Wayjun LEDA3914AUR11, LEDA3914AUR11C, LEDA3914TB11, LEDA3914TB11C, LEDA3914TW11 Schematics
...
Segment Digit LED Display
User's Manual
Segment Digit LED Display
Warranty
All products manufactured by WAYJUN TECHNOLOGY are under warranty regarding defective materials for a
period of two years from the date of delivery to the original purchaser.
Copyright
copyright 2009, by ShenZhen Wayjun Technology Co.,Ltd. All rights are reserved. ShenZhen Wayjun Technology
Co.,Ltd reserves the right to make improvements to the products described in this manual at any time without notice.
Trademark
The names used for identification only may be registered trademarks of their respective companies.
Edition: V1.4
Date:July 2011
ShenZhen Wayjun Technology Co.,Ltd - 2 - www.wayjun.com
Segment Digit LED Display
Catalog
1. 7 Segment Single Digit LED Display...................................................................................................................4
1.1 Common Anode 0.36 Inch (9.14mm)................................................................................................................4
1.2 Common Cathode 0.36 Inch (9.14mm).............................................................................................................6
1.3 Common Anode 0.56 Inch (14.20mm)..............................................................................................................8
1.4 Common Cathode 0.56 Inch (14.20mm).........................................................................................................10
1.5 Common Anode 0.8 Inch (20.40mm)..............................................................................................................12
1.6 Common Cathode 0.8 Inch (20.40mm)...........................................................................................................14
1.7 Common Anode 1.0 Inch (25.40mm)..............................................................................................................16
1.8 Common Anode 1.5 Inch (38.10mm)..............................................................................................................18
1.9 Common Anode 2.3 Inch (57.0mm)................................................................................................................20
1.10 Common Anode 4.0 Inch (100.0mm)............................................................................................................22
2. 7 Segment Double Digit LED Display ...............................................................................................................24
2.1 Common Anode 0.36 Inch (9.14mm)..............................................................................................................24
2.2 Common Anode 0.56 Inch (14.20mm)............................................................................................................26
2.3 Common Cathode 0.56 Inch (14.20mm).........................................................................................................28
2.4 Common Anode 1.0 Inch (25.40mm)..............................................................................................................30
3. 7 Segment Three Digit LED Display..................................................................................................................32
3.1 Common Anode 0.36 Inch (9.14mm)...........................................................................................................32
3.2 Common Cathode 0.36 Inch (9.14mm)........................................................................................................34
4. 7 Segment Four Digit LED Display....................................................................................................................36
4.1 Common Anode 0.36 Inch (9.14mm)...........................................................................................................36
4.2 Common Anode 0.56 Inch (14.20mm)............................................................................................................38
5. Alpha Numeric Single Digit LED Display.........................................................................................................40
5.1 Common Anode 0.39 Inch (9.9mm).............................................................................................................40
5.2 Common Cathode 0.39 Inch (9.9mm)..........................................................................................................42
5.3 Common Anode 0.50 Inch (12.7mm)...........................................................................................................44
5.4 Common Cathode 0.50 Inch (12.7mm)........................................................................................................46
5.5 Common Anode 0.80 Inch (20.32mm).........................................................................................................48
5.6 Common Cathode 0.80 Inch (20.32mm)......................................................................................................50
ShenZhen Wayjun Technology Co.,Ltd - 3 - www.wayjun.com
Segment Digit LED Display
1. 7 Segment Single Digit LED Display
1.1 Common Anode 0.36 Inch (9.14mm)
PRODUCT DESCRIPTION
(1) 0.36 Inch (9.14mm) Digit Height
(2) Low current operation
(3) Excellent color and font characteristics
(4) Colors: White, blue, red, yellow and green
(5) Gray or black color background
(6) Common Anode
(7) RoHs Compliant Part
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85 ℃
Storage Temperature -30 to +85 ℃
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER
(1)
70 50 50 25 25 mA
DICE
MATERIAL
(COLOR)
PEAK
WAVELENGTH
(nm)
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
0.3 mA/℃
LUMINOUS
INTENSITY /
VF
(V)
TYP
VF (V)
MAX.
