Weber E-335, SE-S-335, E-435, S-435, SL-S-435 Manual

Page 1

E335 • S335 • SES335 • SPE335 E435 • S435 • SLS435

LP Owner’s Manual

Scan the QR Code or register online at weber.registria.com

Need help? Visit photoregister.com/help or text help to 71403

Keep this Owner’s Manual for future reference, thoroughly read through it, and if you have any questions please contact us today.

52981

101021

enUS

Page 2

Important SafetyInformation

DANGER, WARNING, and CAUTION statements are used throughout this Owner's Manual to emphasize critical and important information. Read and follow these statements to help ensure safety and prevent property damage. Thestatements are deﬁned below.

m DANGER: Indicates a hazardous

situation which, if not avoided, will result in death or seriousinjury.

Welcome to Weber

m WARNING: Indicates a hazardous

situation which, if not avoided, could result in death or seriousinjury.

m CAUTION: Indicates a hazardous

situation which, if not avoided, could result in minor or moderateinjury.

m DANGER

If you smell gas:

• Shut o gas to the appliance (grill).

• Extinguish any open ﬂame.

• Open lid.

• If odor continues, keep away from the appliance (grill) and immediately call your gas supplier or your ﬁre department.

m WARNING

• Do not store or use gasoline or other ﬂammable liquids or vapors in the vicinity of this (grill) or any other appliance.

• An LP cylinder (tank) not connected for use shall not be stored in the vicinity of this (grill) or any other appliance.

USE OUTDOORS ONLY.

READ THE INSTRUCTIONS BEFORE USING THE APPLIANCE (GRILL).

NOTICE TO INSTALLER: These instructions must be left with the consumer.

NOTICE TO CONSUMER: Retain these instructions for future reference.

Installation and Assembly

m DANGER: This grill is not intended to be installed in

or on recreational vehicles or boats.

m WARNING: Do not use this grill unless all parts

are in place and the grill was properly assembled according to the assembly instructions.

m WARNING: Do not build this model of grill in any

built-in or slide-in construction.

m WARNING: Do not modify the appliance (grill). Liquid

propane gas is not natural gas. The conversion or attempted use of natural gas in a liquid propane gas unit or liquid propane gas in a natural gas unit is unsafe and will void your warranty.

• In the United States, installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/ NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, B149.2; or the Standard for Recreational Vehicles, ANSI A119.2/NFPA 1192, and CSA Z240 RV Series, Recreational Vehicle Code, as applicable.

• InCanada, the installation of this grill must comply with local codes and/or the latest edition of Standard CAN/CSA-B149.2 (Propane Storage and Handling Code). These instructions, while generally acceptable, do not necessarily comply with the Canadian installation codes, particularly with piping above and below ground.

• In Mexico, if there are local codes that apply to portable gas appliances, you must comply with the latest edition of Ocial Mexican Standard (NOM).

• If an external electrical source is utilized (such as a rotisserie) it must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, Part 1, CSA C22.1.

Operation

m DANGER: Only use the grill outdoors in a well-

ventilated area. Do not use in a garage, building, breezeway, tent, any other enclosed area, or beneath overhead combustibleconstruction.

m DANGER: Do not use the grill in any vehicle or in any

storage or cargo area of any vehicle. This includes, but is not limited to, cars, trucks, station wagons, mini-vans, sport utility vehicles, recreational vehicles, andboats.

m DANGER: Do not use the grill within 24 inches (61

cm) of combustible materials. This includes the top, bottom, back and sides of the grill.

m DANGER: Keep the cooking area clear of ﬂammable

vapors and liquids such as gasoline, alcohol, etc., and combustible materials.

m DANGER: This appliance (grill) must be kept away

from ﬂammable materials during use.

m DANGER: Do not put a grill cover or anything

ﬂammable on, or in the storage area under the grill while it is in operation or is hot.

m DANGER: Should a grease ﬁre occur, turn o all

burners and leave lid closed until ﬁre is out.

m WARNING: Accessible parts may be very hot.

Keepyoung children away.

m WARNING: The use of alcohol, prescription drugs,

non-prescription drugs, or illegal drugs may impair the consumer’s ability to properly and safely assemble, move, store, or operate thegrill.

m WARNING: Never leave the grill unattended during

pre-heating or use. Exercise caution when using this grill. The entire cookbox gets hot when in use.

m WARNING: Do not move the appliance (grill)

duringuse.

m WARNING: Keep any electrical supply cord and the

fuel supply hose away from any heated surfaces.

m CAUTION: This product has been safety-tested and

is only certiﬁed for use in a speciﬁc country. Refer to country designation located on outside of box.

• Do not use charcoal or lava rock in the grill.

Storage and/or Nonuse

m WARNING: Turn o the gas supply at the gas

cylinder (tank) after use.

m WARNING: LP tanks must be stored outdoors out of

the reach of children and must not be stored in a building, garage, or any other enclosed space.

m WARNING: After a period of storage and/or nonuse,

the grill should be checked for gas leaks and burner obstructions before use.

m Storage of the grill indoors is permissible only if the

LP tank is disconnected and removed from the grill.

California Proposition 65

m WARNING: Combustion byproducts produced when

using this product contain chemicals known to the state of California to cause cancer, birth defects, or other reproductive harm.

m PROPOSITION 65 WARNING: Handling the brass

material on this product exposes you to lead, a chemical known to the state of California to cause cancer, birth defects, or other reproductive harm.

Wash hands after handling this product.

Page 3

Welcome to Weber

HELLO!

We are so glad that you have joined us on the journey to grilling happiness. Pleasetake some time to read through this Owner’s Manual to ensure that you are up and grilling quickly and easily. We want to be with you for the life of your grill, so please take just a couple of minutes to register yourgrill. When you sign up for a WEBER-ID as part of your registration, wewill deliver special grillrelated content just for you to enjoy.

So, come along and join us online, on your smart device or however else you'd like to stay in touch.

Thank you for choosing WEBER. We are happy you are here.

TABLE OF CONTENTS

2 Welcome to Weber

Important SafetyInformation

4 The Weber Promise

5 Product Features

GENESIS Features

Hign Performance Grilling

6 Getting Started

Important Information about LPGas

& Gas Connections

LP Tank Installation & LeakChecking

Reﬁlling or Replacing an LPTank

10 Operation

The Very First Time You Grill

Every Time You Grill

Igniting the Grill

Using the sear zone

Igniting the Side Burner

14 Tips and Hints

The Flame - Direct or Indirect

Discover What Your Grates Can Do

Grilling Do's and Don'ts

Real Smoke Flavor

Extra on the Side

More Cooking Space

Grilling at Night

18 Product Care

Cleaning and Maintenance

20 Troubleshooting

24 Grilling Guide

25 Replacement Parts

Page 4

The WEBER Promise

At WEBER, we pride ourselves on two things: making grills that last and providing a lifetime of excellent customer service.

Thank you for purchasing a WEBER product. Weber-Stephen Products LLC, 1415 S. Roselle Road, Palatine, Illinois 60067 (“WEBER”) prides itself on delivering a safe, durable, and reliableproduct.

This is WEBER’s Voluntary Warranty provided to you at no extra charge. It contains the information you will need to have your WEBER product repaired in the unlikely event of a failure or defect.

Pursuant to applicable laws, the customer has several rights in case the product is defective. Those rights include supplementary performance or replacement, abatement of

The Weber Promise

the purchasing price, and compensation. In the European Union, for example, this would be a two-year statutory warranty starting on the date of the handover of the product. These and other statutory rights remain unaffected by this warranty provision. In fact, this warranty grants additional rights to the Owner that are independent from statutory warranty provisions.

