Wavecom WMOD2 User Manual

GUIDE 19/04/99, 9:201

WMO2 Modem Series

GSM 900 / 1800 / 1900

USER MANUAL

SUMMARY

1. PRODUCT DESCRIPTION 1

1.1 Package content 1

1.2 P roduct presentation 1

1.3 Physical characteristics 2

1.4 Functions - GSM Modes 2

1.5 Temperature range 2

2. INSTALLATION/START-UP 3

2.1 Mounting the modem 3

2.2 Installing the modem 3

2.3 Electrical characteristics 4

2.3.1 Switching the GSM modem on/off 4

2.3.2 Voltage range 4

2.3.3 Overvoltage/undervoltage 4

2.3.4 Power supply cable 5

2.3.5 Input/output electrical characteristics defined for all external connections 6

2.3.6 Protection/on-board network connection 6

3. DESCRIPTION OF THE INTERFACES 7

3.1 LED Function 7

3.2 Connectors 7

4. TECHNICAL DATA 11

Wavecom WMO2 Modem

SUMMARY

GUIDE 19/04/99, 9:202

5. TROUBLESHOOTING: Specific defaults possibly encountered 12

5.1 The modem does not answer through the serial link 12

5.2 The modem always returns «Error» when trying to issue a communication 13

5.3 The modem always returns «No carrier» when trying to issue a communication 14

6. NOTES ON SAFETY 16

6.1 General safety 16

6.2 Vehicle safety 17

6.3 Car And Maintenance 17

6.4 Your responsibility 18

7. GENERAL INFORMATIONS 19

SUMMARY

Wavecom WMO2 Modem

GUIDE 19/04/99, 9:203

1. PRODUCT DESCRIPTION

r

The Wavecom WMO2 modem exist under three different references:

- WMO2-G900 : GSM 900 MHz version

- WMO2-G1800 : GSM 1800 MHz version

- WMO2-G1900 : GSM 1900 MHz version

1.1 Package content

The Wavecom WMO2 modem package comprises:

- 1 Modem

- 2 holding bridles

- 1 Power supply cable + fuse

- 1 User manual (this document)

1.2 Product presentation

The Wavecom WMO2 modem is a terminal for fax and data transmission, short message service mobile originated, short
message service mobile terminated and voice calls.
The connectors binded to the body guarantee output and input connections.
An extractible holder is used to insert the SIM card (Micro-SIM type). A LED indicates the operating mode.

TM

Micro-Fit

connector
Front cap

Wavecom WMO2 Modem 1

SUB HD
connector

Modem presentation

Back cap

Figure 1

LED

SMA
connecto

Extractible
SIM holder

PRODUCT DESCRIPTION

GUIDE 19/04/99, 9:204

1.3 Physical characteristics

snoisnemiD)srotcennocgnidulcxe(mm52x45x89

thgieWsmarg041<

emuloV3mc32.31

gnisuoHdeliforpmuinimulA

1.4 Functions - GSM Modes

dradnatS 2esahPMSG)W1(1ssalCzHM0091/0081-)W2(4ssalCzHM009
ecafretnI

SMS

ataD

PRODUCT DESCRIPTION

xaF

oiduA )snoitpoerutuf(tikraC:2)snoitpoerutuf(tesdaeH:1:seirosseccA-RFE+RF

1.5 Temperature range

Operating conditions : From -20°C to +55° C
Storage conditions : From -25°C to +70°C

Wavecom WMO2 Modem 2

snoisnemidllarevOmm52x45x011

noitcnufgniduabotuA82.V/42.V232SRecafretnilaireS

70.70&50.70MSGdnaret52.VnodesabtesdnammocTA

.)TM(detanimreTeliboMdna)OM(detanigirOeliboM

.tsacdaorblleC.tniopottniopUDP&txeTedoM

.50.70MSGhtiwecnadroccanI

.s/stib0069,0084,0042suonorhcnysA

.edomtnerapsnarTnoNdnatnerapsnarT

.sduab57/0021,0021,003:ylnoedoMtnerapsnarTnoNnI

.)NDSI(011Vdna)NTSP(zHK1.3edoM

s/stib0069/0027/0084/0042

.edoMtnerapsnarTni26ecivreseletMSG

.elbitapmoc3epuorG.1ssalC

GUIDE 19/04/99, 9:205

2 INSTALLATION/START-UP

2.1 Mounting the modem

For mounting the modem, bind to the body the holding bridles according to the schema below :

Note:

- T o be attached to a plain surface

- Screw head max. height: 2mm

Holding bridles

Figure 2

Modem mounting

2.2 Installing the modem

m
m

2

mm

2

To install the modem, plug the device on a DC power supply (for automotive application,
connect the device on the permanent « + » and insert the SIM card in the holder).

