Webb WEBV26, WELT26, WEBC26, WEHC600 Operator's Manual

Download
Please read & understand this manual, paying particular attention to the safety instructions, before use.
Operator’s Manual & Parts List
6 July 2016
193867001
26cc Petrol Garden
Blower & Vacuum
WEBV26
CONTENTS
SAFETY INSTRUCTIONS SPECIFICATIONS COMPONENTS ASSEMBLY OPERATION MAINTENANCE, CLEANING & STORAGE TROUBLE SHOOTING PARTS DIAGRAM & LIST
DECLARATION OF CONFORMITY WARRANTY
For Spares or Support of your Webb product, please contact us:
Tel: 01793 333212
(Mon – Fri 8.30am to 5.00pm)
Email: customerservice@webblawnmowers.co.uk
www.webblawnmowers.co.uk
CONTENTS
SAFETY INSTRUCTIONS SPECIFICATIONS COMPONENTS ASSEMBLY OPERATION MAINTENANCE, CLEANING & STORAGE TROUBLE SHOOTING PARTS DIAGRAM & LIST
DECLARATION OF CONFORMITY WARRANTY
For Spares or Support of your Webb product, please contact us:
Tel: 01793 333212
(Mon – Fri 8.30am to 5.00pm)
Email: customerservice@webblawnmowers.co.uk
www.webblawnmowers.co.uk
STAY ALERT
Do not operate the machine while under the influence of drugs, alcohol, or any medicaon that could affect your ability to use it properly. Do not use this machine when you are red or distracted from the job at hand. Be aware of what you are doing at all mes. Use common sense. AVOID DANGEROUS CONDITIONS Make sure there is adequate surrounding workspace. Cluered areas invite injuries. Keep your work area clean with sufficient light. Keep area around the machine clear
of obstrucons, stones, scks, wires and other debris or foreign bodies which could cause damage to the machine. DO NOT SMOKE, whilst using the machine.
INSPECT YOUR MACHINE
Check all bolts, nuts, and screws for ghtness before each use, especially those securing guards and drive mechanisms. Vibraon during use may cause these to loosen. Replace damaged, missing or failed parts before using. Warning labels carry important informaon. Replace any missing or damaged warning labels.
DRESS P
ROPERLY
Do not wear loose clothing, gloves, scarfs, neckes or jewelry (rings, wrist watches), which can be caught in moving parts. ALWAYS wear protecve eye and ear wear. Appropriate gloves are also recommended. Wear protecve hair covering to contain long hair, prevenng it from geng caught in machinery. DO NOT use whilst barefoot or wearing open toed footwear. KEEP BYSTANDERS AND CHILDREN AWAY Keep unauthorised persons or animals a minimum distance of 15 metres away from the mower.
Do not allow
children to handle, use, or climb on the lawnmower.
DO NOT OVERREACH
Keep proper foong and balance at all mes, parcularly if using on slopes. The machine should not be used on steep slopes and always be sure of foong.
AVOID INJURY FROM UNEXPECTED ACCIDENT
Keep hands out of the way of moving parts, parcularly the engine and rotang cung tool .
DO NOT FORCE TOOL
Always work within the rated capacity. Do not use the machine for a purpose
for which it was not
intended. Always use the correct handles and shoulder straps provided with the machine.
MAINTAIN YOUR MACHINE WITH CARE
Clean the machine immediately aer use. Keep the machine clean to ensure it operates to its full and safest performance. When maintaining this machine, only the manufacturer’s original replacement parts should be used. The use of non-original manufacturer parts may invalidate your warranty.
STORE IDLE EQUIPME
NT
When not in use, the machine should be stored in a dry locaon. Keep the machine away from children and others not qualified to use it. DO NOT STORE FUEL IN THE MACHINE, fuel over 30 days old can become stale and if used, damage the carburetor, which is not covered by the manufacturer’s warranty.
SAFETY INSTRUCTIONS
Read and understand the owner’s manual and labels affixed to the machine. Learn its applicaon and limitaons as well as the specific potenal hazards. Retain these instrucons for future reference. The operator is responsible for following the warnings & instrucons in this manual and on the product.
Read & understand operator’s manual
before using the machine. Failure to
follow instrucons could result in
death or serious injury.
This graphic and when accompanied by
WARNING or DANGER, calls aenon
to acons which could lead to SERIOUS
INJURY
Always wear eye and ear protecon
WARNING
Never modify a machine in any way.
Incorrect use of a machine can cause
SERIOUS OR FATAL PERSONAL INJURY
Always wear gloves to protect your
hands.
SHARP ROTATING BLADES
It is advisable to wear a face mask to stop debris from entering your body.
Always TURN OFF THE ENGINE,
ensuring the cung tool has stopped,
before cleaning, removing or adjusng
the machine tubes.
15m
Keep all bystanders & animals at least
15 metres away from the machine
during operaon.
If approached, stop the machine
immediately.
No smoking
Risk of Carbon Monoxide Poisoning.
Ensure working area is correctly
venlated.
Do not use near a flame, or sparks
Fire Risk
Fire and its vapors are extremely
flammable & explosive.
Fire or explosion can cause severe
burns or death.
Moving Parts
Rotang parts can contact or entangle
hands, feet, hair, clothing or
accessories.
Traumac amputaon or severe
laceraon can result
Hot Surface.
Running engines produce heat. Engine
parts, especially the exhaust, become
extremely hot.
Severe thermal burns can occur on
contact
Safety alert symbol. Used to alert you to potenal personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous situaon which, if not avoided, will result in serious injury.
WARNING
Indicates a potenally hazardous situaon which, if not avoided, could result in serious injury
CAUTION
Indicates a potenally hazardous situaon which, if not avoided, may result in minor or moderate injury.