WEBER’S VOLUNTARY WARRANTY

WEBER warrants, to the purchaser of the WEBER product (or in the case of a gift or promotional situation, the person for whom it was purchased as a gift or promotional item), that the WEBER product is free from defects in material and workmanship for the period(s) of time specified below when assembled and operated in accordance with the accompanying Owner’s Manual. (Note: If you lose or misplace your WEBER Owner’s Manual, a replacement is available online at www.weber.com, or such country-specific website to which Owner may be redirected.) Under normal, private single family home or apartment use and maintenance, WEBER agrees within the framework of this warranty to repair or replace defective parts within the applicable time periods, limitations, and exclusions listed below. TO THE EXTENT ALLOWABLE BY APPLICABLE LAW, THIS WARRANTY IS EXTENDED ONLY TO THE ORIGINAL PURCHASER AND IS NOT TRANSFERABLE TO SUBSEQUENT OWNERS, EXCEPT IN THE CASE OF GIFTS AND PROMOTIONAL ITEMS AS NOTED ABOVE.

OWNER’S RESPONSIBILITIES UNDER THIS WARRANTY

To ensure trouble-free warranty coverage, it is important (but it is not required) that you register your WEBER product online at www.weber.com, or such country-specific website to which Owner may be redirected. Please also retain your original sales receipt and/or invoice. Registering your WEBER product confirms your warranty coverage and provides a direct link between you and WEBER in case we need to contact you.

The above warranty only applies if the Owner takes reasonable care of the WEBER product by following all assembly instructions, usage instructions, and preventative maintenance as outlined in the accompanying Owner’s Manual, unless the Owner can prove that the defect or failure is independent of non-compliance with the above mentioned obligations. If you live in a coastal area, or have your product located near a pool, maintenance includes regular washing and rinsing of the exterior surfaces as outlined in the accompanying Owner’s Manual.

WARRANTY HANDLING / EXCLUSION OF WARRANTY

If you believe that you have a part which is covered by this Warranty, please contact WEBER Customer Service using the contact information on our website (www.weber.com, or such country-specific website to which Owner may be redirected). WEBER will, upon investigation, repair or replace (at its option) a defective part that is covered by this Warranty. In the event that repair or replacement are not possible, WEBER may choose (at its option) to replace the grill in question with a new grill of equal or greater value. WEBER may ask you to return parts for inspection, shipping charges to be pre-paid.

This WARRANTY lapses if there are damages, deteriorations, discolorations, and/or rust for which WEBER is not responsible caused by:

• Abuse, misuse, alteration, modification, misapplication, vandalism, neglect, improper assembly or installation, and failure to properly perform normal and routine maintenance;

• Insects (such as spiders) and rodents (such as squirrels), including but not limited to damage to burner tubes and/or gas hoses;

• Exposure to salt air and/or chlorine sources such as swimming pools and hot tubs/spas;

• Severe weather conditions such as hail, hurricanes, earthquakes, tsunamis or surges, tornadoes or severe storms.

The use and/or installation of parts on your WEBER product that are not genuine WEBER parts will void this Warranty, and any damages that result hereby are not covered by this Warranty. Any conversion of a gas grill not authorized by WEBER and performed by a WEBER authorized service technician will void this Warranty.

PRODUCT WARRANTY PERIODS

Cookbox: 12 years, no rust through/burn through (2 years paint excluding fading or discoloration)

Lid assembly: 12 years, no rust through/burn through (2 years paint excluding fading or discoloration)

Stainless steel burner tubes: 10 years, no rust through/burn through

Stainless steel cooking grates: 10 years, no rust through/burn through

Stainless steel FLAVORIZER BARS: 10 years, no rust through/burn through

Porcelain-enameled cast iron cooking grates: 10 years, no rust through/burn through

WEBER CONNECT Components: 3 years

All remaining parts: 5 years

DISCLAIMERS

APART FROM THE WARRANTY AND DISCLAIMERS AS DESCRIBED IN THIS WARRANTY STATEMENT, THERE ARE EXPLICITLY NO FURTHER WARRANTY OR VOLUNTARY DECLARATIONS OF LIABILITY GIVEN HERE WHICH GO BEYOND THE STATUTORY LIABILITY APPLYING TO WEBER. THE PRESENT WARRANTY STATEMENT ALSO DOES NOT LIMIT OR EXCLUDE SITUATIONS OR CLAIMS WHERE WEBER HAS MANDATORY LIABILITY AS PRESCRIBED BY STATUTE.

NO WARRANTIES SHALL APPLY AFTER THE APPLICABLE PERIODS OF THIS WARRANTY. NO OTHER WARRANTIES GIVEN BY ANY PERSON, INCLUDING A DEALER OR RETAILER, WITH RESPECT TO ANY PRODUCT (SUCH AS ANY “EXTENDED WARRANTIES”), SHALL BIND WEBER. THE EXCLUSIVE REMEDY OF THIS WARRANTY IS REPAIR OR REPLACEMENT OF THE PART OR PRODUCT.

IN NO EVENT UNDER THIS VOLUNTARY WARRANTY SHALL RECOVERY OF ANY KIND BE GREATER THAN THE AMOUNT OF THE PURCHASE PRICE OF THE WEBER PRODUCT SOLD.

YOU ASSUME THE RISK AND LIABILITY FOR LOSS, DAMAGE, OR INJURY TO YOU AND YOUR PROPERTY AND/OR TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE MISUSE OR ABUSE OF THE PRODUCT OR FAILURE TO FOLLOW INSTRUCTIONS PROVIDED BY WEBER IN THE ACCOMPANYING OWNER’S MANUAL.

PARTS AND ACCESSORIES REPLACED UNDER THIS WARRANTY ARE WARRANTED ONLY FOR THE BALANCE OF THE ABOVE MENTIONED ORIGINAL WARRANTY PERIOD(S).

THIS WARRANTY APPLIES TO PRIVATE SINGLE FAMILY HOME OR APARTMENT USE ONLY AND DOES NOT APPLY TO WEBER GRILLS USED IN COMMERCIAL, COMMUNAL OR MULTI-UNIT SETTINGS SUCH AS RESTAURANTS, HOTELS, RESORTS, OR RENTAL PROPERTIES.

WEBER MAY FROM TIME TO TIME CHANGE THE DESIGN OF ITS PRODUCTS. NOTHING CONTAINED IN THIS WARRANTY SHALL BE CONSTRUED AS OBLIGATING WEBER TO INCORPORATE SUCH DESIGN CHANGES INTO PREVIOUSLY MANUFACTURED PRODUCTS, NOR SHALL SUCH CHANGES BE CONSTRUED AS AN ADMISSION THAT PREVIOUS DESIGNS WERE DEFECTIVE.

Weber-Stephen Products LLC Customer Service Center

1415 S. Roselle Road Palatine, IL 60067 U.S.A.

For replacement parts, call:

1-800-446-1071

PROTECT

YOUR

INVESTMENT

Shield your grill from the

elements with a heavy-duty

premiumgrillcover.

Page 5

Product Features

GENESIS FEATURES

HIGH PERFORMANCE GRILLING

The high performance grilling system sets the standard in the world of gas grilling, and lands Weber in a class of its own. This powerful grilling system is based on over 65 years of grilling experience, culinary expertise, and most importantly, the wants and needs of the people who matter most – our grilling community. Each component was uniquely designed for ease-of-use and to provide an unequaled satisfaction to your backyard grilling experience.

1 INFINITY Ignition

The Inﬁnity Ignition is guaranteed to ignite. Rest assured that you’ll be up-andgrilling the ﬁrst time, ever y time.

2 Burners

The unique, tapered shape delivers a consistent gas ﬂow from front to back. This provides ultimate heat distribution, ensuring that food grills evenly and consistently anywhere on the cooking grates .

3 FLAVORIZER BARS

Stainles s Steel FL AVORIZER BARS are angled just right to catch drippings that smoke and sizzle, adding that irresistible smoky ﬂavor that we all know and love to your food.

A Prep & Serve Table

Use the side tables to keep plat ters, seasonings, and tools within arm’s reach. Hang your essential grilling tools on the hooks for easy access and organization of your backyard workspace.

