Waterfall Victoria XT User guide

MADE IN FRANCE

INSTRUCTIONS MANUAL

FLOOR STANDING GLASS LOUDSPEAKERS

VICTORIA XT

INFORMATION & INSTRUCTIONS FOR USE

Thank you for choosing Waterfall Audio speakers. Our deliberate choice
for aesthetics and performance constantly guides us towards
cutting-edge technologies and design combined with major
innovations.

MUST BE CONSULTED BEFORE USE.
TO BE KEPT AND PASSED ON IN THE EVENT OF RESALE.

Warning : The speaker you have in your possession is equipped

with glass panels. Any impact on the product can irreparably
damage it. This product is fragile and must be used with "common
sense", take this into account when unpacking, installing and
throughout the life of the product. These speakers are designed for
domestic use only. Use outdoors and in public places is prohibited.

UNPACKING AND REPACKING

Unpack and repack your speakers with the help of another person.

STEP 1

Remove the protective foam.

STEP 2

Remove the speaker cover.

Be careful, fragile speaker.

STEP 3

Still with 2 people, lift the speaker
at the same time. Be careful not to

collide the speakers.

- 1 -

LOW FREQUENCY ADJUSTMENT

Your speakers are equipped in their base with a passive subwoofer. You
can adjust the low frequency response by tightening the 27 gram mass.
The acoustic characteristics will be as follows:

dB

100

92

84

76

68

60

30 50 100 150

sans masselote avec masselote 27gr

Hz

Your speakers are delivered with removable covers. They are installed by
“clipping” them onto the speaker.

CONNECTION

Connect directly the speaker to your amplifier or audio video processor.

Make sure that the + and - polarity are correct. Never connect two
speakers in parallel (or in series) on the same channel. Never connect
your speakers to the mains. The "Waterfall Audio" cable is made from

very high quality deoxygenated copper that is particularly well suited to
your speakers. It is available from your dealer.

- 2 -

PLACEMENT

These speakers are designed to be placed on the floor exclusively. Be
careful not to place them in a busy area. Be sure to position your
speakers on a perfectly flat floor. If necessary, the bases are equipped

with 4 M8 threaded holes, your dealer will be able to provide you with

suitable points. If possible, place the speakers so that they diffuse in the

direction of the length of the room. Placement in the corners will favor
the emphasis on low frequencies and moving away from the walls will

have the effect of favoring the sound image. Each room configuration
being particular, we advise you to carry out a few tests to find the best

possible compromise.

CLEANING

To clean your speakers you can use a window cleaner (Ajax window
cleaner is ideal) with a soft, lint-free cloth. Never use abrasive products:
jex pad, sandpaper, etc.

WARRANTY

Waterfall speakers have a 5 years warranty (parts & service) except

amplifiers. Waterfall amplifiers have a 2 years warranty (parts & service).

Check more on www.waterfallaudio.com (warranty section).

IN THE EVENT OF RESALE THE PRESENT THE DOCUMENT HAS TO BE
INCLUDED WITH THE PRODUCT

- 3 -

WATERFALL AUDIO

ZA les praderies - 83 570 Carcès - France

waterfallaudio.com

We operate a policy of continuous improvement and reserve the right to amend designs and specifications without prior notice.

Made in France, 5 years warranty on speakers, 2 years warranty on amplifiers (parts& service).

All drivers and amplifiers are developed and manufactured by ATOHM (France).
