Watts PWRO5MAN User Manual

For Commercial & Residential Applications

ES-WQ-PWRO5MAN

Job Name

Job Location

Engineer

Approval

LEAD FREE

–––––––––––––––––––––––––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––––––

Model PWRO5MAN

One-Piece Manifold Reverse Osmosis System

Watts revolutionizes the industry through state-of-the-art technology. Our patented Manifold RO System provides a seamless water path effectively eliminating 17 connections. The PWRO5MAN brings unequaled water quality and system value.

Features

• Premium filtration package Stage 1: Sediment filter removes particulates down to 5

Stage 2: Carbon Block filter removes chlorine taste and

Stage 3: Carbon Block filter removes chlorine taste and

Stage 4: High-production TFC membrane rejects impurities

Stage 5: Final filter for enhancing water taste

• Adapt-A-Valve™ for easy installation

• Air Gap faucet meets local plumbing codes

• 3-gallon Plastic Storage Tank

Versatility

microns.

odors

down to 1/10,000th of a micron

Contractor

Approval

Contractor’s P.O. No.

Representative

––––––––––––––––––––––––––––––––––––––––––––

–––––––––––––––––––––––––––––––––––––––––––––

––––––––––––––––––––––––––––––––––––––––

PURE WATER

System tested and certied by NSF International against NSF/ANSI Standard 58 for the reduction

of the claims speciﬁed on the performance data sheet.

––––––––––––––––––––––––––––––––––

Model PWRO5MAN

• Space saving design installs under sink or in limited space

• Adapt-A-Valve™ easily connects to water source

• Increased output options available

Reliability

• Advanced design uses patented technology and high-quality

components to ensure years of continuous operation with trouble-free performance

• One-piece manifold minimizes potential for water leakage

• Non-corroding plastic water storage tank

Note: Do not use with water that is microbiologically unsafe or

of unknown quality without adequate disinfection before or after

the system. Systems certified for cyst reduction may be used on disinfected waters that may contain filterable cysts.

Performance

• Produces up to 50 gallons of bottled quality water per day

• NSF tested and Certified to Standard 58

• System goes well beyond basic water filtration and the typical

faucet mount products.

Watts product specifications in U.S. customary units and metric are approximate and are provided for reference only. For precise measurements, please contact Watts Technical Service. Watts reserves the right to change or modify product design, construction, specifications, or materials without prior notice and without incurring any obligation to make such changes and modifications on Watts products previously or subsequently sold.

*The wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight.

System tested and certified by WQA against NSF/ANSI Standard 372 for “lead free” compliance

System Specifications

Temperature: Minimum 40°F (4.4C),

Pressure: Minimum 40psi (2.8kg/cm2),

pH: Minimum 2, Maximum 11

Iron (Fe): Maximum 1.0 ppm

TDS (Total Dissolved Solids): <1800ppm

Turbidity: <5 NTU

Unit Dimensions: Approx. 16.5" W x 17" H x 5" D

Maximum 100°F (37.8C)

Maximum 85psi (6.0 kkg/cm2)

Performance

ELEMENT AVERAGE IN AVERAGE EFFECT % REDUCTION

Arsenic (Pentavalent) 334.615 ug/L 5.0385 ug/L 98.40%

Barium 10.2 mg/L 0.13 mg/L 98.7

Cadmium 0.031 mg/L 0.0001 mg/L 99.7

Chromium (Hexavalent) 0.30 mg/L 0.006 mg/L 98

Chromium (Trivalent) 0.30 mg/L .003 mg/L 99

Copper 3.0 mg/L 0.04 mg/L 98.7

Cysts 222,077#/ml 10 #/m 99.99

Cryptosporidium 222,077#/ml 10 #/m 99.99

Entamoeba 222,077#/ml 10 #/m 99.99

Fluoride 8.0 mg/L 0.33 mg/L 95.9

Giardia 222,077#/ml 10 #/m 99.99

Lead 0.15 mg/L .004 mg/L 97.3

Nitrate 26 mg/L 6.1 mg/L 76.5

Nitrite 2.8 0.50 mg/L 82

Perchlorate 0.10 mg/L 0.003 mg/L 97

Radium 226/228 25pCi/L 5pCi/L 80

Selenium 0.1 <0.001 99

TDS

(Total Dissolved Solids)

Turbidity 81 NTU 0.15 NTU 99.8

Toxoplasma 222,077# 10 #/ml 99.99

765 mg/L 24 mg/L 96.8

Replacement Filter Packs

MODEL FREQUENCY DESCRIPTION

PWFPK3MAN 6 Months Includes sediment and carbon filters only PWFPK5MAN Includes all filters and membrane PWMEM50 2 - 5 years 50 gallon per day membrane PWILGAC10 Annually 10" final in-line filter Note: Water conditions may require more frequent cartridge replacement

A Watts Water Technologies Company

USA: Tel. (800) 224-1299 • www.watts.com

Canada: Tel. (888) 208-8927 • www.watts.ca