SEGMENT
AVERAGE (IF =
10mA)
LEDS3632AUR11 AlGaAs Red 660 10 1.8 2.3 8,000 ucd
LEDS3632TB11 InGaN Blue 468 10 3.3 4.0 20,000 ucd
LEDS3632YG11 GaP Green 568 10 1.9 2.3 8,000 ucd
LEDS3632UY11
LEDS3612TW11 InGaN White 5,500K 10 3.3 4.0 20,000 ucd
AlInGaP
Amber
590 10 1.8 2.3 12,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 4 - www.wayjun.com
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 Common Anode DIG. 1 6 Common Anode DIG. 2
2 Cathode F 7 Cathode DP
3 Cathode G 8 Cathode C
4 Cathode E 9 Cathode B
5 Cathode D 10 Cathode A
ShenZhen Wayjun Technology Co.,Ltd - 5 - www.wayjun.com
Segment Digit LED Display
1.2 Common Cathode 0.36 Inch (9.14mm)
PRODUCT DESCRIPTION
(1) 0.36 Inch (9.14mm) Digit Height
(2) Low current operation
(3) Excellent color and font characteristics
(4) Colors: White, blue, red, yellow and green
(5) Gray or black color background
(6) Common Cathode
(7) RoHs Compliant Part
Absolute Maximum Rating (Ta = 25 ) ℃
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85 ℃
Storage Temperature -30 to +85 ℃
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER
LEDS3632AUR1C AlGaAs Red 660 10 1.8 2.3 8,000 ucd
(1)
70 50 50 25 25 mA
DICE
MATERIAL
(COLOR)
PEAK
WAVELENGTH
(nm)
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
0.3 mA/℃
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
LEDS3632TB1C InGaN Blue 468 10 3.3 4.0 20,000 ucd
LEDS3632YG1C GaP Green 568 10 1.9 2.3 8,000 ucd
LEDS3632UY1C AlInGaP
Amber
LEDS3612TW1C InGaN White 5,500K 10 3.3 4.0 20,000 ucd
590 10 1.8 2.3 12,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 6 - www.wayjun.com
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 Common Cathode DIG. 1 6 Common Cathode DIG. 6
2 Anode F 7 Anode DP
3 Anode G 8 Anode C
4 Anode E 9 Anode B
5 Anode D 10 Anode A
ShenZhen Wayjun Technology Co.,Ltd - 7 - www.wayjun.com
Segment Digit LED Display
1.3 Common Anode 0.56 Inch (14.20mm)
PRODUCT DESCRIPTION
(1) 0.56 Inch (14.20mm) Digit Height
(2) Low current operation
(3) Excellent color and font characteristics
(4) Colors: White, blue, red, yellow and green
(5) Gray or black color background
(6) Common Anode
(7) RoHs Compliant Part
Absolute Maximum Rating (Ta = 25 ) ℃
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85 ℃
Storage Temperature -30 to +85 ℃
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25 ) ℃
PART NUMBER DICE
MATERIAL
(COLOR)
LEDS5612AUR11 AlGaAs Red 660 10 1.8 2.3 10,000 ucd
(1)
70 50 50 25 25 mA
0.3 mA/℃
PEAK
WAVELENGTH
(nm)
MAX. REVERSE
CURRENT /
SEGMENT (uA)
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
LEDS5612TB11 InGaN Blue 468 10 3.3 4.0 28,000 ucd
LEDS5612YG11 GaP Green 568 10 1.9 2.3 12,000 ucd
LEDS5612UY11 AlInGaP
Amber
LEDS5612TW11 InGaN White 5,500K 10 3.3 4.0 28,000 ucd
590 10 1.8 2.3 12,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 8 - www.wayjun.com
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Cathode E 6 Cathode B
2 Cathode D 7 Cathode A
3 Common Anode DIG. 1 8 Comm on Anode DIG. 2
4 Cathode C 9 Cathode F
5 Cathode DP 10 Cathode G
ShenZhen Wayjun Technology Co.,Ltd - 9 - www.wayjun.com
Segment Digit LED Display
1.4 Common Cathode 0.56 Inch (14.20mm)
PRODUCT DESCRIPTION
(1) 0.56 Inch (14.20mm) Digit Height
(2) Low current operation
(3) Excellent color and font characteristics
(4) Colors: White, blue, red, yellow and green
(5) Gray or black color background
(6) Common Cathode
(7) RoHs Compliant Part
Absolute Maximum Rating (Ta = 25 ) ℃
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85 ℃
Storage Temperature -30 to +85 ℃
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25 ) ℃
PART NUMBER DICE
LEDS5612AUR1C AlGaAs Red 660 10 1.8 2.3 10,000 ucd
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
PEAK
WAVELENGTH
(nm)
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
0.3 mA/℃
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
LEDS5612TB1C InGaN Blue 468 10 3.3 4.0 28,000 ucd
LEDS5612YG1C GaP Green 568 10 1.9 2.3 12,000 ucd
LEDS5612UY1C AlInGaP
Amber
LEDS5612TW1C InGaN White 5,500K 10 3.3 4.0 28,000 ucd
590 10 1.8 2.3 12,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 10 - www.wayjun.com
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Anode E 6 Anode B
2 Anode D 7 Anode A
3 Common Cathode DIG. 1 8 Common Cathode DIG. 2
4 Anode C 9 Anode F
5 Anode DP 10 Anode G
ShenZhen Wayjun Technology Co.,Ltd - 11 - www.wayjun.com
Segment Digit LED Display
1.5 Common Anode 0.8 Inch (20.40mm)
PRODUCT DESCRIPTION
(1) 0.8 Inch (20.40mm) Digit Height (5) Gray or black color background
(2) Low current operation (6) Common Anode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25 ) ℃
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85 ℃
Storage Temperature -30 to +85 ℃
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25 ) ℃
PART NUMBER DICE
MATERIAL
(COLOR)
LEDS8012AUR11 AlGaAs Red 660 10 1.8 2.3 10,000 ucd