B WEBER CRAFTED Outdoor Kitchen Collection Cooking Grates and Frame

Your grill is Outdoor Kitchen Collection Ready with the included cooking grates and frame. Additional Outdoor Kitchen Collection accessories sold seperately. (Premium stainless steel co oking grates available on SE model s only)

C Genesis Smoker Box

Positioned beneath the cooking grates, the smoker box adds continuous smoke to your cook. (SE models only)

D Expandable Top Cooking Grate

Keeps food warm, or toasts buns, while the main course ﬁnishes grilling on the grate. Fold it out when you need a secondary cooking sur face.

E Grill Lighting

Integrated with the lid handle, LED lights illuminate the cooking surface to keep grilling as the sun goes down. (SE and Premium models only)

F Side Burner

Use the side burner to simmer BBQ sauce or sauté veggies while the main course grills under the lid.

G Sear zone

The sear zone is designed to create an intense heat zone to quickly add sear marks to your meat.

H Grill Cabinet

The grill cabinet adds enclosed stor age space for all of your ess ential grilling tools and accessor ies.

I Fuel Gauge

The easy-to-read fuel gauge located nex t to the gas tank lets you see how much fuel is left in the tank.

J Weber Crafted Grill Locker

Convenient side storage makes it easy to access and remove cooking accessories.

4 Grease Management System

Drippings that are not vaporized by the FLAVORIZER BARS are funneled away from the burners into the disposable drip tray, located within the removable catch pan under the cookbox. Simply remove the catch pan and replace the drip tray as needed.

The grills illustrated in this Owner’s Manual may vary slightly from the model purchased.

Some features listed are only available on select models.

Page 6

Important Information about LPGas & Gas Connections

What Is LP Gas?

Liqueﬁed petroleum gas, also called LP, LP gas, liquid propane, or simply propane or butane, is the ﬂammable, petroleum-based product used to fuel your grill. It is a gas at moderate temperatures and pressure when it is not contained. But at moderate pressure inside a container, such as a tank, LP is a liquid. As pressure is released from the tank, the liquid readily vaporizes and becomes gas.

Safe Handling Tips For LP Tanks

Getting Started

• A dented or rusty liquid propane tank may be hazardous and should be checked by your liquid propane supplier. Donot use a liquid propane tank with a damaged valve.

• Although your liquid propane tank may appear to be empty, gas may still be present, and the tank should be transported and stored accordingly.

• The LP tank must be installed, transported, and stored in an upright, secure position. LP tanks should not be dropped or handled roughly.

• Never store or transport the LP tank where temperatures can reach 125° F (51.7° C) (the tank will become too hot to hold by hand).

• Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in leakage of propane.

LP Tank Requirements

• The tank must be approximately 18¼inches (46.35 cm) high and 12¼ inches (31.1 cm) in diameter with a marked 20 pound (9.07 kg) LPG capacity or 47.6 pound (21.6 kg) water capacity as stated by the manufacturer. Other tanks may be acceptable provided they are compatible with the grill retention means (tank scale).

• The tank used must be constructed and marked in accordance with the Speciﬁcations for LP gas Cylinders of the U.S. Department of Transportation (D.O.T.); or the Canadian Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable.

• Tanks must be provided with a listed OPD (Overﬁlling Prevention Device) and a Type 1 (CGA 791) tank connection. The tank connection must be compatible with the grill connection.

• The tank must include a collar to protect the tank valve.

• Tanks must have a D.O.T. certiﬁcation (A), and a testing date (B) that is within ﬁve years of current use.

What is a Regulator?

Your gas grill is equipped with a pressure regulator, which is a device to control and maintain uniform gas pressure as gas is released from the LP tank.

Regulator Requirements

• The regulator and hose assembly supplied with this grill must be used. This regulator has a ﬂow limiting device built into the unit that will restrict the ﬂow of gas in the event that a leak is detected.

• Replacement regulator and hose assemblies must be as speciﬁed by Weber-Stephen Products LLC (UL-listed Type 1 (CGA 791) tank connection device as described in the latest edition of ANSI Z21.81).

Page 7

LP Tank Installation

Installation Location

The tank is hung onto the tank scale which is located inside the cabinet. The shape of the collar assembly (the metal protective ring around the tank valve) determines one of t wo direc tions in which the tank will correctly hang on the tank scale (A).

Inspect the Tank

1) Conﬁrm that the tank valve is fully closed. Close by turning valve clockwise.

2) Conﬁrm that the tank valve is the proper mating type for the regulator (B).

3) Inspect the tank valve, including the internal rubber seal for damage or debris (C). If damaged, return tank to local retailer.

Install The Tank

1) Check that all burner control knobs are in the o position. Check by pushing in and turning knobs clockwise.

2) Locate the hose retention clip on the regulator hose. Secure the clip into the slot on the underside of the tank scale(D).

3) Loosen hand nut and rotate tank lock up(E).

4) Lift tank into position on the tank scale (F).

5) Rotate the tank lock down. Tighten the hand nut.

6) Screw the regulator coupling onto the tank valve, turning clockwise (G). Hand-tighten only. Using a wrench could damage the regulator coupling and could cause a leak. Proceed to “CHECKING FOR GASLE AKS.”

Getting Started

m WARNING: The hose must be secured to

the tank scale with the Hose Retention Clip. Failure to do so could cause damage to the hose resulting in a ﬁre or explosion which can cause serious bodily injury or death, and damage to property.

Page 8

LeakChecking

What is a Leak Check?

Once the L P tank is properly installed, it is necessar y to perform a leak check. A leak check is a reliable way to verif y that gas is not escaping after you connect the tank. The fuel system in your grill features factorymade connections that have been thoroughly checked for gas leaks and the burners have been ﬂame-tested. WEBER recommends performing a thorough leak check af ter assembly, as well as annually. The following ﬁttings should b e tested:

• Where the regulator connects to the tank.

• Where the gas hose connects to the bulkhead.

Getting Started

• Where the bulkhead connects to the corrugated gas line.

Checking for Gas Leaks

1) Wet ﬁttings (G) with a soap and water solution,

using a spray bottle, brush, or rag. You can make your own soap and water solution by mixing 20% liquid soap with 80% water; or, you can purchase leak check solution in the plumbing section of any hardware store.

2) Slowly open gas supply by turning tank valve

counterclockwise while checking for bubbles.

3) If bubbles appear there is a leak :

a) If the leak is at the cylinder (H), tur n o the gas.

DONOT OPERATE THE GRILL. Disconnect the tank and return the tank to your local retailer.

b) If the leak is at the regulator (I), tur n o the gas.

NEVER ATTEMP T TO TIGH TEN THE REGULATOR WITH TANK VALVE OPEN. DO NOT OPERATE THE GRILL. Contact the Customer Service Representative in your area using the contact information on our website.

c) If the leak is at any ﬁttings indicated in

illustration (J), re-tighten ﬁtting with a wrench and recheck for leaks with soap and water solution. If leak persist s, turn o the gas. DO NOT OPERATE THE GRILL .

d) If the leak is at any ﬁttings indicated in

illustration (K), turn o the gas. DO NOT OPERATE THE GRILL .

If a leak is present, contact the Customer Service

Representative in your area using the contact information on our website.

4) If bubbles do not appear, leak checking is complete:

a) Turn gas supply o at the tank and rinse

connections with water.

NOTE: Since some leak test solutions, including soap and water, may be slightly corrosive, all conne ctions should be rinsed with water after checking for leaks.

m DANGER: Do not use a ﬂame to check for gas

leaks. Besure there are no sparks or open ﬂames in the area while you check for leaks.

m DANGER: Leaking gas may cause a ﬁre or

explosion.

m DANGER: Do not operate the grill if there is a

gas leak present.

m DANGER: If you see, smell, or hear the hiss of

gas escaping from the liquid propane tank:

1) Move away from liquid propane tank.

