Customer :
Three-phase induction motor - Squirrel cage rotor
No.:
Date: 24-DEC-2012
TECHNICAL PROPOSAL
Product line :
Catalog Number : 00712ET3Y160M-W22 List Price : $2,306
Performed by: Checked:
Three-Phase: W22 IE3 IEC Tru-Metric - TEFC (IP55) Cast Iron Frame
DATA SHEET
Three-phase induction motor - Squirrel cage rotor
Customer : Product line :
Frame : 160M Output : 10 HP Frequency : 60 Hz Poles : 6 Full load speed : 1180 Slip : 1.67 % Voltage : 460 V Rated current : 13.1 A Locked rotor current : 96.9 A Locked rotor current (Il/In) : 7.4 No-load current : 7.00 A Full load torque : 43.9 lb.ft Locked rotor torque : 270 % Breakdown torque : 350 % Design : N Insulation class : F Temperature rise : 80 K Locked rotor time : 25 s (hot) Service factor : 1.25 Duty cycle : S1 Ambient temperature : -20°C - +40°C Altitude : 1000 Degree of Protection : IP55 Approximate weight : 269 lb Moment of inertia : 2.8972 sq.ft.lb Noise level : 59 dB(A)
Three-Phase: W22 IE3 IEC Tru-Metric - TEFC (IP55) Cast Iron Frame
No.:
Date: 24-DEC-2012
D.E. N.D.E. Load Power factor Efficiency (%) Bearings 6309 C3 6209 C3 100% 0.79 91.0 Regreasing interval 20000 h 20000 h 75% 0.72 89.5 Grease amount 13 g 9 g 50% 0.59 87.5
Performed by Checked
PERFORMANCE CURVES RELATED TO RATED OUTPUT
Three-phase induction motor - Squirrel cage rotor
100
1.0 0.0
90
0.9
80
0.8
70
0.7
60
0.6
50
0.5
40
0.4
C
A
B
No.:
Date: 24-DEC-2012
C - Slip D - Current at 460V (A)
1.0
2.0
3.0
4.0
5.0
16
12
A - Efficiency (%)
B - Power factor
0 10 20 30 40 50 60 70 80 90 100 110 120 130
Customer : Product line :
Frame : 160M Output : 10 HP Frequency : 60 Hz Full load speed : 1180 Voltage : 460 V Rated current : 13.1 A Insulation class : F
Three-Phase: W22 IE3 IEC Tru-Metric - TEFC (IP55) Cast Iron Frame
D
Percent of rated output (%)
Locked rotor current (Il/In) : 7.4 Duty cycle : S1 Service factor : 1.25 Design : N Locked rotor torque : 270 % Breakdown torque : 350 %
8
4
0
Performed by Checked
5.0
CHARACTERISTIC CURVES RELATED TO SPEED
Three-phase induction motor - Squirrel cage rotor
No.:
Date: 24-DEC-2012
10.0
B - Current related to rated current (I/In)
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
A - Torque related to rated torque (C/Cn)
Customer : Product line :
0 10 20 30 40 50 60 70 80 90 100
9.0
8.0
B
A
7.0
6.0
5.0
4.0
3.0
2.0
1.0
0.0
Speed related to rated speed (%)
Three-Phase: W22 IE3 IEC Tru-Metric - TEFC (IP55) Cast Iron Frame
Frame : 160M Output : 10 HP Frequency : 60 Hz Full load speed : 1180 Voltage : 460 V Rated current : 13.1 A Insulation class : F
Performed by Checked
Locked rotor current (Il/In) : 7.4 Duty cycle : S1 Service factor : 1.25 Design : N Locked rotor torque : 270 % Breakdown torque : 350 %
1 2 3 4 5 6 7 8
A
B
C
D
A
E
F
254
B
210
D
42k6
GD
8
GB
37
HD
374
d1
DM16
N
250
Holes
4
AA
64
BA
63
E
110
DA
42k6
GF
8 K
14.5 d2
DM16
P
350
AB
308
BB
254
ES
80
EA
110
H
160
L
598
Flange FF-300
T
5
AC
329
C
108
F
12
TS
80
HA
22
LC
712
LA 18
S
19
AD
264
CA
174
G
37
FA
12
HC
327
S1
2XM40X1,5
M
300
Angle
45°
Performed by:
Checked:
Customer:
Three-Phase: W22 IE3 IEC Tru-Metric - TEFC (IP55) Cast Iron Frame
24-DEC-2012Three-phase induction motor
Frame 160M - IP55