(1)
70 50 50 25 25 mA
0.3 mA/℃
PEAK
WAVELENGTH
(nm)
MAX. REVERSE
CURRENT /
SEGMENT (uA)
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
LEDS8012TB11 InGaN Blue 468 10 3.3 4.0 28,000 ucd
LEDS8012YG11 GaP Green 568 10 1.9 2.3 12,000 ucd
LEDS8012UY11 AlInGaP
Amber
LEDS8012TW11 InGaN White 5,500K 10 3.3 4.0 28,000 ucd
590 10 1.8 2.3 12,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 12 - www.wayjun.com
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Cathode E 6 Cathode B
2 Cathode D 7 Cathode A
3 Common Anode DIG. 1 8 Common Anode DIG. 2
4 Cathode C 9 Cathode F
5 Cathode DP 10 Cathode G
ShenZhen Wayjun Technology Co.,Ltd - 13 - www.wayjun.com
Segment Digit LED Display
1.6 Common Cathode 0.8 Inch (20.40mm)
PRODUCT DESCRIPTION
(1) 0.8 Inch (20.40mm) Digit Height (5) Gray or black color background
(2) Low current operation (6) Common Cathode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25 ) ℃
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85 ℃
Storage Temperature -30 to +85 ℃
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25 ) ℃
PART NUMBER DICE
LEDS8012AUR1C AlGaAs Red 660 10 1.8 2.3 10,000 ucd
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
PEAK
WAVELENGTH
(nm)
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
0.3 mA/℃
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
LEDS8012TB1C InGaN Blue 468 10 3.3 4.0 28,000 ucd
LEDS8012YG1C GaP Green 568 10 1.9 2.3 12,000 ucd
LEDS8012UY1C AlInGaP
Amber
LEDS8012TW1C InGaN White 5,500K 10 3.3 4.0 28,000 ucd
590 10 1.8 2.3 12,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 14 - www.wayjun.com
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Anode E 6 Anode B
2 Anode D 7 Anode A
3 Common Cathode DIG. 1 8 Common Cathode DIG. 2
4 Anode C 9 Anode F
5 Anode DP 10 Anode G
ShenZhen Wayjun Technology Co.,Ltd - 15 - www.wayjun.com
Segment Digit LED Display
1.7 Common Anode 1.0 Inch (25.40mm)
PRODUCT DESCRIPTION
(1) 1.0 Inch (25.40mm) Digit Height
(2) Low current operation
(3) Excellent color and font characteristics
(4) Colors: White, blue, red, yellow and green
(5) Gray or black color background
(6) Common Anode
(7) RoHs Compliant Part
Absolute Maximum Rating (Ta = 25 ) ℃
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85 ℃
Storage Temperature -30 to +85 ℃
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25 ) ℃
PART NUMBER DICE
LEDS10012TUR11 AlInGaP Red 630 10 3.6
LEDS10012TB11 InGaN Blue 468 10 6.0
LEDS10012YG11 AlInGaP
LEDS10012UY11 AlInGaP
LEDS10012TW11 InGaN White 5,500K 10 6.0
(1) Cathode DP Vf = 1.8V ONLY uses one led chip for red, yellow and green color.
(2) Cathode DP Vf = 3.3V ONLY uses one led chip for blue and white color.
ShenZhen Wayjun Technology Co.,Ltd - 16 - www.wayjun.com
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
Green
Amber
0.3 mA/℃
PEAK
WAVELENGTH
(nm)
568 10 3.6
590 10 3.6
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
VF
(V)
TYP
(1)
(2)
(1)
(1)
(2)
VF (V)
MAX.
4.2 20,000 ucd
7.0 45,000 ucd
4.2 20,000 ucd
4.2 25,000 ucd
7.0 45,000 ucd
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Cathode E 6 Cathode B
2 Cathode D 7 Cathode A
3 Common Anode DIG. 1 8 Common Anode DIG. 2
4 Cathode C 9 Cathode F
5 Cathode DP (1) 10 Cathode G
(1) Cathode DP Vf = 1.8V for red, yellow and green and Vf = 3.3V for blue.
ShenZhen Wayjun Technology Co.,Ltd - 17 - www.wayjun.com
Segment Digit LED Display
1.8 Common Anode 1.5 Inch (38.10mm)
PRODUCT DESCRIPTION
(1) 1.5 Inch (38.10mm) Digit Height
(2) Low current operation
(3) Excellent color and font characteristics
(4) Colors: White, blue, red, yellow and green
(5) Gray or black color background
(6) Common Anode
(7) RoHs Compliant Part
Absolute Maximum Rating (Ta = 25 ) ℃
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85 ℃
Storage Temperature -30 to +85 ℃
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25 ) ℃
PART NUMBER DICE
LEDS15012TUR11 AlInGaP Red 635 10 3.6(1) 4.2 75,000 ucd
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
PEAK
WAVELENGTH
(nm)
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
0.3 mA/℃
VF (V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
LEDS15012TB11 InGaN Blue 468 10 6.0(2) 7.0 75,000 ucd
LEDS15012YG11 AlInGaP
Green
LEDS15012UY11 AlInGaP
Amber
LEDS15012TW11 InGaN White 5,500K 10 6.0(2) 7.0 75,000 ucd
(1) Cathode DP Vf = 1.8V ONLY uses one led chip for red, yellow and green color.
(2) Cathode DP Vf = 3.3V ONLY uses one led chip for blue and white color.
568 10 3.6(1) 4.2 50,000 ucd
590 10 3.6(1) 4.2 60,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 18 - www.wayjun.com
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Common Anode DIG. 1 6 Cathode B
2 Cathode E 7 Cathode A
3 Cathode D 8 Cathode DP (1)
4 Cathode C 9 Cathode F
5 Common Anode DIG. 2 10 Cathode G
(1) Cathode DP Vf = 1.8V for red, yellow and green and Vf = 3.3V for blue.