Make sure that an antenna is connected.
In order to extract or to insert the Micro SIM card, it is necessary to press the SIM holder ejector with a sharp element (a pen

for example).
If this sequence is not respected, the SIM holder could be damaged.

Wavecom WMO2 Modem 3

GUIDE 19/04/99, 9:216

INSTALLATION/START-UP

2.3 Electrical characteristics

2.3.1 Switching the GSM modem on/off

The device is permanently powered (when connected to the power supply).

2.3.2 Voltage range

Voltage range : 5 to 32V DC (GSM 900) - 6 to 32V DC (GSM 1800/1900)
GND : 0V

2.3.3 Overvoltage/undervoltage

Correct operation of the Wavecom WMO2 modem in communication mode is not guaranteed if input voltage
fall below 5V (GSM 900) - 6V (GSM 1800/1900). The modem is protected against voltage over 32V.
When input voltages exceed 32V, the supply voltage is disconnected in order to protect the electronic components from an
overvoltage.

TWO CASES ARE POSSIBLE:

- IF THE OVERVOLTAGE IS CONTINUOUS, THE PROTECTION IS GUARANTEED BY THE FUSE.

- IN THE CASE OF TRANSIENT PEAKS, THE MODEM GUARANTEES ITS OWN PROTECTION.

INSTALLATION/START-UP

Wavecom WMO2 Modem 4

GUIDE 19/04/99, 9:217

2.3.4 Power supply cable

m

A cable, included in the package shall be used for power supply connection.

The wires are marked as follows:

Cable : 1 wire
Ame : tinned copper 24x0.2 mm
Section : 0.75 mm

2

Cables stripped over 200 mm,

T

M

Connector Molex Micro-Fit 3.0

protected by their own sheath

Side view

-

- +

+

Figure 3

Power supply cable

Wavecom WMO2 Modem 5

GUIDE 19/04/99, 9:218

Stripped wire, tinned over 5 m

Standard cable sheath

INSTALLATION/START-UP

2.3.5 Input/output electrical characteristics defined for all external connections

sretemaraP

:ylppusrewoP

egatlovylppustupnI-5236 23V

noitpotiKraChtiwegatlovylppustupnI- 8181V

tnerrucylppuskaeptupnI- 5.21A

-edomnoitacinummocnitnerrucylppusegarevatupnI 054002Am
edomeldinitnerrucylppusegarevatupnI- 0353Am

:knillaireS 232SR-

:)tesdaeh(oiduA

K2/V2@tnerructupnienohporciM- Ω 5.05.0Am

egatlovtupnienohporcimetulosbA- 001001pVm

051tnerructuptuorekaepS- ΩFn1/6161Am

ecnadepmirekaepsetulosbA- 2323

MIS 5ro35ro3V

.niM.pyT.xaM.niM.pyT.xaM

009MSG0091/0081MSG

INSTALLATION/START-UP

2.3.6 Protection/on-board network connection

The modem is protected by a fuse directly binded on the power supply cable.

Wavecom WMO2 Modem 6

GUIDE 19/04/99, 9:219

tinU

Ω

3. DESCRIPTION OF THE INTERFACES

rotcennoCnoitcnuF

AMSrotcennocannetnaFR

DBUSsnip51
)ytisnedhgih(

knil232SR
knilOIDUA

TOOB

TESER

tiF-orciMsnip4

MT

rotcennocylppusrewoP

rotcennoc»MIS«noitcennocdracMIS

The modem comprises several interfaces:

- LED function indicating operating status

- External antenna (via SMA)

- Serial and control link (via 15 pins SUB D)

- Power supply (via 4 pins Micro-FitTM)

- SIM card holder

3.1 LED Function

- LED off Device switched off - Not ready

- LED on Device switched on - Connecting to network

- LED flashing slowly Device switched on - Idle mode

- LED flashing rapidly Device switched on - Transmission mode

3.2 Connectors

Wavecom WMO2 Modem 7

DESCRIPTION OF THE INTERFACES

GUIDE 19/04/99, 9:2110

SMA connector
(antenna connector)

A SIM card is needed to operate on a GSM network.
To install the card:

- Press the yellow button to eject the holder.

