SPECIFICATIONS

INPUT IMPEDANCE................…………..> 15k?

OUTPUT IMPEDANCE..…………................< 25k?

SIGNAL TO NOISE RATIO

(all controls at MID position)........> 74dBV 'A' Weighted

BYPASS...…………....True Bypass

DIMENSIONS...4-25/32" x 3-3/4" x 1-3/4"

WEIGHT...…………...................14oz.

CURRENT DRAW....…………..8.7mA (9V DC)

POWER SUPPLY..........Standard 9V battery,

Dunlop ECB-03 AC Adapter, Dunlop DC Brick,

or CAE MC-403.

POWER

The Fat Sandwich Distortion can be powered by a single

9V battery or with a Dunlop ECB-003 external DC power supply.

The power input is a 5.5mm x 2.1mm jack with the positive

voltage on the outer sleeve. Using an external power supply

will disconnect the battery. Disconnect the input jack to

preserve battery life when not in use. The pedal will lock

into bypass mode when it is time to change the battery. It

also includes power protection circuitry to prevent damage

from AC power supplies.

DUNLOP MANUFACTURING, INC. P.O. BOX 846 BENICIA, CA 94510 U.S.A.

TEL: 1-707-745-2722 FAX: 1-707-745-2658 WWW.JIMDUNLOP.COM

Fat Sandwich instruction manual

WHE-301

*0dBV = 1Vrms

Features: heavy-duty footswitch with quiet relay-based true

bypass, blue LED indicator, 5.5mm x 2.1mm power jack with

AC protection, easy access non-detachable battery door,

super-duty 0.09” aluminum anodized chassis, high grade

components, great tone and cool name.

92503006785

Dunlop Manual - way huge - fat sandwich

4/4 color Print onto Cover Stock

DUNLOP PART #: 92503006785 UPC #: N/A FILE NAME: 92503006785-WH_FATSAND_MANUAL.PDF FILE LOCATION: CREATIVE ARCHIVE

PROJECT DIRECTOR: JIM SILVA DESIGNER: HANK ALVA CONTACT: JSILVA@JIMDUNLOP.COM

DUNLOP MANUFACTURING, INC.

150 INDUSTRIAL WAY P.O. BOX 846 BENICIA, CA 94510 PHONE: 707.745.2722 FAX: 707.745.2658

CONCEPT

REVISED

PROOF

QUOTE

FINAL ART

TO NE

– adjusts the tonal

mixture in tandem with the

Pres & Reso controls

VO L U M E

- produces tons

of output

RESONANCE

– manipulates

the lo W frequencies

FOO TS WITCH

– to g gl es the

effect on

bypass

(blue LED indicates effect is ON)

PRESENCE

–

va r ies the high

frequency

res ponse

DISTORTION –

ver s heaps of

cru

nchy d

ist

tion

goodness

HARMONIC SATURATOR

The Fat Sandwich is versatile and over-the-top. The consummate distortion pedal for any genre or playing style.

Designed to be used with an amp set clean, the Fat Sandwich delivers heaps of crunchy distortion goodness via its innovative multi-stage clipping circuit. Meticulously designed from the ground

up, the passive tone stack was tuned to bring out the “sweet spot” with any guitar and amp combination. The VOLUME control produces tons of output, while the DRIVE knob goes from mild crunch to full tilt saturation

. Additionally, the Fat Sandwich has three internal mini controls for fine-tuning the pedal to your guitar rig.

Way Huge Electronics: bringing a new age of sweltering saturation to the people...

rve

- for

ne- t u

ing corner frequencies of

the

t s

ta g e of distortion

Highs

- tweaks the high

end be t

ween the 2

drive sta ges

Drive

– adjus ts the gain of the 2nd stage

of distorti on

fat s a ndwich INTERIOR DRAWING :

(right)

(unscrew the 4 rubber feet to a dj ust the interna l tone con trols)