ShenZhen Wayjun Technology Co.,Ltd - 19 - www.wayjun.com
Segment Digit LED Display
1.9 Common Anode 2.3 Inch (57.0mm)
PRODUCT DESCRIPTION
(1) 2.3 Inch (56.80mm) Digit Height
(2) Low current operation
(3) Excellent color and font characteristics
(4) Colors: White, blue, red, yellow and green
(5) Gray or black color background
(6) Common Anode
(7) RoHs Compliant Part
Absolute Maximum Rating (Ta = 25 ) ℃
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85 ℃
Storage Temperature -30 to +85 ℃
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25 ) ℃
PART NUMBER DICE
LEDS23012TUR11 AlInGaP Red 630 10 6.8 (1) 8.0 75,000 ucd
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
PEAK
WAVELENGTH
(nm)
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
0.3 mA/℃
VF (V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
LEDS23012TB11 InGaN Blue 468 10 13.25
(2)
LEDS23012YG11 AlInGaP
Green
LEDS23012UY11 AlInGaP
Amber
LEDS23012TW11 InGaN White 5,500K 10 13.25
568 10 6.8 (1) 8.0 75,000 ucd
590 10 6.8 (1) 8.0 75,000 ucd
(2)
14.0 90,000 ucd
14.0 90,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 20 - www.wayjun.com
Segment Digit LED Display
(1) Cathode DP Vf = 1.8V ONLY uses one led chip for red, yellow and green color.
(2) Cathode DP Vf = 3.3V ONLY uses one led chip for blue and white color.
DEVICE DIAGRAM
PIN NO.
1 Common Anode DIG. 1 6 Cathode B
2 Cathode E 7 Cathode A
3 Cathode D 8 Cathode DP (1)
4 Cathode C 9 Cathode F
5 Common Anode DIG. 2 10 Cathode G
(1) Cathode DP Vf = 1.8V for red, yellow and green and Vf = 3.3V for blue.
ShenZhen Wayjun Technology Co.,Ltd - 21 - www.wayjun.com
Segment Digit LED Display
1.10 Common Anode 4.0 Inch (100.0mm)
PRODUCT DESCRIPTION
(1) 4.0 Inch (100.0mm) Digit Height (5) Gray or black color background
(2) Low current operation (6) Common Anode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25 ) ℃
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85 ℃
Storage Temperature -30 to +85 ℃
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25 ) ℃
PART NUMBER
LEDS40012TUR11 AlInGaP Red 630 10 9.0
LEDS40012TB11 InGaN Blue 468 10 16.25
LEDS40012YG11 AlInGaP
LEDS40012UY11 AlInGaP
LEDS40012TW11 InGaN White 5,500K 10 16.25
(1) Cathode DP Vf = 1.8V ONLY uses one led chip for red, yellow and green color.
(2) Cathode DP Vf = 3.3V ONLY uses one led chip for blue and white color.
ShenZhen Wayjun Technology Co.,Ltd - 22 - www.wayjun.com
(1)
70 50 50 25 25 mA
DICE
MATERIAL
(COLOR)
Green
Amber
PEAK
WAVELENGTH
(nm)
568 10 9.0
590 10 9.0
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
VF
(V)
TYP
(1)
(2)
(1)
(1)
(2)
0.3 mA/℃
VF (V)
MAX.
11.0 120,000 ucd
17.5 130,000 ucd
11.0 120,000 ucd
11.0 120,000 ucd
17.5 60,000 ucd
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO. PIN NO.
1 Common Anode DIG. 1 6 Cathode B
2 Cathode E 7 Cathode A
3 Cathode D 8 Common Anode
4 Cathode C 9 Cathode F
5 Cathode DP (1) 10 Cathode G
(1) Cathode DP Vf = 1.8V for red, yellow and green and Vf = 3.3V for blue.
ShenZhen Wayjun Technology Co.,Ltd - 23 - www.wayjun.com
Segment Digit LED Display
2. 7 Segment Double Digit LED Display
2.1 Common Anode 0.36 Inch (9.14mm)
PRODUCT DESCRIPTION
(1) Double Digit 0.36 Inch (9.14mm) Height
(2) Low current operation
(3) Excellent color and font characteristics
(4) Colors: White, blue, red, yellow and green
(5) Gray or black color background
(6) Common Anode
(7) RoHs Compliant Part
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
MATERIAL
(COLOR)
LEDD3622AUR11 AlGaAs Red 660 10 1.8 2.3 10,000 ucd
(1)
70 50 50 25 25 mA
PEAK
WAVELENGTH
(nm)
MAX. REVERSE
CURRENT /
SEGMENT ( A)
0.3
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
mA/℃
℃
℃
LEDD3622TB11 InGaN Blue 468 10 3.3 4.0 20,000 ucd
LEDD3622YG11 GaP Green 568 10 1.9 2.3 10,000 ucd
LEDD3622UY11 AlInGaP
Amber
LEDD3622TW11 InGaN White 5,500K 10 3.3 4.0 20,000 ucd
590 10 1.8 2.3 10,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 24 - www.wayjun.com
Segment Digit LED Display
DEVICE DIAGRAM
First Digit Segment Second Digit Segment
PIN PIN PIN PIN
1 Cathode G1 6 Cathode D1 1 Cathode G2 6 Cathode D2
2 Cathode DP1 7 Cathode E1 2 Cathode DP2 7 Cathode E2
3 Cathode A1 8 Cathode C1 3 Cathode A2 8 Cathode C2
4 Cathode F1 9 Cathode B1 4 Cathode F2 9 Cathode B2
5 Common Anode 5 10 Common Anode 10 5 Common Anode 5 10 Common Anode 10
ShenZhen Wayjun Technology Co.,Ltd - 25 - www.wayjun.com
Segment Digit LED Display
2.2 Common Anode 0.56 Inch (14.20mm)
PRODUCT DESCRIPTION
(1) Double Digit 0.56 Inch (14.20mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Anode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
MATERIAL
(COLOR)
LEDD5622AUR11 AlGaAs Red 660 10 1.8 2.3 20,000 ucd
LEDD5622TB11 InGaN Blue 468 10 3.3 4.0 30,000 ucd