- Insert the SIM card.

- Check that it fits into place correctly.

SIM card

Figure 4

SMA connector

DESCRIPTION OF THE INTERFACES

Wavecom WMO2 Modem 8

GUIDE 19/04/99, 9:2111

Extractible

SIM card holder

Figure 5

SIM card holder

Yellow button to
eject the holder
(with a sharp element)

15

610

15 11

Figure 6

NIPAIETICCnoitangiseD

SR

232

1DCD901tceteDreirraCataD
6XR401)tuo(ataDevieceR
2XT301ataDtimsnarT
8RTD2.801ydaeRlanimreTataD
9DNGdnuorglangiS
7RSD701ydaeRteSataD

21STR501dnesottseuqeR
11STC601dnesotraelC
31IR521rotacidnigniR

oiduA

4)+(ENOHPORCIM

5)-(ENOHPORCIM

01)+(REKAEPS

51)-(REKAEPS

tooB3TOOB

teseR41TESER

15 pins SUB D connector

(high density)

Pins assignment for

15 pins SUB D Connector

Wavecom WMO2 Modem 9

GUIDE 19/04/99, 9:2212

DESCRIPTION OF THE INTERFACES

Figure 7

4 pins Micro-Fit

TM

connector

rotcennoCtuoyalsniPstnemmoC

1

snip4

2

MT

0.3tiF-orciM

4-3

TM

DESCRIPTION OF THE INTERFACES

The 4 pins Micro-Fit 3.0
The address can be obtained on the following internet site : www.wavecom.com

can be ordered from a supplier called MOLEX.

Wavecom WMO2 Modem 10

GUIDE 19/04/99, 9:2213

21
43

YRETTAB+V
DNUORG

IXUA

1

2

4

3

rewoP

ylppus

CN

4. TECHNICAL DATA

noitpircseDsdnammocTAeludoMstnemmoC

orhcnyseludoM

gnikcehc

nagnivieceR

llacgnimocni

llacaetaitinI

naetaitinI

llacycnegreme

ssolnoitacinummoCREIRRACON

pugnaH

edoCNIPretnE

ehterotS

P2Enisretemarap

Wavecom WMO2 Modem 11

?GERC+TA1,>edom<=GERCkrowtenehtnodezinorhcnysmedoM

2,>edom<=GERC tpmettanoitazinorhcnys-er,tsolnoitazinorhcnyS
0,>edom<=GERCtpmettanoitazinorhcnyskrowteN

GNIR

ATA

KO

4321DTA

;

KOdehsilbatsenoitacinummoC

11:RORREEMC )edom1:EEMC+htiw(deretnetonedocNIP

3:RORREEMC dehsilbatseydaerlasinoitacinummocarodedeecxetidercCOA

211DTA

;

KO

HTA

KO

4321=NIPC+TA

KOdetpeccaedoCNIP

61:RORREEMC+edoCNIPtcerrocnI

3:RORREEMC+ )edom1:EEMC+htiw(deretneydaerlaNIP

W&TA

KOP2EniderotserasgnittesnoitarugifnocehT

llacehtrewsnA

llac»eciov«rofdneehtta»;«ehttegroft'noD

llac»eciov«rofdneehtta»;«ehttegroft'noD

TECHNICAL DATA

GUIDE 19/04/99, 9:2214

5. TROUBLESHOOTING: Specific defaults possibly encountered

5.1 The modem does not answer through the serial link

A) Is the modem correctly powered on?

❏ If not, the correct power supply is 5 to 32V (GSM 900) - 6 to 32V (GSM 1800/1900).

B) Is the serial cable suitable and adjusted in the modem and PC sockets?

❏ A suitable cable must follow pin assignment described on figure 6.
❏ Check in particular , that Rx et Tx are properly connected.

C) Check that your communication program is properly configured:

❏ Modem factory setting for the character framing are:

➫ Data Bits : 8
➫ Parity : None
➫ Stop Bits : 1

❏ The factory setting for baud rate is autobauding mode.

D) Does any other program interfere with your communication program (conflict on communication port access)?

TROUBLESHOOTING

Wavecom WMO2 Modem 12

❏ If yes, close any application likely to interfere (e.g. mouse or printer driver).

