Watchguard DVR8E(PACK), DVR16E(PACK) Quick Installation Manual
MODEL: DVR8E(PACK)
Professional Surveillance Pack
Digital Video Recorder with 8 Security Cameras
„QUICK INSTALLATION GUIDE‟
Digital Video Recorder
8 x 15m IR Day/Night Cameras
- Advanced H.264 Video Compression Technology
- High Quality Image sensor
- Multiplex Operation
- IR Night view range of 15 metres
- Long Recording Duration
- 650TVL Resolution
- Intelligent Video Motion Detection Recording
- Remote Network Surveillance & Backup Functions
- Easy to operate with remote or USB mouse.
- System Auto recovery after power loss (blackout)
N517
V4.0 260614
www.watchguardalarms.com.au
1
2
DVR8E Contents (Before installation, please ensure you have all the parts listed below).
Additional DVR8E(PACK) Contents (Only included when purchased as with the DVR8EPACK)
1 x 8ch Digital Video Recorder with 1TB Hard Disk Drive
● Advanced H.264 Video Compression Technology for High Quality Images
● Easy to Operate
● Can be Connected to a PC Network for Remote Viewing & Backup (Software on Disc)
1 x USB Mouse
● To operate the DVR
1 x IR Remote Control with batteries
● To operate the DVR
1 x HDMI Connection Cable
● Connect the DVR to a HDMI ready TV or Monitor
2 x Switch Mode Low Voltage Power Supplies
● 1 x 12v Power Supply for use with the DVR8E
● 1 x 12v Power Supply for use with the Power Split Cable to Power All Cameras (Pack)
8 x Day/Night Weatherproof Colour Cameras with Infrared LEDs - 20m Range
● IR LEDs for Viewing in Total Darkness up to 20m (B&W Mode)
● 650TVL Resolution
● Ideal for use Indoors and Out
8 x Camera Connection Cables
● Combined DC Power and Video Leads
● Pre-terminated - Allowing Simple Plug-in Connection – No Tools Required
● 4 x 10m, 2x 20m, 2 x 30m Leads Supplied
2 x Power Split Cable
● Allows You to Connect All 8 Cameras to 1 Power Supply
1 x Network Cable
● Allows You to Connect the LAN Port on the DVR to Your PC or Network to Facilitate
Remote Viewing or Backup Functions
3
Before installing this unit, please read through the following points:
Do not place cords from the AC adapter where they can be pinched or stepped on.
Leave at least 50mm of space between the DVR8E and other objects to allow air circulation.
Do not expose the DVR8E or Cameras to excessive heat, cold, or moisture.
Never immerse any component in water, and do not spray cleaners of solvents on the unit. Unplug
units before cleaning. When cleaning, use a damp, lint-free cloth only.
Do not place heavy objects on cords, or cover cords with rugs or carpet.
Service should be handled only by qualified technicians.
Rear Panel
1
VIDEO IN
Connect to analog camera, video input signal.
2
AUDIO OUT
Connect to video output device such as sound box.
3
AUDIO IN
Connect to audio input device such as speaker.
4
VGA
Connect to monitor using VGA cable.
5
HDMI
Connect to Digital Monitor with supplied HDMI cable.
6
USB
Connect to USB storage device, mouse, or DVD-RW.
7
Network port
Connect to LAN.
8
RS485
For RS485 PTZ Control.
9
DC12V
Connect to 12V power supply.
10
Power button
Powers on/off the DVR8E.
11
GROUND
Ground point.
WARNING
Please ensure you use the correct power
supply for each component. Plugging
either Power supply into the wrong deice
cause damage to it.
4
Connection Guide
1. Mount the 8 Cameras as required and connect the supplied combination DC Power and Video
leads.
2. Connect the 8 x corresponding camera Video leads (Yellow) into the camera inputs at the rear of
the DVR. Be sure to take note of the Camera input 1 – 8, as this will determine the camera
channels.
3. Connect the 8 x camera Power leads (RED) into the Power Splitter Cable. Ensure your camera
power supply is connected to each of the cameras power cables.
4. Connect the 12V Power Supply to the DVR8E.
5. Plug power adaptor into a Power-point.
6. Switch DVR8E on from back of device. Then hold front Power button for 3 seconds.
7. The power LED at the front of the DVR8E should now be illuminated and the unit will make a
loud beep sound to indicate it is powered.
8. Connect the included mouse to the USB port on the front or back..
9. Connecting your local network or modem to the DVR8E (we recommend doing this last step
after all the cameras have been configured).
5
Front Panel
1
USB
USB port. Connect to USB storage device, mouse etc.
2
Alarm
Alarm indicator light
When an alarm occurs, the light becomes red to alert you.
3
Network status indicator light
The blue light becomes on when the network connection is
abnormal or offline.
4
HDD status indictor light
The red light becomes on when HDD is abnormal or HDD
space is below the threshold.
5
IR
IR Receiver
Receives the signal from the remote control.
6
ESC
ESC
Go to previous menu, or cancel current operation.
7
FN
Fn
One-window monitor mode, click this button to display
assistant function: PTZ control and image colour.
8
Enter
Enter
Confirm current operation
9
Power
The blue light becomes on when the power connection is OK.
6
Main Screen
Once booted, you will be presented with the screen below (camera may only be black if not yet set up)..
Each camera view will have one or more symbols from below:
1 Currently Recording
3 Video Loss
2 Motion Detected
4 Camera Lock
System Menu
Right Clicking will bring up the System Login screen and the onscreen keyboard.
Once Logged In, right clicking again will bring up a menu.
Selecting “MAIN MENU” will show the system menu.
Right click or press the ESC button to return to previous menus, click on the icon to enter menus.
Channel View Menu
Moving the mouse to the top of each channel in the live view screen will show a menu.
From left to right:
Playback: Show, in live view, the past few minutes of footage.
Search tag: Turn on search tag.
Save: Save the currently displayed file to USB device.
Close: Close the channel view menu.
Default:
The default username is admin, the password is also admin.
On the DVR8E physically, you may also use username of 888888, and the password 888888.
(Users can alter the password later. Please refer to the Advanced set up guide CD)
DVR8E only supports four cameras on screen.