LEDD5622YG11 GaP Green 568 10 1.9 2.3 20,000 ucd
LEDD5622UY11 AlInGaP
Amber
LEDD5622TW11 InGaN White 5,500K 10 3.3 4.0 30,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 26 - www.wayjun.com
(1)
70 50 50 25 25 mA
0.3
PEAK
WAVELENGTH
(nm)
590 10 1.8 2.3 22,000 ucd
MAX. REVERSE
CURRENT /
SEGMENT ( A)
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
mA/℃
℃
℃
Segment Digit LED Display
DEVICE DIAGRAM
PIN PIN PIN PIN
1 Cathode E1 6 Cathode D2 11 Cathode A2 16 Cathode A1
2 Cathode D1 7 Cathode G2 12 Cathode F2 17 Cathode G1
3 Cathode C1 8 Cathode C2 13 Common Anode 2 18 Cathode F1
4 Cathode DP1 9 Cathode DP1 14 Common Anode 1
5 Cathode E2 10 Cathode B2 15 Cathode B1
ShenZhen Wayjun Technology Co.,Ltd - 27 - www.wayjun.com
Segment Digit LED Display
2.3 Common Cathode 0.56 Inch (14.20mm)
PRODUCT DESCRIPTION
(1) Double Digit 0.56 Inch (14.20mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Cathode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER
LEDD5622TW1C InGaN White 5,500K 10 3.3 4.0 25,000 ucd
DICE
MATERIAL
(COLOR)
(1)
70 50 50 25 25 mA
PEAK
WAVELENGTH
(nm)
MAX. REVERSE
CURRENT /
SEGMENT ( A)
VF
(V)
TYP
0.3
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
mA/℃
℃
℃
ShenZhen Wayjun Technology Co.,Ltd - 28 - www.wayjun.com
Segment Digit LED Display
DEVICE DIAGRAM
PIN PIN PIN PIN
1 Cathode E1 6 Cathode D2 11 Cathode A2 16 Cathode A1
2 Cathode D1 7 Cathode G2 12 Cathode F2 17 Cathode G1
3 Cathode C1 8 Cathode C2 13 Common Anode 2 18 Cathode F1
4 Cathode DP1 9 Cathode DP1 14 Common Anode 1
5 Cathode E2 10 Cathode B2 15 Cathode B1
ShenZhen Wayjun Technology Co.,Ltd - 29 - www.wayjun.com
Segment Digit LED Display
2.4 Common Anode 1.0 Inch (25.40mm)
PRODUCT DESCRIPTION
(1) Double Digit 1.0 Inch (25.40mm) Height (5) Gray or bl ack color background
(2) Low current operation (6) Common Anode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
LEDD10022TUR11 AlInGaP Red 630 10 1.8 2.3 30,000 ucd
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
PEAK
WAVELENGTH
(nm)
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
0.3
VF
(V)
TYP
VF (V)
MAX.
mA/℃
℃
℃
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
LEDD10022TB11 InGaN Blue 468 10 3.3 4.0 48,000 ucd
LEDD10022YG11 AlInGaP
Green
LEDD10022UY11 AlInGaP
Amber
LEDD10022TW11 InGan White 5,500K 10 3.3 4.0 –
568 10 1.9 2.3 30,000 ucd
590 10 1.8 2.3 30,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 30 - www.wayjun.com
Segment Digit LED Display
DEVICE DIAGRAM
First Digit Segment Second Digit Segment
PIN PIN PIN PIN
1 Cathode D1 6 Cathode B1 1 Cathode D2 6 Cathode B2
2 Cathode DP1 7 Cathode A1 2 Cathode DP2 7 Cathode A2
3 Cathode E1 8 Cathode F1 3 Cathode E2 8 Cathode F2
4 Cathode C1 9 Cathode G1 4 Cathode C2 9 Cathode G2
5 Common Anode 5 10 Common Anode 10 5 Common Anode 5 10 Common Anode 10
ShenZhen Wayjun Technology Co.,Ltd - 31 - www.wayjun.com
Segment Digit LED Display
3. 7 Segment Three Digit LED Display
3.1 Common Anode 0.36 Inch (9.14mm)
PRODUCT DESCRIPTION
(1) Three Digit 0.36 Inch (9.14mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Anode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
MATERIAL
(COLOR)
LEDT3632AUR11 AlGaAs Red 660 10 1.8 2.3 18,000 ucd
LEDT3632TUR11 InGaAlP Red 630 10 1.8 2.3 30,000 ucd
LEDT3632TB11 InGaN Blue 468 10 3.3 4.0 35,000 ucd
LEDT3632YG11 GaP Green 568 10 1.9 2.3 12,000 ucd
LEDT3632UY11 AlInGaP
Amber
LEDT3632TW11 InGan White 5,500K 10 3.3 4.0 35,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 32 - www.wayjun.com
(1)
70 50 50 25 25 mA
0.3
PEAK
WAVELENGTH
(nm)
590 10 1.8 2.3 30,000 ucd
MAX. REVERSE
CURRENT /
SEGMENT ( A)
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
mA/℃
℃
℃
Segment Digit LED Display
DEVICE DIAGRAM
First Digit Segment Second Digit Segment
PIN PIN PIN PIN
1 Cathode E1 6 NC 1 Cathode E2 6 NC
2 Cathode D1 7 Cathode B1 2 Cathode D2 7 Cathode B2
3 Cathode DP1 10 Cathode F1 3 Cathode DP2 10 Cathode F2
4 Cathode C1 11 Cathode A1 4 Cathode C2 11 Cathode A2
5 Cathode G1 5 Cathode G2
Third Digit Segment
PIN PIN PIN
1 Cathode E3 6 NC 8 Common Anode 8
2 Cathode D3 7 Cathode B3 9 Common Anode 9
3 Cathode DP3 10 Cathode F3 12 Common Anode 10
4 Cathode C3 11 Cathode A3
5 Cathode G3
ShenZhen Wayjun Technology Co.,Ltd - 33 - www.wayjun.com
Segment Digit LED Display
3.2 Common Cathode 0.36 Inch (9.14mm)
PRODUCT DESCRIPTION
(1) Three Digit 0.36 Inch (9.14mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Cathode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
LEDT3632TUR1C InGaAlP Red 630 10 1.8 2.3 40,000 ucd
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
PEAK
WAVELENGTH
(nm)
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
0.3
VF
(V)
TYP
VF (V)
MAX.