GUIDE 19/04/99, 9:2215

5.2 The modem always returns «Error» when trying to issue a communication

A) Issue AT+CMEE=1 to have extended error cause and retry

esuaC

eulav

0eruliafenohPtroppuslacinhcetruoyllaC
3dewollatonnoitarepO

4detroppustonnoitarepO

01detresnitonMIS

11deriuqerNIPMISedocNIPretnE
21deriuqerKUPMIS )edocsihtwonkt’noduoyfiredivorpkrowtenruoyllac(edocKUPretnE

31eruliaFMIS
61drowssaptcerrocnIderetneuoyedocehtkcehC

71deriuqer2NIPMISedoc2NIPretnE
81deriuqer2KUPMIS
62gnolootgnirtslaiD)stigid02xam(rebmunenohpruoykcehC

03ecivreskrowtenoN

citsongaiDtniH

→ ,medomehtforedlohMISehtnidracMISehttresnI
→ .detresniylreporpsititahterusni,detresnisidracMISfI

redivorp

)edoc

For all other codes, and/or details, see A T commands manual.
B) Additional hints

❏ Is the modem registered on the network?

Does the AT-Command AT + CREG? answers 0,1 (registered) or 0,5 (registered roaming)?

➫ If not, check that the received signal is strong enough to synchronize on the Network (use AT+CSQ).

Wavecom WMO2 Modem 13

GUIDE 19/04/99, 9:2216

krowtenruoyllac,degamadMISfI.dracMISruoyfoytidilavkcehC

sihtwonkt’noduoyfiredivorpkrowtenruoyllac(edoc2KUPretnE

TROUBLESHOOTING

❏ Is the modem receiving an incoming call or already in communication?

➫ With some software versions, you must release any incoming or active call (with ATH) before being able

to make an outgoing call.

5.3 The modem always returns «No carrier» when trying to issue a communication

A) After a failed attempt (“no carrier”), issue AT+CEER to have extended error cause

eulavesuaCcitsongaiDtniH

1rebmunenohpdetacollanU

61gniraelcllaclamroN
71ysubresU
81gnidnopserresuoN
91rewsnaon,gnitrelaresU
12detcejerllaC
22degnahcrebmuN
13deificepsnu,lamroN

TROUBLESHOOTING

05debircsbustonytilicafdetseuqeR
86xamMCAnahtretaergrolauqeMCA deripxedracMISdiap-erpruoyfotiderC

252sllacgniogtuonognirabllaC
352sllacgnimocninognirabllaC

,24,14,83,43,92,8,6,3
,36,85,75,94,74,44,34

452,97,07,96,56

sesuackrowteN

For all other codes, and/or details, see A T commands manual.

Wavecom WMO2 Modem 14

)?elbaliava

redivorpkrowtenllacro

noitpircsbusatad(noitpircsbusruoykcehC

sliatedrehtrufroflaunamsdnammocTAeeS

GUIDE 19/04/99, 9:2217

B) Additional hints

❏ Is the antenna properly connected?

➫ For GSM 900 : use a 870 to 960 MHz / 50 Ohms antenna.
➫ For GSM 1800 : use a 1710 to 1880 MHz / 50 Ohms antenna.
➫ For GSM 1900 : use a 1850 to 1990 MHz / 50 Ohms antenna.

❏ Is the received signal strong enough?

➫ With the AT-Command AT+CSQ check that the received signal (1st parameter of the response) is strong

enough to be able to establish a call.

esnopserQSC+TA

)ISSR(

13ot11

01ot0

99+dna

* based on general observations.

❏ The modem always returns «No carrier» when trying to issue a voice communication?

➫ Insure the character «semicolon» is present straight after the phone number on the AT-Command

ATD######;

❏ The modem always returns «No carrier» when trying to issue a data communication?

➫ Insure the selected bearer type is supported by the called party.
➫ Then, insure the selected bearer type is supported by the Network.
➫ If no success, try bearer selection type: AT+CBST=0,0,3.
➫ Insure the SIM Card is available for Data/Fax calls.

Wavecom WMO2 Modem 15

ytilauqlangiS

→
→

*tneiciffusebdluohS

*tneiciffusniebdluoC

TROUBLESHOOTING

GUIDE 19/04/99, 9:2218

6. NOTES ON SAFETY

6.1 General Safety

It is important to follow any special regulations regarding the use of radio equipment due in particular to the possibility of radio
frequency, RF, interference. Please follow the safety advice given below carefully .

❏ Switch OFF your GSM Modem when in an aircraft. The use of cellular telephones in an aircraft may endanger the

operation of the aircraft, disrupt the cellular network and is illegal. Failure to observe this instruction may lead to suspension
or denial of cellular telephone services to the offender , or legal action or both.

