GAS GRILL
LPG Gas Grill Owner’s Guide
E -210/310
SP -210/310
#89618
#00000
YOU MUST READ THIS OWNERS GUIDE
BEFORE OPERATING YOUR GAS GRILL
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open fl ames.
3. Open lid
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fi re department.
Leaking gas may cause a fi re or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING
1. Do not store spare LPG cylinder within
10 feet (3m) of this appliance.
2. Do not store or use petrol or other
fl ammable liquids or vapors within 25
feet (8m) of this appliance.
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading the "Lighting"
Instructions section of this manual.
89618 AU 04/30/07
LP
AUSTRALIA
2
WARNINGS
DANGER
Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or
death, or in a fi re or an explosion causing damage to property.
WARNINGS
Follow regulator connection instructions for your type of gas grill.
Do not store a spare or disconnected LPG cylinder under or near this barbecue.
Do not put a barbecue cover or anything fl ammable on or in the storage area under the barbecue.
Improper assembly may be dangerous. Please follow the assembly instructions carefully.
After a period of storage, and/or nonuse, the Weber® gas barbecue should be checked for gas leaks and burner obstructions
before use. See instructions in this manual for correct procedures.
Do not operate the Weber® gas barbecue if there is a gas leak present.
Do not use a fl ame to check for gas leaks.
Combustible materials should never be within 24 inches (61 cm) of the back or sides of your Weber® gas barbecue.
Do not put a barbecue cover or anything fl ammable on, or in the storage area under the barbecue.
Your Weber® gas barbecue should never be used by children. Accessible parts of the barbecue may be very hot. Keep young
children away while it is in use.
You should exercise reasonable care when operating your Weber® gas barbecue. It will be hot during cooking or cleaning and
should never be left unattended, or moved while in operation.
Should the burners go out while in operation, turn all gas valves off. Open the lid and wait fi ve minutes before attempting to
relight, using the lighting instructions.
Do not use charcoal or lava rock in your Weber® gas barbecue.
Never lean over open grill or place hands or fi ngers on the front edge of the cooking box.
Should a grease fi re occur, turn off all burners and leave lid closed until fi re is out.
Do not enlarge valve orifi ces or burner ports when cleaning the valves or burners.
The Weber® gas barbecue should be thoroughly cleaned on a regular basis.
LPG gas is not natural gas. The conversion or attempted use of natural gas in a LPG unit or LPG gas in a natural gas unit is
dangerous and will void your warranty.
Do not attempt to disconnect any gas fi tting while your barbecue is in operation.
Use heat-resistant barbecue mitts or gloves when operating barbecue.
Keep any electrical supply cord and the fuel supply hose away from any heated surfaces.
Do not use this barbecue unless all parts are in place. The unit must be properly assembled according to the assembly
instructions.
Do not put a fuel tank inside the cabinet.
LPG GAS UNITS ONLY:
Use the pressure regulator and hose assembly that is supplied with your Weber® gas barbecue.
Do not attempt to disconnect the gas regulator and hose assembly or any gas fi tting while your barbecue is in operation.
A dented or rusty LPG cylinder may be hazardous and should be checked by your LPG supplier. Do not use a LPG cylinder
with a damaged valve.
Although your LPG cylinder may appear to be empty, gas may still be present, and the cylinder should be transported and
stored accordingly.
If you see, smell or hear the hiss of escaping gas from the LPG cylinder:
1. Move away from LPG cylinder.
2. Do not attempt to correct the problem yourself.
3. Call your fi re department.
ATTENTION: This product has been safety tested and is only certifi ed for use in a specifi c country. Refer to country
designation located on outer carton.
These parts may be gas carrying or gas burning components. Please contact Weber-Stephen Products Co., Customer Service Department for genuine WeberStephen Products Co. replacement part(s) information.
WARNING: Do not attempt to make any repair to gas carrying or gas burning components without contacting Weber-
Stephen Products Co., Customer Service Department. Your actions, if you fail to follow this product Warning, may cause a
fi re or an explosion resulting in serious personal injury or death and damage to property.