mA/℃
℃
℃
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
LEDT3632TB1C InGaN Blue 468 10 3.3 4.0 35,000 ucd
LEDT3632YG1C GaP Green 568 10 1.9 2.3 12,000 ucd
LEDT3632UY1C AlInGaP
Amber
LEDT3632TW1CG InGaN White 5,500K 10 3.3 4.0 35,000 ucd
590 10 1.8 2.3 30,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 34 - www.wayjun.com
Segment Digit LED Display
DEVICE DIAGRAM
First Digit Segment Second Digit Segment
PIN PIN PIN PIN
1 Anode E1 6 NC 1 Anode E2 6 NC
2 Anode D1 7 Anode B1 2 Anode D2 7 Anode B2
3 Anode DP1 10 Anode F1 3 Anode DP2 10 Anode F2
4 Anode C1 11 Anode A1 4 Anode C2 11 Anode A2
5 Anode G1 5 Anode G2
Third Digit Segment
PIN PIN PIN
1 Anode E3 6 NC 8 Common Cathode 8
2 Anode D3 7 Anode B3 9 Common Cathode 9
3 Anode DP3 10 Anode F3 12 Common Cathode 10
4 Anode C3 11 Anode A3
5 Anode G3
ShenZhen Wayjun Technology Co.,Ltd - 35 - www.wayjun.com
Segment Digit LED Display
4. 7 Segment Four Digit LED Display
4.1 Common Anode 0.36 Inch (9.14mm)
PRODUCT DESCRIPTION
(1) Three Digit 0.36 Inch (9.14mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Anode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
LEDQ3632AUR11 AlGaAs Red 660 10 1.8 2.3 15,000 ucd
LEDQ3632TUR11 AlInGaP Red 660 10 1.8 2.3 30,000 ucd
LEDQ3632TB11 InGaN Blue 468 10 3.3 4.0 20,000 ucd
LEDQ3632YG11 GaP Green 568 10 1.9 2.3 15,000 ucd
LEDQ3632UY11 AlInGaP
LEDQ3632TW11 InGaN White 5,500K 10 3.3 4.0 –
ShenZhen Wayjun Technology Co.,Ltd - 36 - www.wayjun.com
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
Amber
0.3
PEAK
WAVELENGTH
(nm)
590 10 1.8 2.3 30,000 ucd
MAX. REVERSE
CURRENT /
SEGMENT ( A)
VF
(V)
TYP
VF
(V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
mA/℃
℃
℃
Segment Digit LED Display
DEVICE DIAGRAM
First Digit Segment Second Digit Segment
PIN PIN PIN PIN
1 Cathode E1 6 Cathode G1 1 Cathode E2 6 Cathode G2
2 Cathode D1 7 Cathode B1 2 Cathode D2 7 Cathode B2
3 Cathode DP1 10 Cathode F1 3 Cathode DP2 10 Cathode F2
4 Cathode C1 11 Cathode A1 4 Cathode C2 11 Cathode A2
Third Digit Segment Fourth Digit Segment
PIN PIN PIN
1 Cathode E3 6 Cathode G3 1 Cathode E4 6 Cathode G4
2 Cathode D3 7 Cathode B3 2 Cathode D4 7 Cathode B4
3 Cathode DP3 10 Cathode F3 3 Cathode DP4 10 Cathode F4
4 Cathode C3 11 Cathode A3 4 Cathode C4 11 Cathode A4
All Digit Segment
PIN PIN
5 Common Anode 5 9 Common Anode 9
8 Common Anode 8 12 Common Anode 10
ShenZhen Wayjun Technology Co.,Ltd - 37 - www.wayjun.com
Segment Digit LED Display
4.2 Common Anode 0.56 Inch (14.20mm)
PRODUCT DESCRIPTION
(1) Four Digit 0.56 Inch (14.20mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Anode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
LEDQ5642AUR11 AlGaAs Red 660 10 1.8 2.3 20,000 ucd
LEDQ5642TB11 InGaN Blue 468 10 3.3 4.0 30,000 ucd
LEDQ5642YG11 GaP Green 568 10 1.9 2.3 20,000 ucd
LEDQ5642UY11 AlInGaP
LEDQ5642TW11 InGaN White 5,500K 10 3.3 4.0 30,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 38 - www.wayjun.com
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
Amber
0.3
PEAK
WAVELENGTH
(nm)
590 10 1.8 2.3 22,000 ucd
MAX. REVERSE
CURRENT /
SEGMENT ( A)
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
10mA)
mA/℃
℃
℃
Segment Digit LED Display
DEVICE DIAGRAM
First Digit Segment Second Digit Segment
PIN PIN PIN PIN
1 Cathode E1 5 Cathode G1 1 Cathode E2 5 Cathode G2
2 Cathode D1 7 Cathode B1 2 Cathode D2 7 Cathode B2
3 Cathode DP1 10 Cathode F1 3 Cathode DP2 10 Cathode F2
4 Cathode C1 11 Cathode A1 4 Cathode C2 11 Cathode A2
Third Digit Segment Fourth Digit Segment
PIN PIN PIN
1 Cathode E3 5 Cathode G3 1 Cathode E4 5 Cathode G4
2 Cathode D3 7 Cathode B3 2 Cathode D4 7 Cathode B4
3 Cathode DP3 10 Cathode F3 3 Cathode DP4 10 Cathode F4
