Weber 62434, 56070 User Manual

Built-In NG Side Burner Installation/Owner’s Guide

GUÍA DEL PROPIETARIO DE LA BARBACOA DE GAS NATURAL - PG 17 GUIDE DE L’UTILISATEUR DU BARBECUE AU GAZ NATUREL - PG 30

#56070

THIS APPLIANCE MAY BE PURCHASED SEPERATELY FOR YOUR WEBER BUILT-IN BARBECUE GRILL.

YOU MUST READ THIS OWNER’S GUIDE

BEFORE OPERATING YOUR SIDE BURNER

 DANGER

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flames.

3. Open lid.

4. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department.

Leaking gas may cause a fire or explosion which can cause serious bodily injury or death, or damage to property.

 WARNING:

1. Do not store or use gasoline or other flammable liquids or vapors in the vicinity of this or any other appliance.

2. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.

 WARNING: Follow all leak-check

procedures carefully in this manual prior to operation. Do this even if the appliances were dealer-assembled.

NOTICE TO INSTALLER: These instructions must be left with the owner and the owner should keep them for future use.

THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE ONLY.

 WARNING: Do not try to light this appliance

without reading the “Lighting Instructions” section of this manual.

56070 US 04/01/09

US ENGLISH

DANGERS & WARNINGS

 DANGER

Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property.

 WARNINGS

 Do not store a spare or disconnected liquid propane cylinder under or near the barbecue and Side Burner.  Improper assembly may be dangerous. Please follow the assembly instructions carefully.  After a period of storage, and/or nonuse, the Weber

burner obstructions before use. See instructions in this manual for correct procedures.

 Do not operate either the Weber

gas barbecue or Side Burner if there is a gas leak present.

gas barbecue and Side Burner should be checked for gas leaks and

 Do not use a flame to check for gas leaks.  Combustible materials should never be within 24 inches (61 cm) of the back or sides of your Weber® gas appliances.  Do not put a cover or anything flammable on, or in the storage area under the appliances.  Your Weber® gas appliances should never be used by children. Accessible parts of the appliances may be very hot. Keep

young children away while it is in use.

 You should exercise reasonable care when operating your Weber

gas appliances. It will be hot during cooking or cleaning and

should never be left unattended, or moved while in operation.

 Should the burners go out while in operation, turn all gas valves off. Open the lid and wait five minutes before attempting to

relight, using the lighting instructions.

 Do not use charcoal or lava rock in your Weber

gas appliances.

 Never lean over open appliance or place hands or fingers on the front edge of the cooking area.  Should a grease fire occur, turn off all burners and leave lid closed until fire is out.  Do not enlarge valve orifices or burner ports when cleaning the valves or burners.  The Weber® gas appliance should be thoroughly cleaned on a regular basis.  Liquid propane gas is not natural gas. The conversion or attempted use of natural gas in a liquid propane unit or liquid propane

gas in a natural gas unit is dangerous and will void your warranty.

 Do not attempt to disconnect any gas fitting while your appliances are in operation.  Use heat-resistant barbecue mitts or gloves when operating appliances.  Keep any electrical supply cord and the fuel supply hose away from any heated surfaces.  Combustion byproducts produced when using this product contain chemicals known to the state of California to cause cancer,

birth defects, or other reproductive harm.

 Do not use this appliance unless all parts are in place. The unit must be properly assembled according to the assembly

instructions.

 Proposition 65 Warning: Handling the brass material on this product exposes you to lead, a chemical known to the state of

California to cause cancer, birth defects or other reproductive harm.

(Wash hands after handling this product.)

LIQUID PROPANE GAS UNITS ONLY:

 Use the pressure regulator and hose assembly that is supplied with your Weber® gas barbecue.  Do not attempt to disconnect the gas regulator and hose assembly or any gas fitting while your appliances are in operation.  A dented or rusty liquid propane cylinder may be hazardous and should be checked by your liquid propane supplier. Do not

use a liquid propane cylinder with a damaged valve.

 Although your liquid propane cylinder may appear to be empty, gas may still be present, and the cylinder should be

transported and stored accordingly.