CAUTION
Used witho
ut the safety alert symbol indicates a potenally hazardous situaon which, if not avoided, may
result in property damage.
INSTRUCTION MANUAL
STAY ALERT
Do not operate the machine while under the influence of drugs, alcohol, or any medicaon that could affect your ability to use it properly. Do not use this machine when you are red or distracted from the job at hand. Be aware of what you are doing at all mes. Use common sense. AVOID DANGEROUS CONDITIONS Make sure there is adequate surrounding workspace. Cluered areas invite injuries. Keep your work area clean with sufficient light. Keep area around the machine clear
of obstrucons, stones, scks, wires and other debris or foreign bodies which could cause damage to the machine. DO NOT SMOKE, whilst using the machine.
INSPECT YOUR MACHINE
Check all bolts, nuts, and screws for ghtness before each use, especially those securing guards and drive mechanisms. Vibraon during use may cause these to loosen. Replace damaged, missing or failed parts before using. Warning labels carry important informaon. Replace any missing or damaged warning labels.
DRESS P
ROPERLY
Do not wear loose clothing, gloves, scarfs, neckes or jewelry (rings, wrist watches), which can be caught in moving parts. ALWAYS wear protecve eye and ear wear. Appropriate gloves are also recommended. Wear protecve hair covering to contain long hair, prevenng it from geng caught in machinery. DO NOT use whilst barefoot or wearing open toed footwear. KEEP BYSTANDERS AND CHILDREN AWAY Keep unauthorised persons or animals a minimum distance of 15 metres away from the mower.
Do not allow
children to handle, use, or climb on the lawnmower.
DO NOT OVERREACH
Keep proper foong and balance at all mes, parcularly if using on slopes. The machine should not be used on steep slopes and always be sure of foong.
AVOID INJURY FROM UNEXPECTED ACCIDENT
Keep hands out of the way of moving parts, parcularly the engine and rotang cung tool .
DO NOT FORCE TOOL
Always work within the rated capacity. Do not use the machine for a purpose
for which it was not
intended. Always use the correct handles and shoulder straps provided with the machine.
MAINTAIN YOUR MACHINE WITH CARE
Clean the machine immediately aer use. Keep the machine clean to ensure it operates to its full and safest performance. When maintaining this machine, only the manufacturer’s original replacement parts should be used. The use of non-original manufacturer parts may invalidate your warranty.
STORE IDLE EQUIPME
NT
When not in use, the machine should be stored in a dry locaon. Keep the machine away from children and others not qualified to use it. DO NOT STORE FUEL IN THE MACHINE, fuel over 30 days old can become stale and if used, damage the carburetor, which is not covered by the manufacturer’s warranty.
COMPONENTS
1. Blow Pipe A
2. Blow Pipe B
3. Collecon Bag
4. Sucon Pipe A
5. Sucon Pipe B
6. Discharge Pipe
7. Fan Cover
8. On/Off Switch
9. Throle Trigger
10. Air Filter Cover
11. Recoil Starter
12. Choke Lever
13. Fuel Tank
14. Fuel Cap
15. Spark Plug Cap
1
2
3
7
4
6
8
9
10
11
12
13
15
14
5
SPECIFICATIONS
Model WEBV26
Product Number 193867001
Engine (cc) 25.4
Idle Speed (r/min) 3000+200
Fuel Tank Capacity (Litre) 0.5
Fuel Ra o (Petrol:2 Stroke Mineral Oil) Stro
25:1
Dimensions (mm) L-580, W-355, H-370
Weight (kgs) N.W 4.8 - G.W 7.8
The manufacturer reserves the right to change the product specific
n and livery according to con ued
product improvements.
This symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable colle
on point for the recycling of electrical and electronic equipment. For more detailed informa on about recycling of this product, please contact your local council office, your household waste disposal service or shop where you purchased the product.
INSTRUCTION MANUAL
COMPONENTS
1. Blow Pipe A
2. Blow Pipe B
3. Collecon Bag
4. Sucon Pipe A
5. Sucon Pipe B
6. Discharge Pipe
7. Fan Cover
8. On/Off Switch
9. Throle Trigger
10. Air Filter Cover
11. Recoil Starter
12. Choke Lever
13. Fuel Tank
14. Fuel Cap
15. Spark Plug Cap
1
2
3
7
4
6
8
9
10
11
12
13
15
14
5
BLOWER ASSEMBLY
1. Match Blower Tube A, with the locking stubs on the body of the machine.
2. Rotate the tube clockwise to lock into place.
3. Repeat the same acon aaching Blower Tube B to Blower Tube A.
4. Secure Blower Tube A to the body of the machine, using M5x10 screw.
WARNING EXCESSIVE VIBRATION OF THE MULCHING FAN INDICATES IT HAS BEEN DAMAGED. CONSULT YOUR LOCAL APPROVED DEALER FOR ASSISTANCE
ASSEMBLY
Remove the machine and contents from the carton. Be sure the carton is empty before discarding. If you require any assistance with regards to the contents of the lawnmower contact us:
Tel: 01793 333212 - Mon – Fri 8.30am – 5.00pm (excl. Bank Holidays) Email: customerservice@webblawnmowers.co.uk
VACUUM ASSEMBLY
1. Open the fan cover, by loosening the top screw and allowing the fan cover to open.
2. Match Sucon Tube A, with the top & boom locking stubs on the body of the machine.
3. Rota
te the tube clockwise to lock into place.
