantee you complete sat­isfaction through direct assis­tance from our factory.

TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni­cians on our customer hot line
will provide immediate assis­tance, free of charge to you.

CUSTOMER HOT LINE:

1-800-999-3756

Mon.ÐFri., 6 a.m.Ð6 p.m. MST

Model No. WEBE11880
Serial No.

Write the serial number in the space
above for reference.

CAUTION

Read all precautions and instruc­tions in this manual before using
this equipment. Save this manual
for future reference.

Serial Number Decal

USERÕS MANUAL

PATENT PENDING

2

Warning Decal Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Important Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Adjusting the Weight Bench . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Exercise Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Ordering Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover

Table of Contents

The decals shown below have been placed on the weight bench. If a decal is missing, or if it is not legi­ble, please call our Customer Service Department toll-free at 1-800-999-3756, Monday through Friday, 6
a.m. until 6 p.m. Mountain Time (excluding holidays), to order a replacement decal. Apply the replace­ment decal to the location shown.

Warning Decal Placement

Note: A Part List, Exploded Drawing and Part Identification Chart is attached to the center of this manual.
Remove these four pages before beginning assembly.

3

1. Read all instructions in this manual before
using the weight bench.

2. Use the weight bench only as described in
this manual.

3. It is the responsibility of the owner to ensure
that all users of the weight bench are ade­quately informed of all precautions.

4. Use the weight bench only on a level surface.
Cover the floor beneath the weight bench for
protection.

5. Inspect and tighten all parts each time you
use the weight bench. Replace any worn
parts immediately.

6. Keep children under the age of 12 and pets
away from the weight bench at all times.

7. Always use an equal amount of weight on
each side of the barbell (not included).

8. Do not use a barbell (not included) that is
longer than five feet with the weight bench.

9. When you are using the leg lever, place a
barbell (not included) with the same amount
of weight on the weight rests to balance the
bench.

10. Always wear athletic shoes for foot protec­tion while exercising.

11. Keep hands and feet away from moving parts.

12. The weight bench is designed to support a
maximum of 360 pounds, including the user,
a weight bar, and weights. Do not place more
than 110 pounds, including a barbell and
weights, on the weight rests; do not place
more than 50 pounds on the leg lever for
normal use.

13. When using the backrest in an inclined posi­tion, make sure that the support rod is fully
inserted into the uprights and that the lock­ing hook is in place.

14. If you feel pain or dizziness at any time while
exercising, stop immediately and begin cool­ing down.

15. The weight bench is intended for home use
only. Do not use the weight bench in any
commercial, rental or institutional setting.

16. When you are using the lat bar, always stand

clear of the lat upright since the weight car­riage will swing around the upright as it is
raised.

17. Always disconnect the lat bar from the
weight bench when you are performing an
exercise that does not use the lat bar.

18. Never let go of the lat bar when you have
weights raised. The weight carriage will fall
with great force that may cause injury or
damage the weight bench.

WARNING: Before beginning this or any exercise program, consult your physician. This is especially
important for persons over the age of 35 or persons with pre-existing health problems. Read all
instructions before using. ICON assumes no responsibility for personal injury or property damage
sustained by or through the use of this product.

To reduce the risk of serious injury, read the following important
precautions before using the weight bench.

WARNING:

Important Precautions

4

Thank you for selecting the versatile WEIDER¨T28
Weight Bench. The WEIDER¨T28 is designed to help
you develop every major muscle group of the body.
Whether your goal is a shapely figure, dramatic mus­cle size and strength or a healthier cardiovascular sys­tem, the T28 Weight Bench will help you achieve the
specific results you want.

For your benefit, read this manual carefully before
using the WEIDER¨T28 Weight Bench. If you have

additional questions, please call our Customer Service
Department toll-free at 1-800-999-3756, Monday

through Friday, 6 a.m. until 6 p.m. Mountain Time
(excluding holidays). To help us assist you, please
note the product model number and serial number
before calling. The model number is WEBE11880. The
serial number can be found on a decal attached to the
WEIDER¨T28 Weight Bench (see the front cover of
this manual).

Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.

Before You Begin

Seat

Weight Tube

Lat Upright

Weight Rest

Right

Side

Left Side

Leg Lever

Weight Tube

Upright

Foam Pads

Lat Bar

Cable

Weight Carriage

Carriage Pin

Backrest

5

1. Before assembling this product, make sure you
have read and understand the information in the
box above.

Place the Seat Base (50) on the floor next to the
Tower Base (57), as shown in drawing 1.

See drawing 1A. Slide two 5/16Ó x 1 1/2Ó Bolts (56)
through the holes in the indicated bracket on the Seat
Base (50). Slide a 1/2Ó Spacer (54) onto each Bolt.

Slide the Seat Base (50) up next to the Tower Base
(57), and slide the two 5/16Ó x 1 1/2Ó Bolts (56)
through the indicated holes in the Tower Base.

Slide a 5/16Ó Washer (53) onto each of the 5/16Ó x 1
1/2Ó Bolts (56) and secure the Bolts with two 5/16Ó
Nylon Locknuts (15). Do not tighten the Nylon

Locknuts yet.

1

1A

Before beginning assembly, carefully read the
following information and instructions:

¥ Assembly requires two people.

¥ Place all parts in a cleared area and remove the

packing materials. Do not dispose of the packing
materials until assembly is completed.

¥ Tighten all parts as you assemble them, unless

instructed to do otherwise.

¥ For help identifying the small parts, use the PART

IDENTIFICATION CHART on page 5.

¥ As you assemble the weight bench, make sure all

parts are oriented as shown in the drawings.

The following tools (not included) are required
for assembly:

¥ Two (2) adjustable wrenches

¥ One (1) rubber mallet

¥ One (1) standard screwdriver

¥ One (1) phillips screwdriver

¥ Lubricant, such as grease or petroleum jelly

plus soapy water.

Assembly will be more convenient if you have the
following tools: A socket set, a set of open-end or
closed-end wrenches or a set of ratchet wrenches.

Assembly

Make Things Easier for Yourself!

Everything in this manual is designed to ensure
that the assembly of our products can be complet­ed successfully by anyone. However, it is impor­tant to recognize that your new equipment is a
sophisticated product with many small parts and
consequently, the assembly process will take
time. Most people find that by setting aside plenty
of time, and by deciding to make the task enjoy­able, assembly will go smoothly.

57

54

15

53

56

56

50

50

54

53

57