2) Do not attempt to correct the problem yourself.

3) Call your ﬁre department.

m DANGER: Always close the tank valve before

disconnecting the regulator. Do not attempt to disconnect the gas regulator and hose assembly or any gas ﬁtting while this grill is in operation.

m DANGER: Do not store a spare LP tank under

or near this grill. Never ﬁll the tank beyond 80% full. Failure to follow these statements exactly may result in a ﬁre causing death or serious injury.

Page 9

Refilling or Replacing an LPTank

How Much Fuel is in the Tank?

The tank s cale indicates the amount of fuel in a standard 20 pound (9.07 kg) tank once the tank is hung from the s cale. The fuel level is checked by viewing the red level indicator arrow on the front of the grill, adjacent to the door. You can also view the indicator line located on the s cale inside of the cabinet. The indicator points to a full tank (A), and gradually moves to indicate when the tank is empt y(B) and nee ds to be removed to replace or reﬁll .

Removal of the LP Tank

1) Conﬁrm that the tank valve is fully closed. Close by turning valve clockwise (C).

2) Unscrew regulator coupling by turning counterclockwise by hand (D).

3) Loosen tank hand nut and turn tank lock up out of the way.

4) Lift tank o tank scale.

Additional Leak Check Precautions

The following ﬁt tings should be tested for gas leaks each time a tank is reﬁlled and reinstalled:

• Where the regulator connects to the tank (H) and at

the regulator (I).

Follow the instructions for "Checking for Gas Leaks".

Getting Started

•

Look for a basting brush with heat-

resistant silicone bristles and a long

handle, and a mop with long, cotton

BRUSH

AND MOP

threads that sop up the thinner,

•

vinegar-based sauces.

•

Consider these to be an extension

should have an eortless tension

•

GRILLINGPAN

Designed for food that is either too

small or too delicate for the cooking

grates, a perforated grilling pan

•

TONGS

of your hand. The best tongs

mechanism, comfortable hand

grips, and a lock to keep

themcompact.

keeps food right where it ought

tobe—on the grill,

not in it.

•

Page 10

The Very First Time You Grill

Perform an Initial Burn-Off

Heat the grill on the highest setting, with the lid closed, for at least 20 minutes prior to grilling for the ﬁrsttime.

Every Time You Grill

Operation

Meal-to-Meal Maintenance

The Meal-To-Meal Maintenance plan includes the following simple, yet important, steps that should always be performed prior to grilling.

Check for Grease

Your grill was built with a grease management system that funnels grease away from food and into a disposable container. As you cook, grease is channeled down the slide-out grease tray and into a disposable drip tray that lines the catch pan. This system should be cleaned each and every time you grill to preventﬁres.

1. Conﬁrm that the grill is o and cool.

2. Open the doors.

3. Access the slide-out grease tray by pulling the tray

towards you until it stops (A). Remove excess grease with a plastic scraper. Scrape the grease down through the openning in the grease tray, into the catch pan below.

4. Remove the catch pan (B). Check for excessive amounts of grease in the disposable drip pan that lines the catch pan. Discard disposable drip pan when necessary and replace with a new one.

5. Reinstall all components.

Inspect the Hose

Routine inspection of the hose is necessary.

1. Conﬁrm that the grill is o and cool.

2. Check hose for any signs of cracking, abrasions, or

cuts(C). If the hose is found to be damaged in any way, do not use the grill.

Preheat the Grill

Preheating the grill is critical to successful grilling. Preheating helps to prevent food from sticking to the grate and gets the grate hot enough to sear properly. Italso burns o residue of a previously cooked meal.

1. Open the grill lid.

2. Ignite your grill according to the ignition instructions

in this Owner's Manual.

3. Close lid.

4. Preheat the grill with all burners on the start/high

position for 15 minutes(D).

Clean the Cooking Grate

After preheating, any bits of food or debris left over from previous use will be easier to remove. Cleaned grates will also prevent your next meal from sticking.

1. Brush the grates with a stainless steel bristle grill brush immediately after preheating (E).

m DANGER: Do not line the slide-out grease tray

or cookbox with aluminum foil.

m DANGER: Check the slide-out grease tray and

catch pan for grease build-up before each use. Remove excess grease to avoid a grease ﬁre.

m WARNING: Use caution when removing catch

pan and disposing of hot grease.

m WARNING: Use heat-resistant barbecue mitts

or gloves when operating grill.

m WARNING: Grill brushes should be checked for

loose bristles and excessive wear on a regular basis. Replace brush if any loose bristles are found on cooking grates or brush. WEBER recommends purchasing a new stainless steel bristle grill brush at the beginning of every spring.

m WARNING: If the hose is found to be damaged

in any way, do not use the grill. Replace using only WEBER authorized replacement hose.

m WARNING: Keep ventilation openings around

tank clear and free of debris.

Page 11

Igniting the Grill

Using the Electronic Ignition System to Ignite the Grill

Each control knob operates an individual burner, and each burner ignites independently. Ignite the burners starting from left to right. All burners should be lit for preheating, however, all burners do not have to be lit while grilling.

1) Open the gr ill lid (A).

2) Check that all burner control knobs are in the o position. Check by pushing in and turning knobs

clockwise (B).

Note: It is important that all burner control knobs are in the o position before turning on the LP tank. If they are not, the ﬂow limiting device built into the regulator will activate, limiting the ﬂow of gas from the LP tank.

3) Turn the LP tank on by slowly tur ning the tank valve

counterclockwise; wait 60 seconds (C).

Note: It is important that the LP tank is turned on slowly. Ifit is opened too quickly, the ﬂow limiting device built into the regulator will activate, limiting the ﬂow of gas from the LP tank.

4) Begin with the burner furthest to the left. Push the

burner control knob in and turn it counterclockwise to the start/high

5) Push and hold the elec tronic ignition button (E).

Youwill hear it ticking.

6) Check that the burner is lit by looking through the

cooking grates and through the half-circle cutout in the FLAVORIZER bar.

7) If the burner does not ignite, turn burner control

knob to the o allow the gas to clear before attempting to light the burner again.

8) If the burner ignites, repeat steps 4 through 6 to

light the remaining burners.

Should the burners fail to ignite using the electronic ignition, refer to the TROUBLESHO OTING section. Thereyou will ﬁnd instructions on igniting the grill with a match to help determine the exact problem.

To Extinguish Burners

1) Push each burner control knob in and then turn

clockwise all the way to the o position.

2) Turn gas supply o at the LP tank .

position (D).

position and wait ﬁve minutes to

Operation

m WARNING: Open lid during ignition.

m WARNING: Do not lean over open grill while

igniting or cooking.

m WARNING: Each burner must be ignited

individually by pushing the electronic ignition button.

m WARNING: If ignition does not occur within

four seconds of attempting to light the ﬁrst burner, turn the burner control knob to the o position. Wait ﬁve minutes to allow accumulated gas to dissipate, and then repeat the lighting procedure.

Page 12

Using the sear zone

Searing is a direct grilling technique used on meats, such as steak, poultry parts, ﬁsh and chops. Searing browns the surface of the food at a high temperature. By searing both sides of the meat, you caramelize the food surface, creating a more desirable ﬂavor.

Ignition of the sear burner is the same as ignition of a main burner, each burner ignites independently.

Operation

1) Open the lid and ignite all of the bur ners, including the sear burner. Refer to USING THE ELECTRONIC IGNITION SYST EM TO IGNI TE THE GRILL.

2) Preheat the grill with the lid closed and with all burners on the start/high

3) After preheating, leave the sear burner control knob and the adjacent burner control knobs in the start/high tandem with adjacent burners (B). The remaining burner (s) can be turned to o or low.

4) Place meat directly over the sear zone and close lid. Sear each side anywhere from one to four minutes (C), depending on the t ype and thickness of meat. Once searing is complete, the meat can be moved to moderate heat over and cooked to your desired doneness.