4 Cathode C3 11 Cathode A3 4 Cathode C4 11 Cathode A4
All Digit Segment
PIN PIN
6 Common Anode 5 9 Common Anode 9
8 Common Anode 8 12 Common Anode 10
ShenZhen Wayjun Technology Co.,Ltd - 39 - www.wayjun.com
Segment Digit LED Display
5. Alpha Numeric Single Digit LED Display
5.1 Common Anode 0.39 Inch (9.9mm)
PRODUCT DESCRIPTION
(1) 0.39 Inch (9.9mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Anode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
White Led display Blue, red, yellow and green Led display
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
MATERIAL
(COLOR)
LEDA3914AUR11 AlGaAs Red 660 10 1.8 2.3 25,000 ucd
LEDA3914TB11 InGaN Blue 468 10 3.3 4.0 45,000 ucd
LEDA3914YG11 GaP Green 568 10 1.9 2.3 25,000 ucd
LEDA3914UY11 AlInGaP Amber 590 10 1.8 2.3 30,000 ucd
LEDA3914TW11 InGaN White 5,500K 10 3.3 4.0 70,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 40 - www.wayjun.com
(1)
70 50 50 25 25 mA
PEAK
WAVELENGTH
(nm)
MAX.
REVERSE
CURRENT /
SEGMENT
(uA)
VF
(V)
TYP
0.3
VF
(V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
20mA)
mA/℃
℃
℃
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Cathode J 10 Cathode L
2 Cathode H 11 Cathode C
3 Cathode F 12 Cathode DP
4 Common Anode 13 Common Anode
5 Cathode G1 14 Cathode G2
6 Cathode E 15 Cathode B
7 Cathode N 16 Cathode K
8 Cathode D 17 Common Anode
9 Cathode M 18 Cathode A
ShenZhen Wayjun Technology Co.,Ltd - 41 - www.wayjun.com
Segment Digit LED Display
5.2 Common Cathode 0.39 Inch (9.9mm)
PRODUCT DESCRIPTION
(1) 0.39 Inch (9.9mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Cathode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
White Led display Blue, red, yellow and green Led display
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
LEDA3914AUR11C AlGaAs Red 660 10 1.8 2.3 25,000 ucd
LEDA3914TB11C InGaN Blue 468 10 3.3 4.0 45,000 ucd
LEDA3914YG11C GaP Green 568 10 1.9 2.3 25,000 ucd
LEDA3914UY11C AlInGaP
LEDA3914TW11C InGaN White 5,500K 10 3.3 4.0 70,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 42 - www.wayjun.com
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
Amber
0.3
PEAK
WAVELENGTH
(nm)
590 10 1.8 2.3 30,000 ucd
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
20mA)
mA/℃
℃
℃
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Anode J 10 Anode L
2 Anode H 11 Anode C
3 Anode F 12 Anode DP
4 Common Cathode 13 Common Cathode
5 Anode G1 14 Anode G2
6 Anode E 15 Anode B
7 Anode N 16 Anode K
8 Anode D 17 Common Cathode
9 Anode M 18 Anode A
ShenZhen Wayjun Technology Co.,Ltd - 43 - www.wayjun.com
Segment Digit LED Display
5.3 Common Anode 0.50 Inch (12.7mm)
PRODUCT DESCRIPTION
(1) 0.50 Inch (12.7mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Anode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
MATERIAL
(COLOR)
LEDA5014AUR11 AlGaAs / Red 660 10 1.8 2.3 35,000 ucd
LEDA5014TB11 InGaN / Blue 468 10 3.3 4.0 45,000 ucd
LEDA5014YG11 GaP / Green 568 10 1.9 2.3 35,000 ucd
LEDA5014UY11 AlInGaP /
Amber
LEDA5014TW11 InGaN / White 5,500K 10 3.3 4.0 75,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 44 - www.wayjun.com
(1)
70 50 50 25 25 mA
0.3
PEAK
WAVELENGTH
(nm)
590 10 1.8 2.3 35,000 ucd
MAX. REVERSE
CURRENT /
SEGMENT (uA)
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
20mA)
mA/℃
℃
℃
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Cathode A2 10 Cathode DP
2 Cathode A1 11 Cathode M
3 Cathode J 12 Cathode L
4 Cathode H 13 Cathode C
5 Cathode F 14 Cathode G1
6 Cathode E 15 Cathode G2
7 Cathode N 16 Cathode B
8 Cathode D1 17 Cathode K
9 Cathode D2 18 Common Anode
ShenZhen Wayjun Technology Co.,Ltd - 45 - www.wayjun.com
Segment Digit LED Display
5.4 Common Cathode 0.50 Inch (12.7mm)
PRODUCT DESCRIPTION