 If you see, smell or hear the hiss of escaping gas from the liquid propane cylinder:

1. Move away from liquid propane cylinder.

2. Do not attempt to correct the problem yourself.

3. Call your fire department.

WWW.WEBER.COM

WARRANTY, GARANTÍA, GARANTIE

WARRANTY

Weber-Stephen Products Co. (Weber) hereby warrants to the ORIGINAL PURCHASER of this Weber® gas appliance that it will be free of defects in material and workmanship from the date of purchase as follows:

Stainless Steel Lid, 10 years All Remaining Parts, 5 years

When assembled and operated in accordance with the printed instructions accompanying it. Weber may require reasonable proof of your date of purchase. THEREFORE, YOU SHOULD RETAIN YOUR SALES SLIP OR INVOICE. This Limited Warranty shall be limited to the repair or replacement of parts that prove defective under normal use and service and which on examination shall indicate, to Weber’s satisfaction, they are defective. Before returning any parts, contact the Customer Service Representative in your area using the contact information on our website. If Weber confirms the defect and approves the claim, Weber will elect to replace such parts without charge. If you are required to return defective parts, transportation charges must be prepaid. Weber will return parts to the purchaser, freight or postage prepaid. This Limited Warranty does not cover any failures or operating difficulties due to accident, abuse, misuse, alteration, misapplication, vandalism, improper installation or improper maintenance or service, or failure to perform normal and routine maintenance, including but not limited to damage caused by insects within the burner tubes, as set out in this owner’s manual. Deterioration or damage due to severe weather conditions such as hail, hurricanes, earthquakes or tornadoes, discoloration due to exposure to chemicals either directly or in the atmosphere, is not covered by this Limited Warranty.

GARANTÍA

Weber-Stephen Products Co. (Weber) por este medio le garantiza al COMPRADOR ORIGINAL de esta barbacoa de gas Weber® que la misma estará libre defectos en cuanto a materiales y fabricación a partir de la fecha de compra según lo siguiente:

Tapa de acero inoxidable, 10 años Todas las demás partes 5 años

Cuando se ensambla y opera de acuerdo a las instrucciones impresas que lo acompañan. Weber pudiese requerir prueba razonable de la fecha de compra. POR LO TANTO, DEBERÁ GUARDAR SU RECIBO O FACTURA DE VENTA. Esta garantía limitada está limitada a la reparación o reemplazo de piezas que se resultasen defectuosas bajo uso y servicio normal y las cuales al examinarse indiquen, a la plena satisfacción de Weber, que son defectuosas. Antes de devolver cualquier parte, contacte al Representante de Atención al Cliente en su área geográfica, cuya información de contacto la encontrará en nuestro sitio web. Si Weber confirma el defecto y aprueba el reclamo, ésta elegirá reparar o reemplazar tal pieza sin cargo alguno. Si usted tiene que retornarnos las partes defectuosas, los gastos de transporte deben ser prepagados. Weber retornará las partes al comprador con transporte o franqueo prepagado. Esta Garantía Limitada no cubre ninguna falla o problema de operación a causa de accidentes, abuso, mal uso, alteración, uso en aplicaciones indebidas, vandalismo, instalación inapropiada o mantenimiento o servicio inapropiados, o por no llevar a cabo el mantenimiento normal y rutinario, entre los que se incluyen, pero sin limitación, los daños causados por insectos dentro de los tubos quemadores, según se detalla en este manual del propietario. Esta Garantía Limitada no cubre el deterioro o daños a causa de condiciones de tiempo inclementes tales como granizo, huracanes, terremotos o tornados ni tampoco la decoloración por exposición a sustancias químicas bien sea por contacto directo o por las mismas contenidas en la atmósfera.

There are no other express warrants except as set forth herein and any applicable implied warranties of merchantability and fitness are limited in duration to the period of coverage of this express written Limited Warranty. Some regions do not allow limitation on how long an implied warranty lasts, so this limitation may not apply to you. Weber is not liable for any special, indirect or consequential damages. Some regions do not allow the exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not apply to you. Weber does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment; and no such representations are binding on Weber. This Warranty applies only to products sold at retail.

