Wasp WLS8600 Quick Reference Manual
WLS8600
Quick Reference Guide
Wasp Barcode Technologies
1400 10th Street
Plano, Texas USA 75074
Tel. 214-547-4100
Tel. 214-547-4101
©2005-2013 Wasp Barcode Technologies, Inc. (an unpublished work
provided under license).
Patents
This product may be covered by one or more of the following patents:
Design Pat. AU 310201; AU 310202; CN 693980; CN735959; HK
0602013.5M001; HK 0602013.5M002; JP 1305693; KR 30-0460940; US
D570,843 S; USD588,596 S.
US Pat. 5,992,740; 6,305,606 B1; 6,517,003; 6,808,114 B1; 6,997,385 B2;
7,387,246 B2; 5,367,151; 5,449,893; 5,545,889; 6,098,877; 6,220,514 B1;
6,412,698 B2; 6,607,132 B1; 6,817,529 B2; 6,834,805 B2; 7,948,214 B2.
European Pat. 789,315 B1; 895,175 B1; 1,128,314 B1; 1,128,315 B1;
1,396,811 B1; 1,413,971 B1; 1,816,585 B1; 1,942,442 B1.
Additional patents pending.
Table of Contents
Updates and Language Availability ..............................................................................1
Using the WLS8600 .............................................................................................................2
Aiming System ...........................................................................................................2
Setting Up the Reader ........................................................................................................3
Connecting the Cable .............................................................................................3
Connecting to the Host Interface ........................................................................4
Selecting the Interface Type ............................................................................................5
Interface Selection ....................................................................................................5
Keyboard Nationality ...............................................................................................7
PowerScan™ M8300 Default Configuration ...............................................................9
Programming .....................................................................................................................10
Restore Default .......................................................................................................10
Data Format Terminators ....................................................................................10
Operating Test ........................................................................................................10
Technical Features ............................................................................................................11
Default Values ....................................................................................................................12
Compliance .........................................................................................................................13
Laser Safety Compliance .....................................................................................13
LED CLASS ................................................................................................................14
CE Compliance ........................................................................................................14
FCC Compliance .....................................................................................................14
Power Supply ..........................................................................................................14
Wasp Barcode Technologies Limited Factory Warranty ..........................15
Service and Support ........................................................................................................16
NOTES
Quick Reference Guide 1
Updates and Language Availability
UK/US
The latest drivers and documentation updates for this product are available.
Contact WASP Technical Support.
I
Gli ultimi driver e aggiornamenti della documentazione per questo prodotto sono
disponibili.
Contattare WASP supporto tecnico.
F
Les derniers pilotes et mises à jour de documentation pour ce produit sont
disponibles.
Contactez le support technique WASP.
D
Die neuesten Treiber und Dokumentation Updates für dieses Produkt verfügbar sind.
Kontakt WASP Technical Support.
E
Los últimos controladores y actualizaciones de la documentación para este producto
están disponibles.
Póngase en contacto con soporte técnico de WASP.
Quick Reference Guide 2
WLS8600
Using the WLS8600
WLS8600 readers automatically scan barcodes at a distance. Simply aim and pull
the trigger. Code scanning is performed along the scan line emitted from the reading window. This line must cross the entire code. The best reading angles are indicated in the figure below.:
Aiming System
The WLS8600 provides an aiming system. If enabled, a partial trigger press produces a red spot, which should be aimed over the code center to get the best reading
performance, see figure (1) above. By completely pressing the trigger the scan line
appears to start code scanning (2).
After setting up the reader, you can enable or disable the aiming system by reading
the codes below:
Disable Aiming System (Default)
Ì$+Bj0$-"Î
Enable Aiming System
Ì$+Bj1$-'Î
Setting Up the Reader
Quick Reference Guide 3
Setting Up the Reader
Follow the steps below to connect and get your reader up and communicating with
its host.
1. Connect the Cable to the reader and the Host.
2. Configure the Interface (see page 5).
3. Program the Reader starting on page 10 (optional, as needed).
Connecting the Cable
A. Rubber gasket
B. Plastic boot
C. Cable spacer
D. Cover
E. Strain relief
1. Slip the cover over the cable.
2. Push the plastic boot into the rubber gasket. Take care that the tab
on the plastic boot is aligned with
the notch in the rubber gasket.
3. Push the plastic boot and gasket
into the handle. Ensure that the
“Front” marking on the plastic
boot is facing out, with the arrow
pointing towards the front of the
scanner.
4. Insert the cable into the socket of
the plastic boot.
5. Insert the cable spacer into the
cable wire and slide it towards the
handle.
6. Push the cover along the cable
towards the reader, and hook it
over the yellow “tooth”.
7. Insert the strain relief into the
cover and tighten the screw to fix
the whole assembly to the reader
handle.
Align
Notch
Tab
Arrow
Setting Up the Reader
4 WLS8600
Connecting to the Host Interface
USB
WEDGE
RS-232
PEN