(1) 0.50 Inch (12.7mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Cathode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
LEDA5014AUR11C AlGaAs / Red 660 10 1.8 2.3 35,000 ucd
LEDA5014TB11C InGaN / Blue 468 10 3.3 4.0 45,000 ucd
LEDA5014YG11C GaP / Green 568 10 1.9 2.3 35,000 ucd
LEDA5014UY11C AlInGaP /
LEDA5014TW11C InGaN / White 5,500K 10 3.3 4.0 75,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 46 - www.wayjun.com
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
Amber
0.3
PEAK
WAVELENGTH
(nm)
590 10 1.8 2.3 35,000 ucd
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
20mA)
mA/℃
℃
℃
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Anode A2 10 Anode DP
2 Anode A1 11 Anode M
3 Anode J 12 Anode L
4 Anode H 13 Anode C
5 Anode F 14 Anode G1
6 Anode E 15 Anode G2
7 Anode N 16 Anode B
8 Anode D1 17 Anode K
9 Anode D2 18 Common Cathode
ShenZhen Wayjun Technology Co.,Ltd - 47 - www.wayjun.com
Segment Digit LED Display
5.5 Common Anode 0.80 Inch (20.32mm)
PRODUCT DESCRIPTION
(1) 0.80 Inch (20.32mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Anode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
LEDA8018AUR11 AlGaAs / Red 660 10 1.8 2.3 40,000 ucd
LEDA8018TB11 InGaN / Blue 468 10 3.3 4.0 50,000 ucd
LEDA8018YG11 GaP / Green 568 10 1.9 2.3 40,000 ucd
LEDA8018UY11 AlInGaP /
LEDA8018TW11 InGaN / White 5,500K 10 3.3 4.0 75,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 48 - www.wayjun.com
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
Amber
0.3
PEAK
WAVELENGTH
(nm)
590 10 1.8 2.3 40,000 ucd
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
20mA)
mA/℃
℃
℃
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Cathode A2 10 Cathode D2
2 Cathode A1 11 Cathode D1
3 Cathode F 12 Cathode DP
4 Cathode H 13 Cathode C
5 Cathode E 14 Cathode G1
6 Cathode J 15 Cathode B
7 Cathode M 16 Cathode G2
8 Cathode N 17 Common Anode
9 Cathode L 18 Cathode K
ShenZhen Wayjun Technology Co.,Ltd - 49 - www.wayjun.com
Segment Digit LED Display
5.6 Common Cathode 0.80 Inch (20.32mm)
PRODUCT DESCRIPTION
(1) 0.80 Inch (20.32mm) Height (5) Gray or black color background
(2) Low current operation (6) Common Cathode
(3) Excellent color and font characteristics (7) RoHs Compliant Part
(4) Colors: White, blue, red, yellow and green
Absolute Maximum Rating (Ta = 25℃)
PARAMETER RED AMBER GREEN BLUE WHITE UNITS
DC Forward Current Per Segment 30 30 25 30 20 mA
Peak Current Per Segment
Avg. Forward Current (Pulse Operation) Per Segment 30 30 25 25 25 mA
Derating Linear From 25℃ Per Segment
Reverse Voltage
Operating Temperature -25 to +85
Storage Temperature -30 to +85
(1) Pulse conditions of 1/10 duty and 0.1msec width, for long operating life, max. of 20mA recommended
(2) Reverse biasing of the dot matrix is not recommend, will cause damage to the leds
(2)
3 V
Electro-optical Characteristics (Ta = 25℃)
PART NUMBER DICE
LEDA8018AUR11C AlGaAs / Red 660 10 1.8 2.3 40,000 ucd
LEDA8018TB11C InGaN / Blue 468 10 3.3 4.0 50,000 ucd
LEDA8018YG11C GaP / Green 568 10 1.9 2.3 40,000 ucd
LEDA8018UY11C AlInGaP /
LEDA8018TW11C InGaN / White 5,500K 10 3.3 4.0 75,000 ucd
ShenZhen Wayjun Technology Co.,Ltd - 50 - www.wayjun.com
(1)
70 50 50 25 25 mA
MATERIAL
(COLOR)
Amber
0.3
PEAK
WAVELENGTH
(nm)
590 10 1.8 2.3 40,000 ucd
MAX.
REVERSE
CURRENT /
SEGMENT (uA)
VF
(V)
TYP
VF (V)
MAX.
LUMINOUS
INTENSITY /
SEGMENT
AVERAGE (IF =
20mA)
mA/℃
℃
℃
Segment Digit LED Display
DEVICE DIAGRAM
PIN NO.
1 Anode A2 10 Anode D2
2 Anode A1 11 Anode D1
3 Anode F 12 Anode DP
4 Anode H 13 Anode C
5 Anode E 14 Anode G1
6 Anode J 15 Anode B
7 Anode M 16 Anode G2
8 Anode N 17 Common Cathode
9 Anode L 18 Anode K
ShenZhen Wayjun Technology Co.,Ltd - 51 - www.wayjun.com
Loading...