WEBER-STEPHEN PRODUCTS CO. Customer Service Center 1890 Roselle Road, Suite 308 Schaumburg, IL 60195 USA

For replacement parts call: 1-800-446-1071

www.weber.com

No existe ningunas otras garantías expresas que no sean las las acá indicadas y cualesquier garantías implícitas de comerciabilidad y aptitud de uso están limitadas en duración al tiempo de cobertura de esta expresa Garantía Limitada por escrito. Algunas regiones no permiten limitación alguna en el tiempo que una garantía implícita pueda durar, por lo que esta limitación pudiera no aplicarle a usted. Weber no se hace responsable de ningún daño especial, indirecto o emergente. Algunas regiones no permiten la exclusión o limitación de daños incidentales o emergentes, por lo que esta limitación o exclusión pudieran no aplicarle a usted. Weber no autoriza a persona o empresa alguna a asumir en su nombre ninguna obligación o responsabilidad en relación con la venta, instalación, uso, retiro, devolución o reemplazo de sus equipos, y ninguna tal representación será vinculante para Weber. Esta Garantía aplica solo a aquellos productos vendidos al por menor.

WEBER-STEPHEN PRODUCTS CO. Customer Service Center 1890 Roselle Road, Suite 308 Schaumburg, IL 60195 USA

Para partes de repuesto llame a: 1-800-446-1071

www.weber.com

Para compras hechas en México

WEBER-STEPHEN PRODUCTS S.A. de C.V. Marcella No. 338, Colonia Americana 44160 México, C.P. México

Para partes de repuesto llame a: (52) (33) 3615-0736 www.weber.com

GARANTIE

Weber-Stephen Products Co. (Weber) garantit par le présent document à l’ACHETEUR D’ORIGINE de ce grill à gaz Weber® que celui-ci ne comportera aucun défaut de pièce ni de main d’oeuvre à compter de la date d’achat comme suit :

Couvercle en acier inoxydable, 10 ans Toutes les autres pièces, 5 ans

Lorsque celui-ci est monté et utilisé conformément aux instructions imprimées qui l’accompagnent. Weber peut exiger une preuve raisonnable de votre date d’achat. PAR CONSEQUENT, VOUS DEVRIEZ CONSERVER VOTRE TICKET DE CAISSE OU VOTRE FACTURE. La présente Garantie limitée couvre uniquement la réparation ou le remplacement des pièces qui se révèlent défectueuses dans des conditions d’utilisation et d’entretien normales et dont l’examen indique, à la satisfaction de Weber, qu’elles sont défectueuses. Avant de nous retourner toute pièce, veuillez entrer en contact avec le Représentant du service clientèle de votre région grâce aux coordonnées à votre disposition sur notre site Internet. Si Weber confirme le défaut et approuve la demande, Weber décidera de remplacer ces pièces gratuitement. Si vous devez retourner les pièces défectueuses, les frais de transport doivent être prépayés. Weber renverra les pièces à l’acheteur, frais de transport ou de poste prépayés. La présente Garantie limitée ne couvre pas toute panne ou difficulté d’utilisation résultant d’un accident, d’une utilisation abusive, d’une mauvaise utilisation, d’une altération, d’une mauvaise application, d’un acte de vandalisme, d’une utilisation, d’une maintenance ou de réparations incorrectes, ou de l’absence de maintenance normale et régulière, y compris mais pas uniquement les détériorations provoquées par des insectes à l’intérieur des tubes du brûleur, comme indiqué dans le présent mode d’emploi.

WWW.WEBER.COM

Toute détérioration provoquée par des conditions météorologiques extrêmes telles que de la grêle, des ouragans, des séismes ou des tornades, toute décoloration résultant d’une exposition à des agents chimiques directement ou dans l’atmosphère, n’est pas couverte dans le cadre de la présente Garantie limitée.