❏ Switch OFF your GSM Modem when at a refueling point.
❏ Switch OFF your GSM Modem in hospitals and any other place where medical equipment may be in use.
❏ Respect restrictions on the use of radio equipment in fuel depots, chemical plants or where blasting operations are in

progress.

❏ There may be a hazard associated with the operation of your GSM Modem close to in adequately protected personal

NOTES ON SAFETY

Wavecom WMO2 Modem 16

medical devices such as hearing aids and pacemakers. Consult the manufactures of the medical device to determine if it is
adequately protected.

❏ Operation of your GSM Modem close to other electronic equipment may also cause interference if the equipment is

inadequately protected. Observe any warning signs and manufacturers recommendations.

GUIDE 19/04/99, 9:2219

6.2 Vehicle Safety

❏ Do not use your GSM Modem while driving, unless equipped with a correctly installed vehicle kit allowing ‘Hands-Free’

Operation.

❏ Respect national regulations on the use of cellular telephones in vehicles. Road safety always comes first.
❏ If incorrectly installed in a vehicle, the operation of GSM Modem telephone could interfere with the correct functioning of

vehicle electronics. To avoid such problems, ensure that the installation has been performed by a qualified personnel.
Verification of the protection of vehicle electronics should form part of the installation.

❏ The use of an alert device to operate a vehicle’s lights or horn on public roads is not permitted.

6.3 Car And Maintenance

Your GSM Modem is the product of advanced engineering, design and craftsmanship and should be treated with care. The
suggestion below will help you to enjoy this product for many years.

❏ Do not expose the GSM Modem to any extreme environment where the temperature or humidity is high.
❏ Do not attempt to disassemble the GSM Modem. There are no user serviceable parts inside.
❏ Do not expose the GSM Modem to water, rain or spilt beverages, It is not waterproof.
❏ Do not abuse your GSM Modem by dropping, knocking, or violent shaking. R ough handling can damage it.
❏ Do not place the GSM Modem alongside computer discs, credit or travel cards or other magnetic media. The information

contained on discs or cards may be affected by the phone.

Wavecom WMO2 Modem 17

NOTES ON SAFETY

GUIDE 19/04/99, 9:2220

❏ The use of third party equipment or accessories, not made or authorized by Wavecom may invalidate the warranty of GSM

Modem.

❏ Do contact an authorized Service Center in the unlikely event of a fault.

6.4 Your Responsibility

This GSM Modem is under your responsibility . Please treat it with care respecting all local regulations. It is not a toy therefore
keep it in a safe place at all times and out of the reach of children.
T ry to remember your Unlock and PIN codes. Become familiar with and use the security features to block unauthorized use and
theft.

NOTES ON SAFETY

Wavecom WMO2 Modem 18

GUIDE 19/04/99, 9:2221

7. GENERAL INFORMATIONS

GSM reference documents : GSM 03.40, GSM 03.45, GSM 04.11,

GSM 04.21, GSM 05.08, GSM 07.01,
GSM 07.02, GSM 07.05, GSM 07.07.

ETSI contact : ETSI Secretariat

F-06921 Sophia Antipolis Cedex, F rance
e-mail : [e-mail]

Service : The AT commands manual is avalable on W avecom web site:

http://www.wavecom.com

Disclaimer

Modem and GSM-unit specifications and manuals are subject to change without notice. Wavecom assumes no liability for
damage incurred directly or indirectly from errors, omissions or discrepancies between the modem or GSM-unit and their
manuals.

Trademarks

Some mentioned products are registred trademarks of them respective companies.

Copyright

This manual is copyrighted by Wavecom with all rights reserved. No part of this manual may be reproduced in any form without
the prior written permission of Wavecom.
No patent liability is assumed with respect to the use of the information contained herein.

Wavecom WMO2 Modem 19

GENERAL INFORMATIONS

GUIDE 19/04/99, 9:2222

WAVECOM S.A. - 39 rue du Gouverneur Gal. Eboué, F-92130 Issy-les-Moulineaux - France

Tel: [phone] - Fax: [phone]

WAVECOM Inc. - 5405 Morehouse Drive, Suite 330 - San Diego, CA 92121 - USA

Tel: [phone] - Fax: [phone]

WAVECOM Asia Pacific Ltd. - 2 nd floor, Shui On Center, 6/8 Harbour Road - Hong Kong

GUIDE 19/04/99, 9:2323

Tel: [phone] - Fax: [phone]
