KALAHARI
MODEL # 2003B
BOTTOM DRAIN WATERLESS URINAL
DESCRIPTION
Waterless Co. Inc. No-Flush™ urinal Model #2003B Kalahari™ Bottom Drain, wall hung,
made of High Performance Composite material (HPC) for commercial and residential
use. Urinal to have a full 2” interior drain and 2” anged waste outlet; suitable for direct
connection to a 2” waste at the wall . Supplied EcoTrap® insert required. Trap insert to be
of a vertical ow type with 360 degree perimeter openings and installed by press t. Trap
must be replaceable and rellable. Trap inserts are to be removed with a two pronged
heavy duty stainless steel tool. Urinal to be fastened at the bottom front using standard
bolts from brass urinal ange. The bottom of the urinal is to be fully enclosed.
DIMENSIONS
(WxHxD) APPROX. WEIGHT
18.0 x 28.0 x 10.0 inches (457 x 711 x 254 mm) 22 lbs ( 20.5 kg )
KALAHARITM Model # 2003B Bottom Drain
457MM
(18.0")
133MM
133MM
(5.25")
(5.25")
254MM
(10.0")
APPLICATION
• Commercial and Residential Use
FURNISHED WITH
• Two unit integrated wall hangers
• AllFlange™ slots for ange bolts
• Fastening hardware
• Gasket
• Two EcoTraps®, vertical trap design
NOTE:
• Adequate BlueSeal® trap liquid to be
provided for EcoTrap® of urinal,
not furnished.
COLORS
Standard white; other colors available
WARRANTY
3 Year Limited Warranty.
Supply owner with warranty card
610MM
(24.0")
711MM
(28.0")
89MM
(3.5")
610 MM
(24.0")
TO FLOOR
229MM
(9.0")
381 MM
(15.0")
TO FLOOR
572MM
(22.5")
CODES/STANDARDS APPLICABLE: Complies with ASME A112.19.19, Z124.9, others.
FOR STANDARD INSTALLATION: mount at 24” above nished oor to lip of urinal or as
required by architect. Center drain line to be determined by installer.
Supply suitable wall support, i.e. carrier. Install and maintain as per manufacturer’s instructions. Urinal 2” drain outlet installs and drains to 2” waste. Retrot or new construction. Use
standard sanitation practices to maintain xture.
updated 06.30.10
WATERLESS CO. INC. 800.244.6364
In keeping with our policy of product improvement, Waterless
Co. reserves the right to change product specications at any
time without notice. It is the responsibility of the specier,
installer and wholesale seller to conrm specication at time
of sale or installation. No responsibility is assumed, claimed or
accepted by Waterless Co. Inc.
NOTE:
Installation requires purchase of standard ABS 2” drain parts and wall screws plus washers for attachment at bottom, not included. Specify made in USA or Mexico.
