Controls and connectors
T he devic e may no t be di spos ed of wi th hou se hold rub bish .
T his a pplia nce i s la belle d in a cc ordanc e with Europea n
Direc tive 20 02/96/E G conc erning used e lect ric al and elec tronic
appl ianc es (wa ste elec trical and e lec tronic equi pment - W EEE ).
T he gui delin e determ ine s the frame work for the retu rn an d
recyc ling of u sed ap plia nces as ap plic able throug hout the EU.
T o return your us ed de vic e, pl ease use t he ret urn and c olle ctio n
sys tems avail able to you .
1 = Speaker 3 = Level and On/Off Switch
2 = USB charge connector 4 = Operation LED
Charging connection
5 = Audio connection cable
The MOBI contains a powerful rechargable Lithium Ion battery, which
allows many hours of operation due to high battery capacity.
Before first usage, the battery requires recharging.
Connect the charger (USB power supply or PC device USB power) as
shown in the picture. MOBI can be operated while charging.
Operation
To expand for operation or compress for transport, press on the top
half of the cabinet to unlock or lock as shown in the picture.
For operation, connect the audio input to your audio source and switch
on.
Audio Connection
Specifications
- 38mm Wide range speaker driver, magnetic shielded
- Frequency range: 80 – 20.000 Hz
- integrated Amplifier, level switch, operation control indicator
- Connection by audio cable with 3.5mm stereo plug
- integrated rechargeable Li-Ion battery 3.7V 500mAh
- Charge Voltage: 5 V 0.1 A (USB powered)
- Dimensions: Ø 80 x 50 mm
Precautions
Connect the audio input to the line-out, non amplified output. Avoid
connection to the speaker-out jack of your sound source. The
amplified signal from the speaker-out may unnecessary distortion and
may damage the speaker-circuit.
To connect your sound-system with power supply system, please
employ a suitable USB power supply or a PC USB connector..
If the sound-system is not in use for a longer period of time, be sure
that the power source is disconnected from your system.
Do not use alcohol, benzene, thinner or acids to clean the cabinet.
Do not place your sound-system near radiators, airconditioning or
radio-controlled systems.
Avoid leaving the sound-system in permanent strain such as direct
sunlight, extreme moist or dryness, exeptional cold or heat,
mechanical vibrations or shock.
Do not open the cabinet, contact qualified personnel only.
In case there is audible noise, possibly caused by strong radio waves
(e.g. by mobile phones) we recommend to turn down the volume
control of the unit.
We herewith declare, that the WAVEMASTER MOBI speaker system
complies with the following standards or normative documents:
EN55022:2006+A122007; EN55024: 998+ A1: 2001+ A2: 2003
EMC Directive 2004/108/EC:
This statement is based on the test reports of an EMV-laboratory.
CE - Declaration of conformity
All texts and illustrations were produced with greatest care.
WAVEMASTER cannot however accept any legal or other
responsibility for any remaining incorrect information and its
consequences.
Subject to change without further notice.
If you have special questions to the product and cannot find a solution
in this introduction, you can look for more informations on our
homepage. Thank you!
www.wavemaster.eu
