Counterbalanced Cranes
Manual Counterbalanced Crane
National Distributor, Local Service
The WARRIOR HEAVY-DUTY MANUAL
COUNTERBALANCED WORKSHOP CRANE offers 5
variable capacity settings, with a 5-position telescopic jib and
sturdy swivel hook with safety catch. This crane is entirely
freestanding, with exceptional manoeuvrability to suit
a fast-paced operation.
Up to 550kg capacity
Double-acting hand hydraulic pump unit
Pressure relief valve to prevent overloading
Counterbalance allows positioning right
up to the load
MODEL WRTSB550
CAPACITY AT MAXIMUM JIB (KG)
CAPACITY AT JIB POSITION 4 (KG)
CAPACITY AT JIB POSITION 3 (KG)
CAPACITY AT JIB POSITION 2 (KG)
CAPACITY AT MINIMUM JIB (KG)
OVERALL LENGTH (MM)
OVERALL WIDTH (MM)
OVERALL HEIGHT (MM)
OVERALL HEIGHT FOLDED (MM)
NET WEIGHT (KG)
SUPPLIED COMPLETE WITH COUNTERBALANCE!
350
400
450
500
550
2100
1050
1760
870
500