4. Repeat the same acons, aaching Sucon Tube B to Sucon Tube A.
5. Insert the Discharge Tube into the Collecon Bag and secure.
6. Connect the Discharge Tube to the Discharge Outlet of the machine and secure with an M5x10 screw
INSTRUCTION MANUAL
BLOWER ASSEMBLY
1. Match Blower Tube A, with the locking stubs on the body of the machine.
2. Rotate the tube clockwise to lock into place.
3. Repeat the same acon aaching Blower Tube B to Blower Tube A.
4. Secure Blower Tube A to the body of the machine, using M5x10 screw.
WARNING EXCESSIVE VIBRATION OF THE MULCHING FAN INDICATES IT HAS BEEN DAMAGED. CONSULT YOUR LOCAL APPROVED DEALER FOR ASSISTANCE
FUEL & OIL MIXTURE
Fuel & its vapors are very flammable. Do not use or fuel the machine near a flame, sparks or while smoking. Allow the engine to cool for more than 2 minutes, before re-fueling. Never fuel the machine with the engine running. Fuel the engine at least 3 metres away from your work area. Always fuel your machine outdoors.
Use good quality unleaded fuel which contains NO ETHANOL or METHANOL. Use Branded 89 octane or higher
unleaded fuel, known to be of good quality.
Fuel which is older than 30 days old can become stale and cause acid & gum deposits in the fuel system or
essen
al carburetor components. This could result in star ng issues which would not be covered by your
manufacturer’s warranty.
To keep fuel fresh, we recommend you use Handy Parts – Sure Start Garden Machinery Fuel Addi ve which is
available in 250ml bo
les, for 25 litres of fuel.
Helps makes machines easier to start
Extends shelf life of petrol up to 2 years
Keeps carburetor & engine clean
Reduces emissions & increases fuel economy
Only use 2-stroke air cooled engine oil. DO NOT USE automo ve or marine oil. It is recommended that you use a Fuel Mixing Bo
le, to ensure the correct fuel mixture i s used with your machine. We recommend Handy Parts item HP-120. The fuel mixture should be shaken prior to entering the machine fuel tank.
Mix only the quan
ty you require to complete your specific task.
Unscrew the machine fuel cap slowly and fill the fuel tank with your fuel mixture to a maximum of 80%
capacity. This will allow for fuel tank expansion.
Fasten the fuel cap
tly, being careful not to cross-thread. This will also prevent loosening through vibra on
during use.
Wipe away any spillage, with an appropriate material. If the machine has con
nued leaks, the product should not be started. Never use the machine with damaged
igni
n cable or spark plug cap, as there is a risk of sparks.
IMPORTANT
Ensure that any stored petrol/oil mixture is clearly marked in a separate appropriate canister for a maximum
of 4-6 weeks.
If the machine is not going to be used for a long period, drain the mixture from the fuel tank, start the engine
and drain the carburetor of any remaining fuel. (See Maintenance for further instru
on)
Dispose of any unwanted 2-stroke mixture at an authorised recycling point.
Unleaded
Petrol – litre
Two-Stroke
Mineral Oil - ml
1 40
2 80
3
120
4
160
5
200
OPERATION
DANGER
All model Blowers can throw small stones, metal or small objects as well as material. Do not allow anyone t o enter the operang DANGER ZONE with you. The danger zone is an area 15 metres in radius. Insist that persons in the RISK ZONE beyond the danger zone wear eye protecon from thrown objects. If the unit must be used where there are unprotected people, operate at a low throle speed to reduce the risk of thrown objects.
DANGER ZONE WITHIN 15 METRES - RISK ZONE GR
EATER THAN 15 METRES
GENERAL USE
WARNING
Prior to using the machine, ensure all hardware (bolts, screws & nuts) are securely ghtened.
Operate the trigger with your right hand & hold the Lower Handle with your le hand. The trigger increases and decreases the power of the engine to the aachment, increasing the
revoluon/reciprocaon of the aachment.
WORKING PLAN
Blow material to a safe collecon point, away from stones and other hard debris, which could damage the
mulchi
ng fan within the machine.
Limit the amount of me the product is used connuously to a maximum of 40 minutes per session. Leave the machine to rest between sessions for between 10-20 minutes. Total amount of work performed per day with the machine, should be limited to 120 minutes maximum. Connuous use of the machine can cause “Repeve Stress Injury (RSI)”. If you feel discomfort, redness or
swelling of your hands and fingers or any other body part, consult your doctor.
Check local regulaon
s for sound level and hours of operaon constraints.
Never transport the machine, whilst the engine is running.
USING THE VACUUM
When using the vacuum, ensure the bag is not damaged and the zip is in working order, to ensure debris is
not thrown.
When the bag is full, open the zip on the bag and p the contents into a recycling bin or compost heap.
USING THE BLOWER
Always be aware of the strength and direcon of the air stream. Never direct the blower towards period o
r animals.
INSTRUCTION MANUAL
FUEL & OIL MIXTURE
Fuel & its vapors are very flammable. Do not use or fuel the machine near a flame, sparks or while smoking. Allow the engine to cool for more than 2 minutes, before re-fueling. Never fuel the machine with the engine running. Fuel the engine at least 3 metres away from your work area. Always fuel your machine outdoors.
Use good quality unleaded fuel which contains NO ETHANOL or METHANOL. Use Branded 89 octane or higher
unleaded fuel, known to be of good quality.
Fuel which is older than 30 days old can become stale and cause acid & gum deposits in the fuel system or
essen
al carburetor components. This could result in star ng issues which would not be covered by your
manufacturer’s warranty.
To keep fuel fresh, we recommend you use Handy Parts – Sure Start Garden Machinery Fuel Addi ve which is
available in 250ml bo les, for 25 litres of fuel.
Helps makes machines easier to start
Extends shelf life of petrol up to 2 years
Keeps carburetor & engine clean
Reduces emissions & increases fuel economy
Only use 2-stroke air cooled engine oil. DO NOT USE automo ve or marine oil. It is recommended that you use a Fuel Mixing Bo le, to ensure the correct fuel mixture i s used with your
machine. We recommend Handy Parts item HP-120. The fuel mixture should be shaken prior to entering the machine fuel tank.