Il n’y a aucune autre garantie expresse sauf celle présentée ici et toute garantie de commercialisation et d’adaptation à un usage particulier induite est limitée dans le temps à la période de couverture de la présente Garantie limitée écrite expresse. Certaines régions ne permettent pas la limitation de la durée d’une garantie induite, il est donc possible que cette limitation ne s’applique pas à vous. Weber n’est responsable d’aucun dommage particulier, indirect ou induit. Certaines régions n’autorisent pas l’exclusion ou la limitation des dommages secondaires, il est donc possible que cette limitation ou exclusion ne s’applique pas à vous. Weber n’autorise aucune personne ou société à assumer en son nom toute autre obligation ou responsabilité en relation avec la vente, l’installation, l’utilisation, le retrait, le retour, ou le replacement de ses équipements ; et aucune représentation de ce type ne lie Weber. La présente garantie s’applique uniquement aux produits vendus au détail.

WEBER-STEPHEN PRODUCTS CO. Service clientèle 1890 Roselle Road, Suite 308 Schaumburg, IL 60195 USA

Pour des pièces de rechange, appelez le : 1-800-446-1071

www.weber.com

EXPLODED VIEW, DIAGRAMA DE DESPIECE, VISION ECLATEE

 Before installing components,

remove protective film from the stainless steel part.

 Antes de instalar el

componentes, retire la película protectora de la pieza de acero inoxidable.

 Avant d’installer le composants,

retirez la pellicule protectrice de la pièce en acier inoxydable.

WWW.WEBER.COM

EXPLODED VIEW LIST, LISTA DEL DIAGRAMA DE DESPIECE, LISTE DE LA VISION ECLATEE

1. Lid

Tapa

Couvercle

2. Grate

Parrilla

Grille

3. Side Burner

Quemador lateral

Brûleur latéral

4. Mounting Bracket

Ménsula de montaje

Support de montage

5. Locking Washer

Arandela de seguridad

Rondelle de verrouillage

7. Bushing

Pasamuros

Douille

8. Side Burner Box

Caja del quemador lateral

Boîtier du brûleur latéral

9. Side Burner Cap

Tapa del quemador lateral

Cache du brûleur latéral

10. Side Burner Head

Hornilla del quemador lateral

Tête du brûleur latéral

11. Screw

Tornillo

Vis

13. Igniter Button

Botón encendedor

Bouton de l’allumeur

14. Igniter Module

Módulo encendedor

Module de l’allumeur

15. Screw Anchor

Ancla de tornillo

Douille à expansion

16. Non Corrosive Screw

Tornillo no corrosible

Vis non corrosive

17. Grease Tray

Bandeja de grasa

Plateau égouttoir

6. Wing Nut

Tuerca de mariposa

Ecrou à oreille

6 -

1 -

12. Washer

Arandela

Rondelle

HARDWARE LIST, LISTA DE LOS HERRAJES, LISTE DU MATERIEL

2 -

WWW.WEBER.COM

INSTALLATION

The natural gas supply is easy to use and gives you more cooking control than charcoal fuel.

• These instructions will give you the minimum requirements for assembling your

• Not for use by children.

• If there are local codes that apply to portable gas grills, you will have to conform

• This Weber

• Do not use with charcoal fuel.

• Check that the area under the control panel and the bottom tray are free from

Weber

Built-In Side Burner. Please read the instructions carefully before using

your Weber

to them. If there are no local codes, you must conform to the latest edition of the National Fuel Gas Code: ANSI Z 223.1/NFPA54.

Do not use liquid propane (LP) bottled gas. The valves, orifices and hose are for natural gas only.

debris that might obstruct the flow of combustion or ventilation air.

Built-In Side Burner. Improper assembly can be dangerous.

Built-In Side Burner is designed for natural (piped in city) gas only.

STORAGE  The gas must be turned OFF at the natural gas supply when

the Weber® Built-In Side Burner is not in use.

 Check that the areas under the control panel and the slide

out bottom tray are free from debris that might obstruct the flow of combustion or ventilation air.

OPERATING  WARNING: Only use this barbecue outdoors in a well-

ventilated area. Do not use in a garage, building, breezeway or any other enclosed area.

 WARNING: Your Weber® Built-In Side Burner shall not be

used under an unprotected combustible roof or overhang.

 WARNING: Your Weber® Built-In Side Burner is not intended

to be installed in or on recreational vehicles and/or boats.

