Weider 831.150680 User Manual

CAUTION

Read all precautions and instruc­tions in this manual before using
this equipment. Save this manual
for future reference.

Serial Number Decal (Under Seat)

SEARS, ROEBUCK AND CO.,
HOFFMAN ESTATES, IL 60179

Model No. 831.150680
Serial No.

Write the serial number in the
space above for future reference.

USER’S MANUAL

Patent Pending

Visit our website at

www.weiderfitness.com

new products, prizes,

fitness tips, and much more!

WARNING DECAL PLACEMENT

2

WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

PART IDENTIFICATION CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

FULL 90 DAY WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

The decal shown at the right has
been applied to the weight bench.
If the decal is missing, or if it is
not legible, please call our toll­free HELPLINE at 1-800-736-6879,
Monday through Saturday, 7 a.m.
until 7 p.m. Central Time (exclud­ing holidays), to order a free
replacement decal. Apply the
replacement decal in the location
shown.

TABLE OF CONTENTS

1. Read all instructions in this manual before
using the weight bench. Use the weight
bench only as described in this manual.

2. It is the responsibility of the owner to ensure
that all users of the weight bench are ade­quately informed of all precautions.

3. The weight bench is intended for home use
only. Do not use the weight bench in any
commercial, rental, or institutional setting.

4. Use the weight bench only on a level surface.
Cover the floor beneath the weight bench to
protect the floor.

5. Make sure all parts are properly tightened
each time you use the weight bench. Replace
any worn parts immediately.

6. Keep children under the age of 12 and pets
away from the weight bench at all times.

7. Always wear athletic shoes for foot protec­tion while exercising.

8. Keep hands and feet away from moving parts.

9. Always be sure there is an equal amount of
weight on each side of your barbell when
you are using it. When adding or removing
weights, always keep some weight on both
ends of the barbell and prevent the barbell
from tipping. Note: The weight bench does
not include a barbell or weights.

10.

Always exercise with a partner. Your partner
should be ready to catch the barbell if you
cannot complete a repetition.

11. The weight bench is designed to support a
maximum user weight of 250 pounds. Do not
place more than 310 pounds, including a bar­bell and weights, on the weight rests. Do not
place more than 150 pounds on the leg lever.

12. When you are using the leg lever, place a
barbell with the same amount of weight on
the weight rests to balance the bench.

13. When you put weight on the weight rests,
make sure you put at least ten pounds on the
leg lever to balance the weight bench.

14. Make sure that the adjustment knobs are
inserted completely and tightened into the
uprights before beginning any exercise.

15. When adjusting the position of the seat,
make sure that the adjustment pin is inserted
through both adjustment tubes before begin­ning any exercise.

16. Always remove the curl post from the front
leg before performing leg exercises with the
leg lever.

17. If you feel pain or dizziness at any time while
exercising, stop immediately and begin cool­ing down.

WARNING: Before beginning this or any exercise program, consult your physician. This

is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. SEARS assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.

IMPORTANT PRECAUTIONS

3

WARNING: To reduce the risk of serious injury, read the following important precau-

tions before using the weight bench.

4

Backrest

Weight Rests

Upright

Upright

Knob

Adjustment

Tubes

Storage

Tube

Leg Lever

Weight
Tube

Curl Pad

Thank you for selecting the WEIDER®PRO 875 weight
bench. The versatile WEIDER®PRO 875 is designed
to be used with your own weight set (not included) to
develop every major muscle group of the body.
Whether your goal is a shapely figure, dramatic mus­cle size and strength, or a healthier cardiovascular
system, the WEIDER

®

PRO 875 will help you to

achieve the specific results you want.

For your benefit, read this manual carefully before
using the WEIDER

®

PRO 875 weight bench. If you

have additional questions, please call our toll-free

HELPLINE at 1-800-736-6879, Monday through
Saturday, 7 a.m. until 7 p.m. Central Time (excluding
holidays). To help us assist you, please note the prod­uct model number and serial number before calling.
The model number is 831.150680. The serial number
can be found on a decal attached to the weight bench
(see the front cover of this manual).

Before reading further, please look at the drawing
below and familiarize yourself with the parts that are
labeled.

BEFORE YOU BEGIN

Seat

5

This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
each part refers to the part number of the part, from the PART LIST on page 14 of this manual. Important:

Some parts may have been pre-assembled for shipping purposes. If you cannot find a part in the parts
bags, check to see if it has been pre-assembled.

PART IDENTIFICATION CHART

M10 x 81mm Bolt (35)

M10 Washer (41)

M10 x 72mm Bolt (45)

M8 Washer (43)

M6 Washer (40)

M10 Nylon Locknut (36)

M8 Nylon Locknut (44)

M10 x 65mm Bolt (47)

M8 x 58mm Bolt (42)

M6 x 38mm Screw (39)

M6 x 16mm Screw (37)

M4 x 16mm Screw (38)

M10 x 178mm Bolt (46)