Mix only the quan ty you require to complete your specific task.
Unscrew the machine fuel cap slowly and fill the fuel tank with your fuel mixture to a maximum of 80%
capacity. This will allow for fuel tank expansion.
Fasten the fuel cap tly, being careful not to cross-thread. This will also prevent loosening through vibra on
during use.
Wipe away any spillage, with an appropriate material. If the machine has con nued leaks, the product should not be started. Never use the machine with damaged
igni
n cable or spark plug cap, as there is a risk of sparks.
IMPORTANT
Ensure that any stored petrol/oil mixture is clearly marked in a separate appropriate canister for a maximum
of 4-6 weeks.
If the machine is not going to be used for a long period, drain the mixture from the fuel tank, start the engine
and drain the carburetor of any remaining fuel. (See Maintenance for further instru
on)
Dispose of any unwanted 2-stroke mixture at an authorised recycling point.
Unleaded
Petrol – litre
Two-Stroke
Mineral Oil - ml
1 40
2 80
3
120
4
160
5
200
MAINTENANCE, CLEANING & STORAGE
WARNING Improper maintenance & storage of the machine may void your warranty. Keep the machine clean for beer and safer performance.
MAINTENANCE
Before each use, check all nuts & bolts to be sure they are sufficiently ghtened. We recommend only manufacturer original parts are used when maintaining this machine. Failure to do so could
invalidate your manufacturer’s warranty.
The engine must be switched off, with the spark plug cap removed, before the machine is unasse
mbled, cleaned,
serviced or maintained.
ADJUSTING CARBURETOR
Do not adjust carburetor unless necessary. If you have trouble with the carburetor, see your dealer. Improper adjustment may cause engine damage and void warranty.
SPARK PLUG
Check the Spark Plug aer every 10-15 hours of use.
Remove the Spark Plug cap Using the Spark Plug Spanner supplied, remove the Spark Plug by turning it an-clockwise. Clean & adjust the electrode gap to 0.6-0.7mm If the Spark Plug is visibly da
maged or worn, replace immediately (See Specificaon for details)
Install the new/cleaned Spark Plug to finger ghtness, before fully ghtening with the spanner.
CLEANING
Keep your machine clean. Thoroughly clean the machine at the end of each use, paying parcular aenon to cungs in and around the guard and cung tool.
AIR FILTER
Accumulated dust in the air filter will reduce engine efficiency, increase fuel consumpon and allow abrasive parcles to pass in the engine. Remove & clean the air fil
ter regularly to ensure opmum performance.
Remove the air filter cover, by releasing the securing winged screw from the front of the cover. Li off the cover. Remove the sponge air filter from the housing. Tap the filter to remove light surface dust. Heavy deposits should be washed out of the Air Filter in soapy water. Allow the filter to dry completely.
FUEL FILTER
The fuel tank is fied with a filter. It is situated at the free end of fuel pipe and can be picked out through the fuel fi
ller
neck, with a piece of hooked wire or similar.
Check the fuel filter periodically. Do not allow dust to enter into the fuel tank. A clogged filter will cause difficulty in
starng the engine or abnormalies in engine performance.
When the filter is dirty, replace the filter. When the inside of the fuel tank is dirty, it can be cleaned by rinsing the tank out with petrol.
SUCTION & BLOWER TUBES
It is advisable to remove the Sucon & Blower tubes from the machine regularly for cleaning. Use Soapy
water to remove any dirt or grime.
ENGINE STARTING & STOPPING PROCEDURE
STARTING A COLD ENGINE
1. Place the machine onto a flat, firm surface.
2. Keep the machine clear of any surrounding objects
3. Move the stop switch to "START" posion
4. Give a gentle push on the primer pump repeatedly (7-10 mes) unl fuel comes into the primer pump.
5. Pull the Choke Lever up to close the choke
6. Whilst holding the machine down with your le hand, away from the engine and pull the engine recoil starter rope vigorously, unl the engine false starts.
(DO NOT LET THE RECOIL STARTER ROPE
RETRACT BY ITSELF, FEED THE ROPE BACK INTO THE HOUSING)
7. Push the choke lever downwards (excessive cranking with choke lever up will cause the engine to flood, making it difficult to start.)
8. Pull starter handle unl engine starts.
9. Allow engine to warm up for a few minutes before using.
STARTING A WARM ENGINE
1. Move the switch to "START" posion
2. If the fuel tank was run dry on previous operaon, follow steps 3-7 of cold start procedure.
3. Whilst holding the machine down with your le hand, away from the engine and pull the engine r
ecoil starter rope
vigorously, unl the engine false starts.
STOPPING THE ENGINE
1. Move the stop switch to the “STOP” posion
Choke Closed
Cold Start
Posion
Choke Open
Warm Start or
Run Posion
CHOKE LEVER
INSTRUCTION MANUAL
MAINTENANCE, CLEANING & STORAGE
WARNING Improper maintenance & storage of the machine may void your warranty. Keep the machine clean for beer and safer performance.
MAINTENANCE
Before each use, check all nuts & bolts to be sure they are sufficiently ghtened. We recommend only manufacturer original parts are used when maintaining this machine. Failure to do so could
invalidate your manufacturer’s warranty.
The engine must be switched off, with the spark plug cap removed, before the machine is unasse
mbled, cleaned,
serviced or maintained.
ADJUSTING CARBURETOR
Do not adjust carburetor unless necessary. If you have trouble with the carburetor, see your dealer. Improper adjustment may cause engine damage and void warranty.
SPARK PLUG
Check the Spark Plug aer every 10-15 hours of use.