 WARNING: Do not use the barbecue within 24 (60.96cm)

inches of combustible materials, top, bottom, back or sides of the grill.

 WARNING: The entire cooking box gets hot when in use. Do

not leave unattended.

 WARNING: Keep any electrical supply cord and the fuel

supply hose away from any heated surface.

 WARNING: Keep the cooking area clear of flammable vapors

and liquids, such as gasoline, alcohol, etc., and combustible materials.

GAS SUPPLY TESTING

• Disconnect your Weber® gas barbecue when the gas supply is being tested at high pressures. This appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa).

• Turn OFF your Weber® gas barbecue when the gas supply is being tested at low pressures. This appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at the pressure equal to or less than 1/2 psig (3.5 kPa).

“ISLAND” STRUCTURE CONFIGURATION OPTIONS

There are many available options for locating the major components of your Island structure.Your major components are:

1) The Built in Grill

2) Gas supply enclosure

3) Optional Side burner accessory The 3 common options (A, B, C) are illustrated in the “Island Structure Configuration

Options” table.

“ISLAND” STRUCTURE CONFIGURATION OPTIONS

1 Summit® 4-burner/6-burner grill 2 Gas supply 3 Optional sideburner accessory

NOTE: GAS LINE LIMITATION

The gas supply hose from grill manifold to gas supply bulkhead must not exceed 58" (147cm). The 3/8 (9.52mm) Side Burner accessory hose (not included) must not exceed 58 (147cm).

WWW.WEBER.COM

INSTALLATION

LOCATING YOUR BUILT-IN SIDE BURNER APPLIANCE

When determining a suitable location for your Built-In Side Burner installation, give attention to concerns such as exposure to wind, proximity to traffic paths, and keeping any gas supply lines as short as possible. Never locate the Summit® Built-In Side Burner in a garage, breezeway, shed, under overhang, or other enclosed area. Locate the Side Burner and structure so there is enough room to safely evacuate the area in case of a fire.

CLEARANCE FROM COMBUSTIBLE SURFACES OR STRUCTURES

 WARNING: Clearance from the outside walls of the sides

and back of the Built-In Side Burner must be a minimum of 24 inches (61 cm) from any combustible surface. Refer to “Installation/Gas Instructions” section before starting installation.

 DANGER

The structure, “island” counter tops and adjacent work areas for the Built-In Side Burner installation must be built from noncombustible materials only. Incorrect installation may result in a fire, which can cause serious bodily injury or death, and cause damage to property.

NOTE: If you have questions on what materials are considered noncombustible, contact you local building supplier or fire department.

A A

SIDE BURNER LOCATION

A Any Surface B 24" (61 cm) From Any Combustible Surface C Side Burner

Note: For a countertop treatment: Recommended 3/4" (19 mm) overhang.

Notch front edge for frame to fully slide in.

BUILT-IN STRUCTURE CUTOUT DIMENSIONS

All dimensions are to finished surfaces.

 WARNING: All counter top finished surfaces must be

constructed of a noncombustible material.

SIDE BURNER

Cut out Dimensions Tolerances

A 12 3/8" (31.4 cm) + 1/8" - 1/8" (3.18mm) B 7 7/8" (20 cm) - C 27" (68.6 cm) + 1/8" - 1/8" (3.18mm)

WWW.WEBER.COM

INSTALLATION

BUILT-IN GAS LINE LOCATIONS

GENERAL CONSTRUCTION DETAILS

• Summit® Built-In Side Burner unit should be on site before construction begins.

• Provide access for a corrugated gas line depending on the location of the side burner in relation to your main gas supply and regulator position.

• Area should be kept clear of sharp, jagged, or extremely abrasive surfaces to avoid possible damage to gas supply lines. Exercise caution when pulling gas lines through built-in structure.

• A 3/8 inch (9.52 mm) stainless steel corrugated gas line (NOT INCLUDED) should be used to connect the side burner to the bulkhead accessory coupling.

 CAUTION: 3/8 inch (9.52 mm) stainless steel corrugated gas

line must not exceed 58 inches (147 cm) in length. A longer hose could cause an improper pressure drop.

 WARNING: Do not use a rubber gas hose.

