Technical Datasheet

Create Date:08.01.2021 - Seite1/

ESD Precision Wire Stripper

WEICON Wire Strippers enable the fast, easy and even stripping
of stranded and solid conductors. The wire stripper feature an
ergonomic shape as well as an automatic scanning system,
which identifies the cable diameter. This prevents damaging the
inner conductor. The product family of wire strippers comprises
several types, which are suitable for different applications and
tailored to the users’ individual needs. The wire strippers are used
in crafts as well as in industrial applications and are also suitable
for use in the domestic sector.

Semi-automatic wire stripper for the fast and safe stripping of
extremely thin conductors, strands or wires with small diameters
in the range of 0.12 mm - 0.8 mm (36 - 20 AWG). The tool
was tested by an ESD laboratory and complies with the DIN EN
61340-5-1 standard. The wire stripper is suitable for working in
electrostatic protected areas (ESD workspace/ ESD-protected
area). With the adjustable scaled length stop for the working
range from 5 to 45 millimetres, the desired stripping length can be
set quickly and reliably. Two durable, precisely adjusted torsion
springs, which push symmetrically onto the pair of blades with
a defined force and automatically cut the respective insulation
with the appropriate pressure, ensure comfortable working. In
combination with the scanning system that is integrated in the
tool, this ensures damage-free stripping. The tool is suitable for
both right- and left-handed users.

Technical Data

Cable types fine-stranded conductors and strands,

Application range 0.12 mm - 0.8 mm Ø (36 - 20 AWG)

Inner blade built-in, not replaceable

Approval/Certificate ESD standard: DIN EN 61340-5-1

Length 112 mm

Weight 45 g

Item number 51001002

PVC, PTFE/Teflon, Kynar insulations, and more

Note
Note: Working with WEICON Stripping Tools is only permitted on zero-potential, non-current-carrying cables and conductors.