Remove the Spark Plug cap Using the Spark Plug Spanner supplied, remove the Spark Plug by turning it an-clockwise. Clean & adjust the electrode gap to 0.6-0.7mm If the Spark Plug is visibly da
maged or worn, replace immediately (See Specificaon for details)
Install the new/cleaned Spark Plug to finger ghtness, before fully ghtening with the spanner.
CLEANING
Keep your machine clean. Thoroughly clean the machine at the end of each use, paying parcular aenon to cungs in and around the guard and cung tool.
AIR FILTER
Accumulated dust in the air filter will reduce engine efficiency, increase fuel consumpon and allow abrasive parcles to pass in the engine. Remove & clean the air fil
ter regularly to ensure opmum performance.
Remove the air filter cover, by releasing the securing winged screw from the front of the cover. Li off the cover. Remove the sponge air filter from the housing. Tap the filter to remove light surface dust. Heavy deposits should be washed out of the Air Filter in soapy water. Allow the filter to dry completely.
FUEL FILTER
The fuel tank is fied with a filter. It is situated at the free end of fuel pipe and can be picked out through the fuel fi
ller
neck, with a piece of hooked wire or similar.
Check the fuel filter periodically. Do not allow dust to enter into the fuel tank. A clogged filter will cause difficulty in
starng the engine or abnormalies in engine performance.
When the filter is dirty, replace the filter. When the inside of the fuel tank is dirty, it can be cleaned by rinsing the tank out with petrol.
SUCTION & BLOWER TUBES
It is advisable to remove the Sucon & Blower tubes from the machine regularly for cleaning. Use Soapy
water to remove any dirt or grime.
STORAGE
For years of trouble free service, make sure the machine is clean and dry before storing. Before storing, clean the machine thoroughly as indicated above. Store indoors or in a safe, locked protected area during severe weather and winter months. DO NOT STORE in an enclosed area, where fuel vapors can reach an open hot flame. DO NOT STORE fuel in the machine. Ensure fuel is removed from the fuel tank and carburetor. If storing for an extended period, inspect, clean and repair the machine if necessary. Remove all fuel from the fuel tank.
Start the engine, this will remove all fuel from the carburetor and fuel lines. Remove the spark plug, pour a small quanty of 2-stroke oil into the spark plug hole of the cylinder and re-seat spark plug. Store in a clean, dry, dust free area.
DO NOT STORE fuel for longer than 30 days. Fuel can become stale and cause damage to the engine carburetor, which is
not covered by the machines manufacturer’s warranty.
TROUBLE SHOOTING
Failures such as a difficulty in starng the engine, irregularity in funcons and abnormality in performance can normally be prevented if careful aenon is paid to all operang instrucons and maintenance procedures. Should the engine not funcon properly, check the following?
That the fuel system is in good condion and fuel is flowing to the engine. The ignion system is in good condion and the spark plug, sparks correctly. Compression of the engine is adequate.
FAILURE TO START
Correctly follow the starng procedure, not seng the choke lever or priming the engine can cause the engine to not
start.
Dispose of fuel from the tank, parcularly if over 30 days old. Ensure that fuel is fresh and clean. Check fuel filter to ensure it is clean. (Replace filter if necessary). Make sure air filter elements are clean. Install a new, properly gapped spark plug. When there is serious trouble with the unit, do not try to repair it yourself, but have your local approved service dealer
inspect it for you.
INSTRUCTION MANUAL
PARTS LIST - WEBV26 Engine
Item No Webb Part No. Handy Descripon Qty
Item No Webb Part No. Handy Descripon Qty
1 WE03130010013 Spark Plug RCJ6Y 1
24 WE02050030018 Flywheel 1
2 WE03010010061 Bolt M5X20 4
25 WE02070010078 Insulator Gasket 1
3 WE70070130011 Cylinder 1
26 WE02110030031 Insulator 1
4 WE02070010020 Cylinder Gasket 1
27 WE03020020012 Bolt M5X20 2
5 WE02020020003 Piston Ring 2
28 WE02070010061 Carburretor Gasket 1
6 WE02010020006 Piston 1
29 WE02050020045 Carburetor 1
7 WE02020010004 Piston Pin 8X28 1
30 WE70030040038 Choke Lever 1
8 WE02020030017 Snap Ring 2
31 WE70080120007 Air filter Housing 1
9 WE03090020018 Needle Bearing 1
32 WE70030040028 Choke 1
10 WE02020150007 Thrust Washer 2
33 WE03010040008 Bolt ST4×10 1
11 WE02020120026 Cranksha Assembly 1
34 WE02090010011 Air filter Housing 1
12 WE03090010028 Bearing 6001/P5 2
35 WE03020020030 Bolt M5X60 2
13 WE03060010002 Pin B3X10 2
36 WE70030040078 Air Filter Cover 1
14 WE02070010110 Crankcase Gasket 1
37 WE70030180012 Air Filter Screw 1
15 WE03050010014 Rear Crankcase 1
38 WE02070010141 Exhaust Gasket 1