MOUNTING THE SIDE BURNER

1) Attach the mounting bracket(a) to the outside rear of the Side Burner box. Secure with locking washers and wing nuts. Hand-tighten only.

2) Insert bushing(b) into hole at rear/left side of Side Burner box until it snaps into place.

3) Route the 3/8 inch (9.52 mm) stainless steel corrugated gas line through the hole in the left side of the Side Burner box(c). Pass the supply end of the hose to the gas supply enclosure (see “CONNECT GAS SUPPLY” section).

CAUTION: Before installing component, remove protective



film from the stainless steel part.

GAS LINE LOCATIONS

1 3/8" (9.52 cm) Stainless Corrugated Gas Line (58" Max. Length) 2 Gas Supply Enclosure Location

4) Lower the Side Burner box into the Side Burner cut out.

5) Secure the Side Burner box with a non corrosive screw(d) anchored into the finished surface of the “island structure”.

WWW.WEBER.COM

INSTALLATION

6) Secure the rear of the Side Burner box to counter top by adjusting bracket at back

of Side Burner box. Tighten wing nuts.

7) Connect the 3/8 inch (9.52 mm) stainless steel corrugated gas line to the Side

Burner valve located underneath the Side Burner.

CAUTION: Before continuing installation- you must connect the Side Burner gas line to the main gas supply, then test all Side Burner gas connections for leaks. See “CONNECTING GAS SUPPLY” section and “GAS LEAK TESTING” section.

8) Lower the Side Burner into the Side Burner box. Use the 6 included screws and

washers to secure Side Burner to Side Burner box.

WWW.WEBER.COM

INSTALLATION/GAS INSTRUCTIONS

9) Install remaining components.

TYPICAL NATURAL GAS SUPPLY INSTALLATION

We recommend that this installation be done by a LICENSED professional.

GENERAL SPECIFICATIONS FOR PIPING

Note - Contact your local municipality for building codes regulating outdoor gas grill installations. In absence of Local Codes, you must conform to the latest edition of National Fuel Gas Code ANSI Z223.1/NFPA54.

• This grill is designed to operate at 4.5 inches of water column pressure.

• A manual shut-off valve must be installed outdoors, and be accessible, not in the “built-in” structure. An additional manual shut-off valve indoors should be installed

in the branch fuel line in an accessible location near the supply line.

 CAUTION: If young children are in the area, a locking valve

should be considered.

• Pipe compound should be used which is resistant to the action of liquid propane gas when gas connections are made.

• The gas connections must be firmly attached to a rigid, permanent construction.

Note: The information provided in this manual is general for typical installations. We cannot cover all possible installation ideas. We recommend, prior to installation, that you contact your municipality for local building codes and your local fire department for installation verification.

If you have any questions, contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com

GAS LINE PIPING

• Refer to piping chart.

• The corrugated gas line from the manifold is 58 inches (1,473.2 mm) long. Do not extend the gas line.

• We have provided the means to make an SAE 45° flare connection. Do not use pipe sealant on this connection.

• If the length of line required does not exceed 50 feet, use a 5/8" O.D. tube. One size larger should be used for lengths greater than 50 feet. Refer to piping chart.

• Gas piping may be copper tubing, type K or L; polyethylene plastic tube, with a minimum wall thickness of .062 inch (1.57 mm); or standard weight (schedule 40) steel or wrought iron pipe.

• Copper tubing must be tin-lined if the gas contains more than 0.3 grams of hydrogen sulfide per 100 cubic feet of gas.

• Plastic tubing is suitable only for outdoor, underground use.

• Gas piping in contact with earth, or any other material which may corrode the piping, must be protected against corrosion in an approved manner.

• Underground piping must have a minimum of 18" cover.