WWW.WEBER.COM
®
WARRANTY
3
Weber-Stephen Products Co. (Weber) hereby warrants to the ORIGINAL PURCHASER of this Weber®
gas grill that it will be free of defects in material and workmanship from the date of purchase as follows:
Aluminum castings 2-year
on paint excludes fading, 25-years
Stainless steel Shroud, 25-years
Porcelain-enameled shroud, 25-years
Cookbox Assembly 2-year
on paint excludes fading, 10-years
Stainless steel burners tubes, 10-years
Stainless steel cooking grates, 5-years no rust through or burn through
Stainless steel Flavorizer bars, 5-years no rust through or burn through
Porcelain-enameled cast-iron
cooking grates, 5-year no rust through or burn through
Porcelain-enameled
cooking grates, 3-years no rust through or burn through
Porcelain-enameled
Flavorizer bars, 2-years no rust through or burn through
Infrared Rotisserie Burner, 2-years
All remaining parts, 2-years
When assembled and operated in accordance with the printed instructions accompanying it.
Weber may require reasonable proof of your date of purchase. THEREFORE, YOU SHOULD RETAIN
YOUR SALES SLIP OR INVOICE.
This Limited Warranty shall be limited to the repair or replacement of parts that prove defective under
normal use and service and which on examination shall indicate, to Weber’s satisfaction, they are
defective. Before returning any parts, contact the Customer Service Representative in your area
using the contact information on our website. If Weber confi rms the defect and approves the claim,
Weber will elect to replace such parts without charge. If you are required to return defective parts,
transportation charges must be prepaid. Weber will return parts to the purchaser, freight or postage
prepaid.
This Limited Warranty does not cover any failures or operating diffi culties due to accident, abuse,
misuse, alteration, misapplication, vandalism, improper installation or improper maintenance or
service, or failure to perform normal and routine maintenance, including but not limited to damage
caused by insects within the burner tubes, as set out in this owner’s manual.
Deterioration or damage due to severe weather conditions such as hail, hurricanes, earthquakes
or tornadoes, discoloration due to exposure to chemicals either directly or in the atmosphere, is not
covered by this Limited Warranty.
There are no other express warrants except as set forth herein and any applicable implied warranties
of merchantability and fi tness are limited in duration to the period of coverage of this express written
Limited Warranty. Some regions do not allow limitation on how long an implied warranty lasts, so this
limitation may not apply to you.
Weber is not liable for any special, indirect or consequential damages. Some regions do not allow the
exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not
apply to you.
Weber does not authorize any person or company to assume for it any other obligation or liability in
connection with the sale, installation, use, removal, return, or replacement of its equipment; and no
such representations are binding on Weber.
This Warranty applies only to products sold at retail.
WEBER-STEPHEN PRODUCTS CO.
R. McDonald Co. PTY.LTD.
A.C.N., 007 905 384
104 South Terrace
Adelaide, SA 5000
61.8.8221.6111
www.weber.com
®
3
REPLACEMENT HOSE AND REGULATOR
Country Part#
Hose France 41638
Hose Belgium 41639
Hose/Reg Holland 41681
Hose/Reg Greece/Italy 41680
Hose/Reg Germany/Austria 41679
Hose/Reg Spain/Denmark/Portugal 41619
Hose/Reg Sweden 41677
Hose/Reg Switzerland 41676
Hose/Reg Ireland 41588
Hose/Reg England 41588
Hose/Reg Australia 41673
Hose/Reg Norway/Finland 41619
Height Lid Closed
356 mm
832 mm
WWW.WEBER.COM
Gas Connection
Right Hand Side of barbecue
®
• The minimum cylinder capacity for this barbeque is 9 Kg
Height Lid Closed
381.4 mm
832 mm
61 cm
Gas Connection
Right Hand Side of barbecue
63.54 cm
4
EXPLODED VIEW E/S EP 210/310
10
11
12
13
®
SPIRIT
®
E/SP -210, E-310
SPIRIT
E/SP-310
3XX1001 - Spirit® Gas Grill LP 022607
1
2
3
4
5
6
7
8
9
34
35
36
37
38
39
41
42
43
44
45
47
48
40
41
46
48
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
59
WWW.WEBER.COM
®