16 WE03100010009 Oil Seal 12X22X7 2
39 WE02050010018 Exhaust 1
17 WE03120030003 Stop Ring 2
40 WE03040020019 Washer 5 2
18 WE02050100015 Starter Pawl 1
41 WE03050010014 Washer 5 3
19 WE02020110088 Starter Pawl Spring 2
42 WE03010010049 Screw M5X50 2
20 WE70030140015 Starter Pawl 2
43 WE03040010007 Washer 4 2
21 WE03070010002 Woodruff Key 1
44 WE02070010048 Spacer 2
22 WE70070050001 Crankcase - Front 1
45 WE02050050141 Stop Wire 1
23 WE03010010045 Bolt M5X30 3
46 WE02050030024 Ignion Coil 1
47 WE03020020013 Screw M4X20 2
PARTS DIAGRAM - WEBV26 Engine
PARTS LIST - WEBV26 Engine
Item No Webb Part No. Handy Descripon Qty
Item No Webb Part No. Handy Descripon Qty
1 WE03130010013 Spark Plug RCJ6Y 1
24 WE02050030018 Flywheel 1
2 WE03010010061 Bolt M5X20 4
25 WE02070010078 Insulator Gasket 1
3 WE70070130011 Cylinder 1
26 WE02110030031 Insulator 1
4 WE02070010020 Cylinder Gasket 1
27 WE03020020012 Bolt M5X20 2
5 WE02020020003 Piston Ring 2
28 WE02070010061 Carburretor Gasket 1
6 WE02010020006 Piston 1
29 WE02050020045 Carburetor 1
7 WE02020010004 Piston Pin 8X28 1
30 WE70030040038 Choke Lever 1
8 WE02020030017 Snap Ring 2
31 WE70080120007 Air filter Housing 1
9 WE03090020018 Needle Bearing 1
32 WE70030040028 Choke 1
10 WE02020150007 Thrust Washer 2
33 WE03010040008 Bolt ST4×10 1
11 WE02020120026 Cranksha Assembly 1
34 WE02090010011 Air filter Housing 1
12 WE03090010028 Bearing 6001/P5 2
35 WE03020020030 Bolt M5X60 2
13 WE03060010002 Pin B3X10 2
36 WE70030040078 Air Filter Cover 1
14 WE02070010110 Crankcase Gasket 1
37 WE70030180012 Air Filter Screw 1
15 WE03050010014 Rear Crankcase 1
38 WE02070010141 Exhaust Gasket 1
16 WE03100010009 Oil Seal 12X22X7 2
39 WE02050010018 Exhaust 1
17 WE03120030003 Stop Ring 2
40 WE03040020019 Washer 5 2
18 WE02050100015 Starter Pawl 1
41 WE03050010014 Washer 5 3
19 WE02020110088 Starter Pawl Spring 2
42 WE03010010049 Screw M5X50 2
20 WE70030140015 Starter Pawl 2
43 WE03040010007 Washer 4 2
21 WE03070010002 Woodruff Key 1
44 WE02070010048 Spacer 2
22 WE70070050001 Crankcase - Front 1
45 WE02050050141 Stop Wire 1
23 WE03010010045 Bolt M5X30 3
46 WE02050030024 Ignion Coil 1
47 WE03020020013 Screw M4X20 2
PARTS LIST - WEBV26 Machine
Item No Part No. Descripon Qty
Item No Part No. Descripon Qty
1 WE70050010068 Tube A 1
32 WE03010040017 Screw ST4.2×10 1
2 WE70050010069 Tube B 1
33 WE02050050171 Stop Wire 1
3 WE03010060056 Screw M5×16 3
34 WE51010040002 Engine 1
4 WE03040020020 Washer 5 11
35 WE03040050022 Washer 1
5 WE70030030284 Connect Cover 1
36 WE02060020003 Recoil Pulley 1
6 WE03010060078 Screw M5×10 6
37 WE02060020009 Recoil Spring 1
7 WE70030180100 Safety Cover 1
38 WE'70080100004 Housing 1
8 WE02050050002 Safety Switch 1
39 WE03020020041 Screw M5×30 3
9 WE70030070032 Buon Connector 1
40 WE01050010009 Recoil Rope 1
10 WE03040050017 Washer 6 1
41 WE70030140010 Recoil Handle 1
11 WE70030180012 Fan Cover Screw 1
42 WE70050010070 Curved tube 1
12 WE70030030303 Dan Cover 1
43 WE02050040087 Throle Wire 1
13 WE02020160312 Spring sha 1
44 WE02050060050 Collecon Bag 1
14 WE02020110048 Spring 1
45 WE02050060022 Harness 1
15 WE70030010071 Rear Case 1
46 WE01040010003 Return Fuel Pipe(L=70) 1
16 WE03030020002 Nut M8×1 1
47 WE02080030025 Fuel Pipe Rubber Bung 1
17 WE02020070042 Shaer Tooth 1
48 WE01040010014 Inlet Fuel Pipe(L=220) 1
18 WE70030090006 Impellor 1
49 WE02050120002 Fuel Filter 1
19 WE03010010045 Screw M5×30 4
50 WE02110020026 Fuel Cap Assembly 1
20 WE02080020046 Le Handle Rubber Cover 1
51 WE03050010007 Washer 8 1
21 WE70030010055 Front Case 1
52 WE03040050005 Washer 23*8*1 1
22 WE02020160117 Pedestal 4
53 WE70050010066 Tube C 1
23 WE70050030063 Fuel Tank 1
54 WE70050010067 Tube D 1
24 WE'03010040057 Screw M5*20 4
55 WE02050070048 Recoil Rope Guide 1
25 WE70030160093 Lower Handle 1
56 WE02040030020 Bush 1
26 WE02020160398 Throle Lever Sha 1
57 WE02080030015 Wire Lead 1
27 WE70030070109 Throle Lever Handle 1
58 WE03110020023 “O” Sealing Washer 25x2 1
28 WE02050050111 Stop Switch 1
59 WE03010060076 Screw M5×30 2
29 WE02050050171 Short Stop Wire 2
60 WE03020020018 Screw M5×10 1
30 WE70030160048 Upper Handl;e 1
61 WE03050010015 Washer 5 4
31 WE02080020046 Right Handle Rubber Cover 1
62 WE'03010040048 Screw NST5x16 11
PARTS DIAGRAM - WEBV26 Machine
PARTS LIST - WEBV26 Machine
Item No Part No. Descripon Qty
Item No Part No. Descripon Qty
1 WE70050010068 Tube A 1
32 WE03010040017 Screw ST4.2×10 1
2 WE70050010069 Tube B 1
33 WE02050050171 Stop Wire 1
3 WE03010060056 Screw M5×16 3
34 WE51010040002 Engine 1
4 WE03040020020 Washer 5 11
35 WE03040050022 Washer 1
5 WE70030030284 Connect Cover 1
36 WE02060020003 Recoil Pulley 1
6 WE03010060078 Screw M5×10 6
37 WE02060020009 Recoil Spring 1
7 WE70030180100 Safety Cover 1
38 WE'70080100004 Housing 1
8 WE02050050002 Safety Switch 1
