Lift Tables
Eco Manually Operated Mobile Lift Table
Designed to withstand the wear-and-tear of modern operations,
even the most trying tasks.
High-quality hydraulics with a positive feel
Foot-operated lift
Infinitely controlled lowering mechanism
High pushing handle
Two fixed wheels and two swivel castors, fitted with
brake and foot guards
National Distributor, Local Service
Eco
Range
MODEL CAPACITY
(KG)
WR15 150 220 720 450 x 700 950 100 28 SINGLE 46
WR30 300 285 880 500 x 850 990 125 27 SINGLE 74
WR50 500 285 880 500 x 850 990 125 27 SINGLE 81
WR50L 500 290 915 810 x 1600 975 125 55 SINGLE 154
WR75 750 420 990 510 x 1000 990 147 45 SINGLE 125
WR100 1000 380 990 510 x 1016 990 147 82 SINGLE 140
WR100L 1000 360 1360 750 x 2035 1000 180/80 200 SINGLE 198
WR35D 350 335 1300 500 x 910 975 125 53 DOUBLE 105
WR70D 700 445 1500 610 x 1220 1015 125 97 DOUBLE 195
T: 01384 423330 E: [email protected]12
LOWERED TABLE
HEIGHT (MM)
RAISED TABLE
HEIGHT (MM)
TABLE
DIMENSIONS (MM)
(W X L)
HANDLE HEIGHT
(MM)
WHEEL DIAMETER
(MM)
STROKES TO
FULL HEIGHT
SCISSORS
TYPE
NET WEIGHT
(KG)