Tab le

6.2(a)

Nominal

Iron Pipe

Size

(Inches)

Actual

ID:

(Inches)

Maximum Capacity of Metallic Pipe in Cubic Feet of Gas per Hour for Gas Pressures of 2 psi or Less and

a Pressure Drop of 0.3 Inch Water Column. (Based on a 0.60 Specific Gravity Gas)

Length of Pipe (Feet)

10 20 30 40 50 60 70 80 90 100 125 150 175 200

1/4 .364 32 22 18 15 14 12 11 11 10 98876 3/8 .493 72 49 40 34 30 27 25 23 22 21 18 17 15 14 1/2 .622 132 92 73 63 56 50 46 43 40 38 34 31 28 26 3/4 .824 278 190 152 130 115 105 96 90 84 79 72 64 59 55

1 1.049 520 350 285 245 215 195 180 170 160 150 130 120 110 100

1 1/4 1.380 1050 730 590 500 440 400 370 350 320 305 275 250 225 210

1/12 1.160 1600 1100 890 760 670 610 560 530 490 460 410 380 350 320

2 2.067 3050 2100 1650 1450 1270 1150 1050 990 930 870 780 710 650 610

2 1/2 2.469 4800 3300 2700 2300 2000 1850 1700 1600 1500 1400 1250 1130 1050 980

3 3.068 8500 5900 4700 4100 3600 3250 3000 2800 2600 2500 2200 2000 1850 1700 4 4.026 17500 12000 9700 8300 7400 6800 6200 5800 5400 5100 4500 4100 3800 3500

WWW.WEBER.COM

INSTALLATION/GAS INSTRUCTIONS

TEST CONNECTIONS

All connections and joints must be thoroughly tested for leaks in accordance with local codes and all listed procedures in the latest edition of the National Fuel Gas Code ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2, or the Standard for Recreational Vehicles, ANSI A

119.2/NFPA 1192, and CSA Z240 RV Series, Recreational Vehicle Code, as applicable.

CONNECTING GAS SUPPLY

CONNECT GAS SUPPLY

1) Uncap the flare fitting from the optional side burner connection located at regulator.

Note: You must connect your side burner to a Weber® approved regulator (part number #62434) located at main gas supply. If you do not use a Weber regulator the Warranty on the Summit® Built-In Side Burner will be voided. If you have any questions, contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com®.

2) Connect the corrugated gas line to the side burner connection.

approved

 DANGER

Do not use an open flame to check for gas leaks. Be sure there are no sparks or open flames in the area while you check for gas leaks. This will result in a fire or explosion which can cause serious bodily injury or death, and damage to property.

SIDE BURNER NG SUPPLY CONNECTIONS

1 2 3

4 a

Cap (Optional Side Burner)

Hard Piped Gas Supply

Regulator

To SIde Burner

Top View

WWW.WEBER.COM

GAS LEAK TESTING

CHECK FOR GAS LEAKS

After a period of nonuse, we recommend that you perform the following maintenance procedures for your safety.

 WARNING: Check the hose before each use of the grill for

nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the grill. Replace using only Summit

authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com®.

• Inspect the burner for correct flame pattern. Clean if necessary, following the procedures outlined in the “General Maintenance” section of this manual.

• Check all gas fittings for leaks.

TEST CONNECTIONS

119.2/NFPA 1192, and CSA Z240 RV Series, Recreational Vehicle Code, as applicable.

 DANGER

Do not use an open flame to check for gas leaks. Be sure there are no sparks or open flames in the area while you check for leaks. Sparks or open flames will result in a fire or explosion, which can cause serious bodily injury or death and damage to property.

 WARNING: You should check for gas leaks every time you

disconnect and reconnect a gas fitting.

Note - All factory-made connections have been thoroughly checked for gas leaks. The burners have been flame-tested. As a safety precaution however, you should recheck all fittings for leaks before using your Weber® appliances. Shipping and handling may loosen or damage a gas fitting.

 WARNING: Perform these leak checks even if your appliance

was dealer or store assembled.

You will need: a soap and water solution, and a rag or brush to apply it.

Note - Since some leak test solutions, including soap and water, may be slightly corrosive, all connections should be rinsed with water after checking for leaks. Make sure side burner is OFF.

 WARNING: Do not ignite burners when leak checking.

Check for leaks by wetting the connections with the soap and water solution and watching for bubbles. If bubbles form or if a bubble grows, there is a leak.

CHECK SIDE BURNER COMPONENT

Check:

1) Side burner lines to valve connections.