39 WE03020020041 Screw M5×30 3
9 WE70030070032 Buon Connector 1
40 WE01050010009 Recoil Rope 1
10 WE03040050017 Washer 6 1
41 WE70030140010 Recoil Handle 1
11 WE70030180012 Fan Cover Screw 1
42 WE70050010070 Curved tube 1
12 WE70030030303 Dan Cover 1
43 WE02050040087 Throle Wire 1
13 WE02020160312 Spring sha 1
44 WE02050060050 Collecon Bag 1
14 WE02020110048 Spring 1
45 WE02050060022 Harness 1
15 WE70030010071 Rear Case 1
46 WE01040010003 Return Fuel Pipe(L=70) 1
16 WE03030020002 Nut M8×1 1
47 WE02080030025 Fuel Pipe Rubber Bung 1
17 WE02020070042 Shaer Tooth 1
48 WE01040010014 Inlet Fuel Pipe(L=220) 1
18 WE70030090006 Impellor 1
49 WE02050120002 Fuel Filter 1
19 WE03010010045 Screw M5×30 4
50 WE02110020026 Fuel Cap Assembly 1
20 WE02080020046 Le Handle Rubber Cover 1
51 WE03050010007 Washer 8 1
21 WE70030010055 Front Case 1
52 WE03040050005 Washer 23*8*1 1
22 WE02020160117 Pedestal 4
53 WE70050010066 Tube C 1
23 WE70050030063 Fuel Tank 1
54 WE70050010067 Tube D 1
24 WE'03010040057 Screw M5*20 4
55 WE02050070048 Recoil Rope Guide 1
25 WE70030160093 Lower Handle 1
56 WE02040030020 Bush 1
26 WE02020160398 Throle Lever Sha 1
57 WE02080030015 Wire Lead 1
27 WE70030070109 Throle Lever Handle 1
58 WE03110020023 “O” Sealing Washer 25x2 1
28 WE02050050111 Stop Switch 1
59 WE03010060076 Screw M5×30 2
29 WE02050050171 Short Stop Wire 2
60 WE03020020018 Screw M5×10 1
30 WE70030160048 Upper Handl;e 1
61 WE03050010015 Washer 5 4
31 WE02080020046 Right Handle Rubber Cover 1
62 WE'03010040048 Screw NST5x16 11
EC DECLARATION OF CONFORMITY
We Handy Distribuon Ltd - SN3 5HY (Importer) declare that the product:
Designaon: Petrol Blower & Vacuum Model(s): WEBV26 Type/Serial No. As per rang label on machine
Complies with the following direcves:
Machinery Direcve as last amended by EC Direcve 2006/42/EC
The conformity assessment procedure followed was in accordance with
EN ISO 12100-2/A1:2009 EN 15503:2009
Blower Measured Sound Pressure Level: L
PA = 95.7dB(A)
Measured Sound Power Level: L
WA = 112dB(A)
Vacuum Mea
sured Sound Pressure Level: LPA = 94.7dB(A)
Measured Sound Power Level: L
WA = 111dB(A)
Nofied Body:
TÜV SÜD Product Service GmbH
Addresses:
- 10 Huaxia Road(m), Dongng, Wuxi, Jiangsu, 214100 (P.R China)
- Zerfizierselle, Ridlerstraße 65, 80339 München, Germany
Authorised signatory and technical file holder Date: 10/11/2015
Signature: Name: Mr Simon Belcher Posion: Managing Director Company: Handy Distribuon Ltd
Address: Murdock Rd, Swindon, Wiltshire, SN3 5HY.
INSTRUCTION MANUAL
This Service Book is provided with your Webb, to help you look after your purchase to our recommendations and enable you
to take advantage of the 2 year conditional manufacturer domestic warranty*.
* Commercial/Professional & Hire users receive a 90 day warranty
Present this service book to your authorised Webb repair dealer, whenever a service or a warranty appraisal is required.
The booklet is applicable to the following products, in the UK only:
Ride On Lawn Tractors
Petrol & Electric Cylinder Lawnmowers
Petrol Rotary Lawnmowers
Petrol Hand Held Range
Please register your machine using the following pages or at www.webblawnmowers.co.uk. By registering your machine, you
agree to maintain the machine in accordance with the service schedules specied in this manual and services duly recorded.
You may be asked to produce this booklet as proof of servicing in the event of a claim. Proof of purchase should also be kept
as a reference.
Ensure you have the following information available from your machine product label. The two examples below can be found
on your machine:
1
3
4
2
1. Model Number
2. Serial & Product Number
Please complete using BLOCK CAPITALS.
Sections marked* must be completed to validate Warranty.
Cylinder Mowers Only
3. Serial Number
4. Model Number
INSTRUCTION MANUAL
1. Users Statement of Warranty
Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser, is not transferable and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
2. Period of Warranty
2 year conditional warranty from the original date of sale to the rst domestic user.
90 days from the original date of sale to the professional/commercial or for hire user. Engine warranty as per the engine manufacturer’s warranty, which will be supplied with the machine. 90 days from the original date of sale for Replacement Spare Parts
All machines’ must be serviced within the rst 14 months from the original date of purchase, to qualify for a second year
parts & labour warranty, details of the service must be recorded in the service record within this manual. A reduced warranty period of 90 days applies to those items which are subject to normal wear and tear and in normal use, will need replacement or adjustment. These items are chargeable after 90 days of ownership.