Note: Always cook with the lid closed to achieve maximum heat and to avoid ﬂare-ups.

As you gain experience using the sear zone we encourage you to experiment with dierent searing times to ﬁnd the results that work best for your taste.

position (A). The sear burner works in

To Extinguish Burners

1) Push each burner control knob in and then turn clockwise all the way to the o position.

2) Turn gas supply o.

position for 15 minutes.

Page 13

Igniting the Side Burner

Using the Electronic Ignition to Ignite the Side Burner

If one or more of the main burners on your grill are already lit and you would like to ignite the side burner, skip to step 3. If none of the main burners are lit and you are only using the side burner, start with step 1.

1) Check that the side bur ner control knob is in the position. Check by pushing in and turning

o knob clockwise (A). Al so check that all main burner control knobs are in the o

2) Turn the LP tank on by slowly tur ning the tank valve

counterclockwise; wait 60 seconds.

3) Open the side burner lid (B).

4) Push in and turn side bur ner control knob

counterclockwise to start/high

5) Push and hold in the electronic ignition button (D).

You will hear the igniter clicking. Check that the side burner is lit. The side burner ﬂame may b e dicult to see on a br ight sunny day.

6) Once side burner is ignited, continue tur ning the

knob counterclockwise until you reach the desired position.

7) If the side burner does not ignite within 4 seconds,

turn side burner control knob to the o and wait ﬁve minutes to allow the gas to clear before attempting to light the burner again.

Should the side burner fail to ignite using the electronic ignition, refer to the TROUBLESHOOTING section. Thereyou will ﬁnd instructions on igniting the side burner with a match to help determine the exact problem.

To Extinguish Side Burner

1) Push side burner control knob in and then turn

clockwise all the way to the o position.

2) Turn gas supply o at the LP tank .

position.

position (C).

position

Operation

m WARNING: Open side burner lid during ignition.

m WARNING: Do not lean over side burner while

igniting or cooking.

m WARNING: If ignition does not occur within

four seconds of attempting to light the side burner, turn the burner control knob to the o position. Wait ﬁve minutes to allow accumulated gas to dissipate, and then repeat the lighting procedure.

Page 14

The Flame - Direct or Indirect

Tips and Hints

HIGH

DIRECT HEAT

SETUP

Use the direct method for small, tender pieces of food that take less than 20 minutes to cook, suchas: hamburgers, steaks, chops, kabobs, boneless chicken pieces, ﬁsh ﬁllets, shellﬁsh, and slicedvegetables.

With direct heat, the ﬁre is right below the food. It sears the surfaces of the food, developing ﬂavors, texture, and delicious caramelization while cooking the food all the way to thecenter.

OFF

MEDIUM

INDIRECT HEAT

SETUP

Use the indirect method for larger cuts of meat that require 20 minutes or more of grilling time, or for foods so delicate that direct exposure to the heat would dry them out or scorch them, such as: roasts, bone-in poultry pieces, whole ﬁsh, delicate ﬁsh ﬁllets, whole chickens, turkeys, and ribs. Indirect heat can also be used for ﬁnishing thicker foods or bone-in cuts that have been seared or browned ﬁrst over direct heat.

With indirect heat, the heat is on both sides of the grill, or o to one side of the grill. The food sits over the unlit part on the cooking grate.

START/HIGH

OFF

MEDIUM

LOW

•

BARBECUE

MITTS

When in doubt, wear them. The good

ones are insulated and protect

•

both hand and forearm.

•

Page 15

Discover What's Possible

WEBER CRAFTED Outdoor Kitchen Collection Ready

This feature is only available on select models.

Some models are Outdoor Kitchen Collection Ready with the included Grates and Frame. Remove the right-hand cooking grate. Place the Frame on the right-hand side of the cookbox for the widest range of heat control (A). The Spacer included with your grill is used only when cooking with the WEBER CRAFTED Outdoor Kitchen Collection (B).

Look for these and other accessories on weber.com.

Tips and Hints

GrillingDo’s andDon’ts

Preheat each and every time.

If the cooking grates aren’t hot enough, food will stick, and you will likely never have a chance of searing properly or developing those handsome grill marks. Even if a recipe calls for medium or low heat, always preheat the grill on the highest setting ﬁrst. Open the lid, turn up the heat, close the lid, and then let the cooking grate heat up for 15 minutes on high.

Don't grill on dirty grates.

Tossing food onto the cooking grates before they have been cleaned is never a good idea. Leftover “stu” on the grates acts like glue, binding it to the grates and your new food. To avoid tasting last night’s dinner on today’s lunch, make sure you are grilling on a clean cooking grate. Once the grates are preheated, use a stainless steel bristle grill brush to make a clean, smooth surface.

Be present in the process.

Before ﬁring up your grill, make sure that everything you need is within arm’s reach. Don’t forget your essential grilling tools, already oiled and seasoned food, glazes or sauces, and clean cooking platters for cooked food. Having to run back to your kitchen not only means missing out on the fun, but could also result in burning your food. French chefs call this “mise en place” (meaning, “put in place”). We call it “being present”.

Create a little elbow room.

Packing too much food onto the cooking grates restricts your ﬂexibility. Leave at least one-quarter of the cooking grates clear, with plenty of space between each food item, in order to get your tongs in there and easily move the food around. Sometimes grilling involves split-second decisions and the ability to jockey food from one area to another. Sogive yourself enough room to operate.

Try not to peek.

The lid on your grill is for more than just keeping the rain out. Most importantly, it’s for preventing too much air from getting in, and too much heat and smoke from getting out. When the lid is closed, the cooking grates are hotter, the grilling times are faster, the smoky tastes are stronger, and the ﬂare-ups are fewer. So put a lid on it!

Only flip once.

What’s better than a juicy steak with a deep sear and plenty of beautifully caramelized bits? The key to accomplishing these results is to keep your food in place. Sometimes we have the tendency to ﬂip our food before it reaches the desirable level of color and ﬂavor. In nearly all cases, you should turn food just once. If ﬁddling with it more than that, you are probably also opening the lid too much, which causes its own set of problems. So step back and trust the grill.

Know when to tame the flame.

When grilling, sometimes the most important thing to know is when to stop. The most reliable way to test doneness of your food is to invest in an instant-read thermometer. This slim little gem will help you pinpoint that critical moment when your food is at its best.

Don’t be afraid to experiment.

Back in the 1950s, grilling meant one thing: meat (and only meat) charred over open ﬂames. The modern day backyard chef doesn’t need a kitchen in order to prepare a full course meal. Use your grill to make char-grilled appetizers, sides, and even desserts. Register your grill to receive special content that will inspire you along the way. We’d love to join you on your grilling adventures.

Page 16

Real Smoke

UTA

S D

ECAN

AN WO

SPÄN

Flavor

Using the Smoker Box

This feature is only available on select models.

Use dry wood chips in the smoker b ox as they ignite quickly and create smoke faster. For longer cooking foods such as roasts, chicken, and tur keys, etc., ﬁll

Tips and Hints

the entire legth of the smoker box with wood chips. The wood chips will ignite on the end of the smoker box which is positioned over the burner and slowly continue to burn inside the smoker box to provide smoke throughout the cook. As you gain experience in using your smoker, we encour age you to experiment with dierent combinations of wood chips to ﬁnd the smoke ﬂavor that best suits your taste.

Option 1: Setting up for Indirect Cooking

1) Open the gr ill lid.

2) Check that all burner control knobs are in the o position and the grill is cool . Check by pushing in and turning knobs clockwis e.

3) Remove the cooking gr ates to expose the FLAVORIZER BARS (A).

4) Open the lid of the smoker box.

5) Fill the smoker box with wood chips from end to end (B). Close the smoker box lid.

6) With the gr ill o, position the smoker box over the two r ight-hand side FLAVORIZER BA RS, near the front of the grill, making sure only the narrow end with the WEBER logo will be directly over a lit burner (C). This is the end where the wood chips ignite ﬁrst. The main body of the smoker box aligns on a FLAVORIZER BAR without a lit burner beneath it.