2) Side burner line to side burner orifice.

3) Side burner hose to side burner bulkhead.

 WARNING: If there is a leak at connection (1, 2 or 3),

retighten the fitting with a wrench and recheck for leaks with soap and water solution. If a leak persists after retightening the fitting, turn OFF the gas. DO NOT OPERATE THE GRILL OR SIDE BURNER. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com®.

WWW.WEBER.COM

GAS LEAK TESTING

CHECK GAS SUPPLY CONNECTIONS  WARNING: You should check for gas leaks every time you

disconnect and reconnect a gas fitting.

Note - All factory-made connections have been thoroughly checked for gas leaks. As a safety precaution however, you should recheck all fittings for leaks before using your Summit® Built-In side burner. Shipping and handling may loosen or damage a gas fitting.

You will need: a soap and water solution, an d a rag or brush to apply it. Turn on gas supply.

Check for leaks by wetting the connections with the soap and water solution and watching for bubbles. If bubbles form or if a bubble grows, there is a leak.

Note - Since some leak test solutions, including soap and water, may be slightly corrosive, all connections should be rinsed with water after checking for leaks.

 WARNING: Do not ignite burners when leak checking.

Check:

1) Corrugated gas line-to-Accessory “T” Connection.

2) Main gas supply to regulator.

 WARNING: If there is a leak a connection(1 or 2), retighten

the fitting with a wrench and recheck for leaks with soap and water solution. If a leak persists after retightening the fitting, turn OFF the gas. DO NOT OPERATE THE GRILL. Contact the Customer Service Representative in your area using the contact information sheet provided with your manual.

When leak checks are complete, turn gas supply OFF at the source and rinse connections with water.

OPERATING INSTRUCTIONS

SIDE BURNER LIGHTING INSTRUCTIONS

Summary lighting instructions are inside the left hand cabinet door.

 DANGER

Failure to remove the lid while igniting the side burner, or not waiting 5 minutes to allow the gas to clear if the side burner does not light, may result in an explosive flame-up which can cause serious bodily injury or death.

1) Remove the Side Burner lid by pushing down slightly on one end while lifting from

the other end. Store the Side Burner lid in your grill cabinet.

 CAUTION: Do not use lid as a cooking surface or a cutting

surface.

2) Check that the side burner valves are turned OFF. (Push knobs in and turn

clockwise to ensure that they are in the off position.)

 WARNING: The burner control knobs must be in the OFF

position before turning on gas at the source.

3) Turn the gas supply valve on.

WWW.WEBER.COM

4) Push in and turn the side burner control knob (1 - rear) or control knob (2 - front) to START/HI.

OPERATING INSTRUCTIONS

 CAUTION: Do not turn gas on to both burners at the same

time.

5) Push igniter button and hold until burner ignites. You will hear the igniter sparking.

 CAUTION: Side burner flame may be difficult to see on a

bright sunny day.

 WARNING: If the side burner does not light:

1) Turn OFF the side burner control valve.

2) Wait 5 minutes to let the gas clear before you try again

or try to light with a match.

TO EXTINGUISH

Push down and turn each burner control knob clockwise to the OFF position. Turn gas supply OFF at the source.

MANUALLY LIGHTING THE SIDE BURNER

 DANGER

Failure to open the lid while igniting the side burner, or not waiting 5 minutes to allow the gas to clear if the side burner does not light, may result in an explosive flame-up which can cause serious bodily injury or death.

1) Remove the Side Burner lid by pushing down slightly on either end.

2) Check that the side burner valves are turned OFF. (Push the knobs down and turn clockwise to ensure that they are in the off position.)

3) Turn the gas supply valve on.

4) Put match in a match holder and strike match.

5) Push in and turn the side burner control knob (1 - rear) or control knob (2 front) to START/HI.

6) Hold match holder and lit match by right side of side burner.

 CAUTION: Side burner flame may be difficult to see on a

bright sunny day.

 WARNING: If the side burner does not light:

1) Turn OFF the side burner control valve.

2) Wait 5 minutes to let the gas clear before you try again or try to light with a match.

WWW.WEBER.COM

+ 30 hidden pages