Filters
Tyres / Wheels
Drive chains and belts
Brake & clutch friction components
Control cable & starter cords
Fluids & lubricants
Spark plugs
Blades (Lawnmowers & Brushcutters)
Cutter bars (Hedgecutters)
Drive & clutch cable surfaces
Nylon Lines (Line Trimmers)
Carburettor cleaning
Bearings
Bushes
Electric cable
Grass collectors
3. Not covered by this warranty
(a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident. (b) The warranty policy does not cover any costs necessary for the standard periodic maintenance services instructed by the operators manual, or service parts replacement which would include oil, lters, tyres, belts, brake linings, fuses, blades, seals and other service parts unless it can be proven that the item has evidence of faulty manufacture.
(c) The warranty policy will not cover failure or damage caused as a result of parts or accessories being modied without the
written approval of GJ Handy & Co Ltd. (d) The warranty policy will not cover the unit if non-genuine parts have been tted and as a result damage has occurred to the unit. (e) The warranty policy is non-transferable and is only applicable to the original purchaser.
4. Disclaimer
(a) This warranty is only a remedy for defect of products. GJ Handy & Co Ltd will never warranty in terms of the
merchantability or the tness for a particular purpose.
(b) No person is authorised to make any warranties, representations or promises, expressed or implied, on behalf of GJ Handy & Co Ltd, or to modify the terms conditions or limitation of this warranty policy in any way.
(c) Neither GJ Handy & Co Ltd nor any company afliated with GJ Handy & Co Ltd shall be liable in any event or manner whatsoever for incidental or consequential damages or injuries, including, but not limited to, loss of crops, loss of prot, out of pocket expenses or prots, rental of substitute equipment or other commercial losses.
SERVICE BOOK
5. General
(a) Most warrantable failures show up within the rst few weeks of use. These failures are usually straightforward and
warranty assessment is relatively easy. (b) Failures relating to cutter decks and belts need careful investigation, as the cause may not always be straightforward. Look for damage to blades and pulleys especially when the cutter belt or blade boss have snapped or cracked as this could be due to impact damage.
(c) Customers should always refer to the operator/instruction manual when any disputed problem arises, you will nd most
areas covered within the manual.
Protecting your machine
Maintenance
Regular maintenance of your Webb machine is essential to ensure it operates, safely, efciently and therefore reducing the
environmental impact.
It is the owner’s responsibility to ensure that their Webb machine is maintained at specic intervals. Any approved Webb
service dealer can undertake a service, which are specialised in our products and will be aware of your particular machine and any technical updates which will save valuable time & money. If you are using your machine in dry, dusty or high temperatures, you will need to service the machine more regularly.
Fuel
Due to ongoing efforts by fuel companies to reduce emissions, unleaded petrol will oxidize & deteriorate in storage overtime, leaving residue from detergent components. Fuel deterioration problems may occur when petrol is stored for over 30 days. If you are planning to store fuel for over 30 days, we recommend you add Handy Parts Sure-Start fuel stabilizer to fresh fuel after purchasing. Sure-Start cannot reconstitute stale fuel.
Storage
When storing your machine for an extended period, we do recommend that you follow the instructions of engine instruction manual. Always store the fuel in a clean, approved and sealed container. If the container is steel, ensure it is not corroded.
If the container is not lled to its recommended capacity, air can accelerate fuel deterioration.
Always store fuel away from direct sunlight, in a dark, cool environment.
INSTRUCTION MANUAL
Your servicing Webb approved dealer will stamp & date the below relevant sections, when the correct service actions have
been completed.
PLEASE ENSURE THE SERVICE BOOK IS AVAILABLE FOR THE DEALER, DURING SERVICE WORK.
1st Service
This must be stamped by an approved service dealer to
qualify for a free second year warranty.
24 Months
Date Date
36 Months
12 Months
Date
SERVICE BOOK
48 Months
Date
Date
Date
Date
Date
Date
Date
Date
72 Months
96 Months
120 Months
60 Months
84 Months
108 Months
132 Months
INSTRUCTION MANUAL
*House Number *House Name
*Address 1
*Address 2
*Town
*County
*Postcode
Home Tel Mobile Tel
Email
If you have registered online, this form is not necessary.
PLEASE POST THIS COPY TO THE ADDRESS OVERLEAF
*Title *Forename *Surname
Age 18 to 25 26 to 35 36 to 45 46 to 60 61 to 80 81 & over
*Usage Domestic Use Commercial/Professional/Hire Use
Personal Information (* Compulsory)
*Model No:
*Product No:
*Serial No:
*Date of Purchase:
Product Information (* Compulsory)
Webb Lawnmowers privacy commitment to machine owners: Thank you for completing this form. The information supplied, helps us to improve the products & services we provide, including information that we believe is relevant to your and/or your machine. We value your trust by giving us this information about yourself and we are committed to protecting your privacy. From time to time Webb, its associated companies, authorised dealers or third parties working on our behalf may wish to contact you regarding our products, services, offers, technical improvements or just opinions, which may be used for marketing, research or analysis purposes. If you DO NOT wish to be contacted by either of the following methods, please tick the relevant box POST TELEPHONE If you would like us to contact you be Email, please tick this box You may give Webb Lawnmowers notice in writing at any time that you no longer wish to receive direct marketing communications
*Dealer Stamp (Complete Address)
*Dealer Name
*Dealer Address
*Date of Purchase
*Selling Retailer (If dealer stamp not available)
WARRANTY REGISTRATION
Webb Lawnmowers
Murdock Road
Dorcan
Swindon
Wiltshire
SN3 5HY
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