7) Add water to the water pan of the smoker box (D) for more ﬂ avorful smoke during the co ok.

8) Reinstall the cooking grates over the smoker box (E).

9) Ignite the grill and preheat for 10 minutes with only the main bur ners on high. Refer to "Igniting the Grill". After preheating, turn o center burner and reduce outer burners to low (F).

Smoke will start in approximately 10 minutes and last as long as 90 minutes. Do not attempt to move hot components to reﬁll the smoker with wood chips. Keep the lid of the grill closed while cooking.

Option 2: Setting up for Direct Cooking

The smoker box is positioned where the Weber logo is over the center burner during grilling, with main burners set on low (G).

Notes: For best smoking results, burners in use should be on low. Do not place the main body of the smoker box directly over a burner. This could ignite all of the wood chips at once resulting in reduced smoking times.

Always grill with the lid closed to allow the smoke to fully penetrate the food.

When you're finished smoking, turn burners off and close the grill lid until the wood chips have extinguished.

Remove smoker box from the grill if not in use.

m DANGER: Do not use any ﬂammable ﬂuid or

combustible products in the smoker to ignite the wood chips. This will cause serious bodily injury.

m WARNING: Do not remove hot components

from the grill while in use.

m WARNING: Never use wood that has been

treated or exposed to chemicals.

m Always avoid soft, resinous woods like pine,

cedar, and aspen.

Cleaning the Smoker Box

Before each use, empty the smoker of ash to allow proper air ﬂow.

Note: Smoking will leave a “smoke” residue on the surface of the smoker. This residue cannot be removed and will not affect the function of the smoker. To a lesser degree, a “smoke” residue will accumulate on the inside of your gas grill. This residue need not be removed and will not adversely affect the function of your gas grill.

Page 17

Tips and Hints

Extra on the Side

WEBER CRAFTED Grill Locker

This feature is only available on select models.

The side s torage area (A) is ideal for s toring accessories and grillware. Adjustable condiment basket keeps smaller items close at hand.

Always make sure the rubber mat is in place to protect surfaces.

Storage Hooks

Use the double-sided hooks on the side of the cabinet (B) for convenient storage of cooking grates on the outside of the grill. Additional hooks on the inside of the cabinet store the WEBER CRAF TED spacer grate, which can b e used with WEBER CRAFTED Outdoor Kitchen Collection grillware..

Note: Do not place hot cooking grates on storage hooks.

More Cooking Space

Using the Expandable Top Cooking Grate

Use it as a war ming rack to keep food warm (A ) or unfold it when you need a secondary cooking surface. To unfold, lift the front half of the grate slightly and rotate outward (B). For storage, fold the gr ate and lift the entire grate from the cookbox (C). Hang the grate ver tically on the back edge of the cookbox. Use heat-resistant mitts or gloves when adjusting rack .

Grilling atNight

This feature is only available on select models.

Using the Grill Lighting

To activate the grill light press the awake button. The grill light has a tilt sensor that will tur n on the light if the grill lid is opened and turn o the light when the grill lid is closed. If the lid is left open or closed for more than 30 minutes, the grill light will automatically deactivate. To turn the light back on, press the awakebutton.

Page 18

Cleaning and Maintenance

Cleaning the Inside of the Grill

Over time, the per formance of your grill can diminish if it has not been maintained properly. Low temperature s, uneven heat, and food sticking to cooking grates are all signs that cleaning and maintenance are overdue. When your grill is o and cool, start by cleaning the inside, from the top down. A thorough cleaning is recommended at least twice a year. Consistent use may require quarterly cleanings .

Product Care

Cleaning the Lid

From time to time you may notice “paint-like” ﬂakes on the inside of the lid. During use, grease and smoke vapors slowly change into carbon and dep osit on the inside of your lid. These deposits will eventually peel, and looks very similar to paint. These deposits are non-toxic, but the ﬂakes could fall onto your food if you do not clean the lid regularly.

1) Brush the carbonized grease from the inside of the lid with a stainless steel bristle grill brush (A). To minimize further build-up, the inside of the lid can be wiped with a paper towel af ter grilling while the grill is still warm (nothot).

Cleaning the Cooking Grates

If you have b een cleaning your cooking grates as recommended, the debris on your grates should be minimal.

1) With grates installed, brush the debris o your cooking grate with a stainless steel bristle grill brush(B).

2) Take the grates out and set aside.

Cleaning the FLAVORIZERBARS

FLAVORIZER BARS catch drippings that smoke and sizzle, adding ﬂavor to your food. Any drippings that are not vap orized by the FLAVORIZER BA RS are funneled away from the burners. This helps prevent ﬂare- ups inside of your grill, and protects the burners from getting clogged.

1) Scrape the FLAVORIZER BARS with a plastic scraper(C).

2) If neces sary, br ush the FL AVORIZER BARS with a stainless steel bristle grill brush.

3) Remove FL AVORIZER BARS and set aside.

Cleaning the Burners

Two areas on the burners that are key to optimum performance are the ports (small raised openings running along the length of the burners) and the spider/insect screens on the ends of the burner. Keeping these areas clean is essential for safe operation.

Cleaning the Burner Ports

1) Use a clean stainless steel bristle grill brush to clean the outside of the burners by brushing across the top of the burner ports (D).

2) When cleaning the bur ners, avoid damaging the ignition electrode by carefully br ushing around it(E).

Cleaning the Spider Screens

1) Locate the ends of the burners on the underside of the control panel where they meet the valves.

2) Clean the spider/insect screens on each of the burners using a sof t bristle brush (F).

m WARNING: Turn your grill o and wait for it to

cool before thoroughly cleaning.

m WARNING: Over time, the development of

rough surfaces can form on the FLAVORIZER BARS. Wearing gloves is recommended when handling. Do not clean FLAVORIZER BARS or cooking grates in a sink, dishwasher, or selfcleaning oven.

m WARNING: When cleaning the burners, never

use a brush that has already been used to clean the cooking grates. Never put sharp objects into the burner port holes.

m CAUTION: Do not place any grill components

onto the side tables as they may scratch the paint or stainless steel surfaces.

m CAUTION: Do not use any of the following

to clean your grill: abrasive stainless steel polishes or paints, cleaners that contain acid, mineral spirits or xylene, oven cleaner, abrasive cleansers (kitchen cleansers), or abrasive cleaning pads.

Page 19

Cleaning the Heat Deflectors

Located under the burners, the heat deﬂectors distribute heat evenly throughout the cookbox while cooking. Keeping heat deﬂectors clean will enhance the cooking per formance of your grill.

1) Scrape the heat deﬂectors with a plastic scraper(G).

2) If neces sary, br ush the heat deﬂectors with a stainless steel bristle grill brush.

3) Remove heat deﬂectors and set aside.

Cleaning the Cookbox

Look inside the cookbox for any grease accumulation or leftover food particles. Excessive accumulation can cause a ﬁre.

1) Use a plastic scrap er to scrape debris o the sides and bottom of the grill into the opening in bottom of the cookbox(H). This opening leads debris into the slide-out grease tray.

Cleaning the Grease ManagementSystem

The grease management system consists of an angled slide-out grease tray and a catch pan. T hese components were designed to be easily removed, cleaned, and replaced; an essential step ever y time you prepare to grill. Instructions on inspecting the grease management system can be found in MEAL-TOMEAL MAINTENANCE.

Cleaning the Outside of theGrill

The out side of your grill may include stainless steel, porcelain-enameled, and plastic surfaces. WEBER recommends the following methods based on the surfacetype.

Cleaning Stainless Steel Surfaces

Clean stainless steel using a non-toxic, non-abrasive stainless steel cleaner or p olish designed for use on outdoor produc ts and grills. Use a microﬁber cloth to clean in the direction of the grain of the stainless steel. Donot use paper towels.

Note: Do not risk scratching your stainless ste el with abrasive pastes. Pastes do not clean or polish. They will change the color of the metal by removing the top chromium oxide ﬁlm coating.

Cleaning Painted, Porcelain-Enameled Surfaces and PlasticComponents

Clean painted, porcelain-enameled and plastic components with warm soapy water, and paper towels or cloth. After wiping down the surfaces, rinse and dr y thoroughly.

Cleaning the Outside of Grills that are in Unique Environments

If your grill is subject to a particular ly harsh environment, you will want to clean the out side more often. Acid rain, pool chemicals, and salt water can cause surface rusting to appear. Wipe down the outside of your grill with war m soapy water. Follow up with a rinse and thorough dr ying. Additionally, you may want to apply a stainless steel cleaner weekly to prevent surface rust.

Product Care

•

FOILPANS

Perfect for lining the

catchpan to make cleanup

convenient and easy.

•

A must-use before you even dream

of grilling. A quick once-over on hot

grates prevents the charred remains

GRILLBRUSH

of meals past from sticking to

•

your meals present.

•

Page 20

MAIN BURNERS or SIDE BURNER WILL NOT IGNITE

SYMPTOM

• Main burners or side burner do(es) not ignite when following the electronic ignition instructions in the “Operation” section of this owner's manual.

CAUSE SOLUTION

There is a problem with gas ﬂow. If any burner does not ignite, the ﬁrst step is to deter mine if there is gas ﬂowing to the bur ner(s). Tocheck

There is a problem with the electronic ignition s ystem. If any burner does not ignite, the ﬁrs t step is to determine if there is gas ﬂowing to the burner (s). Tocheck this,

Troubleshooting

this, follow the instructions below for “Lighting Your Grill with a Match.”

If match lighting IS NOT successful, follow the “GAS FLOW” troubleshooting suggestions on the nex t page.

follow the instructions b elow for “Lighting Your Grill with a Match.”

If match lighting IS successful, follow the instructions for “Checking the Components of the Electronic IgnitionSystem.”

Lighting Your Grill with a Match

Using a Match to Determine if there is Gas Flow to the Main Burners

1) Open the gr ill lid.

2) Check that all burner control knobs (including side

burner control knob) are in the o by pushing in and turning knobs clockwise.

3) Turn the LP tank on by slowly tur ning the tank valve

counterclockwise; wait 60 seconds.

4) Begin with the burner furthest to the left. Put

match in the matchstick holder and strike match. (Matchstick holder is locate d under lef t side table.) Insert lit match down through the cooking grates, past the FLAVORIZER bars and next to the burner(A).

5) Pushthe burner control knob in and slowly turn it

counterclockwise toward the star t/high

6) Check that the burner is lit by looking through

the cooking grates and through the cutout in the FLAVORIZER bar.

7) If the burner does not ignite within 4 seconds,

turn burner control knob to the o wait ﬁve minutes to allow the gas to clear before attempting to light the burner again. If repeated attempts fail, follow the gas ﬂow troubleshooting instructions on the next page.

8) If the burner ignites, the problem lies in the ignition

system. Follow the instructions for “Checking the Components of the Electronic Ignition System”.

9) Replace the matchstick holder by hanging

underneath left side table (B).

position. Check

position.

position and

Using a Match to Determine if there is Gas Flow to the Side Burner

1) Open the side burner lid.

2) Check that the side bur ner control knob is in the position. Check by pushing in and turning knob

o clockwise. Also check that all main burner control knobs are in the o position.

3) Turn the LP tank on by slowly tur ning the tank valve

counterclockwise; wait 60 seconds.

4) Put match in the matchstick holder and strike

match. (Matchstick holder is located under left side table.) Hold lit match by the side burner(C).

5) Pushthe side burner control knob in and slowly

turn it counterclockwise toward the s tart/high position.

6) Check that the side bur ner is lit . The side burner

ﬂame may be dicult to see on a bright sunny day.

7) If the side burner does not ignite within 4 seconds,

turn side burner control knob to the o and wait ﬁve minutes to allow the gas to clear before attempting to light the burner again. If repeated attempts fail, follow the gas ﬂow trouble shooting instructions on the next page.

8) If the burner ignites, follow the instructions for

“Checking the Component s of the Electronic Ignition Sys tem”.

position

REPLACEMENT

PARTS

To obtain replacement parts,

contact the local retailer

in your area or log onto

weber.com.

Page 21

GAS FLOW

SYMPTOM

• Grill does not reach desired temperature or heatsunevenly.

• One or more of the burners fail to ignite.

• Flame is low when burner is on high position.

• Flames do not run the whole length of the burner.

• Burner flame pattern is erratic.

CAUSE SOLUTION

The “ﬂow limiting device” has been activated. Thissafety feature built into the regulator restricts the gas ﬂow in the event of a gas leak. You can inadvertently activate this safety feature without having a gas leak. This typically occurs when you turn on the gas at the LP tank and one or more of the control knobs are not in the o position. It may also occur if you turn on the LP tank too quickly.

The LP tank is low or empty. Reﬁll LP tank.

Fuel hose is bent or kinked. Straighten fuel hose.

Burner p orts are dirt y. Clean burner por ts. Refer to “Cleaning the

SYMPTOM

• Gas is smelled in conjunction with burner flames that appear yellow andlazy.

CAUSE SOLUTION

Spider screens on the burners are obstructed. Clean spider screens. Refer to “Cleaning the Spider

Reset the “ﬂow limiting device” by closing the LP tank valve and turning all the bur ner control knobs to the o position. Wait ﬁve minute s to allow accumulated gas to dissipate, then ignite the grill again following the instructions in the “Operation” section.

BurnerPorts .”

Screens” in the Product Care section. Also refer to the illustrations and information in this section about proper ﬂ ame pattern and spiderscreens.

Troubleshooting

Proper Burner Flame Pattern

The burners in your grill were factor y set for the correct air and gas mixture. When the burners are per forming correctly, you will see a speciﬁc ﬂame pat tern. T he tips may o ccasionally ﬂicker yellow (A), with a descending light blue (B) to dark blue ﬂ ame (C).

Spider Screens

The combustion air openings of the burners(D) are ﬁtted with stainless steel screens to prevent spiders and other insects from spinning webs and building nests inside the burners. Additionally, dust and debris can accumul ate on the out side of the spider/insect screen and obstruct the ox ygen ﬂow to the burners.

SYMPTOM

• The smell of gas and/or a light hissing sound.

CAUSE SOLUTION

The inter nal rubber seal in the LP tank valve could be damaged.

Connection between regulator and LP tank could be incomplete.

Extinguish any op en ﬂame. Shut o gas to the appliance (grill). Inspect the rubber seal for damage. If damaged, return tank to place of purchase.

Extinguish any op en ﬂame. Shut o gas to the appliance (grill). Refer to LP TANK INSTALLATION & LEAK CHECKING section of your owner’s manual.

m WARNING: Do not attempt to make any

repair to gas carrying, gas burning, ignition components or structural components without contacting Weber-Stephen Products LLC, Customer Service Department.

m WARNING: Failure to use genuine Weber-

Stephen parts for any repair or replacement will void all warranty protection.

m CAUTION: The burner tube openings must be

positioned properly over the valve oriﬁces.

Page 22

Troubleshooting

GREASY GRILL (Peeling Paint & Flare-Ups)

SYMPTOM

• Inside of lid appears to have the appearance of peelingpaint.

CAUSE SOLUTION

The ﬂake s you see are accumul ated cooking vapors that have turned into carbon.

SYMPTOM

• Experiencing flare-ups when grilling or preheating.

CAUSE SOLUTION

There is leftover food from the previous meal. Always preheat the grill on the highest setting for 10

The inside of the grill needs to b e cleaned thoroughly. Follow the steps in the "Cleaning and Maintenance"

Replacing Batteries for the Grill Lighting

Use alkaline batteries only. Do not mix old and new bat teries or dierent types of batteries (standard, alkaline, or rechargeable). If you do not plan to use the grill for a month or more, remove the batteries.

1) Close the lid. Locate the bat tery housing on the side of the lid handle and unscrew the cap (A). Do not change batteries with the lid open.

2) Remove the battery sleeve.

3) Replace three size C batteries (B).

4) Line up graphic indicators (C) on the sleeve and handle as you reinstall the sleeve. Tighten cap.

NOTE: Periodically wipe the lenses with a damp cloth to keep the lights illuminating brightly.

This happ ens over time after repeated use of your grill. T his is not a defect. Clean the lid. Refer to the “Product Care” s ection.

to 15 minutes.

section to clean the grill inside from the top down.

CALL

CUSTOMER

SERVICE

If you are still experiencing any

problems, contact the CustomerService

Representative in your area using

the contact information on

weber.com.

Page 23

Checking the Components of the Electronic Ignition System

When pressing the ignition button you should hear a ticking sound. If you cannot hear the ticking sound, check the batter y, then check the wire s.

Checking the Battery

There are three potential issues with the battery that supplie s the power to your ignition module that need to be checked:

1) Some bat teries have a plastic protective wrap around them. (Do not confuse this plastic with the battery label.) Check that this plastic wrap is removed.

2) Conﬁrm that the battery is installe d correctly (C).

3) If the battery is old, replace it with a new battery.

Checking the Wires

There are two potential trouble spot s that need to be checked:

1) Check that the ignition wires are connec ted securely to the terminals on the ignition button under the control panel.

2) Make sure the ignition wires are properly attached to the ignition module. The wire terminals are color coded to correspond with the terminals on the ignition module. T he number of wires will vary per model.

Troubleshooting

335 Igniter Module Wire Chart

Checking the Ground Wire

Models 425s and 435 have a ground wire connected to the manifold bracket. This is visible from beneath the control panel (D):

1) Check that the ground wire is properly secured with a screw.

1 2 34 5

435 Igniter Module Wire Chart

1 3 425

Page 24

Grilling Guide

Type Thickness/Weight Approximate Total Grill Time

RED MEAT

¾ inch (19 mm) thick 4 to 6 minutes direct high heat

Steak: New York strip, porterhouse,

rib-eye, T-bone, and ﬁlet mignon (tenderloin)

Flank Steak 1½ to 2 pounds (0,68 - 0,91 kg), ¾ inch (19 mm) thick 8 to 10 minutes direct medium heat

Ground Beef Patty ¾ inch (19 mm) thick 8 to 10 minutes direct medium heat

Tenderloin 3 to 4 pounds (1,36 -1,81 kg)

PORK

Bratwurst: fresh 3 ounce (85 g) link 20 to 25 minutes direct low heat

Chop: boneless or bone in

Ribs: baby back, spareribs 3 to 4 pounds (1,36 -1,81 kg) 1½ to 2 hours indirect medium heat

Ribs: country-style, bone in 3 to 4 pounds (1,36 -1,81 kg) 1½ to 2 hours indirect medium heat

Tenderloin 1 pound (0,45 kg)

POULTRY

Chicken Breast: boneless, skinless 6 to 8 ounces (170-226 g) 8 to 12 minutes direct medium heat

Chicken Thigh: boneless, skinless 4 ounces (113g) 8 to 10 minutes direct medium heat

Chicken Pieces: bone in, assorted 3 to 6 ounces (85-170 g)

Chicken: whole 4 to 5 pounds (1,81-2,27 kg) 1 to 1¼ hours indirect medium heat

Cornish Game Hen 1½ to 2 pounds (0,68-0,91 kg) 60 to 70 minutes indirect medium heat

Turkey: whole, unstued 10 to 12 pounds (4,54-5,44 kg) 2 to 2½ hours indirect medium heat

SEAFOOD

Fish, Fillet, or Steak: halibut, red snapper, salmon, sea bass, swordﬁsh, and tuna

Fish: whole

Shrimp 1½ ounces (42,5 g) 2 to 4 minutes direct high heat

VEGETABLES

Asparagus ½ inch (12,7 mm) diameter 6 to 8 minutes direct medium heat

Corn

Mushroom

Onion

Potato

1 inch (25 mm) thick 6 to 8 minutes direct high heat

2 inches (5 cm) thick

¾ inch (19 mm) thick 6 to 8 minutes direct high heat

1¼ to 1½ inches (3,18 - 3,81 cm) thick

¼ to ½ inch (6,35-12,7 mm) thick 3 to 5 minutes direct medium heat

1 to 1¼ inches (25-31 mm) thick 10 to 12 minutes direct medium heat

1 pound (0,45 kg) 15 to 20 minutes indirect medium heat

3 pounds (1,36 kg) 30 to 45 minutes indirect medium heat

in husk 25 to 30 minutes direct medium heat

husked 10 to 15 minutes direct medium heat

shiitake or button 8 to 10 minutes direct medium heat

portobello 10 to 15 minutes direct medium heat

halved 35 to 40 minutes indirect medium heat

½ inch (12,7 mm) slices 8 to 12 minutes direct medium heat

whole 45 to 60 minutes indirect medium heat

½ inch (12,7 mm) slices

14 to 18 minutes sear 6 to 8 minutes direct high heat, then 8 to 10 minutes indirect high heat

45 to 60 minutes 15 minutes direct medium heat, then 30 to 45 minutes indirect medium heat

10 to 12 minutes sear 6 minutes direct high heat, then 4 to 6 minutes indirect high heat

30 minutes sear 5 minutes direct high heat, then 25 minutes indirect medium heat

36 to 40 minutes 6 to 10 minutes direct low heat, then 30 minutes indirect medium heat

9 to 11 minutes parboil 3 minutes, then 6 to 8 minutes direct medium heat

The cut s, thicknesses, weight s, and grilling times above are meant to be guidelines. Factors such as altitude, wind, and outside temperature can aect cooking times. Two rules of thumb: Grill steaks, ﬁsh ﬁllets, boneless chicken pieces, and vegetables using the direct method for the time given on the chart (or to the desired doneness), turning food once halfway through gr illing time. Grill roasts , whole poultry, bone-in poultry pieces , whole ﬁsh, and thicker cuts using the indirect method for the time given on the chart (or until an instant-read thermometer registers the desired internal temperature). Cooking times for beef and lamb use the USDA’s deﬁnition of medium doneness unless otherwise noted. Before carving, let roasts, larger cuts of meat, and thick chops and steaks rest for 5 to 10 minutes af ter cooking. The internal temperature of the meat will rise by 5 to 10 degre es during this time.

DON'T FORGET TO REGISTER

Page 25

GENESIS E335 • S335

Replacement Parts

394140

333432

363837

2627282930

242523

1718192021

131415

12354

GENESIS - E/S-335 LP - US 063021

656664

GENESIS SES335

141516

343533

586059

2728293031

252624

1819202122

404241

373938

1235476

weber.com

676866

GENESIS - SE-S-335 LP - US 063021

606261

Page 26

GENESIS E435 • S435

Replacement Parts

12 13

14 15

17 18 19

1 2

3 4

GENESIS - E/S-435 LP - US 063021

52 53

20 21

25 26

27 28

29 30 31

32 33

34 35 36 37

38 39

40 41

Page 27

GENESIS SPE335

Replacement Parts

404241

343533

373938

2728293031

252624

192021

141516

1235476

GENESIS - SP-E-335 LP - US 063021

676866

GENESIS SLS435

384140

363037

606261

262728

323433

172018

131415

123

476

weber.com

GENESIS - SL-S-435 LP - US 063021

666867

Page 28

weber.com

U.S.:

1-800-446-1071

Canada:

1-800-446-1071

Mexico:

01 800 0093237

Weber E-335, SE-S-335, E-435, S-435, SL-S-435 Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
